Dorner 2200 series User manual

851-733 Rev. E
For other service manuals visit our website at:
www.dornerconveyors.com/manuals-literature
Record Conveyor Serial Number Here
2200 and 2700 Series Side
Mount Drive Package
Installation, Maintenance & Parts Manual

Dorner Mfg. Corp. 2 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Table of Contents
Introduction ......................................................................... 2
Warnings - General Safety .................................................. 3
Product Description ............................................................. 4
Specifications ...................................................................... 4
Gearmotor Mounting Package ......................................... 4
Table 1: Gearmotor Specifications - Standard Load........ 4
U.S. Version ................................................................. 4
CE Version ................................................................... 5
Table 2: 60 Hz Gearmotor Specifications - Heavy Load. 5
Table 3: RPM/Torque for Standard Load
Fixed Speed 90° Gearmotors ........................................... 5
U.S. Version (60 Hz Gearmotors)................................ 5
CE Version (50 Hz Gearmotors).................................. 5
Table 4: RPM/Torque for Standard Load
Variable Speed 90° Gearmotors ...................................... 6
U.S. Version 42CZ C Face (60 Hz Gearmotors).......... 6
U.S. Version 56 C Face (60 Hz Gearmotors)............... 6
CE Version (50 Hz Gearmotors).................................. 6
Table 5: Belt Speeds for Fixed Speed SEW Gearmotors 6
Table 6: Belt Speeds for Variable Speed
SEW Gearmotors ............................................................. 6
Table 7: RPM/Torque for Heavy Load Fixed Speed
90° Gearmotors ................................................................ 7
U.S. Version (60 Hz Gearmotors)................................ 7
Table 8: RPM/Torque for Heavy Load Variable Speed
90° Gearmotors................................................................. 7
U.S. Version 230/460 V, 3 Phase (60 Hz Gearmotors) 7
U.S. Version 575 V, 3 Phase (60 Hz Gearmotors) ....... 7
Fastener Torque Specifications ........................................ 7
Installation............................................................................ 8
Required Tools ................................................................. 8
Mounting .......................................................................... 8
Preventive Maintenance and Adjustment .......................... 10
Required Tools ............................................................... 10
Gear Reducer Replacement ............................................ 10
Motor Replacement ........................................................ 12
Single Phase Motor..................................................... 12
Three Phase Motor...................................................... 12
All Models .................................................................. 12
Replace Wiring ........................................................... 12
Notes .................................................................................. 13
Service Parts....................................................................... 14
2200 Series Side Mount Drive Package ......................... 14
2700 Series Side Mount Drive Package ......................... 16
U.S. Version Gearmotors ............................................... 18
CE Version Gearmotors ................................................. 19
SEW Gearmotors ........................................................... 19
Return Policy...................................................................... 20
Introduction
Upon receipt of shipment:
• Compare shipment with packing slip. Contact factory
regarding discrepancies.
• Inspect packages for shipping damage. Contact carrier
regarding damage.
• Accessories may be shipped loose. See accessory instruc-
tions for installation.
Dorner’s Limited Warranty applies.
Dorner 2200 Series conveyors are covered by patent number
5,174,435, 6,109,427, 6,298,981, 6,422,382, 6,685,009 and
corresponding patents and patent applications in other
countries.
Dorner reserves the right to make changes at any time
without notice or obligation.
Dorner has convenient, pre−configured kits of Key Service
Parts for all conveyor products. These time saving kits are
easy to order, designed for fast installation, and guarantee
you will have what you need when you need it. Key Parts
and Kits are marked in the Service Parts section of this
manual with the Performance Parts Kits logo.
IMPORTANT
Some illustrations may show guards
removed. DO NOT operate equipment
without guards.

851-733 Rev. E 3 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Warnings - General Safety
A
WARNING
The safety alert symbol, black triangle with
white exclamation, is used to alert you to
potential personal injury hazards.
A
DANGER
Climbing, sitting, walking or riding on
conveyor will cause severe injury.
KEEP OFF CONVEYORS.
A
DANGER
DO NOT OPERATE CONVEYORS IN AN
EXPLOSIVE ENVIRONMENT.
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
A
WARNING
Gearmotors may be HOT.
DO NOT TOUCH Gearmotors.
A
WARNING
Exposed moving parts can cause severe
injury.
REPLACE ALL GUARDS BEFORE RUNNING
CONVEYOR.
A
WARNING
Dorner cannot control the physical
installation and application of conveyors.
Taking protective measures is the
responsibility of the user.
When conveyors are used in conjunction
with other equipment or as part of a multiple
conveyor system, CHECK FOR POTENTIAL
PINCH POINTS and other mechanical
hazards before system start-up.

Dorner Mfg. Corp. 4 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Product Description
Refer to Figure 1 for typical conveyor components. Figure 1
Figure 1
Specifications
Gearmotor Mounting Package
Table 1: Gearmotor Specifications - Standard Load
U.S. Version
1Conveyor
2 Gearmotor Mounting Package
3 Gearmotor Assembly
4 Spider Web Bushing
5 Shaft Coupling Half, 3 Jaw
6 Coupling Half, 3 Jaw
7 Key, Coupling
8 Drive Plate and Short Drive Guard Assembly
9 Drive Plate Screws
10 Cover
11 Screws, Cover
12 Pin, Quick Release
6
4
2
7
8
5
3
9
10
1
12
11
DC
B
A
Output Shaft Type:
Gearmotor Type:
H = Heavy Load
Mount Style = Side Mount
Mount Position = A or D
(see detail to the right)
SE H A
Language Code:
M = U.S. English
U = CE English
22 M
E = 90 Industrial
22 = 2200 Series Conveyor
2L = 2700 Series Conveyor
S = Standard Load
Single Phase Three Phase
Output Power 0.25 hp (0.19 kw)
Input Voltage 115 Volts A.C. 208 to 230/460 Volts A.C.
Input Frequency 60 Hz
Input Current 5.0 Amperes 1.2 /0.6 Amperes
Motor RPM 1725
Gearmotor Ratios 5:1, 10:1, 20:1, 40:1, 60:1
Frame Size NEMA 42 CZ NEMA 56 C
Motor Type Totally Enclosed, Fan-cooled

851-733 Rev. E 5 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Specifications
CE Version
Table 2: 60 Hz Gearmotor Specifications - Heavy Load
Table 3: RPM/Torque for Standard Load Fixed Speed 90° Gearmotors
U.S. Version (60 Hz Gearmotors)
(vp) = voltage and phase 11 = 115 V, 1-phase
23 = 208−230/460 V, 3-phase
CE Version (50 Hz Gearmotors)
(vp) = voltage and phase
21 = 230 V, 1-phase
23 = 230 V, 3-phase
43 = 400 V, 3-phase
Single Phase Three Phase VFD Variable Speed
Output Power 0.18 kw
Input Voltage 230 Volts A.C. 230/400 Volts A.C. 230 Volts A.C.
Input Frequency 50 Hz 25 to 63 Hz
Input Current 1.6 Amperes 1.4 /0.8 Amperes 1.4 Amperes
Gearmotor Ratios 5:1, 10:1, 20:1, 40:1, 60:1
Protection Rating IP55
Frame Size IEC 63 B5
Heavy Load Gearmotor
Single- Phase Three Phase VFD Variable Speed
Output Power 0.5 hp (0.37 kw)
Input Voltage 115VAC 208 – 230/460 VAC 230 VAC
Input Frequency 60Hz 10 – 60Hz
Input Current (Amperes) 7.4 2.1 – 2/1 1.6
Gearmotor Ratios 5:1, 10:1, 20:1, 40:1, 60:1
Frame Size NEMA 56C
Motor Type Totally enclosed, Fan cooled
NOTE
For belt speed other than those listed in
Tables 3
− 8, contact factory for details.
Gearmotors
Part Number RPM In lb 1 Phase In lb 3 Phase N-m 1 Phase N-m 3 Phase
62M060ES4(vp)FN 29 134 134 15.1 15.1
62M040ES4(vp)FN 43 160 160 18.1 18.1
62M020ES4(vp)FN 86 133 151 15 17.1
62M010ES4(vp)FN 173 75 114 8.5 12.9
62M005ES4(vp)FN 345 39 60 4.4 6.8
Gearmotors
Part Number RPM N-m 1 phase N-m 3 phase
62Z060ES4(vp)FN 23 36 36
62Z040ES4(vp)FN 35 26.9 35.5
62Z020ES4(vp)FN 70 16 21.2
62Z010ES4(vp)FN 140 8.7 11.4
62Z005ES4(vp)FN 280 4.5 5.9

Dorner Mfg. Corp. 6 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Specifications
Table 4: RPM/Torque for Standard Load Variable Speed 90° Gearmotors
U.S. Version 42CZ C Face (60 Hz Gearmotors)
U.S. Version 56 C Face (60 Hz Gearmotors)
CE Version (50 Hz Gearmotors)
Table 5: Belt Speeds for Fixed Speed SEW Gearmotors
Table 6: Belt Speeds for Variable Speed SEW Gearmotors
Gearmotors
Part Number RPM In-lb N-m
62M060ES423EN 5-29 134 15.1
62M040ES423EN 7-43 160 18.1
62M020ES423EN 14-86 151 17.1
62M010ES423EN 29-176 114 12.9
62M005ES423EN 58-345 60 6.8
Gearmotors
Part Number RPM In-lb N-m
32M060EL423EN 3-29 319 39
32M040EL423EN 4-43 238 26.9
32M020EL423EN 9-86 142 16.0
32M010EL423EN 17-173 77 8.7
32M005EL423EN 35-345 40 4.5
Gearmotors
Part Number RPM N-m
62Z060ES423EN 12-29 36.0
62Z040ES423EN 18-44 35.5
62Z020ES423EN 35-88 21.2
62Z010ES423EN 70-176 11.4
62Z005ES423EN 140-353 5.9
Part Number RPM In-lb N-m Ft/min M/min
22M039WS423EN 46 203 22.9 16.2 4.9
22M017WS423EN 109 159 18.0 38.2 11.6
22M008WS423EN 219 132 14.9 76.8 23.4
Part Number RPM In-lb N-m Ft/min (max) Ft/min (min) M/min (max) M/min (min)
22M039WS423EN 46 203 22.9 16.2 2.7 4.9 0.8
22M017WS423EN 109 159 18.0 38.2 6.4 11.6 1.9
22M008WS423EN 219 132 14.9 76.8 12.8 23.4 3.9

851-733 Rev. E 7 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Specifications
Table 7: RPM/Torque for Heavy Load Fixed Speed 90° Gearmotors
U.S. Version (60 Hz Gearmotors)
(vp) = voltage and phase
11 = 115 V, 1-phase
23 = 208−230/460 V, 3-phase
Table 8: RPM/Torque for Heavy Load Variable Speed 90° Gearmotors
U.S. Version 230/460 V, 3 Phase (60 Hz Gearmotors)
U.S. Version 575 V, 3 Phase (60 Hz Gearmotors)
Fastener Torque Specifications
Gearmotors
Part Number RPM In-lb N-m
32M060ES4(vp)FN 29 319 36.0
32M040ES4(vp)FN 43 378 42.7
32M020ES4(vp)FN 86 285 32.2
32M010ES4(vp)FN 173 153 17.3
32M005ES4(vp)FN 345 80 9.0
32M005ES223FN 672 33 3.7
Gearmotors
Part Number RPM In-lb N-m
32M060ES423EN 3-29 319 36.0
32M040ES423EN 4-43 378 42.7
32M020ES423EN 9-86 285 32.2
32M010ES423EN 17-173 153 17.3
32M005ES423EN 35-345 80 9.0
32M005ES223EN 67-672 33 3.7
Gearmotors
Part Number RPM In-lb N-m
32M060ES453EN 3-29 319 36.0
32M040ES453EN 4-43 378 42.7
32M020ES453EN 9-86 285 32.2
32M010ES453EN 17-173 153 17.3
32M005ES453EN 35-345 80 9.0
Flat Head Socket Head Button/Low Head Set Screw
Size Torque Size Torque Size Torque Size Torque
M4 x 0.7 2.5 mm 3.4 Nm
(30 in lbs)
3 mm 5.9 Nm
(52 in lbs)
2.5 mm 2.9 Nm
(26 in lbs)
2 mm 2.1 Nm
(19 in lbs)
M5 x 0.8 3 mm 6.9 Nm
(61 in lbs)
4 mm 12.0 Nm
(106 in lbs)
3 mm 5.9 Nm
(52 in lbs)
2.5 mm 4.7 Nm
(42 in lbs)
M6 x 1.0 4 mm 12.0 Nm
(106 in lbs)
5 mm 20.3 Nm
(180 in lbs)
4 mm 10.0 Nm
(89 in lbs)
3 mm 7.7 Nm
(68 in lbs)
M8 x 1.25 5 mm 28.0 Nm
(248 in lbs)
6 mm 48.8 Nm
(432 in lbs)
5 mm 24.0 Nm
(212 in lbs)
4 mm 17.8 Nm
(158 in lbs)
M10 x 1.5 6 mm 56.0 Nm
(496 in lbs)
8 mm 97.5 Nm
(863 in lbs)
6 mm 48.0 Nm
(425 in lbs)
5 mm 35.0 Nm
(310 in lbs)

Dorner Mfg. Corp. 8 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Installation
Required Tools
• Hex key wrenches:
2 mm, 2.5 mm, 3 mm, 5 mm
• Torque wrench
Mounting
Installation Component List:
1. Typical components (Figure 2).
Figure 2
Figure 2
2. Remove two screws (Figure 3, item 1).
Figure 3
Figure 3
3. Install screw (Figure 3, item 2) and washer.
4. Install drive plate (Figure 4, item 1) with two screws
(Figure 4, item 2). Tighten screws to 60 in-lb (7 Nm).
Figure 4
Figure 4
5. Making sure key (Figure 4, item 3) is installed in slot in
gear reducer output shaft assembly (Figure 4, item 4).
6. Install 3 jaw coupling (Figure 5, item 1) onto shaft
(Figure 5, item 2).
Figure 5
Figure 5
7. Be certain 3 jaw coupling is fully on shaft and secure
position with set screw (Figure 5, item 3).
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
1Conveyor
2 Gearmotor Mounting Package
3 Gearmotor Assembly
4 Spider Web Bushing
5 Shaft Coupling Half, 3 Jaw
6 Coupling Half, 3 Jaw
7 Key, Coupling
8 Mounting Plate, Coupling
9 Mounting Plate Screws
10 Cover
11 Screws, Cover
12 Pin, Quick Release
6
4
2
7
8
5
3
9
10
1
12
11
1
2
1
2
3
4
3
1
2

851-733 Rev. E 9 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Installation
Figure 6
Figure 6
8. Install spider bushing (Figure 7, item 1) in mating
female portion of 3 jaw coupling on gearmotor
assembly (Figure 7, item 2).
Figure 7
Figure 7
9. Slide and pivot gearmotor and gearmotor mounting ring
(Figure 7, item 3) onto four screws (Figure 7, item 4)
(through slots in gearmotor bracket).
10. Tighten four screws (Figure 8, item 1) to
60 in-lb (7 Nm).
Figure 8
Figure 8
11. Install quick release pin (Figure 9, item 1).
Figure 9
Figure 9
12. Install cover (Figure 10, item 1) and two screws
(Figure 10, item 2). Tighten screws to 60 in-lb (7 Nm).
Figure 10
Figure 10
NOTE
Gearmotor may be operated in positions 1, 3
or 4 (Figure 6).
13
4
4
4
2
1
3
1
1
1
2

Dorner Mfg. Corp. 10 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Preventive Maintenance and Adjustment
Required Tools
• Hex-key wrenches:
2 mm, 2.5 mm, 3 mm, 5 mm
• Adjustable wrench (for hexagon head screws)
• Straight edge
• Torque wrench
Gear Reducer Replacement
1. Remove quick release pin (Figure 11, item 1).
Figure 11
Figure 11
2. Loosen four screws (Figure 12, item 1).
Figure 12
Figure 12
3. Rotate and remove gearmotor and gearmotor mounting
ring (Figure 13, item 1) from four screws (Figure
13, item 2) (through slots in gearmotor bracket) and
remove entire gearmotor assembly from conveyor.
Figure 13
Figure 13
4. Remove spider bushing (Figure 13, item 3) from
mating female portion of 3 jaw coupling on gearmotor
assembly (Figure 13, item 4).
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
A
WARNING
Gearmotor can rotate and fall off, causing
injury.
Support the gearmotor prior to removal.
1
1
2
2
4
3
1

851-733 Rev. E 11 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Preventive Maintenance and Adjustment
5. Remove four socket head screws (Figure 14, item 1)
and remove spacer plate (Figure 14, item 2) assembly
from gearmotor (Figure 14, item 3).
Figure 14
Figure 14
6. Remove four screws (Figure 15, item 1). Detach motor
(Figure 15, item 2) from gear reducer (Figure
15, item 3), making note of position of switch (Figure
15, item 4) for reassembly. Retain motor output shaft
key (Figure 15, item 5).
Figure 15
Figure 15
7. Inspect gear reducer output shaft assembly for wear or
damage. If necessary, loosen set screw (Figure
16, item 1) and remove 3 jaw coupling (Figure
16, item 2) from gear reducer output shaft (Figure
16, item 3).
Figure 16
Figure 16
8. Loosen set screw (Figure 17, item 1), and remove 3 jaw
coupling (Figure 17, item 2) from shaft (Figure
17, item 3).
Figure 17
Figure 17
9. Remove key from in slot in gear reducer output shaft
assembly (Figure 16, item 4). Install new components
for shaft reverse of removal. Tighten set screw (Figure
16, item 1) to 35 in-lb (4 Nm).
10. With key (Figure 15, item 5) in keyway, slide motor
(Figure 15, item 2) and gear reducer (Figure
15, item 3) together, noting where position of switch
(Figure 15, item 4) will be during installation on
conveyor.
11. Install screws (Figure 15, item 1) and tighten to
60 in-lb (7 Nm).
12. Install components in reverse order of removal.
1
1
3
2
324
5
1
IMPORTANT
Be extremely careful when coupling motor to
gear reducer. Avoid misalignment and forcing
the connection causing possible permanent
gear reducer seal damage.
4
31
2
1
2
3

Dorner Mfg. Corp. 12 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Preventive Maintenance and Adjustment
Motor Replacement
Single Phase Motor
1. For single phase motor, unplug power cord from outlet.
Three Phase Motor
1. Loosen terminal box screws (Figure 18, item 1) and
remove cover (Figure 18, item 2).
Figure 18
Figure 18
2. Record wire colors on terminals 1, 2 and 3. Loosen wire
nuts and remove wires 1, 2 and 3.
3. Loosen cord grip and remove cord.
All Models
1. Remove four (4) screws (Figure 19, item 1). Detach
motor (Figure 19, item 2) from gear reducer (Figure
19, item 3). Retain motor output shaft key (Figure
19, item 4).
Figure 19
Figure 19
2. With key (Figure 19, item 4) in keyway, slide motor
(Figure 19, item 2) and gear reducer (Figure
19, item 3) together, noting where position of switch
(Figure 19, item 5) will be during installation on
conveyor.
3. Install screws (Figure 19, item 1) and tighten to 60 in-
lb (7 Nm).
Replace Wiring
• For a single phase motor, reverse step 1 in “Single Phase
Motor” on page 12.
• For a three phase or VFD variable speed motor, reverse
step 2 in “Three Phase Motor” on page 12.
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
A
DANGER
Hazardous voltage will cause severe injury or
death.
LOCK OUT POWER BEFORE WIRING.
2
1
1
IMPORTANT
Be extremely careful when coupling motor to
gear reducer. Avoid misalignment and forcing
the connection causing possible permanent
gear reducer seal damage.
325
4
1

851-733 Rev. E 13 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Notes

Dorner Mfg. Corp. 14 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Service Parts
2200 Series Side Mount Drive Package
NOTE
For replacement parts other than those shown in this section, contact an authorized Dorner Service Center
or the factory. Key Service Parts and Kits are identified by the Performance Parts Kits logo . Dorner
recommends keeping these parts on hand.
1
35
3
5
18
13
20
15
14
4
19
16
2
8
11
7
7
12
6
10
9
17

851-733 Rev. E 15 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Service Parts
Item Part Number Description
1 807-1143 3-Jaw Spider
2 807-1169 Quick Release Pin
3 807-1566 3 Jaw Coupling
4 980416M Square Key, 4 mm x 16 mm (for 42CZ
and 56 C Face Gearmotors)
5 202359 Long Side Drive Guard (x2)
206856 Long Side Drive Guard (x2)
(for SEW Gearmotors)
6 202454 Drive Plate
7 301092 Short Side Drive Guard (x2)
8 301094 Mounting Ring
201755 Mounting Ring (for SEW Gearmotors)
9 920608M Socket Head Screw, M6-1.00 x 8 mm
(for SEW Gearmotors)
10 920612MF Flanged Socket Head Screw,
M6-1.00 x 12 mm
11 920630M Socket Head Screw, M6-1.00 x 30 mm
12 920670M Socket Head Screw, M6-1.00 x 70 mm
920680M Socket Head Screw, M6-1.00 x 80 mm
(for SEW Gearmotors)
13 807-2059 Cover (for 42CZ C Face Gearmotors)
807-2016 Cover (for 56 C Face Gearmotors)
14 912-084 Square Key, 0.188 x 1.50 (for 42CZ
and 56 C Face Gearmotors)
980428M Square Key, 4 mm x 28 mm (for SEW
Gearmotors)
15 202273 Output Shaft
(for 42CZ C Face Gearmotors)
350121 Output Shaft
(for 56 C Face Gearmotors)
201677 Output Shaft (for SEW Gearmotors)
16 400026 Spacer Ring (for 42CZ C Face
Gearmotors)
350115 Adapter Ring (for 56 C Face
Gearmotors)
201755 Adapter Ring (for SEW Gearmotors)
17 605280P Washer
(for 42CZ C Face Gearmotors)
18 920612M Socket Head Screw, M6-1.00 x 12 mm
19 920620M Socket Head Screw, M6-1.00 x 20 mm
(for 56 C Face and SEW Gearmotors)
20 920893M Low Head Cap Screw, M8-1.25 x 16
mm (for 42CZ C Face Gearmotors)
931020M Flat Head Screw, M10-0.50 x 20 mm
(for 56 C Face Gearmotors)
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]

Dorner Mfg. Corp. 16 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Service Parts
2700 Series Side Mount Drive Package
6
7
4
5
4
20 16
21
15
19
22
23
17
8
3
12
2
2
13 1
10 9
18
14
11

851-733 Rev. E 17 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Service Parts
Item Part Number Description
1 208428 Drive Plate
2 301092 Short Side Drive Guard (x2)
3 301094 Mounting Ring
201722 Mounting Ring (for SEW Gearmotors)
4 301075-00508-M Long Side Drive Guard (x2)
(for 42CZ C Face Gearmotors)
301075-00496-M Long Side Drive Guard (x2)
(for 56 C Face and IEC Gearmotors)
301075-00446-M Long Side Drive Guard (x2)
(for SEW Gearmotors)
5 208496 3 Jaw Coupling
6 807-1143 3 Jaw Spider
7 807-1566 3 Jaw Coupling
8 807-1169 Quick Release Pin
9 807-2092 Lock Washer
10 920616M Socket Head Cap Screw, M6-1.00 x 16 mm
11 920625M Socket Head Cap Screw, M6-1.00 x 25 mm
12 920630M Socket Head Cap Screw, M6-1.00 x 30 mm
13 920670M Socket Head Cap Screw, M6-1.00 x 70 mm
(for 42CZ C Face Gearmotors)
920665M Socket Head Cap Screw, M6-1.00 x 65 mm
(for 56 C Face and IEC Gearmotors)
920660M Socket Head Cap Screw, M6-1.00 x 60 mm
(for SEW Gearmotors)
14 202270-00043 Adapter (for 42CZ C Face Gearmotors)
15 202273 Output Shaft (for 42CZ C Face
Gearmotors)
350121 Output Shaft (for IEC Gearmotors)
350135 Output Shaft (for 56 C Face Gearmotors)
201677 Output Shaft (for SEW Gearmotors)
16 208241 Cover Plate (for 42CZ C Face Gearmotors)
807-2016 Cover (for 56 C Face and IEC Gearmotors)
17 400026 Spacer Ring (for 42CZ C Face
Gearmotors)
350115 Spacer Ring (for 56 C Face and IEC
Gearmotors)
18 605280P Washer (for 42 CZ C Face Gearmotors)
19 912-084 Square Key, 0.188 x 1.50 (for 42CZ and 56
C Face Gearmotors)
980428M Square Key, 4 mm x 28 mm (for IEC
Gearmotors)
20 950620M Low Head Cap Screw, M6-1.00 x 20 mm
(for 42CZ C Face Gearmotors)
920612M Socket Head Cap Screw, M6-1.00 x 12 mm
(for 56 C Face, IEC and SEW Gearmotors)
21 950816M Low Head Cap Screw, M8-1.25 x 16 mm
(for 42CZ C Face Gearmotors)
931020M Flat Head Screw, M10-1.50 x 20 mm (for
56 C Face and IEC Gearmotors)
22 980416M Square Key, 4 mm x 16 mm (for 42CZ C
Face, 56 C Face and IEC Gearmotors)
23 920620M Socket Head Cap Screw, M6-1.00 x 20 mm
(for 56 C Face and IEC Gearmotors)
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
customerser[email protected]

Dorner Mfg. Corp. 18 851-733 Rev. E
2200 and 2700 Series Side Mount Drive Package
Service Parts
U.S. Version Gearmotors
Item Part No. Part Description
1 62MES411FN Motor, 0.25 hp (0.19 Kw), 115 Volts, 60
Hz, 1 Phase
62MHS423FN Motor, 0.38 hp (0.28 Kw), 208-230/460
Volts, 60 Hz, 3 Phase
62MES423EN Motor, 0.38 hp (0.28 Kw), 208-230/460
Volts, 60 Hz, 3 Phase, Variable
Frequency
32MS423EI* Motor, 0.25 hp (0.19 Kw), 230/460 Volts,
60 Hz, 3 Phase, Variable Frequency/
Indexing
62MEH411FN Motor, 0.50 hp (0.37 Kw), 115 Volts, 60
Hz, 1 Phase
32MES423FN Motor, 0.50 hp (0.37 Kw), 208-230/460
Volts, 60 Hz, 3 Phase
32MES423EN Motor, 0.50 hp (0.37 Kw), 208-230/460
Volts, 60 Hz, 3 Phase, Variable
Frequency
32MES223EN Motor, 0.75 hp (0.56 Kw), 208-230/460
Volts, 60 Hz, 3 Phase, Variable
Frequency
826-805 Motor, 0.50 hp (0.37 Kw), 332/575 Volts,
60 Hz, 3 Phase
1
2
2 32M005EL Gear Reducer, 5:1, 42 CZ
32M010EL Gear Reducer, 10:1, 42 CZ
32M020EL Gear Reducer, 20:1, 42 CZ
32M040EL Gear Reducer, 40:1, 42 CZ
32M060EL Gear Reducer, 60:1, 42 CZ
32M005ES Gear Reducer, 5:1, 56C (for motors with
part numbers ending with EI or EN only)
32M010ES Gear Reducer, 10:1, 56C (for motors
with part numbers ending with EI or EN
only)
32M020ES Gear Reducer, 20:1, 56C (for motors
with part numbers ending with EI or EN
only)
32M040ES Gear Reducer, 40:1, 56C (for motors
with part numbers ending with EI or EN
only)
32M060ES Gear Reducer, 60:1, 56C (for motors
with part numbers ending with EI or EN
only)
820-533 Gear Reducer, 5:1, 56C, (for 575 Volts
Motor)
820-538 Gear Reducer, 10:1, 56C, (for 575 Volts
Motor)
820-539 Gear Reducer, 20:1, 56C, (for 575 Volts
Motor)
820-540 Gear Reducer, 40:1, 56C, (for 575 Volts
Motor)
820-541 Gear Reducer, 60:1, 56C, (for 575 Volts
Motor)
*This motor is rated at 1/2 hp when running as a fixed speed motor
at 60 hz or when used as an indexing motor. When used as a
variable speed motor, the HP rating is reduced to 1/4 hp.
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]
Item Part No. Part Description

851-733 Rev. E 19 Dorner Mfg. Corp.
2200 and 2700 Series Side Mount Drive Package
Service Parts
CE Version Gearmotors SEW Gearmotors
Item Part No. Part Description
1 62ZHS421FN Motor, 0.19 Kw, 230 Volts, 1400 RPM,
50 Hz, 1-Phase
62ZHS423EN Motor, 0.19 Kw, 230/400 Volts, 1400
RPM, 50 Hz, 3-Phase
2 62Z005ES Gear Reducer, 5:1, 63 B5
62Z010ES Gear Reducer, 10:1, 63 B5
62Z020ES Gear Reducer, 20:1, 63 B5
62Z040ES Gear Reducer, 40:1, 63 B5
62Z060ES Gear Reducer, 60:1, 63 B5
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]
1
2
Item Part No. Part Description
1 22M039WS423EN Gearmotor, 0.25 Hp (0.19 Kw),
230/460 Volts, 60 Hz, 39:1
22M017WS423EN Gearmotor, 0.33 Hp (0.25 Kw),
230/460 Volts, 60 Hz, 16.5:1
22M008WS423EN Gearmotor, 0.50 Hp (0.37 Kw),
230/460 Volts, 60 Hz, 8.2:1
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]
1

851-733 Rev. E Printed in U.S.A.
Return Policy
Returns must have prior written factory authorization or they will not be accepted. Items that are returned to Dorner without authorization will not
be credited nor returned to the original sender. When calling for authorization, please have the following information ready for the Dorner factory
representative or your local distributor:
1. Name and address of customer.
2. Dorner part number(s) of item(s) being returned.
3. Reason for return.
4. Customer's original order number used when ordering the item(s).
5. Dorner or distributor invoice number. Include part serial number if available.
A representative will discuss action to be taken on the returned items and provide a Returned Materials Authorization (RMA) number for
reference. RMA will automatically close 30 days after being issued. To get credit, items must be new and undamaged. There will be a return
charge on all items returned for credit, where Dorner was not at fault. It is the customer’s responsibility to prevent damage during return
shipping. Damaged or modified items will not be accepted. The customer is responsible for return freight.
Returns will not be accepted after 60 days from original invoice date. The return charge covers inspection, cleaning, disassembly, disposal and
reissuing of components to inventory. If a replacement is needed prior to evaluation of returned item, a purchase order must be issued. Credit (if
any) is issued only after return and evaluation is complete.
Dorner has representatives throughout the world. Contact Dorner for the name of your local representative. Our Customer Service Team will
gladly help with your questions on Dorner products.
For a copy of Dorner's Warranty, contact Dorner, an authorized sales channel or visit our website: www.dorner.com.
For replacement parts, contact an authorized Dorner Service Center or the factory.
Product Type
Standard Products Engineered to
order parts
Product Line Conveyors Gearmotors
& Mounting
Packages
Support
Stands
Accessories Spare Parts
(non-belt)
Spare Belts
- Standard
Flat Fabric
Spare Belts -
Cleated &
Spec. Fabric
Spare Belts -
Plastic Chain
All equipment
and parts
1100 Series
30% return fee for all products except:
50% return fee for conveyors with modular belt,
cleated belt or speciality belts
All Electrical items are assigned original manufacturers return policy.
non-returnable case-by-case
2200 Series
3200 Series
Pallet Systems
FlexMove/SmartFlex
GAL Series
All Electrical
7100 Series
50% return fee for all products
7200/7300 Series
AquaGard 7350
Series Version 2
GES Series
AquaGard
7350/7360 Series non-returnable
AquaPruf Series
