User Manual
VER:D3-1-V1.0

Function description
This product is a solar power bank used for hunting cameras:
●it can charge the battery under the sun outside
●The battery inside the solar panel can be charging with the adapter
Introduction

1.DC IN 2.LED indicator 3.DC OUT(TYPE-C)
4.Solar panels 5.Lock switch
Function declaration：
1.DC IN: it can charge the solar bank with an adapter(DC 2V/1A,
Spec.: Φ2.5mm/0.65mmw stylet)
2.DC OUT: Solar DC output to Hunting Camera,(TYPE-C port, install on
top of machine)
3.LED indicator: When the adapter recharges the solar power, the red
light is on, once fully, the red light is off. when the solar bank is
recharged, the blue light is on, once fully, the blue light is off
4.Solar panels: When the sun shines on the solar panels, the panels can
convert light energy into electricity to recharge the battery
5.Lock switch: Align the clasp position，Press down the solar bank, the
Lock snap automatically, Press the lock button to pull out the solar bank
Installation and Attention
●Chen installing solar panels, don't let other leaves and objects hold the
sun's rays where the sun can shine. It's best to install them in the open place
●Connect the connection line from the DC out of the solar bank to the
camera DC IN, then it can be used
●About the solar bank, if there is any ports not to use, please cover the
hole with the silicone to prevent leakage into the machine inside

Parameter
Product
DC IN
DC OUT
Capacity
Over charge protection
Over discharge protection
Water resistant
Operating /storage temperature
Dimension
Solar Power Bank
12 V/DC 1A
DC 6.0V/2A Max（TYPE-C port）
3.6V 2500mAh 18650 Li-ion
Yes
Yes
IP65
-20°C to +60°C
97x70x43 mm
Note: Product design specifications are based on the latest information at
the time of writing this manual. Subject to change without notice, please
refer to the actual camera.
