DMX Mode This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page 16.
1) Press <MODE/ESC> until is displayed.
2) Use the <UP> and <DOWN> buttons to select the desired address.
DMX Channel Values (19-channel mode)
CHANNEL VALUE FUNCTION (19-CHANNEL MODE)
1 000 Ù255 Pan 1: 128 = halfway point
2 000 Ù255 Tilt 1: 128 = halfway point
3 000 Ù255 Pan 2: 128 = halfway point
4 000 Ù255 Tilt 2: 128 = halfway point
5 000 Ù255 Pan 3: 128 = halfway point
6 000 Ù255 Tilt 3: 128 = halfway point
7 000 Ù255 Pan 4: 128 = halfway point
8 000 Ù255 Tilt 4: 128 = halfway point
9 000 Ù255 Pan 5: 128 = halfway point
10 000 Ù255 Tilt 5: 128 = halfway point
11 000 Ù255 Pan 6: 128 = halfway point
12 000 Ù255 Tilt 6: 128 = halfway point
13 000 Ù255 Vector Speed: (Normal > Slow)
14
000 Ù099
100 Ù133
134 Ù243
244 Ù249
250 Ù255
Dimmer/Shutter
Dimmer (0 – 100%)
Open
Strobe (Fast > Slow)
No Function
Open
15 000 Ù255 Gobo 1 & 4
16 000 Ù255 Gobo 2 & 5
17 000 Ù255 Gobo 3 & 6
18
000 Ù016
017 Ù135
136
137 Ù255
Gobo Rotate
No Function
Counter-clockwise (Slow > Fast)
No Rotate
Clockwise Rotate (Slow > Fast)
19
000
001 Ù007
008 Ù015
016 Ù023
024 Ù031
032 Ù039
040 Ù047
048 Ù055
056 Ù063
064 Ù071
072 Ù079
080 Ù087
088 Ù095
096 Ù103
104 Ù111
112 Ù119
120 Ù127
128 Ù160
161 Ù193
194 Ù226
227 Ù254
255
Mode
No Function
Auto 1
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Auto 10
Auto 11
Auto 12
Auto 13
Auto 14
Auto 15
Auto 16
Sound 1
Lamp On (after 5 seconds)
Lamp off (after 5 seconds)
Reset (after 5 seconds)
No Function
Constellation User Manual 13 2007-01-09/10:53

DMX Channel Values (13-channel mode)
Gobo DMX Values
CHANNEL VALUE FUNCTION (19-CHANNEL MODE)
1 000 Ù255 Pan 1 & 4: 128 = halfway point
2 000 Ù255 Tilt 1 & 4: 128 = halfway point
3 000 Ù255 Pan 2 & 5: 128 = halfway point
4 000 Ù255 Tilt 2 & 5: 128 = halfway point
5 000 Ù255 Pan 3 & 6: 128 = halfway point
6 000 Ù255 Tilt 3 & 6: 128 = halfway point
7 000 Ù255 Vector Speed: (Normal > Slow)
8
Dimmer/Shutter
Dimmer (0 – 100%)
Open
Strobe (Fast > Slow)
No Function
000 Ù099
100 Ù133
134 Ù243
244 Ù249
250 Ù255 Open
9 000 Ù255 Gobo 1 & 4
10 000 Ù255 Gobo 2 & 5
11 000 Ù255 Gobo 3 & 6
12
Gobo Rotate
No Function
Counter-clockwise (Slow > Fast)
No Rotate
000 Ù016
017 Ù135
136
137 Ù255 Clockwise Rotate (Slow > Fast)
13
Mode
No Function
Auto 1
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Auto 10
Auto 11
Auto 12
Auto 13
Auto 14
Auto 15
Auto 16
Sound 1
Lamp On (after 5 seconds)
Lamp off (after 5 seconds)
Reset (after 5 seconds)
000
001 Ù007
008 Ù015
016 Ù023
024 Ù031
032 Ù039
040 Ù047
048 Ù055
056 Ù063
064 Ù071
072 Ù079
080 Ù087
088 Ù095
096 Ù103
104 Ù111
112 Ù119
120 Ù127
128 Ù160
161 Ù193
194 Ù226
227 Ù254
255 No Function
VALUE GOBO
000 Ù015
016 Ù031
032 Ù047
048 Ù063
064 Ù079
080 Ù095
096 Ù111
112 Ù127
128 Ù191
192 Ù255
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo scroll counter-clockwise (Fast > Slow)
Gobo scroll clockwise (Fast > Slow)
