Connects2 CTKMZ01 User manual

CTKMZ01
Complete Installation Kit
for Mazda vehicles
APPLICATION
FEATURES
Mazda BT-50 2012 - 2017
• Allows for the installation of a double DIN aftermarket stereo
• Comes complete with accessories for tment of double DIN stereo
• Retains steering wheel control functionality
• Retains time/date setting functionality
• Provides outputs for park brake, reverse gear, antenna remote and speed pulse
• Includes additional accessories including antenna adapter and patch lead
• Finished in black to match the vehicles dashboard
The information provided in this document is subject to change without notice due to manufacturer changes and/or improvements to the product/s. This
instruction manual is based on documented data and research. The manufacturer of this product cannot be held responsible for any changes made to the
vehicle by the manufacturer or damages that may occur through the installation of this product in accordance with the steps outlined herein.
Note: Application data is subject to change at any time
DISCLAIMER
CTKMZ01_IG_v1
i. Double DIN Fascia
ii. Brackets & Accessories
iii. Vehicle Interface & Harness
IN THE KIT
ii. i.
iv.
v.
iii.
iv. Antenna Adapter
v. Universal Patch Lead
Note: vehicle will need modication. Please familiarise yourself with the instructions before undertaking installation.

2
Need help? Visit support.connects2.com/tickets/technical
CTKMZ01_IG_v1
IN ISO CONNECTOR
Purple Right Rear Speaker +
Purple/Black Right Rear Speaker -
Green Left Rear Speaker +
Green/Black Left Rear Speaker -
Grey Right Front Speaker +
Grey/Black Right Front Speaker -
White Left Front Speaker +
White/Black Left Front Speaker -
ADDITIONAL CONNECTIONS
Pink Speed Pulse
Green Park Brake
Purple/White Reverse Gear
WIRING KEY
Yellow Permanent 12V
Black Ground
Red Ignition 12V
Orange Illumination
PRODUCT INFORMATION
The CTKMZ01 is a complete installation kit that allows for the tment of an aftermarket head unit into
the OEM dashboard of Mazda BT-50 vehicles. The interface provided helps retain steering wheel control
presets. The lead features plug-and-play connectors for an easier installation process.
Also provided is an antenna adapter, and a universal patch lead, to ensure compatibility with almost any
head unit on the market.
STEERING WHEEL CONTROL FUNCTIONALITY
The following diagram, though based on careful research, is an example only. Individual steering wheel control congurations may differ.
1
2
3 4
5
1. Volume Up
2. Volume Down
3. Track Down
4. Track Up
5. Mute (Short Press)
Access Time/Date (Long Press)
• Pressing & holding the Speech button (Fig.5) for 2 seconds will enable the ‘menu mode’ option.
• Using Volume Up/Down (Fig.1/2) you are able to navigate to ‘Set Time’. Once here, single press Speech (Fig.5) to conrm.
• Now you can adjust the vehicles clock by using Volume Up/Down (Fig.1/2), and select between hours & minutes by using the
Track Up/Down (Fig.3/4). When nished, a single press of Speech (Fig.5) will conrm the changes.
• The same process above can also be utilised for the setting of date.
Note that the menu option will time out after 15-20 seconds of inactivity.
SETTING TIME & DATE THROUGH SWC
Blue/White Antenna Remote
White/Red RCA Aux Retention

3CTKMZ01_IG_v1
FASCIA DIAGRAM

4
Need help? Visit support.connects2.com/tickets/technical
CTKMZ01_IG_v1
WIRING DIAGRAM
Flying Wires
Pink - Speed Pulse
Green - Park Brake
Purple - Reverse Gear
Blue - Antenna Remote ISO Connector
Connect to aftermarket stereo
Vehicle Specific Connector [24 Pin]
Connect to OEM connector from vehicle
Main Wiring Loom
Connector [14 Pin]
Connect to
Interface Box
Interface Box
Vehicle Display Connector
Connect connection from
vehicle display to interface
Connect vehicle display
connector on harness to
vehicles connection
Stereo Connection (Patch)
Lead Connector [12 Pin]
Connect to Interface Box
Note: Must be connected
first, before power
connection is made to the
interface
White/Red RCA Connectors (AUX)
Connect to aftermarket stereo
AUX
Speaker Module
Speaker Module
Connector [4-pin]
Connect connector
from harness to
speaker module.
Fakra Antenna Connection
Connect to OEM Antenna connector from vehicle
DIN Antenna Connection
Connect to aftermarket stereo

5CTKMZ01_IG_v1
PRIOR TO INSTALLATION
Read the manual prior to installation. Technical knowledge is necessary for installation. The place of installation
must be free of moisture and away from heat sources. Please ensure that the correct tools are used during the
installation to avoid damage to the vehicle or product. Connects2 can not be held responsible for the installation
of this product.
Use a panel removal tool to unclip and
release the main fascia panel. Once
released, pull away from the dashboard
and disconnect any wiring.
1.
INSTALLATION GUIDE - FASCIA
DASH DISASSEMBLY
Take the fascia to one side and begin to
unclip the 2x air vents (shown here) and
relocate them into the new fascia.
3.
2. Undo the 2x screws that hold the main
head unit in place and once free, proceed
to disconnect all of the wiring.
FASCIA ASSEMBLY

6
Need help? Visit support.connects2.com/tickets/technical
CTKMZ01_IG_v1
5.
INSTALLATION GUIDE - FASCIA
DASH MODIFICATION
4. Take the original fascia and unclip the top
display trim and relocate this into the top
aperature of the new fascia.
FASCIA ASSEMBLY
The highlighted area(s) on the inner dash
will need to be cut out in order to allow the
new double DIN unit to sit correctly.
When performing any modication to the
vehicle, always ensure to measure where
the stereo will sit and take due care when
performing cuts to the vehicle. Connects2
always promotes the use and expertise of
professional installers. Connects2 will not
be held responsible for any damage to the
vehicle.
BRACKET ASSEMBLY
Attach the supplied brackets to either side
of the aftermarket head unit. Note that the
brackets are labelled “L” and “R” for left
and right hand side.
6.

7CTKMZ01_IG_v1
INSTALLATION GUIDE - WIRING See Wiring Diagram on Pg.4 for more information
Before installing the interface, the factory stereo must be removed and disconnected. To do this, please consult the vehicle
owner’s manual/handbook or contact a tting professional.
For universal patch leads, prepare the wiring loops in accordance with the instruction manual supplied before installation.
2. Connect the opposite end of the stereo connection (patch) lead to the steering wheel control input on the back of
the aftermarket stereo.
NOTE: This may be a 3.5mm jack connector or a wired input depending on the brand of aftermarket stereo being tted.
Please consult the aftermarket stereo installation manual for further information on where to make the connection.
IMPORTANT: THIS STEP MUST BE COMPLETED BEFORE CONNECTING POWER TO THE INTERFACE.
FAILURE TO DO SO MAY RESULT IN A LACK OF FUNCTIONALITY AND THE NEED TO REINSTALL THE PRODUCT
!
3. Connect the 14 Pin connector from the supplied wiring loom to the interface box.
1. Connect the 12 Pin connector from the stereo connection (patch) lead to the interface box.
4. Connect the power/speaker ISO connector to the power/speaker ISO connector at the rear of aftermarket stereo.
Note: For aftermarket stereos which do not have an ISO connector, please see ‘Wiring Key’ on Pg.2 for information on which wires to connect.
5. Connect any additional ying wires from the harness to the head unit as required.
Note: Additional ‘flying’ wires can be connected to the vehicle to support various features i.e. parking brake trigger, reverse gear and speed
pulse. Details of these can be found under ‘Additional Connections’.
7.
INSTALLATION GUIDE - FASCIA
DASH ASSEMBLY
Once the installation of the head unit and
wiring has taken place, take the new fascia
plate in hand and transplant the clips from
the OEM panel to the back. Once done,
simply clip the new fascia over the head
unit to complete the installation.
6. Attach the red & white RCA connectors to the rear aux inputs on the aftermarket head unit.
7. Take the speaker box that comes within the kit and attach the 4 Pin connector to the corresponding connector
found on the harness.
8. Remove the top display from the dashboard and unclip the 12 Pin connector, this will need to be connected to the
appropriate side of the interface box.
9. Then take the 12 Pin display connector from the harness and plug it into the rear of the top display. This can then
be replaced into position in the dashboard.

8
Need help? Visit support.connects2.com/tickets/technical
CTKMZ01_IG_v1
NOTES
INSTALLATION GUIDE - WIRING See Wiring Diagram on Pg.4 for more information
12. Test stereo and steering wheel control functionality for correct operation before reassembling the vehicle
dashboard. If steering wheel control functions are unresponsive, please uninstall the interface and wiring and
reinstall carefully in accordance with the above steps.
For further help, please contact and ll out a support ticket with the full details of your issue at:
support.connects2.com/tickets/technical
10. Connect the vehicle specic connector on the supplied harness to the OEM connector from the vehicle.
11. Attach the antenna adapter in between the vehicles pre-existing connector as well as the rear of the aftermarket
head unit.
