N8600: DROP-IN SELF-CONTAINED HOT & COLD COMBINATION PAN
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
Model: N8600
Drop-In Self-Contained Hot & Cold Combination Pan
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date ____________________
SPECIFICATIONS
Top: Top is constructed of one-piece 20-gauge
stainless steel.
Interior: Interior liner is constructed of 18-
gauge stainless steel with a 1” (2.54cm) drain.
Adjustable stainless steel pan rest for flush mount
heating or 2” recessed cooling to accommodate
up to 6” (15.2cm) deep 12”x20” pans, supplied
by others. Stainless steel immersion heater(s)
installed in bottom for wet only heating
operation.
Exterior: Exterior body is constructed of
24-gauge galvanized steel with high density
polyurethane insulation throughout.
Refrigeration: Condensing unit is suspended on a
16-gauge galvanized steel frame. Environmentally
friendly HFC-404A refrigerant is utilized.
Temperature controlled by thermostat located next to
condensing unit.
Operation: Remote control panel contains 3-way
Hot/Cold/Off power switch and thermostat for heated
operation.
Electrical: All units must be hard wired at
installation.
MODELS
❑ N8630 30” hot & cold combination pan drop-in
❑ N8643 43” hot & cold combination pan drop-in
❑ N8656 56” hot & cold combination pan drop-in
❑ N8669 69” hot & cold combination pan drop-in
OPTIONS AND ACCESSORIES
❑ Additional adaptor bars or plates
❑ Relocate compressor
❑ Remote refrigeration
❑ Automatic water fill
❑ 220V/50C electrical
❑ 3-phase electrical
❑ Counter protectors
❑ Extended warranty
STANDARD FEATURES
• NSF-4 and NSF-7 certified for hot and cold
operation
• Stainless steel immersion heaters with stainless
steel perforated covers
• Remote control panel with 3-way hot/cold/off
power switch and thermostat for hot operation
• Thermostat for cold operation located next to
condensing unit
• Adjustable pan support for flush mounted hot
operation or 2” recessed cold operation
• 1’’ stainless steel drain with screen
• Stainless steel louver provided
• High density polyurethane foam throughout
• Push-in flange gasket is standard
• Adaptor bars for 12”x20” pans provided
• Environmentally friendly HFC-404A refrigerant
• Standard 90 day labor and one year parts
warranty
❑ N8681 81” hot & cold combination pan drop-in

Drop-In Self-Contained Hot & Cold Combination Pan
Model #__________
CSI Section 11400
Printed in the USA.
05/06
DSN8600
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com























 






































 






































 















Model Number Cutout Dimensions Volts/Hertz/Phase Amps H.P. Ship Weight
N8630 29.75” X 25”, (75.6cmX63.5cm) 120/60/1 24 1/4 164 LBS./74.5kg
N8643 42.50” X 25”, (107.9cmX63.5cm) 120-240/60/1 21 1/4 198 LBS./90kg
N8656 55.25” X 25”, (140.3cmX63.5cm) 120-240/60/1 21 1/4 233 LBS./105.9kg
N8669 68” X 25”, (172.7cmX63.5cm) 120-240/60/1 42 1/4 266 LBS./120.9kg
N8681 80.75” X 25”, (205.1cmX63.5cm) 120-240/60/1 42 1/3 301 LBS./136.8kg
N8630 N8643 N8656
N8669 N8681
END ELEVATION
ALL MODELS
Mechanical Data























 






































 















Remote Control Detail
Cutout Dimensions
12.25”x4.25”
(31.1cm X 10.8cm)
