1. BEFORE YOU BEGIN
What is included
1 x Intimidator™Scan LED
1 x Power Cord
1 x Warranty Card
1 x User manual
Unpacking Instructions
Immediately upon receiving the fixture, carefully unpack the carton, check the contents to ensure that
all parts are present and that have arrived in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that the fixture
must be returned to the factory, it must be returned in the original factory box and packing.
Symbols
This paragraph contains critical installation, configuration or operation information. Failure to comply
with this information may render the system partially or completely inoperative, cause damage to the
system or cause harm to the operator/user/technician
This paragraph contains important installation or configuration information. Failure to comply with this
information may prevent the system from functioning correctly.
This paragraph reminds you of useful, although not critical, information.
AC Power
This fixture has an auto-switching power supply that can accommodate a wide range of input voltages
(100 V - 240 VAC, 50/60 Hz). Before powering on the unit, make sure the line voltage to which you
are connecting it is within the range of accepted voltages.
Always connect the fixture to a switched circuit. Never connect the fixture to a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used only as a 0% to 100% switch.
To determine the power requirements for a particular fixture, see the label affixed to the back plate of
the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating indicates its
average current draw under normal conditions.
Before applying power to a fixture, check that the source voltage matches the fixture’s requirement.
Check the fixture or device carefully to make sure that if a voltage selection switch exists, it is set to
the correct line voltage you will use.
Always connect the fixture to a circuit with a suitable electrical ground.

Intimidator™Scan LED 2 2009-06-04/10:14
Safety Instructions
Please read these instructions carefully, which include important information about
the installation, usage and maintenance of this product.
Please keep this User Manual for future consultation. If you sell the unit to another user, be sure
that they also receive this User Manual.
This product is for indoor use only! To prevent risk of fire or shock, do not expose fixture to rain
or moisture.
Make sure there are no flammable materials close to the unit while operating.
Secure fixture to fastening device, using a safety chain.
Maximum ambient temperature (Ta) is 104° F (40° C). Do not operate fixture at temperatures
higher than this.
In the event of a serious operating problem, stop using the unit immediately. Never try to repair
the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center.
Make sure the power cord is not crimped or damaged.
Never disconnect the power cord by pulling or tugging on the cord.
Avoid direct eye exposure to the light source while it is on.
Do not daisy chain power to more than 20 units @ 120 V.
There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs. In the unlikely event that your unit may require service, please
contact CHAUVET at 954-929-1115.
2. INTRODUCTION
Features
5-channel DMX-512 LED scanner
Pan: 180o/ tilt: 90
Color wheel
11 colors + white
1 quad color, 1 tri color
Rainbow color spin effect
Gobo wheel with Gobo shake
14 gobos + open
12 metal, 2 glass installed
Gobo wheel spin effect
Additional Features
High-power, 22W (1,360mA) LED
Additional power output: max 20 units @ 120V (see manual for details)
Built-in automated programs via master/slave
Built-in sound activated programs via master/slave
Double bracket yoke doubles as floor stand
Automatically enters stand alone when no DMX signal is present
Options
Easy Controller (CA-8 or CA-9)

Intimidator™Scan LED 3 2009-06-04/10:14
Product Overview
Mirror
Hanging Yoke, double
bracketed for floor
positions
Double-bracketed
yoke used for floor
positions.
Power & Fuse
compartment
Microphone
Sound Sensitivity
Knob
Remote Controller Input
DMX connectors
Manual focus
adjustment
Power out
Safety eyebolt

Intimidator™Scan LED 4 2009-06-04/10:14
Rotate manual
focus adjustment
clockwise and
counter-clockwise
to achieve desired
focus.
The fuse is located
inside this
compartment.
Remove using a flat
head screwdriver.
DMX Channel Summary
CHANNEL
FUNCTION
1
Strobe
2
Gobo
3
Color
4
Pan
5
Tilt
3. SETUP
Light Source
The fixture does not use a halogen lamp as its light source. Instead, it uses a high luminosity LED,
which comes preinstalled, and does not need to be setup or replaced.
Manual Focusing
To adjust the focus, please follow the instructions
below:
1) If operating in stand-alone mode, turn the music
down so that the unit temporarily stops any activity.
2) In DMX control mode, create a static scene with
any gobo of your choice pointed to a flat surface,
ideally at a halfway point of the fixture’s total
coverage area.
3) Rotate the manual focus either clockwise or counter-clockwise until the spot is defined by a hard
edge.
Fuse Replacement
Disconnect the power cord before replacing a fuse and always replace it with the
same type of fuse.
With a flat head screwdriver, wedge the fuse
holder out of its housing. Remove the blown
fuse from its holder and replace with the exact
same type of fuse. Insert the fuse holder back
in its place and reconnect power.

Intimidator™Scan LED 5 2009-06-04/10:14
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller
or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The
combined number of channels required by all the fixtures on a serial data link determines the number
of fixtures the data link can support.
Fixtures on a serial data link must be daisy chained in one single line. To comply
with the EIA-485 standard no more than 32 devices should be connected on one
data link. Connecting more than 32 fixtures on one serial data link without the use
of an optically isolated DMX splitter may result in deterioration of the digital DMX
signal.
Maximum recommended serial data link distance: 500 meters (1640 ft.)
Maximum recommended number of fixtures on a serial data link: 32
DMX Data Cable
To link two or more fixtures together you must use DMX compliant data cables. You can purchase
CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable.
If you choose to create your own cable, please use data-grade cables that can carry a high quality
signal and are less prone to electromagnetic interference. Use a Belden© 9841 or equivalent cable,
which meets the specifications for EIA RS-485 applications.
Standard microphone cables cannot transmit DMX data reliably over long
distances.
The cable must have the following characteristics:
Type: shielded, 2-conductor twisted pair
Maximum capacitance between conductors: 30 pF/ft.
Maximum capacitance between conductor and shield: 55 pF/ft.
Maximum resistance: 20 ohms / 1000 ft.
Nominal impedance: 100 –140 ohms
Cable Connectors
Do not allow contact between the common and the fixture’s chassis ground.
Grounding the common can cause a ground loop, and your fixture may perform
erratically. Test the cables with an ohmmeter to verify correct polarity and to make
sure the pins are not grounded or shorted to each other.
COMMON
DMX +
DMX -
INPUT
OUTPUT
1
3
2
1
3
2
1
3
2
120 ohm ¼ W
resistor between
pin 2 (DMX -) and
pin 3 (DMX +) of
the last fixture.
To avoid signal transmission
problems and interference, it is
always advisable to connect a DMX
signal terminator.
DMX connector configuration

Intimidator™Scan LED 6 2009-06-04/10:14
This drawing provides
a general illustration of
the DMX Input/output
panel of a lighting
fixture.
Universal DMX Controller
Continue the link
Master
Slave
Slave
3-Pin to 5-Pin Conversion Chart
If you use a controller with a 5-pin DMX output connector, you will need to use a 5-
pin to 3-pin adapter like the CHAUVET Model No. DMX5M.
The chart below shows a proper cable conversion.
3-PIN TO 5-PIN CONVERSION CHART
Conductor
3-Pin Female (output)
5-Pin Male (Input)
Ground/Shield
Pin 1
Pin 1
Data ( - ) signal
Pin 2
Pin 2
Data ( + ) signal
Pin 3
Pin 3
Not used
Pin 4
Not used
Pin 5
Setting up a DMX Serial Data Link
1) Connect the (male) 3-pin connector of the
DMX cable to the output (female) 3-pin
connector of the controller.
2) Connect the other end of the cable to the
(male) 3-pin input connector of the first
fixture
3) Connect the cable from the output of the
first fixture to the input of the second
fixture.
4) Continue connecting the other features
as indicated above.
CHAUVET Certified DMX Data Cables
Order Code Description
DMX1.5 DMX Cable 1.5 m/4.9 ft
DMX4.5 DMX Cable 4.5 m/14.8 ft
DMX10 DMX Cable 10 m/32.8 ft
Master/Slave Fixture Linking
1) Link the fixtures as indicated in steps 1 to 4 of the previous section.
2) The Master/Slave mode of the fixture does not require any setup or initialization. The first fixture
in the daisy chain automatically assumes the role of Master unit regardless of its DIP switch
settings.
3) Similarly, the fixtures that follow in the daisy chain automatically assume the role of Slave units,
regardless their DIP switch settings.

Intimidator™Scan LED 7 2009-06-04/10:14
Hanging Clamp
Mounting
Orientation
This fixture may be mounted in any safe position.
Rigging
It is important never to obstruct the fan or vents pathway. Mount the fixture using, a suitable “C” or “O”
type clamp. Adjust the angle of the fixture by loosening both knobs and tilting the fixture. After finding
the desired position, retighten both knobs.
When selecting an installation location, consider ease of access for routine maintenance.
Always use safety cables.
Never mount the unit in places where it will be exposed to rain, high humidity, extreme
temperature changes or restricted ventilation.
Clamp is sold separately

Intimidator™Scan LED 8 2009-06-04/10:14
4. OPERATING INSTRUCTIONS
Operating Modes
The unit can be operated in stand-alone (sound activated), Master/Slave mode, or DMX mode.
Stand-alone
The Stand-alone mode is activated automatically when the fixture does not receive a DMX signal,
regardless of DIP switch settings. The fixture will run through its built in program (sound activated).
Master/Slave
The Master/Slave mode will allow you to link up to as many units as you want, without a controller, in
a daisy chain fashion. In this mode, the first unit in the daisy chain will automatically command all
other units following regardless of their DIP switch settings. See the Setup section for instructions on
how to connect the various units.
DMX Mode
This mode allows the unit to be controlled by any universal DMX controller.
Using DMX Mode
If you are unfamiliar with DMX, please read the DMX Primer section.
1) Daisy chain the fixture(s), using DMX cables, from the output of the DMX controller as indicated
in the Setup section.
2) Assign the individual DMX address, using DIP switches 1 to 9 on each unit.
3) When the fixtures detect DMX signal, they will automatically switch to DMX operation mode.

Intimidator™Scan LED 9 2009-06-04/10:14
DMX Channel Values
Channel
Value
Function
1
000 015
016 091
092 135
136 195
196 255
Strobe
Gobo Stopped
Adjacent gobo strobe: Slow > Fast
Adjacent color strobe: Slow > Fast
Adjacent color and gobo strobe: Slow > Fast
Gobo shake: Slow > Fast
2
000 007
008 015
016 023
024 031
032 039
040 047
048 055
056 063
064 071
072 079
080 087
088 095
096 103
104 111
112 119
120 127
128 255
Gobo
Blackout
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 8
Gobo 9
Gobo 10
Gobo 11
Gobo 12
Gobo 13
Gobo 14
Gobo Spin: Slow > Fast
3
000 010
011 012
022 023
033 034
044 045
055 065
066 076
077 087
088 098
099 109
110 120
121 127
128 255
Color
Open/White
Red
Cyan
Yellow
Green
Magenta
Light Blue
Dark Yellow
Light Green
Orange
Tri-Color (Red-White-Blue)
Quad-Color
Color Spin: Slow > Fast
4
000 255
Pan
0° - 180°
5
000 255
Tilt
0° - 90°
1
14

Intimidator™Scan LED 10 2009-06-04/10:14
Setting the Starting Address
If this is your first time addressing a fixture using the DMX-512 control protocol,
you should skip to the Appendix and read the “DMX Primer” section. It contains
very useful information that will help you understand how it works.
Set the starting address using the group of DIP switches located usually on bottom of the fixture.
Each DIP switch has an associated value. Adding the value of each switch in the ON position will
provide the starting address. The following instructions will help you to figure out which switches to
toggle ON given a specific starting address:
1) Determine the largest value switch that is less than the starting address. Turn this switch on.
2) Subtract the value of the switch you just turned on from the starting address number.
3) Determine the largest value switch that is less than the remainder from the previous subtraction.
Turn this switch on.
4) Subtract the value of the switch you just turned on from the remainder of the previous
subtraction.
5) Repeat steps three and four until you have a remainder of zero.
EXAMPLE STARTING ADDRESS
Address 10
Switch # 4 = 8
Switch # 2 = 2
Total = 10
Address 26
Switch # 5 = 16
Switch # 4 = 8
Switch # 2 = 2
Total = 26
Resolving the starting
address using simple math.
Address 233
233 –(128) = 105 - Turn ON Dip # 8
105 –(64) = 41 - Turn ON Dip # 7
41 –(32) = 9 - Turn ON Dip # 6
9 –(8) = 1 - Turn ON Dip # 4
1 –(1) = 0 - Turn ON Dip # 1
DIPSWITCH
(DMX VALUE)
1
2
3
4
5
6
7
8
9
1
2
4
8
16
32
64
128
256
13456789
ON
OFF
1 2 4 8
16 32 64
128 256
13456789
ON
OFF
1 2 4 8
16 32 64
128 256
13456789
ON
OFF
1 2 4 8
16 32 64
128 256
13456789
ON
OFF
1 2 4 8
16 32 64
128 256
13456789
ON
OFF
1 2 4 8
16 32 64
128 256
12222223456789
ON
OFF
1 2 4 8
16 32 64
128 256
123456789
ON
OFF
1 2 4 8
16 32 64
128 256
123456789
ON
OFF
1 2 4 8
16 32 64
128 256
123456789
ON
OFF
1 2 4 8
16 32 64
128 256
123456789
ON
OFF
1 2 4 8
16 32 64
128 256
123456789
ON
OFF
1 2 4 8
16 32 64
128 256
123456789
ON
OFF
1 2 4 8
16 32 64
128 256

Intimidator™Scan LED 11 2009-06-04/10:14
DMX Quick Reference Chart
DMX Address Quick Reference Chart
Dip Switch Position
DMX DIP SWITCH
SET
0=OFF
1=ON
X=OFF or ON
#9
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
#8
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
#7
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
#6
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
Dip Switch
Position
DMX Address
#1
#2
#3
#4
#5
0
0
0
0
0
32
64
96
128
160
192
224
256
288
320
352
384
416
448
480
1
0
0
0
0
1
33
65
97
129
161
193
225
257
289
321
353
385
417
449
481
0
1
0
0
0
2
34
66
98
130
162
194
226
258
290
322
354
386
418
450
482
1
1
0
0
0
3
35
67
99
131
163
195
227
259
291
323
355
387
419
451
483
0
0
1
0
0
4
36
68
100
132
164
196
228
260
292
324
356
388
420
452
484
1
0
1
0
0
5
37
69
101
133
165
197
229
261
293
325
357
389
421
453
485
0
1
1
0
0
6
38
70
102
134
166
198
230
262
294
326
358
390
422
454
486
1
1
1
0
0
7
39
71
103
135
167
199
231
263
295
327
359
391
423
455
487
0
0
0
1
0
8
40
72
104
136
168
200
232
264
296
328
360
392
424
456
488
1
0
0
1
0
9
41
73
105
137
169
201
233
265
297
329
361
393
425
457
489
0
1
0
1
0
10
42
74
106
138
170
202
234
266
298
330
362
394
426
458
490
1
1
0
1
0
11
43
75
107
139
171
203
235
267
299
331
363
395
427
459
491
0
0
1
1
0
12
44
76
108
140
172
204
236
268
300
332
364
396
428
460
492
1
0
1
1
0
13
45
77
109
141
173
205
237
269
301
333
365
397
429
461
493
0
1
1
1
0
14
46
78
110
142
174
206
238
270
302
334
366
398
430
462
494
1
1
1
1
0
15
47
79
111
143
175
207
239
271
303
335
367
399
431
463
495
0
0
0
0
1
16
48
80
112
144
176
208
240
272
304
336
368
400
432
464
496
1
0
0
0
1
17
49
81
113
145
177
209
241
273
305
337
369
401
433
465
497
0
1
0
0
1
18
50
82
114
146
178
210
242
274
306
338
370
402
434
466
498
1
1
0
0
1
19
51
83
115
147
179
211
243
275
307
339
371
403
435
467
499
0
0
1
0
1
20
52
84
116
148
180
212
244
276
308
340
372
404
436
468
500
1
0
1
0
1
21
53
85
117
149
181
213
245
277
309
341
373
405
437
469
501
0
1
1
0
1
22
54
86
118
150
182
214
246
278
310
342
374
406
438
470
502
1
1
1
0
1
23
55
87
119
151
183
215
247
279
311
343
375
407
439
471
503
0
0
0
1
1
24
56
88
120
152
184
216
248
280
312
344
376
408
440
472
504
1
0
0
1
1
25
57
89
121
153
185
217
249
281
313
345
377
409
441
473
505
0
1
0
1
1
26
58
90
122
154
186
218
250
282
314
346
378
410
442
474
506
1
1
0
1
1
27
59
91
123
155
187
219
251
283
315
347
379
411
443
475
507
0
0
1
1
1
28
60
92
124
156
188
220
252
284
316
348
380
412
444
476
508
1
0
1
1
1
29
61
93
125
157
189
221
253
285
317
349
381
413
445
477
509
0
1
1
1
1
30
62
94
126
158
190
222
254
286
318
350
382
414
446
478
510
1
1
1
1
1
31
63
95
127
159
191
223
255
287
319
351
383
415
447
479
511

Intimidator™Scan LED 12 2009-06-04/10:14
STAND BY
MODE
FUNCTION
BLACKOUT
LED ON: Slow Mode
Pan & Tilt is sound activated but
Gobo and Color wheel are static and
controlled by the Function button.
Tap the Function button to step
through the 11 colors then once
more to step to the next gobo.
LED OFF: Fast Mode
The unit’s movement Pan & Tilt and
Gobo/Color is sound activated.
Press and hold the Function button
to achieve the following results.
a. Strobe in different colors and
gobos
b. Synchronous strobe in white
c. Two-light strobe in white color
CA-9 Easy Controller
Daisy Chain
Connection
To other units
Remote
Control
Jack
CA-9 Easy Controller (Optional)
.

Intimidator™Scan LED 13 2009-06-04/10:14
General Troubleshooting
Symptom
Solution(s)
Applies to
Lights
Foggers &
Snow
Controllers
Dimmers &
Chaser
Auto shut off
Check fan thermal switch reset

Beam is very dim or not
bright
Clean optical system or replace lamp
Check 220/110 V switch for proper setting

Breaker/Fuse keeps
blowing
Check total load placed on device

Chase is too slow
Check user’s manual for speed adjustment



Device has no power
Check for power on Mains.
Check device’s fuse. (internal and/or external)



Fixture is not
responding
Check DMX Dip switch settings for correct
addressing
Check DMX cables
Check polarity switch settings

Fixture is on but there
is no movement to the
audio
Make sure you have the correct audio mode on
the control switches. If audio provided via ¼” jack,
make sure a live audio signal exists
Adjust sound sensitivity knob



Light will not come on
after power failure
Some discharge lamps require a cooling off period
before the electronics in the fixture can kick start it
again. Wait 5 to 10 minutes before powering it up
again.

Loss of signal
Use only DMX cables
Install terminator
Note: Keep DMX cables separated from power
cables or black lights.




Moves slow
Check 220/110 V switch for proper setting

No light output
Check slip ring & brushes for contact
Install bulb
Call service technician

Remote does not work
Make sure connector is firmly attached to device


Stand alone mode
All Chauvet lighting fixtures featuring stand-alone
functions will start in this mode upon power on
without additional settings.

If you still have a problem after trying the above solutions, please contact CHAUVET Technical
Support at the location on the next page.

Intimidator™Scan LED 14 2009-06-04/10:14
Contact Us
World Wide
General Information CHAUVET
3000 North 29th Court
Hollywood, FL 33020
voice: 954.929.1115
fax: [phone]
toll free: 800.762.1084
Technical Support CHAUVET
3000 North 29th Court
Hollywood, FL 33020
voice: 954.929.1115 (Press 4)
fax: [phone] (Attention: Service)
World Wide Web www.chauvetlighting.com
5. APPENDIX
DMX Primer
The DMX mode enables the use of a universal DMX controller device. There are 512 channels in a
DMX-512 connection. Channels may be assigned in any manner. A fixture capable of receiving DMX
512 will require access to one or more sequential channels. To do this, each fixture requires a "start
address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data
on the channel indicated by the start address. For example, a fixture that uses six DMX channels and
was addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103,
104, and 105.
The user must assign a starting address on the fixture that indicates the first channel reserved in the
controller. There are many different types of DMX controllable fixtures and they all may vary in the
total number of channels required. Choosing a start address should be planned in advance. Channels
should never overlap. If they do, this will result in erratic operation of the fixtures whose starting
address are set incorrectly. However, you can control multiple fixtures of the same type using the
same starting address as long as the intended result is that of unison movement or operation. In other
words, the fixtures will be slaved together and they will all respond in exactly the same way.
DMX fixtures are designed to receive data through a DMX Daisy Chain. In a Daisy Chain, the DATA
OUT of one fixture connects to the DATA IN of the next fixture. The order in which the fixtures are
connected is not important and has no effect on how a controller communicates to each fixture. Use a
connection order that provides for the easiest and most direct cabling, however.
CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and
DMX-1.5 (5’)

Intimidator™Scan LED 15 2009-06-04/10:14
General Maintenance
To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining the cleaning frequency. As a general rule,
fixtures should be cleaned at least twice a month. Dust build up reduces light output performance and
can cause overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure
to power off fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass surfaces when the fixture is cold
with a mild solution of glass cleaner or Isopropyl Alcohol and a soft lint-free cotton cloth or lens tissue.
Apply solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish
optical surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. Always dry the parts carefully. Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing; call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #).
Products returned without an RMA # will be refused. Call CHAUVET and request an RMA #, prior to
shipping the fixture. Be prepared to provide the model number, serial number and a brief description
of the cause for the return. Be sure to properly pack fixture; any shipping damage resulting from
inadequate packaging is the customer’s responsibility. As a suggestion, proper UPS packing or
double-boxing is always a safe method to use. CHAUVET reserves the right to use its own discretion
to repair or replace product(s).
Once you have received the RMA#, please include the following information on a
piece of paper inside the box:
1) Your name
2) Your address
3) Your phone number
4) The RMA #
5) A brief description of the symptoms
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore, any damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged during shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage
must be made within seven (7) days of receiving merchandise.

Intimidator™Scan LED 16 2009-06-04/10:14
Technical Specifications
WEIGHT & DIMENSIONS
Length ..............................................................................................................................17.4 in (441 mm)
Width................................................................................................................................ 10.1 in (256 mm)
Height................................................................................................................................. 5.6 in (142 mm)
Weight................................................................................................................................10.2 lbs (4.6 kg)
POWER
Autoswitching.........................................................................................................100-240 VAC 50/60 Hz
Fuse ........................................................................................................F3 A 250 V (5x20 mm fast-blow)
Power Consumption ........................................................................................50 W (0.6 A) max @ 120 V
Inrush Current....................................................................................................................(0.2 A) @ 120 V
Power Consumption ........................................................................................53 W (0.4 A) max @ 230 V
Inrush Current....................................................................................................................(0.3 A) @ 230 V
Power Output...............................................................20 units max @ 120 VAC, 40 units max @ 230 V
LIGHT SOURCE
LED ..................................................................................................22 W 1,360 mA (1 White) 50,000 hrs
PHOTO OPTIC
Luminance @ 1m ......................................................................................................................... 1,530 lux
Beam angle.............................................................................................................................................15°
THERMAL
Maximum ambient temperature .......................................................................................... 104° F (40° C)
CONTROL & PROGRAMMING
Data input................................................................................................... locking 3-pin XLR male socket
Data output ............................................................................................. locking 3-pin XLR female socket
Data pin configuration.................................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols...........................................................................................................................DMX-512 USITT
DMX Channels...........................................................................................................................................5
ORDERING INFORMATION
Intimidator™Scan LED......................................................................................INTIMIDATORSCANLED
WARRANTY INFORMATION
Warranty..................................................................................................................2-year limited warranty
