CHERUBINI Plug & Play 3000 User manual

ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
INSTRUCTIONS - INSTRUCCIONES
I
GB
D
F
E
MOTORE TUBOLARE CON REGOLAZIONE AUTOMATICA
O MANUALE DEL FINECORSA ELETTRONICO
TUBULAR MOTOR WITH AUTOMATIC OR MANUAL
ADJUSTMENT OF THE ELECTRONIC LIMIT SWITCH
ROHRMOTOR MIT AUTOMATISCHER ODER MANUELLER
EINSTELLUNG DER ELEKTRONISCHEN ENDLAGEN
MOTEUR TUBULAIRE AVEC RÉGLAGE AUTOMATIQUE OU
MANUEL DES FINS DE COURSE ÉLECTRONIQUES
MOTOR TUBULAR CON REGULACIÓN AUTOMÁTICA O
MANUAL DEL FIN DE CARRERA ELECTRONICO
Plug & Play 3000
C
M
Y
CM
MY
CY
CMY
K
Plug&Play3000 cop. Fronte.pdf 1 10/09/2014 17:02:16

14
Table of contents:
Electrical connections ............................................................................................. p. 15
How to prepare the motor ...................................................................................... p. 16
Instruction xing with clamp .................................................................................. p. 17
Key to symbols........................................................................................................ p. 18
Command sequences example ............................................................................... p. 18
Limit switch learning .............................................................................................. p. 19
Limit switch learning in automatic mode................................................................ p. 19
Limit switch setting in manual mode ...................................................................... p. 20
Procedure for limit switch setting in manual mode ................................................ p. 20
Example 1: Setting as rst the upper limit switch .................................................... p. 20
Example 2: Setting as rst the lower limit switch .................................................... p. 21
Limit switch setting in mixed mode ........................................................................ p. 21
Changing limit switches ......................................................................................... p. 22
Deleting of single limit switch positions ................................................................. p. 22
Deleting of all limit switch positions....................................................................... p. 22
Activation and adjustment of the super-sensitivity ................................................. p. 23
Deactivation super-sensitivity function ................................................................... p. 23
Limit switches and obstacle detection .................................................................... p. 24
Restoring the original conguration ....................................................................... p. 24
Declaration of conformity ....................................................................................... p. 58
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
ENGLISH

15
- To prevent any danger or malfunction, the size of electrical control components
connected to the motor must be compatible with the electrical features of the motor.
- Means for disconnection must be incorporated in the xed wiring in accordance with
the national installation standards.
- The selectors inverting the direction of rotation of the motor must be provided with
mechanical interlocking.
- Invert the brown and the black conductor to change the direction of rotation.
- NEVER connect two or more selectors to the same motor.
- For outdoor use, provide the appliance with a supply cord with designation H05RN-F
containing at least 2% of carbon.
- Cable length between motor and control-switch maximal 50 m.
In case of cable length more than 50 m an interface-relay have to be used.
ELECTRICAL CONNECTIONS
ENGLISH
1- brown (UP)
2- black (DOWN)
3- blue
4- yellow-green

16
HOW TO PREPARE THE MOTOR
NB: If you use tubes with a round form, the driving pulley must be xed to the tube, and
the installation is to be paid by the person who installs the system. For other tube sections
the tting is optional, but strongly recommended.
STOP RING NUT ADAPTOR
DRIVING PULLEY
STOP RING NUT
1
2
3
1. Insert the adaptor in the stop ring nut
mating the groove with the reference notch
and push till they touch.
2. Fix the driving pulley on the motor pin
until the stop pin clicks.
3. Insert the motor fully in the rolling tube.
ENGLISH

17
ENGLISH
The clamp allows to x the motor directly on the side-cover bolt
(Ø 12 mm).
The clamp may be used only for motors until maximal torque of
15 Nm.
INSTRUCTION FIXING WITH CLAMP
The bolt has to be in aluminum with minimal Ø 11,5 and maximal Ø 11,9 mm.
Close the screw using an hexagonal key 5 mm.
Closing torque minimal 9 Nm maximal 11 Nm, by keeping the motor as near as
possible to the sidecover.
The clamp is supplied pre-assembled with the tightening of the screw on right
side, in case should be necessary to tighten the screw on the left side go on as
follows:
- remove the screw
- remove the plate
- remove the clamp and reinsert it upside down
- insert the screw from the left side.
2
3
1
1
3
2

18
KEY TO SYMBOLS
COMAND SEQUENCES EXAMPLE
Press the up or down buttons to raise
the blind.
Press the buttons as indicated in rapid sequence and hold
the button down at the step marked by “HOLD”, to check
the motor conrmation movement.
Most of the command sequences have three or six distinct steps.
The buttons should be pressed quickly (<0.5 sec) as indicated in the sequence.
The time interval between each step should not be more than 1 second, otherwise the
command sequence will be cancelled.
To receive conrmation that the sequence has been accepted by the motor, the button
must be held down at the nal step marked by HOLD.
UP DOWN
Press the
UP-button
Press the
DOWN-button DOWN
UP
Motor
rotation to
conrm
DOWN DOWN
HOLD
UP
2 sec
2 sec
DOWN DOWN
HOLD
UP
2 sec
Command sequence example in 3 steps:
Attention! If the sequence requires a repetition of the same commands
(Up+Up/Down+Down), an interposition of the Stop position could be necessary
depending on the type of switch in use.
DOWN
UP ?
ENGLISH

19
LIMIT SWITCH LEARNING
The motor can learn the limit switches in different modes: automatic, manual, mixed.
It is suggested that the strength of the blind, its couplings and its safety lugs be checked.
As long as both of the limit switch positions have not been learned, the motor
will move briey, stop and then start back up again.
LIMIT SWITCH LEARNING IN AUTOMATIC MODE
To learn the limit switches in automatic mode, the blind must have either
internal or external safety lugs (A).
The motor is capable of automatically detecting the presence of exible (B) or
rigid (C) ribs for the connection between the tube and the blind.
Limit switch learning sequence in automatic mode
A
BC
1- Using either the up or down button, open the blind completely until it is fully stopped
and releases the tension.
2- Continue to hold the button down until the blind begins to move in the opposite
direction (after about 2 seconds), or use the up or down button,until the lower limit
switch is detected.
3- Release the control button used to perform the procedure and check that the blind
moves without interruption in the direction desired.
Example of automatic limit switch learning:
PLEASE NOTE: At the end of the limit switch learning procedure, the motor
automatically assigns the ASCENT to the BROWN wire and the DESCENT to the
BLACK wire.
UP
DOWN
1 2 3
ENGLISH

20
LIMIT SWITCH SETTING IN MANUAL MODE
Learning the limit switches in manual mode is required for blinds that do not
have either internal or external safety lugs (A).
Either exible (B) or rigid (C) ribs may be used for the connection to the tube.
A
BC
PROCEDURE FOR LIMIT SWITCH SETTING IN MANUAL MODE
Depending on your individual needs, it’s possible to learn rst either the upper or the
lower limit switch.
EXAMPLE 1
SETTING AS FIRST THE UPPER LIMIT SWITCH
If the rolling shutter is completely open, you have rst to drive it down by around
20 cm.
Using the button switch, put the blind to the upper desired position and to memorise,
perform the indicated sequence of commands; (UP-UP-UP).
Using the button switch, put the blind to the lower desired position and to memorise,
perform the indicated sequence of commands; (DOWN-DOWN-DOWN).
UP UP
HOLD
UP
2 sec
DOWN DOWN DOWN
HOLD
2 sec
DOWN
UP ?
ENGLISH

21
EXAMPLE 2:
SETTING AS FIRST THE LOWER LIMIT SWITCH
If the rolling shutter is completely down, you have rst to drive it up by around
20 cm.
Using the button switch, put the blind to the lower desired position and to memorise,
perform the indicated sequence of commands; (DOWN-DOWN-DOWN).
Using the button switch, put the blind to the upper desired position and to memorise,
perform the indicated sequence of commands; (UP-UP-UP).
DOWN DOWN DOWN
HOLD
2 sec
DOWN
UP ?
LIMIT SWITCH SETTING IN MIXED MODE
Where required for, the limit switch positions can be set in mixed mode.
EXAMPLE:
SETTING AS FIRST THE UPPER LIMIT SWITCH IN MANUAL MODE AND THE LOWER
LIMIT SWITCH IN AUTOMATIC MODE
If the rolling shutter is completely open, you have rst to drive it down by around
20 cm.
Using the button switch, put the blind to the upper desired position and to memorise,
perform the indicated sequence of commands; (UP-UP-UP).
UP UP
HOLD
UP
2 sec
UP UP
HOLD
UP
2 sec
DOWN
UP ?
Using the down button drive the blind to the complete lower position allowing the motor
to automatically detect the limit switch.
ENGLISH

22
CHANGING LIMIT SWITCHES
The following command sequences may be performed only after the limit switches have
been learned and only when the motor is completely on one of the two limit switch
positions: either lower or upper limit positions.
DELETING OF SINGLE LIMIT SWITCH POSITIONS
DELETING OF ALL LIMIT SWITCH POSITIONS
Deleting the UPPER limit starting from the UPPER limit switch position
Deleting both limit switch position starting from the UPPER limit
Deleting the LOWER limit starting from the LOWER limit switch position
Deleting both limit switch position starting from the LOWER limit
Deleting of one or both limit switches is indicated by the motor pausing briey before
moving again until both limit switch positions have been memorised again.
PLEASE NOTE: When the limit switches are deleted, the super-sensitivity settings
are also deleted
UP UP UP UP UPDOWN
HOLD
2 sec
UP UP UP UPDOWN DOWN
HOLD
2 sec
UPDOWN DOWN DOWN DOWN DOWN
HOLD
2 sec
UP UPDOWN DOWN DOWN DOWN
HOLD
2 sec
ENGLISH

DOWNUPUP
DOWN DOWN UP
DOWN UP UP
HOLD
DOWNDOWNUP
HOLD
DOWN DOWN UP
HOLD
DOWNUPUP
HOLD
DOWN DOWN DOWN
HOLD
UP UPUP
HOLD
MAX
MAX
MID
MID
MIN
MIN
From the CLOSING position
From the OPENING position
To complete activation of the
super-sensitivity, run the blind
through a complete cycle of
opening and closing.
conrm
conrm
ACTIVATION AND ADJUSTMENT OF THE SUPER-SENSITIVITY
2 sec
2 sec
DEACTIVATION SUPER-SENSITIVITY FUNCTION
From the OPENING position
From the CLOSING position
UP UP UPDOWN DOWNDOWN
HOLD 2 sec
UP UP UP
DOWNDOWN DOWN
HOLD
2 sec
23
ENGLISH

LIMIT SWITCHES AND OBSTACLE DETECTION
Obstacle detection in both direction is enabled only after both limit switches have been
set.
The motor also has an super-sensitivity obstacle detection in downwards, which can be
set on three levels (see page 23).
In the event an obstacle is detected, the motor will perform a safety movement in reverse.
RESTORING THE ORIGINAL CONFIGURATION
To restore the original motor conguration perform the procedure as described below:
- Connect both the brown and black motor wires under the same switch, e.g. UP.
PLEASE NOTE: recovery of the default conguration will delete the limit switches
and disabling the super-sensitivity.
- Press the UP button for at least 2 seconds.
- Disconnect and then restore the original control switch electrical connections (see
page 15).
1- Brown
2 - Black
3 - Blue
4 - Yellow-green
DOWNUP
24
ENGLISH

CHERUBINI S.p.A. dichiara che il motore PLUG & PLAY 3000 è conforme alle seguenti Direttive:
Direttiva 2006/42/CE
Direttiva 2014/35/UE
Direttiva 2014/30/UE
Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito:
www.cherubini.it.
IDichiarazione di conformità
Hereby, Cherubini S.p.A. declares that the PLUG & PLAY 3000 motor is in compliance with the
EU Directives:
Directive 2006/42/EC.
Directive 2014/35/EU
Directive 2014/30/EU
The full text of the EU declaration of conformity is available upon request at the following
website: www.cherubini.it.
GB Declaration of conformity
Hiermit erklärt Cherubini S.p.A.,dass der Motor PLUG & PLAY 3000 den EU Richtlinien entspricht:
Richtlinie 2006/42/EG
Richtlinie 2014/35/EU
Richtlinie 2014/30/EU
Der vollständige Text der EU-Konformitätserklärung ist unter der Web-Seite verfügbar:
www.cherubini.it.
DKonformitätserklärung
Le soussigné Cherubini S.p.A déclare que le moteur PLUG & PLAY 3000 est conforme aux
Directives:
Directive 2006/42/CE
Directive 2014/35/UE
Directive 2014/30/UE
Le texte complet de la déclaration UE de conformité est disponible sur le site internet:
www.cherubini.it.
FDéclaration de conformité
Por la presente, Cherubini S.p.A. declara que el motor PLUG & PLAY 3000 es conforme a las
Directivas:
Directiva 2006/42/CE
Directiva 2014/35/UE
Directiva 2014/30/UE
El texto completo de la declaración UE de conformidad está disponible en el sito:
www.cherubini.it.
EDeclaración de conformidad
58

Rev: 5 07/2017 - Cod: A4518_6B98
CHERUBINI Deutschland GmbH
Siemensstrasse, 40 - 53121 Bonn - Deutschland
Tel. [phone] / 35 | Fax [phone]
[e-mail] | www.cherubini-group.de
CHERUBINI France S.a.r.l.
ZI Du Mas Barbet
165 Impasse Ampère
30600 Vauvert -France
Tél. [phone] | Fax [phone]
[e-mail] | www.cherubini.fr
CHERUBINI Iberia S.L.
Avda. Unión Europea 11-H
Apdo. 283 - P. I. El Castillo
03630 Sax Alicante - Spain
Tel. [phone] | Fax [phone]
[e-mail] | www.cherubini.es
CHERUBINI S.p.A.
Via Adige 55
25081 Bedizzole (BS) - Italy
Tel. [phone] | Fax [phone]
[e-mail] | www.cherubini.it
