DEMA 607-3 User manual

DEMA MODEL 607-3, 607-3DF & 607-3SS
HI-FLOW FILL STATION
INSTALLATION INSTRUCTIONS
I-935 Pg. 1 of 3
Rev. A-35120 12/01/09
I. PARTS:
PARTS CHECKLIST
ITEM PART NUMBER DESCRIPTION 607-3 607-3DF 607-3SS
A. 607-3, 607-3DF or 607-3SS Fill Station Assembly 1 1 1
B. 60-47 Outlet Tubing 10’ long 1 1 1
C. 76-2-13 Hose Clamp 1 1 1
D. 100-16E-4 Tubing & Foot Valve Assembly 1 2 1
E. 61-107 Ceramic Weight 1 2 1
F. 66-54 #10 Screw & Anchor Kit 1 1 1
G. 61-9K Metering Tip Kit 1 1 1
H. 60-52 Wire Hose Hanger 1 1 1
II. PURPOSE:
The only difference between the 607-3 and the 607-3DF is that the 607-3 is a single product unit whereas the 607-
3DF is a two product unit (the DF stands for DUAL FEED).
III. INSTALLATION:
CAUTION: ALL WORK DONE SHOULD ADHERE TO ALL APPLICABLE PLUMBING CODES.
1. Hold assembly to wall, locate positions of mounting screws. Drill holes in wall about 1” deep. Mount
assembly to wall using screws and anchors provided.
2. Install priming ring in outlet tubing (large diameter), a few inches from one end. Slip tubing over threads of
injector, with priming ring close to the injector. Secure with tubing clamp and cut to convenient length.
3. Attach water supply hose (not provided) to water inlet and tighten.
4. To install wire hose hanger, slip outlet tubing through hose hanger.
IV. CHEMICAL ADJUSTMENT:
CAUTION: Be careful when working with hazardous chemicals.
1. Select metering tip using Table 1 as a guide. Screw tip into inlet barb of injector.
2. Cut inlet tube to convenient length, at least 18” long to insure priming but not more than 6’ (greater lifts reduce
injection capacity).
3. Slip ceramic weight over tubing and insert end with foot strainer into chemical. Attach other end to inlet barb
of injector.
Table 1: Induction readings taken at 50-psi
inlet pressure & 9 GPM.
METERING TIPS 1 CPS
COLOR OZ/GAL RATIO
Clear 0.21 606.3 – 1
Purple 0.26 496.9 – 1
Yellow 0.44 288.6 – 1
Green 0.83 155.0 – 1
Pink 0.95 134.1 – 1
Turquoise 1.57 81.6 – 1
Black 2.01 63.6 – 1
Gray 2.64 48.4 – 1
Red 3.40 37.7 – 1
Blue 4.11 31.1 – 1
Brown 5.64 22.7 – 1
White 7.19 17.8 – 1
Orange 8.71 14.7 – 1
None 14.88 8.6 – 1
Induction rates may vary from product to product,
NOTE: IN ORDER FOR UNIT
TO OPERATE PROPERLY,
FLOW RATE NEEDS TO BE 10
GPM OR GREATER.

DEMA MODEL 607-3, 607-3DF & 607-3SS
HI-FLOW FILL STATION
INSTALLATION INSTRUCTIONS
I-935 Pg. 2 of 3
Rev. A-35120 12/01/09
field test are recommended.
RETURNS: NO MERCHANDISE MAY BE RETURNED FOR CREDIT WITHOUT DEMA’S
WRITTEN PERMISSION. RETURN MERCHANDISE AUTHORIZATION NUMBER
REQUIRED IN ADVANCE OF RETURN.
WARRANTY: DEMA products are warranted against defective material and workmanship under normal use and
service for one year from the date of manufacture. This limited warranty does not apply to any
products which have a normal life shorter than one year or failure and damage caused by
chemicals, corrosion, improper voltage supply, physical abuse, or misapplication. Rubber and
synthetic rubber parts such as “o”- rings, diaphragms, squeeze tubing and gaskets are considered
expendable and are not covered under warranty. This warranty is extended only to the original
buyer of DEMA products. If products are altered or repaired without prior approval of DEMA,
this warranty will be void.
Defective units or parts should be returned to the factory with transportation prepaid. If inspection
shows them to be defective, they will be repaired or replaced without charge, F.O.B. factory.
DEMA assumes no liability for damages. Return merchandise authorization number, to return
units for repair or replacement, must be granted in advance of return.

DEMA MODEL 607-3, 607-3DF & 607-3SS
HI-FLOW FILL STATION
INSTALLATION INSTRUCTIONS
I-935 Pg. 3 of 3
Rev. A-35120 12/01/09
NO. PART NO. DESCRIPTION
1 60-9 Siphon Breaker (1/2” NPT)
2 95-4-1 Ball Valve (1/2” NPT MXF)
3 90-7 Street Elbow (Plated) ½”
NPT
4 90-73-1 Pipe Nipple (Plated) ½” NPT
X 1-1/8” Lg.
5 93-104-2 Hose Swivel Coupling (Plated) ¾” FGHT X ½”
FPT
6 100-38 Strainer Washer
7 90-73-9 Pipe Nipple (Plated) ½” NPT
X 5” Lg.
8 61-8-1 Proportioner Body
9 63-80 Inlet Barb, 3/8” (with O-Ring)
10 65-5-1 Plug
NO. PART NO. DESCRIPTION
11 63-78 O-Ring, EPDM (O-Ring only)
12 61-9- Metering Tip (Specify Color)
13 66-54 Mounting Screw & Anchor
Kit (4 EA)
14 60-47 Outlet Tubing (1” ID X 10
Ft. Long
15 100-12L Vinyl Tubing (3/8” ID X 8’
Long
16 61-107 Ceramic Weight (for 3/8” ID
1/2" OD tubing)
17 100-16E Foot Valve
18 76-2-13 Outlet Tubing Worm Clamp
19 60-49 Priming Ring
FOR 607-3DF ONLY
13
FOR 607-3
ONLY
14
12
9
12
9
11
11
10
2
8
11
7
34
3
1
12
9
8
11 19
18
6
5
17
16
15
