Crestron UC-B31-Z-WM-INDIA User manual

The UC-B31-Z-WM and UC-B31-Z-WM-INDIA Crestron Flex
conferencing system provides a small room video conference solution for
use with Zoom Rooms® software. It supports up to three video displays
and features a wall mount touch screen, UC bracket assembly, and
smart soundbar and camera.
The latest firmware must be loaded onto the touch screen prior to
operation. Refer to the touch screen's product page (resources tab) to
download the latest device firmware. The latest UC-B31-Z-WM and UC-
B31-Z-WM-INDIA firmware is installed using the auto update feature.
Minimum Requirements:
lA video display (not included) connected to the UC Engine. A second
or third display is optional.
lA Zoom Rooms account or activation code (not included).
In the Box
Wall Mount Touch Screen
1 10.1 in. Wall Mount Touch Screen (6510814)
Mounting hardware
Smart Soundbar with Camera
1 Jabra PanaCast 50 video bar for Crestron Flex systems
(6512600) or
Jabra PanaCast 50 video bar for Crestron Flex systems,
India (6512698)
UC Bracket Assembly
1 UC Bracket Assembly with UC Engine and HDMI® content
ingest (UC-BRKT-200-S-Z-ASSY, 6512690)
2 Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (9.5mm x
12.7mm) (2052565)
1 Key, Anchor (4529654)
2 Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo
(2052567)
4 Tie Wrap (2047935)
Additional Items
1 PoE injector (6502429)
2 Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924)
1 Cable, DisplayPort™ to HDMI, 6 ft (1.8 m) (6508282)
1 Cable, HDMI, 20 ft (6.1 m) (6503567)
1 Cable, HDMI, 6 ft (1.8 m) (6503565)
1
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software

Mount Devices
Mount the UC Bracket Assembly
Mount the UC Bracket Assembly to VESA® compliant display devices, a
wall, or other building structure. Anchors and screws are supplied for
installation on walls with 3/8 in. (9.5mm) to 3/4 in. (19mm) thickness.
CAUTION: Preinstalled screws may protrude from the back of the
UC Bracket Assembly. Exercise caution when handling the UC
Bracket Assembly to avoid scratching or damaging surfaces.
NOTE: The integrated cable tie wraps are reusable. Avoid damaging
the cable tie wraps.
Mount the Soundbar with Camera
Mount the included soundbar with camera according to its included
documentation.
Mount the Touch Screen
Mount the included touch screen according to the TSW-1070 Quick
Start (Doc. 8552).
2
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software

3
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
Connect
Identify the UC Bracket Assembly
The UC Bracket Assembly is available in two models. Identify the model included with your Crestron Flex system. Tap or click the corresponding
image below to navigate to the appropriate connection instructions.
UC Bracket Assembly with HD-CONV-USB-200 UC Bracket Assembly with HD-CONV-USB-300

4
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
System Overview
For UC Bracket Assembly with HD-CONV-USB-200
When connections are complete, the system appears as shown below. Refer to Make Connections for detailed connection instructions.

5
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
For UC Bracket Assembly with HD-CONV-USB-300
When connections are complete, the system appears as shown below. Refer to Make Connections for detailed connection instructions.

6
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
Make Connections
NOTE: For reference, the UC Bracket Assembly is shown with the HD-CONV-USB-200 in the following connection diagrams. Unless otherwise
indicated in this guide, the connections remain the same for the UC Bracket Assembly with HD-CONV-USB-200 and HD-CONV-USB-300.
1. Make UC Engine and touch screen connections as shown in the following illustration.

7
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
2. Connect displays to the UC Engine.

8
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
3. Connect the soundbar to the UC Engine as shown in the image below. Do not connect the soundbar to any of the other USB ports.

9
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software
4. Connect a laptop to the HD-CONV-USB-200 or HD-CONV-USB-300.
5. Bundle the cables to the bracket assembly with the integrated cable tie wraps. The cable tie wraps are reusable.

Configure
Apply Power
Press the power button on the bottom of the UC Engine and apply
power to all of the other devices in the system. The connected display
device will show a pairing code.
Log In to the Zoom Rooms Service
1. Tap Touch Here to Enable a Specific Application on the bottom of the
screen. A list of applications is displayed.
2. Tap Zoom Rooms and then tap Confirm. The touch screen will reboot.
3. Enter the pairing code shown on the display to pair the touch screen
with the UC Engine. The Zoom Rooms controller app is displayed.
4. Log in to the Zoom Rooms service with an activation code or Zoom
Rooms Credentials (email and password).
lActivation Code:
a. Tap Enter Activation Code.
b. Enter the 16-digit activation code provided by the
administrator to activate the Zoom Room that is assigned to
the activation code. The Zoom Rooms Conference Room screen
is shown on the display.
lSign In:
a. Tap Sign In.
b. Enter the Zoom Room credentials and tap Sign In.
c. Select the conference room name from the list and tapNext.
The Zoom Rooms Conference Room screen is shown on the
display.
5. Tap Settings. If a password is required, enter the password (the
default password is "1234"). The Settings screen is displayed.
6. Tap Microphone and select the as the source.
7. Tap Speaker and select the as the source.
8. Tap Meet Now to exit.
Configure the System
Connect a USB keyboard and mouse (sold separately) to a USB port on
the UC Engine to configure system features. For detailed information on
using Zoom Rooms, refer to the Zoom Rooms Help Center.
10
UC-B31-Z-WM and UC-B31-Z-WM-INDIA QuickStart
Crestron Flex Small Room Conference System with Jabra® PanaCast® 50 Video Bar and Wall Mounted
Control Interface for Zoom Rooms® Software

Visit the Product Page
Scan the QR code to visit the product page.
UC-B31-Z-WM
www.crestron.com/model/6512604
UC-B31-Z-WM-INDIA
www.crestron.com/model/6512702
