Dorma ED 100 User manual

DORMA
DORMA
1
ED 100/250
ED 100
ED 250
Mounting instructions

DORMA
DORMA
2
DORMA
ED 100/250
Contents
  Page
1. Foryoursafety 2-4
2. Technicalspecifications 5-6
3. Systemsetup 7
4. Accessories 8
5. Mountingonhingesidewith12.5mmpivotpin 9
6. Mountingonhingesidewith25mmpivotpin 10
7. Mountingonoppositehingeside 11
8. Installationinstructions 12-16
9. Connectiondiagram 17
10. Commissioning 18-20
11. UpgradeCards 21-22
12. Parameterisation/Service 23-29
13. Diagnosis/Troubleshooting 30-31
14. Errormessages 32-34
15. Furthermounting 35
16. Option:radioreceiver 36
17. Option:Double-leafdoor 37-39
18. Option:Strainrelief 40
„Translation of original operating instructions”
1. For your safety
Thisdocumentationcontainsimportantinformationregarding
themountingandthesafeoperationofthedoorsystem.
Readtheseinstructionscarefullybeforeoperatingthe
ED 100/250.
It is important for your personal safety to abide by all
enclosed instructions.
Anincorrectlyperformedinstallationmightcauseserious
injuries.
Usingcontrolelements,makingadjustmentsorperforming
proceduresthatarenotdescribedinthisdocumentation
mightcauseelectricshocks,dangercausedbyelectric
voltage/currentand/ordangerduetomechanicalincidents.
Pleasekeepthesedocumentsforfurtherreferenceandhand
themovertothepersoninchargeincasethesystemis
transferredtoanotherparty.
Explanation of symbols
NOTE This symbol underlines important
information that may facilitate your
work.
REMARK This symbol warns you of possible
system damage and explains how to
avoid this damage.
WARNING This symbol indicates dangers that
might cause personal or material
damage or even kill people.
Intended application
Aselectromechanicalswingdooroperators,theED 100 and
the ED 250 are only designed to open and close interior
swing doors with a door-leaf weight of up to 100 and 250 kg
respectively.
Simplyselectthesuitableversionaccordingtoyourprevailing
door-leafwidthandweight.
Bothoperatorsaresuitableforinstallationaspull-version
withEDslidechannelsetandaspush-versionwiththe
EDstandardarm.
Theclosingforcepathshavebeenoptimisedforthe
respectivewaysofmountingandcomplywiththe
requirementsofDIN18263part4.
Pleaseensurethatthesystemisapprovedforinstallationat
therespectivedoorbeforeinstallingthesystematafireor
smokedoor.
Beforeyoustartwiththeinstallationofthesystem,please
ensurethatyouroperatorissuitablefortheprevailing
doorsituationasexplainedinthetechnicalspecifications
inchapter2andthatthedoorisequippedwithadequate
hingesforoperationwithanautomaticoperator.
Themaximumcablelengthforexternalcomponentsmust
notexceed30m.
Limitation of liability
TheED 100/250 may only be used according to their
specified intended application. DORMA GmbH + Co. KG
will not accept any liability for damage resulting from
unauthorised modifications of the ED 100/250. Furthermore
components/accessories that have not been approved by
DORMA are exempted from liability.

DORMA
DORMA
DORMA
3
ED 100/250
Safety instructions
Work on electrical equipment may only be performed
by properly qualified staff (electricians).
• DonotallowchildrentoplaywiththeED 100/250
or its rigidly mounted adjustment and control devices.
• Keepremotecontrolsoutofreachofchildren.
• Neverstickmetalobjectsintotheopeningsofthe
ED 100/250; otherwise you might sustain an
electric shock.
• IftheED 100/250 is mounted onto a metal door leaf,
you have to earth (ground) the door leaf properly.
• Alwaysusesafetyglasswhenmounting
glassdoorpanels.
Important technical data
WeightofED 100/250 12 kg
Powersupply 230VAC+/-10%50Hz
Fuse(byothers) 16A
Max.operatingnoise 50db(A)
Standards, laws, codes and regulations
Thelatestversionsofthecommonandcountry-specific
standards,laws,codesandregulationshavetobeobserved.
formation/provisions regarding the application of the
ED 100/250 at fire and smoke doors:
• Pleaseconsiderthetechnicalbulletinforthe
applicationofhold-opendevices.
• Pleaseusetheguidelinesforhold-opendevices
issuedbytheDIBt(GermanInstituteforCivil
Engineering)inBerlin.
Low-energy product
TheED 100/250 may be adjusted so that it meets the
requirements of a low-energy application (low-energy
operator) to DIN 18650, ANSI 156.19 and BS 7036-4.
During commissioning, the operator has to be adjusted in
accordance with the prevailing standard.
Therequiredsystemsafetyisensuredbythefollowing
means:
• Reduceddynamicforceatdoorleaf/contactforce
• Lowdrivingspeed
• Reducedstaticforceatdoorleaf/contactforce
• Forcelimitation
Theapplicationofadditionalsafetysensors(IRS-4)to
protecttheswingpathisnotexplicitlystipulatedbutshould
beconsideredasanoptioniftheindividualriskassessment
revealsthatfurthersensorsarerequired.Theprotectionof
thesecondaryclosingedgehastobeassessedindividually.
Risk assessment on the part of the installer
Duetospecialspatialconditionsandtheexpecteduser
groupsofthedoor,theapplicationofsafetysensorsmay,
however,alsobereasonableforalow-energyoperator.
Thereforethemanufacturer,i.e.theinstallerofthesystem,
hastoperformanindividualriskassessmentduringthe
planningofthedoorsysteminordertodecidewhether
additionalsafetyequipmentisrequiredornot.
Pleaserefertoourhomepagewww.dorma.com and consider
the provided “risk assessment form” under PRODUCTS
for further assistance when performing your individual risk
assessment.
Special requirements regarding the protection of people in
need of protection
Incasetheriskassessmentrevealsthatthereisahealthrisk
orriskofinjurycausedbythedoorhittingapersonusingthe
doorwithanunacceptableforce,anadditionalprotection
withtheaidofappropriatesafetyequipment(connectionofa
safetysensor)isrequired.
Thisisespeciallynecessarywhenpeopleinneedof
protection(children,elderlypeopleordisabledpeople)use
thedoor.
Dangers at closing edges
Automatic doors may cause hazards by crushing,
shearing, hitting and drawing-in at the different closing
edges.

Opposingclosingedge
Secondaryclosingedge
Mainclosingedge

Dangers caused by slide channel and arm
The slide channel and the arm may cause hazards by
crushing and shearing.
Residual risk
Dependingonthestructuralconditions,theprevailingdoor
versionandtheavailablesafetyequipment,residualrisks
(suchascrushingandhitting–withlimitedforce)cannotbe
excluded.
Allpeopleusingadooraregenerallyawareofthedanger
spotatthesecondaryclosingedgeofeveryswingdoor
(alsoatmanuallyoperateddoors).Thisdangerspotcannot
beinfluencedbythemanufactureroftheoperatoranda
protectionofthisclosingedgeoftencannotberealised
duetoitsconstructionandtechnicalfunction.Asuitable
clampingprotection(likearubberortextilecover)isavailable
inthespecialisedtradeandnotpartofthescopeofdelivery.

DORMA
DORMA
4
DORMA
ED 100/250
Recycling and disposal
 BoththeED 100/250 and its packing mainly
consist of recyclable raw material.
 TheED 100/250 and the respective accessories
must not be disposed of as domestic waste.
 Pleaseensurethattheoldapplianceandthe
respectiveaccessories(ifavailable)areproperly
disposedof.
Abidebytheprevailingnationalstatutoryprovisions!
Safety during mounting
• Theworkingareahastobesecuredagainst
unauthorisedaccessfromotherpeople.Fallingitems
ortoolsmightcauseinjuries.
• TheED 100/250 has to be secured against water and
other liquids.
• Inanycase,thewayofmountingandthemounting
equipment,likeforexamplescrewsandwallplugs,
havetobeadequatewithregardtothestructural
conditions(steelstructure,wood,concreteetc.).
• BeforemountingtheED 100/250, the door leaf has
to be checked with respect to proper mechanical
condition and smooth running.
• The mounting of the ED 100/250 described herein is
only an example.
Structural or local conditions, available tools or other
conditions might suggest a different approach.
• Followingthesuccessfulinstallationofthesystem,the
settingsandtheproperfunctionoftheED 100/250
and the safety equipment have to be checked.
• Onlyspeciallyqualifiedstaffmayopenthepower
supplyhousing.
• DisconnecttheED 100/250 from power supply
(de-energise the system) before removing the cover of
the power supply housing.
Safety during commissioning
• Theprotectiveearthconductorhastobeconnected.
• Separatelysuppliedcomponentssuchastheprogram
switch,theEMERGENCYOFFpushbuttonand
activators(radarmotiondetectors,NIGHT-/BANKkey
switches)havetobemountedandconnected.
• Ensurethatthedoorleavesrunsmoothly.
• Theoperatorandthedoorleafmustbeproperly
linked.
Inspection and system approval
Beforethefirstcommissioninganddependingon
requirements,however,atleastonceayear,theED 100/250
has to be inspected by a properly qualified technician and
serviced if required.
A person trained by DORMA has to perform the inspection
and approve the system with the aid of the inspection book.
Therespectiveresultshavetobedocumentedandthefacility
operatorhastokeepthesedocumentsforatleastoneyear.
We would recommend taking out a maintenance
agreement with DORMA.
Briefing:
Followingtheadjustment,commissioningandfunctional
testingofthedoorsystem,theoperatinginstructionshave
tobehandedovertothefacilityoperatorandabriefinghas
tobemade.
Maintenance
Thesystemhastobede-energised/disconnectedfrompower
supplybeforeanykindofmaintenanceworkisperformed
(switchofffuse).
Pleaseconsidertheleafletregardingtheapplicationof
hold-opendevicesforfurtherinformationandinstructions
regardingtheapplicationoftheED 100/250 at fire and
smoke doors.
Care
Thesystemhastobede-energised(disconnectedfrompower
supply)beforecleaningthesystem.
Removepowerplugor,withpermanentpowersupply,switch
offfuse.
YoumaycleantheED 100/250 with a damp cloth and
standard commercial detergents.
Youshouldnotusescouringagentsforcleaningpurposesas
theymightdamagethesurfacefinish.
Payattentionthatnowaterorotherliquidsdroponorinto
theED 100/250.
Neverstickmetalobjectsintotheopeningsofthe
ED 100/250; otherwise you might sustain an electric shock.
Wear
Thefollowingwearpartshavetobeinspectedonceayear
andreplacedifrequired:
• Arm
• Slideshoe
• Slidechannel
Only use original spare parts.

DORMA
DORMA
DORMA
5
ED 100/250
2. Technical specifications
Thefollowingtechnicalspecificationswillhelpyoutocheckadditionallyifthesystemfulfilstherequirements.Youcanstart
mountingifthesystemcomplieswiththeparameters.
ED 100 EN2-4,push-version,fireprotection,EN2-4,pull-version,fireprotection Article-No.29222301
ED 250 EN4-6,push-version,fireprotection,EN4-6,pull-version,nospecifications Article-No.29202301
 EN4-6,pull-version,fireprotection Article-No.29202302
 EN4-5,pull-version,fireprotection Article-No.29202303
Required operating conditions
Ambienttemperature -15to+50°C
Onlysuitablefordry
environments
relativehumiditymax.93%
non-condensing
Powersupply 230VAC+/-10%50Hz
Classofprotection IP20
General specifications
Dimensions(WxHxD) 685x70x130mm
Min.distancebetweenhinges
(double-leafsystems)
1,400mm
Min.distancebetweenhinges
(double-leafsystems)
withESR(doorcoordinator)
1,450mm
Min.distancebetweenhinges
(double-leafsystems)with
VARIOCover
1,500mm
Operatorweight 12kg
Powersupplyforexternal
accessories
24VDC+/-10%,1.5A
Openingangle Max.110°
Inputs
Connections Max.1,5mm2
Potential-freeactivator Insideandoutside
(NOcontact)
Night-/Bank(intercomsystem) 8-24VDC/AC+10%
Night-/Bank(keyswitch) NOcontact/NCcontact
Safetysensor Hingesideandopposite
hingeside(NCcontact)
Testsignalforsafetysensor Hingesideand
oppositehingeside
Deactivationofoperator
function(lockswitch)
NCcontact/NOcontact
Outputs
Connections Max.1,5mm2
Potential-freestatusindicator Doorclosed
Dooropen
Malfunction
Integrated functions
Latchingaction Adjustablefrom5°-0°
Hold-opentime 0-30seconds
Night-/Bankhold-opentime 0-30seconds
Blockingbehaviourduring
closingcycle
Reversing/
Doorcloserfunction
Delayedopeningforlocking
mechanism(electricstrike)
0-1second/s
Lockingfeedbackcontact Motorlock
Windloadcontrol upto150N
Voltage-independentbraking
circuit
Adjustableviapotentiometer
Electroniclatchingactionpulse Forceadjustable
LEDstatusindicator green
 red
 yellow
-powersupplyavailable
-malfunction
-serviceintervalindicator
Integratedprogramswitch OFF
AUTOMATIC
PERMANENTOPEN
EXITONLY(onlyforsingle-
leafsystems)
Userinterfacewithinformation
display
Statusindicatorand
parameterisation
SlotforDORMAUpgradeCards Extensionoffunctionalrange
Updateinterface Firmwareupdate
TMP–Temperature
ManagementProgram
Overloadprotection
IDC–InitialDriveControl Drivingphaseoptimisation
Cyclecounter 0–1,000,000
(reasonablysubdivided)
PowerAssistFunction Servo-supportedmanual
opening
Push&GoFunction Thedooropenswhenitis
movedmanuallyby4°

DORMA
DORMA
6
DORMA
ED 100/250
ED 250
Max.powerconsumption 240Watts
Closingforce EN4–6continuously
adjustable
Max.door-leafweightfor
linteldepthsofupto300mm
250kgfordoor-leafwidths
ofupto1,400mm
190kgfordoor-leafwidths
ofupto1,600mm
Max.door-leafweightforlintel
depthsfrom301to500mm
160kg
Door-leafwidth 700–1,600mm
Door-leafwidthfor
fireprotectiondoors
700–1,400mm
Max.openingspeed **60°(27°*)/second
Max.closingspeed **60°(27°*)/second
Axleextension 30/60/90mm
Linteldepthforslidechannel +/-30mm
Linteldepthforstandardarm 0–500mm
ED 100
Max.powerconsumption 120Watts
ClosingforceEN1154 EN2–4continuously
adjustable
Max.door-leafweightfor
linteldepthsofupto300mm
100kg
Door-leafwidth 700–1,100mm
Max.openingspeed **50°(27°*)/second
Max.closingspeed **50°(27°*)/second
Axleextension 30/60mm
Linteldepthforslidechannel +/-30mm
Linteldepthforstandardarm 0–300mm
* Thevaluesinbracketsindicatethemaximumspeed
inLow-EnergyModewithoutFull-EnergyorFire
ProtectionUpgradeCards.
** Dependingonthedoor-leafweightautomatically
limitedaccordingtoDIN18650,BS7036-4and
ANSI156.19.
Torque overview
ED 100
Wayofmounting Lintelmountingonhingeside
withslidechannel,pull-version
Lintelmountingonoppositehinge
sidewithstandardarm,push-version
minimum maximum minimum maximum
ClosersizeEN1154 EN2 EN4 EN2 EN4
Closingtorque(manually)[Nm] 13 34 13 37
Closingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorque(manually)[Nm] 30 50 35 55
Openingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorqueofmanually-activated
Power-AssistFunction(Nm)*
23 23 23 23
ED 250
Wayofmounting Lintelmountingonhingeside
withslidechannel,pull-version
Lintelmountingonoppositehinge
sidewithstandardarm,push-version
minimum maximum minimum maximum
ClosersizeEN1154 EN4 EN6 EN4 EN6
Closingtorque(manually)[Nm] 26 65 26 70
Closingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorque(manually)[Nm] 55 85 60 90
Openingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorqueofmanually-activated
Power-AssistFunction(Nm)*
23 23 23 23
FE WithFull-EnergyorFireProtectionUpgradeCardFull-Energy,
LE Low-EnergybasicoperatorwithoutUpgradeCard
* Power-Assistadjustedtomaximum,effectivefromanopeningwidthofapprox.3°.
** ThetorqueisactivatedbyanautomaticopeninginAUTOMATICmode.
Power-Assist Function
ThePower-AssistFunctionmaybeactivatedwhilethedoor
isindoorclosermode(parameterHd=1).Assoonasauser
opensthedoormanuallybysomedegrees,theservo-function
supportsthemanualopeningcycle.Theservosupport
automaticallyadaptstotheadjustedsizeofthedoorcloser.
Thelevelofservosupportisadjustableinordertomeet
therequirementsofDIN18040,DINSpec1104,CEN/TR
15894,BS8300/2100anddocument"M",evenuptoclass
EN6
Thesmallestadjustableopeningtorqueamountsto23Nm/5
lbf.,unlessthehold-opendeviceistriggeredorintheevent
ofapowerfailure.WiththeaidofthePower-AssistFunction,
thesystemmeetstherequirementsoftheEuropeanstandard
EN1154andprovidesbarrier-freeaccessduringstandard
operation.
However,itisnotpossibletousethesysteminconjunction
withthePush&GoFunctionorthewindloadcontrolas
thesefunctionsmayaffecttheeasymanualopening.

DORMA
DORMA
DORMA
7
ED 100/250
3. System setup
Operator system
Theoperatorsystemcomprisesallcorecomponents.
Selectthesysteminaccordancewiththedoor-leafwidthandthedoor-leafweight.
1. Powerswitch
2. Mainsconnection
3. Connectionunit
4. Axleconnectiononbothsides
5. Drivesystem(motor/gear/spring)
6. Adjustmentofclosingforce
7. Controlunit
8. Switchingpowersupplyunit
9. SlotforDORMAUpgradeCards
10. Userinterfacewithinformationdisplay
11. Internalprogramswitch
12. *Slidechannel(Set)
13. *Standardarm
14. *Completecover
*Notpartofthescopeofdelivery.
1312
14
46
11
10987
6
54
32
1
Door closer mode & Automatic mode
Usersmaychoosebetweentwooperationmodes:doorcloser
andAutomaticmode.Whileadjustedtodoorclosermode
(parameterhd=1),thesystemisoptimisedformanual
operation.WithitsoptionalPower-AssistFunction,thedoor
closermodeistailoredtopredominantlymanually-operated
doorswhereadoorcloserfunctionisdesired.TheAutomatic
mode(parameterhd=0)inturnisespeciallysuitablefor
mainlyautomaticaccessviamotiondetectororpushbutton.
Inaddition,thedoorreversesassoonasitrunsintoan
obstructionwhileclosing.OnactivationoftheAutomatic
mode,alsothewindloadcontrolisavailable.However,the
doorsarestillreadyformanualaccess.Inthiscasewewould
recommendthePush&Gofunction.
Wind load control
ED100andED250operatorsareespeciallysuitablefor
applicationatexteriordoorsthataresubjecttovaryingwind
loadsandforinteriordoorsseparatingroomswheredifferent
pressureprevails.WhilethesystemisinAUTOMATICmode,
thewindloadcontrolmonitorstheactualdrivingspeedand
adjuststhespeedcorrespondinglyifitdoesnotcorrespond
totheadjustedvalue.InconjunctionwiththeFull-Energy
UpgradeCard,theoperatorprovidesaforceofupto150N
atthemainclosingedge–whichisthenusedtocompensate
environmentalinfluences.
Theelectroniclatchingactionisactivatedduringthelast5°
oftheclosingcycleinordertosupporttheclosingaction.

DORMA
DORMA
8
DORMA
ED 100/250
4. Accessories
Electrical connection
ApartfromthebroadrangeofDORMAaccessories,also
othermanufacturersoffervariousactivators,lockingdevices,
safetysensorsandfurtheraccessoriesthatarecompatible
withED 100andED 250operators.Allaccessoriesthatare
approvedbyDORMAforapplicationatED 100andED 250
operatorsarelistedonthepositivelistforaccessories.
Pleasefindthecurrentversionofthepositivelistinour
swingdooroperatorproductrangeatwww.dorma.com.
DORMAcannotensurethecompatibilityofdevicesthatare
notlistedonthepositivelist.Ifthesecomponentsareused
nonetheless,itmighthappenthatthefullrangeoffunctions
isnotavailableorthattheoperatorworksimproperly.
Furthermoretheoperatorortheconnectedcomponentmight
bedamaged.
Seelimitationofliabilityonpage3.
Activator
Ingeneralwerefertothefollowingdevicesasactivators:
• Radarmotiondetectors
• Passiveinfraredmotiondetectors
• Pushbuttons
• Switches
• Sensors
• Radiosystems,infraredreceivers
• Accesscontrolsystems
• Telephonesystemsandintercoms
Minimum requirements
Operatingvoltagewithpowersupplyviaoperator:
24VDC+/-10%
Pulsewidth:
min.200ms
Potential-freeoutput
(Wheninstalledatinternalsignalinput,external
detectororNight-/Bank)
Energisedoutput(telephonesystems):
8-24VDC/AC+10%
Locking device
Ingeneralwerefertothefollowingdevicesaslocking
devices:
• Electricstrikeplates
• ElectricstrikesMotorlocks
• Multi-pointlockingdevicewithfeedbackcontact
• Doormagnets
Motorlockswithoutfeedbackcontactcanbedirectly
connectedtotheoperatoraslongasthedelayedopeningfor
thelockingmechanismamountstolessthan4seconds.In
ordertoensurethattheoperatorandthelockingdevicework
togetherproperly,thelockingdevicehastocomplywiththe
followingspecifications:
Minimum requirements
Operatingvoltagewithpowersupplyviaoperator:
24VDC+/-10%
Operatingvoltagewithexternalpowersupply:
max.48VDC/AC
Currentloadforrelaycontactoflockingdevice:
max.1A
Ratedforcontinuousduty:electricstrike:
min.30%
Ratedforcontinuousduty:motorlock:
100%
Powerconsumptionforaccessories:
Theoperatormayprovideamaximumof1.5Aat
24VDCforexternalaccessories.Incaseyouneed
morepower(evenifonlyforashortperiodoftime),an
externalpowersupplyunitisrequiredinordertoavoid
malfunctions.

DORMA
DORMA
DORMA
9
45
150
106
45
120 120 95
451
155
B
D
A
C
120100
32
19
63
Ø 6,6
ED 100/250
Upperedgeofdoor
Upperedgeofdoor
Maximumlinteldepth±30mm
Cableinsert
Door without rebate
5. Mounting on hinge side with 12.5 mm pivot pin
Axle extension ED 100 ED 250 A B C D
Standard(9mm) 31mm 50mm 22mm 41mm
30mm 61mm 80mm 52mm 71mm
60mm 91mm 110mm 82mm 101mm
90mm --- 121mm 140mm 112mm 131mm

DORMA
DORMA
10
DORMA
45
32
45
150
106 120 120 95
451
155
B
D
A
C
120100
32
63
Ø 6,6
ED 100/250
Upperedgeofdoor
Upperedgeofdoor
Cableinsert
Door with rebate
6. Mounting on hinge side with 25 mm pivot pin
Axle extension ED 100 ED 250 A B C D
Standard(9mm) 31mm 63mm 22mm 54mm
30mm 61mm 93mm 52mm 84mm
60mm 91mm 123mm 82mm 114mm
90mm --- 121mm 153mm 112mm 144mm
Maximumlinteldepth±30mm

DORMA
DORMA
DORMA
11
45
45
150
10695
245
B
D
C
120 100120120
50
32
63
A
33
Ø 6,6
ED 100/250
Bottomedgeoflintel
Bottomedgeoflintel
ED100=0mm-300mm
ED250=0mm-500mm
Cableinsert
7. Mounting on opposite hinge side
Axle extension ED 100 ED 250 A B C D
Standard(9mm) 19mm 51mm 9mm 42mm
30mm 49mm 81mm 39mm 72mm
60mm 79mm 111mm 69mm 102mm
90mm --- 109mm 141mm 99mm 132mm

DORMA
DORMA
12
DORMA
5 mm 2,5 mm
6 mm 13 mm
1 / 2 / 3
2,5 mm
8 mm
5 mm
2.
1.
1.
1.
2.
1
2
3
4
ED 100/250
8. Installation instructions
Required tools
1. Removethetwotransportsafetyscrewsandthe
cardboard.
The screws are no self-locking screws; therefore they
must not be used to fix the arm.
2. Relaxthe8fixingscrews.
1. Remove230Vplug.
2. Removeoperatorfrommountingplate.
Useascrewdrivertolevertheoperator
offthebaseplate.
Putawoodenblockorsimilarbelowtheoperatorinorderto
avoidthattheconnectionunitcomesloose.
1. Fixthemountingplatewith12screwsthroughthe
providedholes.
Use adequate dowels and screws in accordance with
the prevailing substructure to fix the mounting plate.
2. Screwtheprovidedretainingpinintooneofthetwo
tappedholes.
insulated

DORMA
DORMA
DORMA
13
L1 N
1.
2. 5 mm
9 mm 30 mm 60 mm 90 mm
5
6
7
8
9
ED 100/250
Connectthe230Vpowersupply.
Work on electrical equipment may only be performed
by properly qualified staff (electricians).
Connect earthing (grounding) cable.
Form a loop of the end of the cable
Removetheprotectivefoilfromtheheatconductivepadsat
thebottomofthepowersupplyunit.
The heat conductive pads must remain clean.
Attachtheoperatortotheboltsonthebaseplate.
Laytheconnectioncablesthroughthehousing.
Pressagainsttheoperatoruntilyouhearitlockinposition.
1. Screwdownthe8screwsthoroughly.
2. Pluginmainsconnection.
Drivetheaxleextensionintothearm.
Turn the square end so that its mounting position
corresponds to the picture.

DORMA
DORMA
14
DORMA
1 2 3 4 55
1 4 3 2 55
2,5 mm
DIN L
DIN R
1.
2.
35 Nm
5 mm
10a
11a
12a
13a
14a
25mm
12.5mm
ED 100/250
a Mounting of slide channel
(hinge side)
Assembleslideshoe.
Insertthepivotpinintheslideshoe(12.5or25mm)
andsecurewithlockwasher.
Usetheshortpinfordoorswithoutrebate.
Positiontheindividualcomponentsinsidetheslidechannel
andscrewdownthefixings.
1-Slidechannel
2-Endstop
3-Buffer
4-Slideshoe
5-Fixing
Fixtheslidechannelwith2screwsthroughtheprovided
holes.
Mounttheslidechannelcover.
1. Fixtheendcapsontothespacers.
2. Insertbothcomponentsintothecover.
Ensure that the mounting position is correct.Install the
spacers and end caps as indicated on the picture.
Alignthesystemsothattheendcapsareflushwiththe
coveronbothsides.
Useahightorque(35Nm)tofixthearmtotheoperator
axle.
Only use the provided self-locking screw. In case the
screw has to be relaxed during repair or maintenance
work, it has to be replaced by a new self-locking screw
(see spare part list).

DORMA
DORMA
DORMA
15
SW 13 mm
5 mm
35 Nm
5 mm
AB
90o
2.
1.
1.
2.
B
A
15a
10b
11b
12b
16
ED 100/250
Fixarmtoslidechannel.
b Standard arm
(opposite hinge side)
Fixtheadjustmentscrew(A) with 2 screws through the
provided holes. Use a high torque (35 Nm) to fix the arm (B)
to the operator axle.
Only use the provided self-locking screw. In case the
screw has to be relaxed during repair or maintenance
work, it has to be replaced by a new self-locking screw
(see spare part list).
Theadjustmentscrewmustbepositionedatrightanglesto
thedoorleaf.
1. Relaxthecounternutattheadjustmentscrew.
2. Relax/tightentheadjustmentscrewsothatitisat
rightanglestothedoorleafwhenthearmisclipped
together.
1. Presstheballheadoftheadjustmentscrewintothe
providedholeinsidethearm.
2. Securetheadjustmentscrewwiththeaidofthe
hexagonnut.
Adjustment of braking circuit
1. Ensure that the power supply is switched off!
2. Insertdoublejumperaccordingtotherespectiveway
ofmounting.
(A) = Mounting with arm.
(B) = Mounting with slide channel.
The brake circuit will not work if the jumper is
improperly connected. The door might close at high
speed.

DORMA
DORMA
16
DORMA
5 mm
2. 1.
1.
2.
4.
5.
3.
17
18
19
ED 100/250
Adjustment of spring force
Whenthesystemisdelivered,thespringisfullytensioned.
Thespringhastobepre-tensioned-atleast10revolutions
arerequiredtooperatethesystem.Thesystemchecksthe
springadjustmentduringthelearningcycle;thecyclewillbe
interruptedifthespringisinsufficientlytensioned.
Alearningcyclehastobeperformedwheneverthespringis
readjusted.Thetablebelowwillhelpyoutodeterminethe
requirednumberoffullrevolutionstotensionthespring.
Desired EN class
Door-leafwidthinmm 850 950 1,100 1,250 1,400
ENclass EN2 EN3 EN4 EN5 EN6
Min.closingtorque
at2° 13Nm 18Nm 26Nm 37Nm 54Nm
Revolutions of adjustment screw
ED100 10 14 16 -- --
ED250 -- -- 14 18 24
Possible arm versions
Standardarm X X X X X
Slidechannel X X X X X
The table only indicates approximate values. Therefore
check the closing torque at 2° according to EN 1154
and adjust it as required. For lintel depths of more than
300 mm, additionally check the min. closing torque
between 88° - 92°.
Adjustment of closing speed under cut-out conditions
1. Adjustspeedforareafrom~7°-0°(Latchingaction).
2. Adjustclosingspeedforareafrom110°-~7°.
Strictly abide by the indicated order, as the
adjustments depend on each other.
 Thespeedshavetobeadjustedinanycase!
Ifthedoorrequireslessthan3secondstoclose,error
message73(brakingcircuittest)willbeemitted.
Adjustment of latching action (point of activation) while the
system is de-energised (disconnected system from power
supply)
Bymovingthemicroswitch,youmaychangetheangleat
whichthesystemswitchesfromoneclosingspeedtothe
other.
Priortothissetting,thetwospeedshavetobeadjustedwith
theaidofpotentiometer1and2–seepicture18.
1. Removeribboncable
2. Relaxscrew
3. Useascrewdrivertomovetheplateintothedesired
direction.
Move the lever away from the control unit to increase
the angle at which potentiometer 1 determines the
speed (picture 18).
4. Tightenthescrew
5. Re-connectribboncable
 Insomecasesthedoorhastobesloweddowninstead
ofbeingaccelerated.Inthiscasetheplugwiththe
redleads(comingfromthemicroswitchfortheangle
recognition)hastoberemovedfromthecontrolunit
andmustbereplacedbytheplugwiththeblackleads.

DORMA
DORMA
DORMA
17
97 98 99 30 31 32 34 33 3 335 13 6 144a
3B A 157 57a 1 42 31 41 3115 17 31 11 13 3
43 3 64 63 62 1G 3
A
B
B
A
20
ED 100/250
9. Connection diagram
ConnectthecablestotheconnectionterminalsandattachthemtothePCB.
Themaximumcurrentloadatterminal1,1Gand3amountsto1.5A.
Thecablelengthmustnotexceed30mwhenusingJ-Y(ST)Y0.8mm.
Thisterminalispartofthescopeofdelivery
oftheUpgradeCardDCW.
Thisterminalispartofthescopeofdelivery
oftheFireProtectionUpgradeCard.
0V B A 8-24VDC/AC+10% +24V +24V Signalinput
0V
+24V
COM
Lockingrelais
max.1A/48VDC/AC
NO
NC
0V
Lockingfeedbackcontact
0V +24V Signalinput
0V 0V
+24V
0V
Signalinput
0V
PartialOpen
PermanentOpen
ExitOnly
AUTOMATIC
Off
NC
NO
max.1A/48VDC/AC COM
0V Signalinput Testoutput +24V 0V Signalinput Testoutput +24V 0V
Night-/Bank
Deactivationof
operatorfunction
Smokedetector
Night-/Bank
Program-
switch
Status
relay
Internal pulse
External pulse Safetysensor onhingeside Safetysensoron oppositehingeside
DCW

DORMA
DORMA
18
DORMA
ED 100/250
10. Commissioning
TheDORMA ED 100 and ED 250 are electromechanical
operators. Only if the motor gear unit and the control
unit work together properly, can the door open and close
automatically. Thus the control unit requires certain
parameters in order to achieve the best possible operating
behaviour.
Thecontrolunitisequippedwithauserinterfaceandan
informationdisplay.Withtheaidofthisequipmentyou
canperformalladjustmentsthatarestipulatedonthe
parameterisationlist.
Information display
Theinformationdisplayisatwo-digitdisplay.Itisconfigured
duringcommissioningsothatthedisplaywillindicatethe
figuresandnumberscorrectlynomatterinwhichdirection
thesystemismounted.
User interface
Usethefourkeystoenterinformation.Amongothers,also
thefunctionofthekeysisadaptedtothemountingdirection
duringcommissioning.Thisensuresthatthekeysarealways
allocatedinthesameway.
Youcanremoveandturnthekeydesignation.
Use the keys to activate the following functions:
Key at bottom
• Adjustmentofmountingdirectionfollowingapowerreset
• Scrollingthroughparametersanderrormessages
• ReducingtheparametervalueOpeningpulse -Activatethekeyforlessthan3seconds
• Learningcycle -Activatethekeyformorethan3seconds(PGSOff)
• Toresetsystemtofactorysettings -Activatethekeyformorethan8seconds(PGSOff)
Key at TOP
• Scrollingthroughparametersanderrormessages
• Increasingtheparametervalue
Right key
• Openingtheparametermenu -Activatethekeyformorethan3seconds
• Changingtheselectedparameters
• Savingthechangedparametervalue
Left key
• Cancellingtheparameteradjustment
• Quittingtheparametermenu
Left and right key simultaneously
• Erroracknowledgement -Activatethekeyforlessthan3seconds
• Reset -Activatethekeyformorethan3seconds
< 3s Quit
> 3s Reset
< 3s
> 3s
LEARN
> 8s
Fact-Setup
> 3s
PRG
00
< 3s Quit
> 3s Reset
< 3s
> 3s
LEARN
> 8s
Fact-Setup
> 3s
PRG
00
DIN L
DIN R

DORMA
DORMA
DORMA
19
ED 100/250
First commissioning or following the system has been reset to factory settings
When starting with the commissioning, the operator must be completely installed and the door must be closed.
The motor needs to be cold during the subsequent learning cycle.
Switch on power supply:Thedisplaywillindicateasequenceofsymbolstoindicatethecurrentstatus.
Meaning Display What to do
Thesystemisbeingchecked.
Twomovingsegmentsinthemiddleofthedisplayindicatethatthe
controlunitiswaitingforinternalsignals
(max.1second).
Twounderscoresthatmoveupanddownindicatethatitisnowtime
toenterthemountingposition.Incaseyourentrywasincorrect,the
symbolswillbedisplayedupsidedown.
Activatethekeyatthebottom
(onlyrequiredduringfirst
commissioning).

Thedevicecode"runs"throughthedisplay.ED100orED250andthefirmwareversion(shownbyXX XX).
Asmall,rotating"o"anda"P"indicatethatthesystemrequiresafurther
parameterisation.(Onlyduringfirstcommissioningorfollowingthe
systemhasbeenresettofactorysettings).
Thefollowingparametershave
tobeadjusted:Wayofmounting
(AS),linteldepth(rd)anddoor-
leafwidth(Tb)
Changing the parameters
1. Openparametermenu withkey      Pressandholdkeyfor3seconds
2. Selectdesiredparameter withkey   or
3. Showparametervalue withkey  
4. Selectthevaluetochange withkey      =>thevalueblinks
5. Adjustdesiredvalue withkey   or
6. Storenewvalue withkey   
7. Returntoparametermenu withkey 
8. Selectnextparameter withkey   or
Parameters/Display Range Unit
factory setting
= bold print
Explanation
Configuration
Wayofmounting

0to1 0Lintelmountingonhingesidewithslidechannel,
pull-version
1 Lintelmountingonoppositehingesidewithstandardarm,push-
version
Linteldepth

ED 100: -3 to 30
ED 250: -3 to 50
0Thelinteldepthisindicatedinstepsof10mm.Considerthe
installationdrawingstofindtherequireddimension.
Door-leafwidth

ED 100: 7 to 11
ED 250: 7 to 15
10 Therebateisincludedinthedoor-leafwidth.
Thedoorwidthisindicatedinstepsof100mm.
Afterleavingtheparameterisationmode,thedisplayshowsasmall,
rotating"o"and"O".
Startlearningcycle.

DORMA
DORMA
20
DORMA
ED 100/250
Learning cycle
ThedoormustbeclosedandtheprogramswitchhastobesettoOFF before you start the learning cycle.
Thefollowingthreeparametersmusthavebeenadjusted:
Wayofmounting(armorslidechannel),linteldepthanddoorwidth(Seepage18”Firstcommissioning”).
The learning cycle has to be performed while the motor is cold. You must not move the door leaf manually or hold the
door open during the learning cycle; otherwise the control unit cannot determine the parameters correctly.
Safetysensorsandactivatorsareswitchedoffduringthelearningcycletoensurethatthecycleisnotinterrupted.The
movementrangeofthedoorleafmustthusbesafeguardedmanually.
Smokedetectorsareactivatedandtheoperatorfunctionsaredeactivated(deactivationofoperatorfunction).
Meaning Display What to do
Asmallrotating"o"and"O"indicatethatalearningcycleisrequired. Pressandholdthelowerkey
for3seconds.
Thedoorperformsseveralmovementsandthedisplayshowsasequenceofsymbols.
Youmustnotinterruptthemovementsofthedoorleaf.
Thedoorstandsatanangleof70°andwaitsfortheopeningwidthto
beadjusted.
Movethedoortothedesired
"open"positionandpressthe
lowerkey 
Thedoorperformsseveralmovementsandthedisplayshowsasequenceofsymbols.
Youmustnotinterruptthemovementsofthedoorleaf.
Incasethespringforceisinsufficient,thedisplaywillshowasmall
rotating"o"and"F".
Increasespringforceand
restartlearningcycle.
Thedoorisreadyforoperation.

