Short Form Specifications
Top is one-piece 20-gauge stainless steel. Interior liner is
22-gauge stainless steel and is creased to a 1.00” (2.54cm)
diameter drain. A stainless steel bracket adjusts for pans flush
with top, recessed 1” (2.54cm), 2” (5.1cm), or 3” (7.6cm) to
accommodate 12” x 20” (30.5cm x 50.8cm) pans 4” (10.2cm)
or 6” (15.2cm) deep supplied by others. Temperatures of 33°F
(1°C) to 41°F (5°C) are maintained when 4” (10.2cm) deep
pans are recessed 3” (7.6cm) at 86°F ambient room tempera-
ture, meeting NSF 7 requirements. Adapter bars are optional.
Sides and bottom are wrapped with refrigeration lines and
insulated with high-density closed-cell polyurethane. Exterior
housing is 22-gauge galvanized steel.
Condensing unit is suspended below the cold pan on
a 16-gauge steel frame and uses HFC-134a refrigerant.
Temperature control has ON/OFF position to shut down cold
pan. Unit has an 8’ (2.4m) cord and NEMA 5-15P plug.
Two stainless steel louvers are provided for field installation
on the front of the cabinet, 4" below top of counter; cutout
dimension for each is 12” x 23.5” (30.5cm x 59.7cm). Allow at
least 12" between the two louvers to provide air circulation to
and from the condensing unit.
Optional Accessories & Modifications
• Custom sizes and styles
• Single or double service flip-up sneezeguards
• Relocate compressor
• Mullion fan assembly
• Adapter bars
• *220V/50 cycle
* Inclusion of this option will alter the
electrical specifications of the unit
N8100NB
Narrow Drop-In Self Contained Bloomington Style Refrigerated Cold Pans
Model N8168NB
(pans by others)
The refrigeration system
on this equipment uses
HFC-134a refrigerant.
®
®
®
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT _____________________________________
ITEM NUMBER_________________________________
QUANTITY _______________ DATE ________________
APPROVAL____________________________________

11.12"
(28.2cm)
21.87"
(55.6cm)
1/5 HP 115V-60C-1PH
13.62"
(34.6cm)
16.75"
(42.5cm)
18"
(45.7cm)
6.76"
(17.2cm)
A
B
C
9.35"
(23.7cm) 10.75" (27.3cm)
TYPICAL PLAN VIEW
TYPICAL ELEVATION VIEW TYPICAL END VIEW
A - 1.25" (3.2cm)
A - 4.5" (11.4cm)
14"
(35.6cm)
18"
(45.7cm)
MODEL COUNTER CUTOUT # OF 12” x 20” VOLTAGE BTU SYS. SHIPPING
NUMBER A B C DIMENSIONS (D x L) PANS HELD HERTZ/PHASE H.P. AMPS LOAD CAP. WEIGHT
N8146NB 46.75” 14.41” 8.34” 17” X 45.75” 2 115/60/1 1/5 4.0 454 680 175 lbs
118.7cm 36.6cm 21.2cm 43.2cm x 113.7cm 80 kg
N8168NB 67.5” 14.41” 18.71” 17” x 66.5” 3 115/60/1 1/5 4.0 676 804 240 lbs
171.5cm 36.6cm 47.5cm 43.2cm x 168.9cm 109 kg
Mechanical Data: Standard Unit
NOTE: Drain location on
left if facing service side.
N8100NB
Narrow Drop-In Self Contained Bloomington Style Refrigerated Cold Pans
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
DSN8100NB 01/02
