Dorner 2200 series User manual

851-716 Rev. C
For other service manuals visit our website at:
www.dornerconveyors.com/manuals-literature
Record Conveyor Serial Number Here
2200 and 2700 Series Bottom
Mount Drive Package for
SEW 60 Hz Gearmotors
Installation, Maintenance & Parts Manual

Dorner Mfg. Corp. 2 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Table of Contents
Introduction ......................................................................... 2
Warnings −General Safety ................................................. 3
Product Description ............................................................. 4
Specifications ...................................................................... 4
Gearmotor Mounting Package ........................................ 4
Table 1: Gearmotor Specifications .................................. 4
Table 2: Belt Speeds for Fixed Speed SEW Gearmotors 5
Table 3: Belt Speeds for Variable Speed
SEW Gearmotors ............................................................ 6
Fastener Torque Specifications........................................ 7
Installation ........................................................................... 8
Required Tools................................................................. 8
Mounting.......................................................................... 8
Motor Wiring ................................................................. 11
Preventive Maintenance and Adjustment .......................... 12
Required Tools .............................................................. 12
Timing Belt Tensioning.................................................. 12
Timing Belt Replacement .............................................. 13
Drive or Driven Pulley Replacement ............................ 14
Gearmotor Replacement................................................. 14
Service Parts....................................................................... 16
2200 Series Bottom Mount Drive Package
for SEW Gearmotors ..................................................... 16
2700 Series Bottom Mount Drive Package
for SEW Gearmotors ...................................................... 17
Gearmotors .................................................................... 18
Notes .................................................................................. 19
Return Policy...................................................................... 20
Introduction
Upon receipt of shipment:
• Compare shipment with packing slip. Contact factory
regarding discrepancies.
• Inspect packages for shipping damage. Contact carrier
regarding damage.
• Accessories may be shipped loose. See accessory instruc-
tions for installation.
Dorner 2200 Series conveyors are covered by patent number
5,174,435, 6,109,427, 6,298,981, 6,422,382, 6,685,009 and
corresponding patents and patent applications in other
countries.
Dorner’s Limited Warranty applies.
Dorner reserves the right to make changes at any time
without notice or obligation.
Dorner has convenient, pre−configured kits of Key Service
Parts for all conveyor products. These time saving kits are
easy to order, designed for fast installation, and guarantee
you will have what you need when you need it. Key Parts
and Kits are marked in the Service Parts section of this
manual with the Performance Parts Kits logo .
IMPORTANT
Some illustrations may show guards
removed. Do NOT operate equipment without
guards.

851-716 Rev. C 3 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Warnings −General Safety
A
WARNING
The safety alert symbol, black triangle with
white exclamation, is used to alert you to
potential personal injury hazards.
A
DANGER
Climbing, sitting, walking or riding on
conveyor will cause severe injury. KEEP OFF
CONVEYORS.
A
DANGER
Do NOT OPERATE CONVEYORS IN AN
EXPLOSIVE ENVIRONMENT.
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
A
WARNING
Gearmotors may be HOT.
DO NOT TOUCH Gearmotors.
A
WARNING
Exposed moving parts can cause severe
injury.
REPLACE ALL GUARDS BEFORE RUNNING
CONVEYOR.
A
WARNING
Dorner cannot control the physical
installation and application of conveyors.
Taking protective measures is the
responsibility of the user.
When conveyors are used in conjunction
with other equipment or as part of a multiple
conveyor system, CHECK FOR POTENTIAL
PINCH POINTS and other mechanical
hazards before system start-up.

Dorner Mfg. Corp. 4 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Product Description
Refer to Figure 1 for typical components. Figure 1
Figure 1
Specifications
Gearmotor Mounting Package
* See Engineering manual for details.
Table 1: Gearmotor Specifications
1Conveyor
2 Mounting Bracket
3 Gearmotor
4 Timing Belt Tensioner
5Cover
6 Timing Belt
7DrivePulley
8 Driven Pulley
1
5
2
4
8
3
7
6
2 M B S WW A 32 32
2W
Driven Pulley
Drive Pulley
Belt Type ( - = flat belt, C = cleated belt)
Mount Position = A, B, C or D
(see detail to the right)
Conveyor Width Reference*
Gearmotor Type = Standard Load, Industrial
Output Shaft Type = SEW
Mount Style = Bottom Mount
Language Code = U.S. English
22 = 2200 Series Conveyors
2L = 2700 Series Conveyors
DC
B
A
Three Phase VFD Variable Speed
Output Power 0.25 Hp (0.19 Kw) 0.33 hp (0.25 kW) 0.5 Hp(0.37 kW) 0.25 Hp (0.19 Kw) 0.33 hp (0.25 kW) 0.5 Hp(0.37 kW)
Input Voltage 230/460 230/460
Input
Frequency
60 Hz 10 to 60 Hz
Input Current 0.89/0.44 1.24/0.62 1.84/0.92 0.89/0.44 1.24/0.62 1.84/0.92
RPM 46 109 219 8 to 46 18 to 109 37 to 219
Ratio 39:1 16.5:1 8.2:1 39:1 16.5:1 8.2:1
Motor Frame IEC71 IEC71
Motor Type IP54 Totally Enclosed Fan Cooled IP54 Totally Enclosed Fan Cooled

851-716 Rev. C 5 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Specifications
Table 2: Belt Speeds for Fixed Speed SEW Gearmotors
Part Number RPM In-lb N-m Ft/min M/min Drive Pulley Driven Pulley
22M039WS423EN 46 203 22.9 11.1 3.4 22 32
22M039WS423EN 46 203 22.9 14.2 4.3 28 32
22M039WS423EN 46 203 22.9 16.2 4.9 28 28
22M039WS423EN 46 203 22.9 18.5 5.6 32 28
22M039WS423EN 46 203 22.9 22.3 6.8 44 32
22M039WS423EN 46 203 22.9 23.6 7.2 32 22
22M039WS423EN 46 203 22.9 24.3 7.4 48 32
22M039WS423EN 46 203 22.9 25.5 7.8 44 28
22M017WS423EN 109 159 18.0 26.3 8.0 22 32
22M039WS423EN 46 203 22.9 27.8 8.5 48 28
22M039WS423EN 46 203 22.9 30.4 9.3 60 32
22M039WS423EN 46 203 22.9 32.4 9.9 44 22
22M017WS423EN 109 159 18.0 33.4 10.2 28 32
22M039WS423EN 46 203 22.9 34.7 10.6 60 28
22M039WS423EN 46 203 22.9 35.4 10.8 48 22
22M017WS423EN 109 159 18.0 38.2 11.6 28 28
22M017WS423EN 109 159 18.0 43.7 13.3 32 28
22M039WS423EN 46 203 22.9 44.2 13.5 60 22
22M017WS423EN 109 159 18.0 52.5 16.0 44 32
22M008WS423EN 219 132 14.9 52.8 16.1 22 32
22M017WS423EN 109 159 18.0 55.6 16.9 32 22
22M017WS423EN 109 159 18.0 57.3 17.5 48 32
22M017WS423EN 109 159 18.0 60.0 18.3 44 28
22M017WS423EN 109 159 18.0 65.5 20.0 48 28
22M008WS423EN 219 132 14.9 67.2 20.5 28 32
22M017WS423EN 109 159 18.0 71.6 21.8 60 32
22M017WS423EN 109 159 18.0 76.4 23.3 44 22
22M008WS423EN 219 132 14.9 76.8 23.4 28 28
22M017WS423EN 109 159 18.0 81.9 25.0 60 28
22M017WS423EN 109 159 18.0 83.4 25.4 48 22
22M008WS423EN 219 132 14.9 87.8 26.8 32 28
22M017WS423EN 109 159 18.0 104.2 31.8 60 22
22M008WS423EN 219 132 14.9 105.6 32.2 44 32
22M008WS423EN 219 132 14.9 111.7 34.1 32 22
22M008WS423EN 219 132 14.9 115.2 35.1 48 32
22M008WS423EN 219 132 14.9 120.7 36.8 44 28
22M008WS423EN 219 132 14.9 131.7 40.1 48 28
22M008WS423EN 219 132 14.9 144.0 43.9 60 32
22M008WS423EN 219 132 14.9 153.6 46.8 44 22
22M008WS423EN 219 132 14.9 164.6 50.2 60 28
22M008WS423EN 219 132 14.9 167.6 51.1 48 22
22M008WS423EN 219 132 14.9 209.5 63.8 60 22

Dorner Mfg. Corp. 6 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Specifications
Table 3: Belt Speeds for Variable Speed SEW Gearmotors
Part Number RPM In-lb N-m Ft/min (max) Ft/min (min) M/min (max) M/min (min) Drive
Pulley
Driven
Pulley
22M039WS423EN 46 203 22.9 11.1 1.9 3.4 0.6 22 32
22M039WS423EN 46 203 22.9 14.2 2.4 4.3 0.7 28 32
22M039WS423EN 46 203 22.9 16.2 2.7 4.9 0.8 28 28
22M039WS423EN 46 203 22.9 18.5 3.1 5.6 0.9 32 28
22M039WS423EN 46 203 22.9 22.3 3.7 6.8 1.1 44 32
22M039WS423EN 46 203 22.9 23.6 3.9 7.2 1.2 32 22
22M039WS423EN 46 203 22.9 24.3 4.1 7.4 1.2 48 32
22M039WS423EN 46 203 22.9 25.5 4.3 7.8 1.3 44 28
22M017WS423EN 109 159 18.0 26.3 4.4 8.0 1.3 22 32
22M039WS423EN 46 203 22.9 27.8 4.6 8.5 1.4 48 28
22M039WS423EN 46 203 22.9 30.4 5.1 9.3 1.5 60 32
22M039WS423EN 46 203 22.9 32.4 5.4 9.9 1.6 44 22
22M017WS423EN 109 159 18.0 33.4 5.6 10.2 1.7 28 32
22M039WS423EN 46 203 22.9 34.7 5.8 10.6 1.8 60 28
22M039WS423EN 46 203 22.9 35.4 5.9 10.8 1.8 48 22
22M017WS423EN 109 159 18.0 38.2 6.4 11.6 1.9 28 28
22M017WS423EN 109 159 18.0 43.7 7.3 13.3 2.2 32 28
22M039WS423EN 46 203 22.9 44.2 7.4 13.5 2.2 60 22
22M017WS423EN 109 159 18.0 52.5 8.8 16.0 2.7 44 32
22M008WS423EN 219 132 14.9 52.8 8.8 16.1 2.7 22 32
22M017WS423EN 109 159 18.0 55.6 9.3 16.9 2.8 32 22
22M017WS423EN 109 159 18.0 57.3 9.6 17.5 2.9 48 32
22M017WS423EN 109 159 18.0 60.0 10.0 18.3 3.1 44 28
22M017WS423EN 109 159 18.0 65.5 10.9 20.0 3.3 48 28
22M008WS423EN 219 132 14.9 67.2 11.2 20.5 3.4 28 32
22M017WS423EN 109 159 18.0 71.6 12.0 21.8 3.6 60 32
22M017WS423EN 109 159 18.0 76.4 12.8 23.3 3.9 44 22
22M008WS423EN 219 132 14.9 76.8 12.8 23.4 3.9 28 28
22M017WS423EN 109 159 18.0 81.9 13.7 25.0 4.2 60 28
22M017WS423EN 109 159 18.0 83.4 13.9 25.4 4.2 48 22
22M008WS423EN 219 132 14.9 87.8 14.7 26.8 4.5 32 28
22M017WS423EN 109 159 18.0 104.2 17.4 31.8 5.3 60 22
22M008WS423EN 219 132 14.9 105.6 17.6 32.2 5.4 44 32
22M008WS423EN 219 132 14.9 111.7 18.7 34.1 5.7 32 22
22M008WS423EN 219 132 14.9 115.2 19.2 35.1 5.9 48 32
22M008WS423EN 219 132 14.9 120.7 20.2 36.8 6.1 44 28
22M008WS423EN 219 132 14.9 131.7 22.0 40.1 6.7 48 28
22M008WS423EN 219 132 14.9 144.0 24.0 43.9 7.3 60 32
22M008WS423EN 219 132 14.9 153.6 25.7 46.8 7.8 44 22
22M008WS423EN 219 132 14.9 164.6 27.5 50.2 8.4 60 28
22M008WS423EN 219 132 14.9 167.6 28.0 51.1 8.5 48 22
22M008WS423EN 219 132 14.9 209.5 35.0 63.8 10.7 60 22
NOTE
For belt speed other than those listed, contact
factory for details.

851-716 Rev. C 7 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Specifications
Fastener Torque Specifications
Flat Head Socket Head Button/Low Head Set Screw
Size Torque Size Torque Size Torque Size Torque
M4 x 0.7 2.5 mm 3.4 Nm
(30 in lbs)
3 mm 5.9 Nm
(52 in lbs)
2.5 mm 2.9 Nm
(26 in lbs)
2 mm 2.1 Nm
(19 in lbs)
M5 x 0.8 3 mm 6.9 Nm
(61 in lbs)
4 mm 12.0 Nm
(106 in lbs)
3 mm 5.9 Nm
(52 in lbs)
2.5 mm 4.7 Nm
(42 in lbs)
M6 x 1.0 4 mm 12.0 Nm
(106 in lbs)
5 mm 20.3 Nm
(180 in lbs)
4 mm 10.0 Nm
(89 in lbs)
3 mm 7.7 Nm
(68 in lbs)
M8 x 1.25 5 mm 28.0 Nm
(248 in lbs)
6 mm 48.8 Nm
(432 in lbs)
5 mm 24.0 Nm
(212 in lbs)
4 mm 17.8 Nm
(158 in lbs)
M10 x 1.5 6 mm 56.0 Nm
(496 in lbs)
8 mm 97.5 Nm
(863 in lbs)
6 mm 48.0 Nm
(425 in lbs)
5 mm 35.0 Nm
(310 in lbs)

Dorner Mfg. Corp. 8 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Installation
Required Tools
• Hex key wrenches:
3/32", 3 mm, 5 mm, 6 mm
• Socket wrenches:
8 mm, 11 mm
• Torque wrench
• Straight edge
Mounting
Figure 2
Figure 2
Figure 3
Figure 3
Installation Component List:
1. Typical components (Figure 4).
Figure 4
Figure 4
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
A
WARNING
For Cleated Belt Conveyors, Gearmotors
must be mounted as shown in Figure 3.
Failure to do so creates pinch points which
can cause severe injury.
NOTE
Gearmotor position on Flat Belt conveyors
shown in Figure 2. Gearmotor position on
Cleated Belt conveyors shown in Figure 3.
Flat Belt Conveyor
1 Bottom Mount Assembly
2DrivePulley
3Cover
4 Socket Head Screws (4x)
5 Driven Pulley
6 Socket Head Screws (2x)
7 Timing Belt
NOTE
Flat belt mounting package shown above
(Figure 4), cleated belt mounting package
similar.
Cleated Belt Conveyor
1
2
4
3
6
57

851-716 Rev. C 9 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Installation
Figure 5
Figure 5
2. If required, change gearmotor position by removing four
(4) screws (Figure 6, item 1). Rotate gearmotor to other
position and replace screws (Figure 6, item 1). Tighten
to 103 in-lb (12 N−m).
Figure 6
Figure 6
3. Locate drive output shaft (Figure 7, item 1) and remove
two (2) screws (Figure 7, item 2).
Figure 7
Figure 7
4. Attach mounting assembly (Figure 8, item 1) with
screws (Figure 8, item 2). Tighten to 80 in-lb (9 N−m).
Figure 8
Figure 8
5. Install key (Figure 8, item 3).
6. Wrap timing belt (Figure 9, item 1) around driven
pulley (Figure 9, item 2) and drive pulley (Figure
9, item 3). Install driven pulley (Figure 9, item 2) onto
conveyor shaft.
Figure 9
Figure 9
NOTE
Gearmotor may be operated in positions 1, 3
or 4 (Figure 5). Dependent on conveyor belt
speed and gearmotor type, position 4 may
require a vibration dampening bracket.
1
4
3
1
1
12
A
WARNING
Drive shaft keyway may be sharp.
HANDLE WITH CARE.
1
2
3
1
2
3

Dorner Mfg. Corp. 10 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Installation
7. Remove cam bearing and spacer (Figure 10, item 1).
Figure 10
Figure 10
8. Place the cam bearing and spacer (Figure 11, item 1)
next to the driven pulley (Figure 11, item 2). Ensure the
flanges of the driven pulley are aligned with the cam
bearing. Tighten driven pulley set screws (Figure
11, item 3). This will allow for proper belt alignment
while conveyor is in use. Replace cam bearing and
spacer.
Figure 11
Figure 11
9. Depending on conveyor belt travel (Figure 12, item 1),
or (Figure 12, item 2), locate timing belt tensioner
assembly (Figure 12, item 3) as shown. Tension timing
belt to obtain 0.125¨ (3 mm) deflection for 1.0 lb (456
grams) of force at timing belt mid-point (Figure
12, item 4). Tighten tensioner screw to 103 in-lb (12 N−
m).
Figure 12
Figure 12
10. Install cover (Figure 13, item 1) with four (4) screws
(Figure 13, item 2). Tighten to 35 in-lb (4 N−m).
Figure 13
Figure 13
1
1
23
3
4
4
1
2
1
2

851-716 Rev. C 11 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Installation
Motor Wiring
1. Remove cover (Figure 14, item 1).
Figure 14
Figure 14
2. To determine wiring configuration, refer to the inside of
the motor cover (Figure 15).
Figure 15
Figure 15
3. Install cord grip and power cord (Figure 16, item 1)
mount to terminal box as required.
Figure 16
Figure 16
4. Connect wires.
5. Close cover.
A
DANGER
Hazardous voltage will cause severe injury or
death.
LOCK OUT POWER BEFORE WIRING.
NOTE
Lug terminals are recommended for wiring
connections.
1
NOTE
Image of wiring diagram for reference only.
See inside motor cover for motor specific
instructions.
1

Dorner Mfg. Corp. 12 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Preventive Maintenance and Adjustment
Required Tools
• Hex key wrenches:
3/32”, 3 mm, 5 mm, 6 mm
• Socket wrenches:
8 mm, 11 mm
• Torque wrench
• Straight edge
Timing Belt Tensioning
1. Remove four (4) screws (Figure 17, item 1) and
remove cover (Figure 17, item 2).
Figure 17
Figure 17
2. Loosen tensioner (Figure 18, item 1).
Figure 18
Figure 18
3. Depending on conveyor belt travel (Figure 19, item 1),
or (Figure 19, item 2), locate timing belt tensioner
assembly (Figure 19, item 3) as shown. Tension timing
belt to obtain 0.125¨ (3 mm) deflection for 1.0 lb (456
grams) of force at timing belt mid-point (Figure
19, item 4). Tighten tensioner screw to 103 in-lb (12 N−
m).
Figure 19
Figure 19
4. Install cover (Figure 17, item 2) with four (4) screws
(Figure 17, item 1).Tighten to 35 in-lb (4 N−m).
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
2
1
1
3
4
4
1
2

851-716 Rev. C 13 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Preventive Maintenance and Adjustment
Timing Belt Replacement
1. Remove four (4) screws (Figure 20, item 1) and
remove cover (Figure 20, item 2).
Figure 20
Figure 20
2. Loosen tensioner (Figure 21, item 1).
Figure 21
Figure 21
3. Remove timing belt (Figure 22, item 1).
Figure 22
Figure 22
4. Install new timing belt.
5. Depending on conveyor belt travel (Figure 23, item 1),
or (Figure 23, item 2), locate timing belt tensioner
assembly (Figure 23, item 3) as shown. Tension timing
belt to obtain 0.125¨ (3 mm) deflection for 1.0 lb (456
grams) of force at timing belt mid-point (Figure
23, item 4). Tighten tensioner screw to 103 in-lb (12 N−
m).
Figure 23
Figure 23
6. Install cover (Figure 20, item 2) with four (4) screws
(Figure 20, item 1). Tighten to 35 in-lb (4 N−m).
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
2
1
1
NOTE
If timing belt does not slide over pulley flange,
loosen driven pulley set screws (Figure
22, item 2) and remove pulley with belt. For
re-installation, see steps 6,7 and 8 on page 9.
1
2
3
4
4
1
2

Dorner Mfg. Corp. 14 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Preventive Maintenance and Adjustment
Drive or Driven Pulley Replacement
1. Complete steps 1 through 3 of “Timing Belt
Replacement” section on page 13.
2. Loosen set screws and remove drive or driven pulley.
3. Complete steps 6 through 10 of “Installation” section on
page 9.
Gearmotor Replacement
1. Disconnect power. Remove terminal box cover and
wires.
2. Remove four (4) screws (Figure 24, item 1) and
remove cover (Figure 24, item 2).
Figure 24
Figure 24
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
NOTE
If drive pulley (Figure 22, item 3) is replaced,
wrap timing belt around drive pulley and
complete step 3.
A
WARNING
Exposed moving parts can cause severe
injury.
LOCK OUT POWER before removing guards
or performing maintenance.
A
DANGER
Hazardous voltage will cause severe injury or
death.
LOCK OUT POWER BEFORE WIRING.
2
1

851-716 Rev. C 15 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Preventive Maintenance and Adjustment
3. Loosen tensioner (Figure 25, item 1) and remove
timing belt (Figure 25, item 2).
Figure 25
Figure 25
4. Loosen set screws and remove drive pulley (Figure
26, item 1).
Figure 26
Figure 26
5. Remove four (4) mounting screws (Figure 27, item 1)
and remove gearmotor.
Figure 27
Figure 27
6. Remove shaft mounting bolt (Figure 28, item 1) and
remove shaft.
Figure 28
Figure 28
7. Repeat in reverse order to install new gearmotor.
1
2
1
1
1

Dorner Mfg. Corp. 16 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Service Parts
2200 Series Bottom Mount Drive Package for SEW Gearmotors
NOTE
For replacement parts other than those shown in this section, contact an authorized Dorner Service Center
or the factory. Key Service Parts and Kits are identified by the Performance Parts Kits logo . Dorner
recommends keeping these parts on hand.
4
1
2
3
5
6
7
8
9
10
11
12
14
13
15
17
16
Item Part Number Description
1 802-046 Bearing
2 201559 Output Shaft
3 450445 Spacer
4 202390M Nut Follower
5 450375 Cam Mounting Cover Bracket
6 450376M Drive Guard
7 450443M Mounting Plate
8 450365MP Driven Pulley, 19 Tooth
450366MP Driven Pulley, 22 Tooth
450367MP Driven Pulley, 28 Tooth
450368MP Driven Pulley, 32 Tooth
9 450365MP Drive Pulley, 19 Tooth
450366MP Drive Pulley, 22 Tooth
450367MP Drive Pulley, 28 Tooth
450368MP Drive Pulley, 32 Tooth
450369MP Drive Pulley, 44 Tooth
450370MP Drive Pulley, 48 Tooth
450371MP Drive Pulley, 60 Tooth
10 814-104 Timing Belt, 15 mm W x 450 mm L
814-105 Timing Belt, 15 mm W x 460 mm L
814-065 Timing Belt, 15 mm W x 475 mm L
814-112 Timing Belt, 15 mm W x 495 mm L
814-101 Timing Belt, 15 mm W x 500 mm L
814-108 Timing Belt, 15 mm W x 520 mm L
814-064 Timing Belt, 15 mm W x 535 mm L
814-099 Timing Belt, 15 mm W x 565 mm L
11 920481M Flange Socket Head Screw, M4-0.7 x 8 mm
12 950512M Low Head Cap Screw, M5-0.80 x 12 mm
13 920625M Socket Head Screw, M6-1.00 x 25 mm
14 950616M Low Head Cap Screw, M6-1.00 x 16 mm
15 910840M Button Head Screw, M8-1.25 x 40 mm
16 980428M Square Key
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]
Item Part Number Description

851-716 Rev. C 17 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Service Parts
2700 Series Bottom Mount Drive Package for SEW Gearmotors
5
1
23
4
6
7
8
910
11
13
15
14
16
18 17
12
Item Part Number Description
1 802-046 Bearing
2 201559 Output Shaft
3 450445 Spacer
4 202390M Nut Follower
5 450375 Cam Mounting Cover Bracket
6 450376M Drive Guard
7 208337 Mounting Plate
8 450366MP Driven Pulley, 22 Tooth
208488 Driven Pulley, 28 Tooth
208489 Driven Pulley, 32 Tooth
9 450365MP Drive Pulley, 19 Tooth
450366MP Drive Pulley, 22 Tooth
450367MP Drive Pulley, 28 Tooth
450368MP Drive Pulley, 32 Tooth
450369MP Drive Pulley, 44 Tooth
450370MP Drive Pulley, 48 Tooth
10 814-104 Timing Belt, 15 mm W x 450 mm L
814-105 Timing Belt, 15 mm W x 460 mm L
814-065 Timing Belt, 15 mm W x 475 mm L
814-101 Timing Belt, 15 mm W x 500 mm L
814-108 Timing Belt, 15 mm W x 520 mm L
814-064 Timing Belt, 15 mm W x 535 mm L
11 920481M Flange Socket Head Screw, M4-0.70 x 8 mm
12 950512M Low Head Cap Screw, M5-0.80 x 12 mm
13 920625M Socket Head Screw, M6-1.00 x 25 mm
14 950616M Low Head Cap Screw, M6-1.00 x 16 mm
15 920845M Socket Head Screw, M8-1.25 x 45 mm
16 980422M Square Key
17 920616M Socket Head Screw, M6-1.00 x 16 mm
18 807-2092 Washer
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]
Item Part Number Description

Dorner Mfg. Corp. 18 851-716 Rev. C
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Service Parts
Gearmotors
Item Part No. Part Description
1 22M039WS423EN Gearmotor, 0.25 Hp (0.19 Kw),
230/460 Volts, 39:1
22M017WS423EN Gearmotor, 0.33 Hp (0.25 Kw),
230/460 Volts, 16.5:1
22M008WS423EN Gearmotor, 0.50 Hp (0.37 Kw),
230/460 Volts, 8.2:1
Service parts can be obtained through your distributor or directly
from Dorner Mfg. Corp. [phone] or
[e-mail]
1

851-716 Rev. C 19 Dorner Mfg. Corp.
2200 and 2700 Series Bottom Mount Drive Package for SEW 60 Hz Gearmotors
Notes

851-716 Rev. C Printed in U.S.A.
Return Policy
Returns must have prior written factory authorization or they will not be accepted. Items that are returned to Dorner without authorization will not
be credited nor returned to the original sender. When calling for authorization, please have the following information ready for the Dorner factory
representative or your local distributor:
1. Name and address of customer.
2. Dorner part number(s) of item(s) being returned.
3. Reason for return.
4. Customer's original order number used when ordering the item(s).
5. Dorner or distributor invoice number. Include part serial number if available.
A representative will discuss action to be taken on the returned items and provide a Returned Materials Authorization (RMA) number for
reference. RMA will automatically close 30 days after being issued. To get credit, items must be new and undamaged. There will be a return
charge on all items returned for credit, where Dorner was not at fault. It is the customer’s responsibility to prevent damage during return
shipping. Damaged or modified items will not be accepted. The customer is responsible for return freight.
Returns will not be accepted after 60 days from original invoice date. The return charge covers inspection, cleaning, disassembly, disposal and
reissuing of components to inventory. If a replacement is needed prior to evaluation of returned item, a purchase order must be issued. Credit (if
any) is issued only after return and evaluation is complete.
Dorner has representatives throughout the world. Contact Dorner for the name of your local representative. Our Customer Service Team will
gladly help with your questions on Dorner products.
For a copy of Dorner's Warranty, contact Dorner, an authorized sales channel or visit our website: www.dorner.com.
For replacement parts, contact an authorized Dorner Service Center or the factory.
Product Type
Standard Products Engineered to
order parts
Product Line Conveyors Gearmotors
& Mounting
Packages
Support
Stands
Accessories Spare Parts
(non-belt)
Spare Belts
- Standard
Flat Fabric
Spare Belts -
Cleated &
Spec. Fabric
Spare Belts -
Plastic Chain
All equipment
and parts
1100 Series
30% return fee for all products except:
50% return fee for conveyors with modular belt,
cleated belt or speciality belts
All Electrical items are assigned original manufacturers return policy.
non-returnable case-by-case
2200 Series
3200 Series
Pallet Systems
FlexMove/SmartFlex
GAL Series
All Electrical
7100 Series
50% return fee for all products
7200/7300 Series
AquaGard 7350
Series Version 2
GES Series
AquaGard
7350/7360 Series non-returnable
AquaPruf Series
