Connects2 CTUST02 User manual

CTUST02
Infodapter Interface
for Seat Vehicles
APPLICATION
FEATURES
Seat Arona 2017-UP
Seat Ibiza (6P, KJ) 2015-UP
Seat Leon (5F) 2012 - 2015
• Retains Steering Wheel Control Functionality
• Retains Phone Button Functionality
• Retains Vehicle Settings and Generates Settings Menus
• Provides Optional Input for Reversing Camera
• Retains Parking Sensor Audio and Generates Parking Sensor Graphics
• Provides Outputs for Park Brake, Reverse Gear, Speed Pulse and Mute
• Software Updatable (contact supplier for more information)
The information provided in this document is subject to change without notice due to manufacturer changes and/or improvements to the product/s. This
instruction manual is based on documented data and research. The manufacturer of this product cannot be held responsible for any changes made to the
vehicle by the manufacturer or damages that may occur through the installation of this product in accordance with the steps outlined herein.
Note: Application data is subject to change at any time
DISCLAIMER
For vehicles with MIB II systems
CTUST02_IG_v2
i. Interface Box
ii. Video/Camera RCA (Yellow)
iii. Quadlock Connector
iii iviii v
iv. Additional Outputs
v. ISO Power/Speaker Connector

2CTUST02_IG_v2
PRIOR TO INSTALLATION
Read the manual prior to installation. Technical knowledge is necessary for installation. The place of instal-
lation must be free of moisture and away from heat sources. Please ensure that the correct tools are used
during the installation to avoid damage to the vehicle or product. Connects2 can not be held responsible for
the installation of this product.
IN ISO CONNECTOR
Purple Right Rear Speaker +
Purple/Black Right Rear Speaker -
Green Left Rear Speaker +
Green/Black Left Rear Speaker -
Grey Right Front Speaker +
Grey/Black Right Front Speaker -
White Left Front Speaker +
White/Black Left Front Speaker -
ADDITIONAL CONNECTIONS
Pink Speed Pulse
Green Park Brake
Purple/White Reverse Gear
Grey Mute
WIRING KEY
Yellow Permanent 12V
Black Ground
Red Ignition 12V
Orange Illumination
Yellow RCA (Male) Infodapter Video
Yellow RCA (Female) Connect Aftermarket Camera
INTERFACE CONNECTIONS
1 2 3 4
DIP Switch 1 - ‘ON’ for Pioneer, ‘OFF’ for other brand head unitsDIP Switch 1 - ‘ON’ for Pioneer, ‘OFF’ for other brand head units
DIP Switch 2 - ‘ON’ for PAL reversing camera, ‘OFF’ for NTSC reversing camera (Default is ‘OFF’/NTSC)DIP Switch 2 - ‘ON’ for PAL reversing camera, ‘OFF’ for NTSC reversing camera (Default is ‘OFF’/NTSC)
DIP Switch 3 - Change from ‘OFF’ to ‘ON’ and back to reset screen settings to factory defaults.DIP Switch 3 - Change from ‘OFF’ to ‘ON’ and back to reset screen settings to factory defaults.
Note: During this procedure, the screen background will change to red and no settings adjustments can be made.Note: During this procedure, the screen background will change to red and no settings adjustments can be made.
DIP Switch 4 - Not UsedDIP Switch 4 - Not Used
12 3 45
1
4
2
3
5
Reverse Camera Extension Harness InputReverse Camera Extension Harness Input
Power Harness InputPower Harness Input
Head Unit Connection (Patch) Lead InputHead Unit Connection (Patch) Lead Input
Not usedNot used
!Please be aware that whilst we retain most of the original vehicle feature with our interfaces, some
features may be lost. As we continue our research, this product may be updated and
improved to support more OEM functionality.

3
Need help? Visit support.connects2.com/tickets/technical
CTUST02_IG_v2
INSTALLATION GUIDE See Wiring Diagram on Pg.4 for more information
Before installing the interface, the factory stereo must be removed and disconnected. To do this, please con-
sult the vehicle owner’s manual/handbook or contact a tting professional.
A stereo connection (patch) lead is also required for the installation of this interface (supplied seperately).
Please ensure that you have the correct lead before proceeding. For universal patch leads, prepare the wiring
loops in accordance with the instruction manual supplied with the product before installation.
1. Connect the 12 Pin connector from the stereo connection (patch) lead to the interface box
2. Connect the opposite end of the stereo connection (patch) lead to the steering wheel control input on the
back of the aftermarket stereo
NOTE: This may be a 3.5mm jack connector or a wired input depending on the brand of aftermarket stereo
being tted. Please consult the aftermarket stereo installation manual for further information on where to
make the connection
IMPORTANT: THIS STEP MUST BE COMPLETED BEFORE CONNECTING POWER TO THE INTERFACE.
FAILURE TO DO SO MAY RESULT IN A LACK OF FUNCTIONALITY AND THE NEED TO REINSTALL THE PRODUCT
!
3. Connect the 14 Pin connector from the supplied wiring loom to the interface box
4. Connect 4 Pin camera extension harness to the interface box
5. Connect the power/speaker ISO connector to the power/speaker ISO connector at the rear of the after-
market stereo.
6. Connect any additional outputs from the main wiring harness to the head unit. See ‘Additional Connec-
tions’ on Page 2 for more information.
7. Connect the male yellow RCA to the reverse camera input of the aftermarket head unit
8. To connect a reversing camera, connect the female yellow RCA from the camera extension harness to the
male yellow RCA of the camera.
Note: Ensure that the ‘Camera Connected’ option in the Preferences menu is set to ‘Yes’ for the camera to
function correctly
9. Connect the quadlock connector on the supplied harness to the quadlock connector from the vehicle
10. Test stereo and steering wheel control functionality for correct operation before reassembling the vehicle
dashboard. If Infodapter functions are unresponsive, please uninstall the interface and wiring and reinstall
carefully in accordance with the above steps.

4CTUST02_IG_v2
WIRING DIAGRAM
ISO Connector
Connect to aftermarket stereo
Quadlock Connector
Connect to quadlock connector from vehicle
Stereo Connection (Patch) Lead Connector [12 Pin]
Connect to Interface Box
Note: Must be connected first, before power
connection is made to the interface
Main Wiring Loom Connector [14 Pin]
Connect to Interface Box
Additional Outputs
Pink - Speed Pulse
Green - Park Brake
Purple/White - Reverse Gear
Grey - Mute
Male Yellow RCA Connector
Connect to aftermarket radio
camera input
Female Yellow RCA Connector
Connect reversing camera

5
Need help? Visit support.connects2.com/tickets/technical
CTUST02_IG_v2
OK
USER GUIDE
The following diagram, though based on careful research, is an example only. Individual steering wheel control congurations may differ.
Press and hold the MUTE or VOICE button*
or
Double press the MUTE or VOICE button
*Note: pressing and holding MUTE or VOICE may activate the voice assistant (e.g. SIRI) in some vehicles. If this oc-
curs, double press the button instead
Entering the Conguration (Main) Menu
EXAMPLE STEERING WHEEL CONTROL DIAGRAM
The Infodapter will retain several of the vehicle’s original steering wheel control functions including moving
up and down between tracks, adjusting the volume and picking up or hanging up calls.
In addition to this functionality, the vehicle’s steering wheel controls are also used to enter, exit and navigate
the Infodapter menus. An example conguration can be seen below:
Short press MUTE or VOICE to enter a sub-menu or conrm an option within a menu
Long press MUTE or VOICE to return to the previous menu
Press TRACK + to scroll up through the menu items, or to increment an option within a menu
Press TRACK - to scroll down through the menu item, or to decrement an option within a menu
Navigating the Infodapter Menus
Press and hold the MUTE or VOICE button whilst in the top level Conguration Menu to exit the Infodapter
menu system and return to standard stereo operation
Exiting the Conguration (Main) Menu
Mute Voice
Track +
Track -
Driving Mode Park Assist
The park assist button can be used as
normal to activate or deactivate park
assist. The graphic will be shown on
the head unit display
The driving mode button can be used as
normal. The graphic for the mode will be
shown on the head unit display
MODE
P
MODE
P

6CTUST02_IG_v2
INFODAPTER MENU
Press and hold or double press MUTE or VOICE to
enter the Infodapter Conguration menu and navigate
through the various options and settings below:
VEHICLE SETTINGS
The Infodapter interface retains the ability to adjust
vehicle settings that were present when the original
head unit was installed.
The options available will depend on the individual
vehicle and system specication.
See the vehicle handbook for more information re-
garding these features and how they operate
INFODAPTER SETTINGS
Screen Size/Position
Change horizontal and vertical screen size/position to
align the Infodapter with the aftermarket display
Picture Settings
Adjust the brightness, contrast and colour saturation
Preferences
Change options based on vehicle functionality and
specication (see Page 7)
Vehicle Settings
Infodapter Settings
Car
Language
Version
Back
Configuration Menu
Vehicle Settings
Infodapter Settings
Car
Language
Version
Back
Configuration Menu
Vehicle Settings
Infodapter Settings
Car
Language
Version
Back
Configuration Menu
OK
OK
ENTER
MENU

7
Need help? Visit support.connects2.com/tickets/technical
CTUST02_IG_v2
CAR
Access the vehicle’s trip computer and view data
including distance travelled, fuel consumption etc
LANGUAGE
Select language (English/French/German/etc)
VERSION
View software version screen
Vehicle Settings
Infodapter Settings
Car
Language
Version
Back
Configuration Menu
PREFERENCES (SUB-MENU)
Driver Position
Select Left or Right depending upon whether the
vehicle is left or right-hand drive.
Camera Connected
Select Yes if an optional camera is connected
Reverse Priority
Select whether camera or park assist image is
shown by default when reversing.
Park Brake Source
Set Park Brake output to activate when park
brake is on (Park), when speed is less than
3km/h (Speed) or to remain on at all times (Al-
ways On)
Climate
Select how long the climate display should be
shown on the head unit when adjusted. Selecta-
ble range is between 3 and 30 seconds
Restore Factory Settings
Restores all Infodapter settings to factory de-
faults. Note, this does not restore vehicle settings
to defaults.
Driver Position
Camera Connected
Reverse Priority
Park Brake Source
Climate
Restore Factory Settings
Preferences
Back
Right
Yes
Park Assist
Speed
5s

8CTUST02_IG_v2
Need Help?
Send us a ticket online 24/7
Troubleshoot with our skilled team
Get support until your issue is resolved
No problem.
support.connects2.com/tickets
