CAS PR-II User manual

PR-IIPR-II
MANUAL
www.globalcas.com
Manual_PR2_V2

Table of contents
1. Notes on commissioning and installation............................................................ 3
Column installation (Typ PR-II P) ..........................................................................................................4
2. Overview................................................................................................................... 4
3. Display and Key Board............................................................................................. 5
PR-II B – Front display.............................................................................................................................5
PR-II B – Rear display ..............................................................................................................................5
PR-II P – Displaycover .............................................................................................................................5
4. Basic Operations...................................................................................................... 6
Turn on ......................................................................................................................................................6
Zero tracking (manual)...........................................................................................................................6
Simple weighing .....................................................................................................................................6
Tare function............................................................................................................................................7
PLU Saving & Calling-up ........................................................................................................................8
User’s Set-up Mode ................................................................................................................................8
Sales transaction ....................................................................................................................................9
5. Battery maintance ................................................................................................. 10
Low battery warning ............................................................................................................................10
6. Error massage ........................................................................................................ 10
7. Specifications ......................................................................................................... 10
With this scale you have acquired a modern, highly technical measuring instrument. CAS scales are
designed and manufactured under strict quality control to guarantee you the best performance, reliability
and durability. This manual will help you to get the maximum benet from your CAS scale. Please read it
carefully before use and keep it handy during subsequent use to nd quick solutions to problems.
ENGLISH
2
EN

1. NOTES ON COMMISSIONING AND INSTALLATION
Make sure you use the correct mains voltage. To obtain optimum performance,
switch on the scale 30 minutes before starting work to warm it up.
Do not disassemble the scale! When
any damage or defect occurs, contact
your CAS authorized dealer
immediately for proper repair.
Do not pull by its cord when
unplugging. Damaged cord could cause
electric shock or re.
Avoid placing the scale near heater or
in direct sunlight.
Insert plug rmly to wall outlet to prevent
electric shock.
Use proper adapter. Incorrect adapter
could damage the scale.
For consistent and accurate reading
maintain periodical check by your CAS
authorized dealer.
Avoid sudden shock to the scale. Grab on the bottom of the scale when
moving.
Always remove the batteries from the
scale if it is not going to be used for a
long time. This prevents damage due to
possible leakage.
Keep the scale away from other
electromagnetic enerating devices.
This may interfere with accurate
reading.
Place the scale on rm and temperature
consistent environment.
By adjusting 4 corners of the scale, set
the scale even using the built in scale
levelling indicator.
To prevent from re occurring, do not place
or use the scale near ammable or
corrosive gas.
To reduce electric shock or incorrect
reading, do not spill water on the scale
or place it in human condition.
Do not overload beyond the maximum
weight limit.
Scale must be grounded to minimize
electricity static. This will minimize
defect or electric shock.
Only use batteries approved by CAS! There
is a risk of explosion with incorrect
batteries or rechargeable batteries.
3
EN

■Column installation (Typ PR-II P)
1. Slide the rod into the holder. 2. Screw the two fastening
screws into the bracket. Make sure,
that the cable is not pinched.
2. OVERVIEW
Illustration 1 Illustration 2
SCREWS
STANDHOLDER
STAND
KEYBOARD
PLATFORM
DISPLAY
STANDARD VERSION
(TYP PR-II B)
VERSION WITH HIGH DISPLAY
(TYP PR-II P)
DISPLAY
STAND
4
EN

3. DISPLAY AND KEY BOARD
■PR-II B – Front display
■PR-II B – Rear display
■PR-II P – Displaycover
5
EN

■KEY FUNCTIONS
KEYS FUNCTIONS
–Used to enter all the numeric data
–PLU key
Function key (Back-light, Power Save)
Used to enter PLU setting
Used to clear all the numeric price display
Used to correct the zero point
To set or clear tare value
Double zero key
+Used to change back-light setting.(OFF, ON, AUTO)
+Power Save Mode
4. BASIC OPERATIONS
■Turn on
• Turn on the [ON/OFF] switch (below the scale) Then, the display will show all the
segments and count up „9“ to „0“.
• Once the weight is stable, the „ “ is displayed.
■Zero tracking (manual)
During operation, deviations in the zero position may occur due to various inuences such as temperature
uctuations or similar. By pressing the key, the current load is adopted as the zero position.
■Simple weighing
1. Place the goods on the platform. The weight is
displayed at the top left.
2. Remove the goods from the platform.
6
EN

■Tare function
Tare means the weight of container. You may use tare function when you weigh an item with container
and measure only the weight of item.
• One time tare
1. Place a container on the platter. EX)200g of tare.
2. Press Tare key to set zero point.
• Successive tare
3. Place another container on the platter. EX: 100g of
tare.
4. Press TARE key to set zero point.
5. After weighing item remove all of the container from
the platter. EX: 300g Tara
6. Press TARE key again to set zero.
➜ NOTICE: To remove TARE funtion press “TARE” Key again after removing the container from the palt-
ter. Automatic tare clearing function may not be applied to all of PR series..
7
EN

■PLU Saving & Calling-up
This section explains how to save unit price in PLU.
• Saving unit price on PLU
1. Use the number keys to enter the desired price per kilo.
EX) 199€
2. Now press and hold the PLU button you want to save
for 5 seconds. A beep conrms that the key has been
saved.EX) M1
• PLU call up
3. Press the respective PLU key to , until to call up
the item. EX) M1
The deposited price is displayed at the top right.
4. Press key to clear PLU mode and return to the
normal weighing mode.
■User’s Set-up Mode
KEY Display FUCTION
+
bL-oFF Do not use a back-light
bL- on Use back-light always
+
ps-0 Do not use power save mode
ps-1 Use power save mode
+
*
rS-Co Continually mode
rS-PC Command mode
rS-St Stable mode
* RS232-Optional interface
8
EN

■Sales transaction
• Input the unit price through the numeric key
1. Place an item on the platter and press appropriate
numeric keys to input unit price.
EX) 199 for unit price.
2. Remove the item from the platter.
3. Press key to clear and return to the normal
weighing mode.
➜ Note: You can also place the item on the weighing platform rst and enter the unit price
on the scale in the second step.
• Input the unit price through calling up PLU
4. Press
to
key can call up the PLU.
EX) M1
5. Place an item on the platter.
6. Remove an item from the platter.
7. Press key to clear PLU mode and return to the
normal weighing mode.
➜ Note: You can also place the item on the weighing platform rst and enter the desired PLU key on the
scale in the second step.
9
EN

5. BATTERY MAINTANCE
■Low battery warning
• This product is a combination product dry battery and rechargeable battery.
• When the battery is low the display shows the „bAt-Lo„ sign. You need to replace the battery with a
new one. If you use a rechargeable battery, please charge it immediately, otherwise you can shorten
the life of the battery. If you still use the scale without replacing the battery the scale may provide
incorrect result on measurement.
• If the display shows „Err b“, the battery must be changed or charged, otherwise incorrect weighing
results may be delivered.
6. ERROR MASSAGE
Display Description Solution
Z-Err
The „Z-Err“ occurs when a current zero point has
shifted from the last span calibration.
Please call your CAS dealer.
Err 3
The Err 3 („oL“) is an overload error. Please remove the weight.
Err b
The Err b („bAt-Lo“) is battery low Please change new battery. If rechargeable
battery, please charge immediately.
7. SPECIFICATIONS
PR-II
Capacity
3 / 6 kg 6 / 15 kg 15 / 30 kg
Interval (e)
1 / 2 g 2 / 5 g 5 / 10 g
External Resolution
1/3000 1/3000 1/3000
MAX Tare
-2,999 kg -5,998 kg -14,995 kg
Display
6/6/6 (Weight / Unit price/ Total price); 54 × 19 mm
Symbols
ZERO, TARE, kg/lb,100g/1oz, ADD, SUM, Low Battery, AC POWER
Keys
ZERO, TARE, M1~M7 KEY, FUCTION, ADD, SUM
Platter size
330 (W) x 235 (D)[mm] / 129.92 (W) x 92.52 (D)[inch]
Dimensions
B TYPE : 341 (W) x 383 (D) x 102 (H)[mm] / 134 (W) x 151 (D) x 40 (H)[inch]
P TYPE : 341 (W) x 435 (D) x 474 (H)[mm] / 134 (W) x 171 (D) x 186 (H)[inch]
Weight
Typ B: 2,8 kg / Typ P: 3,2 kg
10
EN

PR-II
Power
1.5 V x 3 units (D size Battery), Pb 4V/4Ah, 6 V Adapter
Operation
Time
Approx. 300 hours (Manganese Battery) / 600 hours
(Alkaline at 20 °C / 68 °F) / Backlight off
Operating
Temperature
-10 °C ~ +40 °C / 14 °F ~ 104 °F
Option RS232, USB, Manganese Battery, Pole Type
➜ Notice: Specications are subject to change for improvement without notice.
11
EN

Your CAS dealer
CAS DEUTSCHLAND AG ∙ Brackestraße 1 ∙ 38159 Vechelde ∙ Germany
Specifications are subject to change or improvement without prior notice.
DC-71111202
