Climax Mobile Lite Assembly instructions

Mobile Lite
Cellular Emergency Alarm System
Installer’s Guide
12 June, 2020

Table of Contents
1. INTRODUCTION .................................................................................................................... 1
1.1. MOBILE LITE SERIES ............................................................................................................1
1.2. WHAT’S IN THE BOX..............................................................................................................1
2. SYSTEM OVERVIEW ............................................................................................................ 3
2.1. IDENTIFYING THE PARTS .......................................................................................................3
2.2. POWER SUPPLY ....................................................................................................................4
3. GETTING STARTED –SETTING UP MOBILE LITE.......................................................... 5
3.1. SIM CARD INSERTION...........................................................................................................5
3.2. CHARGING MOBILE LITE.......................................................................................................5
3.3. HARDWARE INSTALLATION....................................................................................................6
3.4. SOFTWARE INSTALLATION ....................................................................................................8
3.4.1. Installing USB Driver................................................................................................... 8
3.4.2. Installing PC Programming Tool.............................................................................. 8
4. PROGRAMMING MOBILE LITE........................................................................................... 9
4.1. PC PROGRAMMING TOOL (INSTALLERS ONLY)...................................................................9
4.1.1. Profile............................................................................................................................ 11
4.1.2. SMS Program.............................................................................................................. 13
4.1.3. APN................................................................................................................................ 13
4.1.4. Report Setting.............................................................................................................14
4.1.5. Geo-fence..................................................................................................................... 20
4.1.6. Setting........................................................................................................................... 24
4.1.7. Device........................................................................................................................... 30
4.1.8. Miscellaneous............................................................................................................. 31
4.1.9. Firmware ...................................................................................................................... 32
4.2. SMS REMOTE PROGRAMMING...........................................................................................33
5. LOCAL RF DEVICE MANAGEMENT ................................................................................ 34
6. OPERATION......................................................................................................................... 35
6.1. ANSWERING INCOMING CALLS...........................................................................................35
6.2. CURRENT OPERATION CONDITION .....................................................................................36
6.3. GPS/WI-FI LOCATE FUNCTION..........................................................................................36
6.4. GEOFENCING ......................................................................................................................37
6.5. ALARM ACTIVATION ............................................................................................................38
6.5.1. Alarm Report Procedure.......................................................................................... 40
6.5.2. Callback Mode ............................................................................................................ 43
6.5.3. Speech Reporting Method.......................................................................................44

6.5.4. Report Sequence .......................................................................................................45
6.6. SLEEP MODE.......................................................................................................................47
6.7. USAGE RECOMMENDATION FOR FALL DETECTION............................................................48
6.8. VOICE PROMPTS .................................................................................................................49
7. APPENDIX............................................................................................................................ 50
7.1. SMS REMOTE PROGRAMMING COMMANDS TABLE........................................................... 50
7.2. CONTACT ID COMMUNICATIONS PROTOCOL AND FORMAT ...............................................53
7.3. SIADIGITAL COMMUNICATION STANDARD......................................................................... 56

1
1. Introduction
1.1. Mobile Lite Series
Mobile Lite is a light, portable and richly featured cellular medical alarm with
GPS positioning, Wi-Fi positioning, GeoFencing and mobile network that
protect you wherever you go. With its built -in fall sensor, Mobile Lite will raise
an alarm call when a fall has been detected.
The device is a standalone medical alarm capable of playing voice prompts to
raise the users’self-awareness and reporting events via Speech, SMS and IP
protocols to directly communicate with the monitoring centers.
1.2. What’s in the Box
Your Mobile Lite package includes the following items:
Items
Mobile Lite
Charging Cradle (CT-5)
Micro-USB cable
AC Adapter
Micro-USB Cable
Mobile Lite has a micro USB port for charging or programming.
For charging Mobile Lite via connecting to charging cradle, a regular USB
cable is provided.
For programming via connecting Mobile Lite to computer, a special
programming USB cable is required. The USB end of programming cable is
larger than the regular cable.
Always use the Programming micro USB cable for connecting Mobile Lite to
computer. Never use a regular micro USB cable for computer connection.
The programming cable is ONLY provided for sample order.
If extra Programming cable is needed, please contact your supplier.

2
Lanyard and Attachment
Using the Lanyard
Step 1. Attach the lanyard to the Mobile Lite unit by looping the lanyard strap
through the lanyard holes on the Mobile Lite unit, and then pulling the
strap through until it is tight.
Step 2. Lock the release buckle by inserting the male part into the female part
until you hear a click sound.
Step 3. Put the lanyard around the neck of the user.
Programming
Micro-USB Cable
Regular Micro-USB
Cable

3
2. System Overview
2.1. Identifying the Parts
Button/LED/Component
Behavior
Function/Indication
1. Microphone
2. Top LED (Green)
On
Mobile Lite is charging
1 flash every 5 seconds
Mobile Lite operating normally
Top LED (Red)
1 Flash every 3 seconds
Mobile Lite low on battery
When Mobile Lite is charging, the Red LED will not indicate
the battery status.
3. Bottom LED (Amber)
1 Flash every 3 seconds
Cellular Network fault
4. Active Button
Press and hold for 5 seconds
- To turn on the unit (exits
sleep mode).
- To turn off the unit (enters
sleep mode).
Cellular module will be
powered down 30
seconds after the button
is pressed for 5
seconds.
Press once when idle
To activate an alarm
Press and hold for 5 seconds
during a Guard Time
To cancel alarm
Press once when Mobile Lite
is ringing
To pick up the call
Press and hold for 5 seconds
during a call
To terminate the call
Press and hold for 8 seconds
in normal mode
To enter RF device learning
mode
Press once in learning mode
To leave learning mode

4
Press twice in learning mode
To remove all learnt in RF
device
5. Speaker
6. SIM Card / USB Port
Cover Fixing Screw
7. SIM Card and USB Port
Cover
8. Micro SIM Card Slot
9. Micro USB Jack
10. Lanyard Hole
11. Charging Contact
Plates
12. Anti-Slide Magnets
Charging Cradle (CT-5)
A. Charging Cradle
B. Cradle Charging Contact Plates
C. Cradle USB Jack
2.2. Power Supply
Mobile Lite is powered by rechargeable battery.
As the battery may not be 100% charged when you get your Mobile Lite,
make sure to charge your Mobile Lite before the first use.
The typical charging time is 4 hours.
To Charge Mobile Lite, please refer to 3.2. Charging Mobile Lite.
When Mobile Lite is low on battery, the Top LED will flash Red every 3
seconds and Mobile Lite will make Low Battery report.
If battery is not changed after making Low Battery report, Mobile Lite will
make the second Low Battery report when battery voltage drops too low
and turn off GPS/Wi-Fi positioning function.
Mobile Lite makes a battery restored report to the CMS when its battery is
fully recharged.

5
3. Getting Started –Setting up Mobile Lite
3.1. SIM Card Insertion
Step 1. Loosen the Protective Cover Fixing Screws using a Philips
screwdriver and remove the SIM Card and USB Protective Cover.
Step 2. Hold Mobile Lite with its front side facing you. Insert a micro SIM card
into the SIM card slot with the chip side of the SIM card facing you as
shown in the picture below.
Please make sure that the micro SIM card PIN code is deactivated
and all SMS messages removed before insertion.
Step 3. Replace the Protective Cover and tighten the Protective Cover Fixing
Screws using a Philips screwdriver.
3.2. Charging Mobile Lite
Step 1. Place Mobile Lite into the Charging Cradle. Please make sure that the
Charging Contact Plates (of both Mobile Lite and the cradle) are in
contact with each other. The Anti-Slide Magnets should help align
Mobile Lite into the Charging Cradle.

6
Step 2. Insert the device/cradle end of the Micro-USB Cable into the
Micro-USB jack as shown in the picture:
Step 3. Insert the programming/charging end of the USB cable into the AC
Adapter and plug the adapter into a power socket.
3.3. Hardware Installation
To use PC Programming Tool for programming Mobile Lite, follow the
hardware installation steps below:
Step 1. Loosen the Protective Cover Fixing Screws using a Philips
screwdriver and remove the SIM Card and USB Protective Cover.
Step 2. Insert the device/cradle end of the Programming Micro-USB Cable
into the Micro-USB jack as shown in the picture:

7
Step 3. Insert the programming/charging end of the Programming Micro-USB
Cable into a computer USB port as shown in the picture below:
<
<W WA AR RN NI IN NG G> >
If programming cable is not provided, please contact your supplier. DO
NOT attempt to connect Mobile Lite to computer with a regular Micro-USB
cable.
Programming
Micro-USB Cable
Regular Micro-USB
Cable

8
3.4. Software Installation
3.4.1. Installing USB Driver
Mobile Lite can be programmed via USB port connection of a computer using
the PC Programming Tool software (using the Programming Cable).
If the computer cannot recognize the USB connection, please try installing the
USB driver as instructed below.
Step 1. Make sure Mobile Lite and the computer is connected properly
(please refer to 3.3. Hardware Installation)
Step 2. Please go to http://www.ftdichip.com/Drivers/VCP.htm. Scroll down
the webpage and select the driver file according to your operation
system, download and install the driver.
3.4.2. Installing PC Programming Tool
PC Programming Tool for Mobile Lite is a portable application and requires no
installation. After installing the USB driver, simply unzip the file to a desired
folder and execute the “Mobile_Tool.exe” file.

9
4. Programming Mobile Lite
Mobile Lite can be programmed by sending SMS commands to the device or
using a PC Programming Tool.
4.1. PC Programming Tool (Installers Only)
For system setting programming with PC Programming Tool software via USB
port, follow instruction below.
Step 1. Execute the programming tool:
The following configuration screen will be opened.

10
Step 2. Select the following settings in the top section of the configuration
screen and click “Open.”
Port: Select the COM port generated for Mobile Lite after
installing the USB Driver (the USB port connected to Mobile
Lite).
Baud rate: 115200
Data: 8
Parity: None
Stop: 1
FlowCtrl: None
Step 3. Read Configuration
To start configuring Mobile Lite settings, click on “Open”. A Read configuration
success message will pop up, click “OK” to proceed:
The current Mobile Lite setting will be displayed. Click on different tabs to see
and edit Mobile Lite functions.

11
4.1.1. Profile
The Profile function allows you to create and edit different setting profiles
which can be easily accessed in the future for quick programming.
Current Setting
After reading the configuration of Mobile Lite, the Profile scroll down bar will
now display “Current Setting” indicating PC Programming Tool is now
displaying the current Mobile Lite configurations. Selecting different tabs will
show the current values of each setting.
If you select a different profile from the drop down menu, the “Current Setting”
profile will disappear to indicate the PC Programming Tool is no longer
displaying Mobile Lite’s current configuration. To access Current Setting again,
click on “Read”.
Default
When “Default” is selected, the PC Programming Tool will display default
configurations of Mobile Lite, you can use this profile to return Mobile Lite to its
default setting.
New Profile
To create a new profile, click on “New Profile”. A pop-up window will prompt
you to enter a profile name:
After entering a profile name, the profile scroll down bar will show the new
profile name:

12
After editing the settings, click “Save Profile”to save the profile settings. A
pop-up window will indicate the profile has saved. You can use this profile in
the future to apply the same setting to other Mobile Lite.
Apply profile
If you wish to apply all the configuration of a profile into Mobile Lite, go to each
individual page and click on all the “Write”buttons to make sure all settings are
programmed into Mobile Lite.
Profile Manager
Click on “Profile Manager” to manage the profiles:
Delete Profile
Select a profile and click on “Delete Profile”. A pop-up window will ask you to
confirm the selection:
Select “Yes” to delete the profile, or “No” to return to the previous page.

13
4.1.2. SMS Program
This tab allows the user to program SMS Keyword (15 characters max.) and
Access Code 1 (4-8 digits) which are used for SMS Programming feature.
Enter the information and click “Write” to complete programming. Please note
that SMS Keyword is case-sensitive. For detail information, please refer to 4.2.
SMS Programming.
SMS Keyword: PROG (default)
Access Code: 1111 (default)
4.1.3. APN
The APN setting must be completed for Mobile Lite to report events via cellular
network.
Click “APN” to set APN Name, APN User and APN Password and click “Write”
to confirm.
APN Name: The name of an access point for GPRS. Please ask your SIM
card service provider for your APN.
APN User: Offered by your SIM card service provider. Please ask your
service provider for your GPRS username. If no username is required, you
may skip this step.
APN Password: Offered by your SIM card service provider. Please ask
your service provider for your GPRS password. If no password is required,
you may skip this step.

14
4.1.4. Report Setting
The “Report”tab allows the user to configure report settings.
Mobile Lite reports over 3 media: IP (Mobile Network), Speech channel, and
SMS message.
5 Report Indexes are available for setting:
4 programmable settings are available per Report Index:
1. Report Destination
Enter a report destination. The format of the report destination will depend
on the Reporting Format (Type). Please see Report Destinations below.
If there are no report destinations programmed, Mobile Lite will not report
upon alarm activation and will emit 1 beep as a reminder.
2. Event Filter
Select an event filter. The event filter determines which events are reported
to the selected Report Destination.
3. Reporting Format (Type)
Select a reporting format. The reporting format determines how the events
are reported to the Report Destination.
4. (Reporting) Groups
Assign the Report Index to a Reporting Group. The Reporting Group
determines the sequence of reporting.
Click “Write” to the apply the settings to Mobile Lite.
Report Destinations
After Report Format is determined, enter the Report Destinations according to
the designated Report Format:
IP Report Format: AccountNumber@server:port
IP Reporting: When activated, Mobile Lite will send event code and
location information (if available) via mobile network.

15
AccountNumber: Enter 4 to 23 alphanumeric account number assigned by
CMS.
Server: Enter either the IP address or the domain name of receiver.
Port: Separate from Server with a colon “:”, then enter the port number
Example : [email protected]:50123
For XML Report Format, you can also enter
http://AccountNumber@server url or
https://AccountNumber@server url
AccountNumber: Enter 4 to 23 alphanumeric account number assigned by
CMS.
Server URL: Enter the Server URL of receiver.
Example : http://[e-mail]/soap/test
https://[e-mail]/soap/test
Speech reporting and SMS Text Report Format: PhoneNumber
Example: 0912345678
Speech Reporting: When activated, Mobile Lite will dial to the telephone
number and open two-way voice communication directly.
Speech reporting is for Emergency Event only. Status event will not
be sent via speech.
Please note that Location info cannot be sent via Speech.
It is recommended to program at least one IP report before a Speech
Report. The IP and speech reports each should be assigned to a
separate Group. During two-way communication, Mobile Lite location
info will be updated every minute, and at the same time reported via
the last successful IP channel. (refer to 6.5. Alarm Activation for
more details).
SMS Text Reporting: When activated, Mobile Lite sends a SMS text
message to the recipient. The message contains event information and a
Google Map link for location. If the recipient’s receiver device supports
map function, he/she can click on the link to locate Mobile Lite.
Event Filter
This parameter determines which events are reported to the selected Report
Destination.
3 options: “All”, “Emergency”and “Status”. When an event is triggered, it will

16
be reported to the reporting destination according to the setting. If set to All,
the panel will report all events regardless of event type.
For example:
Mobile Lite being low on battery is a “status” event. If report index 3 and 5
are set as “status” and index 4 as “all” in event filters, this status event will
be reported to destinations 3, 4, and 5.
For more information, refer to 8. Appendix for event code types.
Reporting Format (Type)
The available reporting formats include:
Speech: Mobile Lite reports over the Speech channel to allow the user to
talk directly to the call recipient.
SIA_CID over IP:Mobile Lite reports digital CID event codes and
location information over mobile network TCP Protocol in SIA format.
SIA2_CID over IP: Mobile Lite reports digital CID event codes and
location information over mobile network TCP Protocol in SIA2 format.
SIA_CID over UDP: Mobile Lite reports digital CID event codes and
location information over mobile network UDP Protocol in SIA format.
SIA2_CID over UDP: Mobile Lite reports digital CID event codes and
location information over mobile network UDP Protocol in SIA2 format.
XML: XML reporting in Avant Guard XML protocol.
SMS CID: Mobile Lite sends a SMS text message containing event code
and a location link.
SMS TEXT: Mobile Lite sends a SMS text message containing event
information and a location link.
Group
The Reporting Group determines the sequence of reporting.
One Report Index can only be assigned to one Group.
Reporting within a Group:
If there are multiple Report Indexes programmed within a Group:
Mobile Lite will report according to the numeric order (e.g. 1 > 2 > 3, etc.)
of the Report Index in a Group. Report will stop when one report is
successful and Mobile Lite will regard reporting to this Group successful.
For example, if Report Index 1 and 4 are assigned to Group 1, Mobile Lite
will stop reporting if reporting to Index 1 is successful. If reporting to Index

17
1 failed, Mobile Lite will carry on reporting to Index 4.
If all reporting in a group failed, Mobile Lite will retry reporting.
Mobile Lite will try reporting within the same group for up to three times,
(or until one of the reports is successful). If three times of trying within the
same group failed, Mobile Lite will regard reporting to this Group
unsuccessful.
From the example above, suppose all report failed, the report sequence
would be:
1 > 4 > 1 > 4 > 1 > 4
Reporting Cycle
If multiple groups are assigned to the same event type (emergency or
status), Mobile Lite will report according the group numeric order from the
first programmed Group to the last programmed group. This report
sequence is one reporting cycle.
Reporting cycle is regarded as successful if any Group is successful, but
Mobile Lite will terminate reporting only after completing the reporting
cycle (going from the first programmed group to the last programmed
group).
Reporting behavior depends on the event type:
Emergency Events:
- When reporting to the first group is successful, Reporting is
regarded as successful. Mobile Lite will still report to the next
group until all groups have been tried to complete the reporting
cycle.
For example, Groups 1 and 3 are assigned to Emergency
Events:
If Group 1 is successful, Mobile Lite will still report to Group 3.
If reporting to Group 3 is successful, Mobile Lite will terminate
reporting.
If reporting to Group 3 is unsuccessful (going through all the
Report Indexes within the group for 3 times), Mobile Lite will
also terminate reporting.
- When reporting to the first group failed (going through all the
Report Indexes within the group for 3 times), Mobile Lite will
start reporting to the next group. When reporting to the second
group succeeds, reporting is regarded as successful. If no
other group is programmed, Mobile Lite will stop reporting. If
there are more groups programmed, Mobile Lite will continue
reporting until all groups have been tried to complete the
reporting cycle.
