Doro IP880 DECT User manual

ip880dect
Owners Manual
English

Index
About this User Manual 1
Welcome ����������������������������������������������������������������������������������������������������������� 1
Handset – view 2
Display��������������������������������������������������������������������������������������������������������������� 2
Gateway – view 3
Gateway – rear view������������������������������������������������������������������������������������������ 3
Gateway – front view����������������������������������������������������������������������������������������� 3
Installation 4
Prerequisites ����������������������������������������������������������������������������������������������������� 4
Power ���������������������������������������������������������������������������������������������������������������� 4
Installing the Gateway ��������������������������������������������������������������������������������������� 5
Install and Register the Handset ����������������������������������������������������������������������� 5
Belt clip�������������������������������������������������������������������������������������������������������������� 5
First setup via the handset 6
Set handset language ��������������������������������������������������������������������������������������� 6
Using the Menus and Typing Text and Numbers ���������������������������������������������� 6
Country selection ���������������������������������������������������������������������������������������������� 7
Change the time zone ��������������������������������������������������������������������������������������� 7
Change emergency line settings����������������������������������������������������������������������� 7
Configure VoIP servers and accounts� 8
VoIP Server ������������������������������������������������������������������������������������������������������� 8
SIP Account(s).�������������������������������������������������������������������������������������������������� 8
Change the PIN code �������������������������������������������������������������������������������������� 8
First setup via web-interface 9
Configure using a web browser������������������������������������������������������������������������� 9
Making and answering calls 10
Internet call������������������������������������������������������������������������������������������������������ 10
Landline Calls�������������������������������������������������������������������������������������������������� 11
Caller ID ���������������������������������������������������������������������������������������������������������� 12
During calls ����������������������������������������������������������������������������������������������������� 13
Intercom ���������������������������������������������������������������������������������������������������������� 15
Making conference calls���������������������������������������������������������������������������������� 17
Contacts 18
Groups������������������������������������������������������������������������������������������������������������� 20
Voice Mail 21

Settings 22
Audio Settings 22
Telephony Settings 22
VoIP settings 23
Internet Settings 23
System Settings 24
Firmware update ��������������������������������������������������������������������������������������������� 25
Restore configuration settings������������������������������������������������������������������������� 25
Configuring via web-interface 26
Configure using a web browser����������������������������������������������������������������������� 26
Home��������������������������������������������������������������������������������������������������������������� 27
VoIP Server 1 (or 2)����������������������������������������������������������������������������������������� 27
VoIP Accounts������������������������������������������������������������������������������������������������� 27
Management Settings ������������������������������������������������������������������������������������� 28
NAT/RTP Settings ������������������������������������������������������������������������������������������� 28
IP Settings������������������������������������������������������������������������������������������������������� 29
Pincode Settings ��������������������������������������������������������������������������������������������� 29
Telephony Services����������������������������������������������������������������������������������������� 30
Telephony Settings������������������������������������������������������������������������������������������ 30
Time Settings �������������������������������������������������������������������������������������������������� 31
Debug�������������������������������������������������������������������������������������������������������������� 31
SIP Trace��������������������������������������������������������������������������������������������������������� 31
Provisioning 32
System Requirements ������������������������������������������������������������������������������������� 32
Setting up the Network������������������������������������������������������������������������������������ 32
Setting up the Boot/Update Server ����������������������������������������������������������������� 32
Creating Configuration Files���������������������������������������������������������������������������� 33
Changing the Configuration File location �������������������������������������������������������� 35
Provisioning����������������������������������������������������������������������������������������������������� 36
Troubleshooting 37
Other 39
Specific Absorption Rate (SAR) ���������������������������������������������������������������������� 39
Declaration of conformity �������������������������������������������������������������������������������� 39
Guarantee ������������������������������������������������������������������������������������������������������� 39

1www.doro.com
About this User Manual
Welcome
Thank you for purchasing the Doro ip880dect. This user manual describes how to install,
congure, and use the phone, enabling you to make Internet calls, landline calls, and receive
on-screen information services.
This user manual consists of a number of sections to guide you through the process of
installing, conguring, and setting up your phone for rst use. These sections are best read
from beginning to end.
In this manual we have used the following abbreviations:
DHCP – Dynamic Host Conguration Protocol
IP – Internet Protocol
LAN – Local-Area Network
NAT – Network Address Translation
SIP – Session Initiation Protocol
STUN – Simple Traversal of UDP through NAT
URL – Uniform Resource Locator
WAN – Wide-Area Network
On the website you can also nd additional information about the phone such as support
contact information. www.doro.com
Have your serial number and MAC address ready when contacting support. You nd the
numbers on the bottom of the gateway/base. For inquiries concerning telephony services,
contact your Internet Telephony Service Provider. For inquiries concerning your broadband
connection, contact your Internet Service Provider (ISP).

2www.doro.com
Handset – view
Display
1)
Black/black - out of range of the gateway
Yellow/black - within range of the gateway, but not ready for Internet calls
Yellow/yellow – within range of the gateway, and ready for Internet calls on primary line.
CALL LOG
for incoming, outgoing
and missed calls
Display
Volume UP/DOWN
Speaker
Line button/R button (Recall)
Keypad
Headset jack
Disconnect ON/OFF
Navigation buttons
OK button 0
LEFT/RIGHT softkey
1�
2�
3�
4�
5�
6�
7�
8�
9�
10�
1
2
3
10
4
5
6
7
8
9
INTERCOM
for communication
between two handsets
MESSAGES
CONTACTS
SETTINGS
BATTERY STATUS
and charging indicator
CONNECTION
STATUS INDICATORS 1)

3www.doro.com
POWER CONNECTION
RESET BUTTON
for activating configuration
changes and enabling
handset registration
Landline
connection port
(POTS/PSTN)
WAN connection port
for Ethernet cable
POWER indicator
indicates power on
I-NET indicator
I-net indicator is flashing during
boot. It indicates that the gateway
has received an IP address
CALL indicator
Call indicator is flashing during
firmware update. Constant light
indicates landline or
Internet call in
progress
VOIP INDICATOR
indicates that the gateway is
connected to the Internet
Telephony Service Provider
Gateway – view
Gateway – rear view
Gateway – front view

4www.doro.com
Installation
Prerequisites
In order to take full advantage of the features of the phone, you need to have the following
in place:
Broadband Internet connection – cable, DSL, or equivalent
Internet Telephony Service Provider subscription – to make Internet calls
Landline telephone subscription – to make ordinary phone calls (optional)
Furthermore, before you start the installation process, make sure that you have the
following close to the gateway:
Wired Ethernet router or broadband modem
Power outlet for the gateway
Telephone wall outlet used for landline telephony (optional)
Note:
The gateway can either be placed on a tabletop or mounted on the wall. If longer cables are
required, you can use ordinary cable extensions. The handset has an indoor signal range
of up to 50 meters (150 feet) from the gateway, and you must place your handset charger
within the signal range. Concrete and metal objects might affect the signal range.
Power
Only use below power supply units for the product.
Product Brand
Name
Model Number Input Power
(VAC)
Output Power
(VDC)
Base KTEC KSLFB1200030W1UV-1 100~240V
50/60Hz 0.15A
12.0V, 300mA
Handset
charger
KTEC KSLFB0500035W1UV-1 100~240V
50/60Hz 0.15A
5.0V, 350mA
Handset
battery
DORO ip880dect Lithium ion
battery 3.7V 650mAH
-- 3.9V nominal
CAUTION: risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions
Changable adapters
Both mains power adapters have
changable plugs
Select the UK or EU plug and seat it
in the adapter top.
Press in gently until you hear a click.
The adapter is now ready for use.
To change plug, pull the release button
downwards.
•
•
•
•
•
•
1�
2�
3�
2
1
3
EU
UK

5www.doro.com
Installing the Gateway
Connect the Ethernet cable to the WAN port and then to a LAN port on your
broadband modem or router.
Connect the telephone cord to the LINE port and then to a telephone outlet.
Connect the appropriate power adapter to the gateway and to a mains power outlet.
SELV (Safety Extra Low Voltage) Compliance
Warning: To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits
to telephone-network voltage (TNV) circuits. LAN ports contain SELV circuits, and
PSTN ports contain TNV circuits. Some LAN and PSTN ports both use RJ-45 (8P8C)
connectors. Use caution when connecting cables.
Install and Register the Handset
Open the battery cover.
Insert the battery in the handset, making sure that contacts of battery are correct.
Connect the power adapter to the charger and the other end to an active power outlet
Place the handset in the charger, and charge the battery. We recommend that you charge
the batteries fully before rst use. This takes approximately 4 hours. When you place the
handset in the charger, the handset automatically registers with the gateway.
Note: After registration of the rst handset, there is a 5-minute period during which you
can register any additional handsets. If you want to register additional handsets after the 5-
minute period has expired, press the Reset button on the rear of the gateway to start a new
5-minute registration period.
Belt clip
To attach the belt clip, insert the removal tool into the slot on
the top of the phone.
Gently press the cover lid upwards.
Remove the cover lid and gently t the belt clip into place
and press it downwards.
1�
2�
3�
1�
2�
3�
4�
1�
2�
3�
1
2
2Gateway
Phone socket
3Gateway
AC 110/220 V
1Gateway / WAN
Router / LAN

6www.doro.com
First setup via the handset
Before you start using your phone, we strongly recommend that you set handset language,
country selection, time zone, and routing of emergency numbers to ensure that your
functions properly.
Set handset language
Press 0, choose Settings and press 0.
Choose System settings 0, and then choose Language. Press 0.
Choose the preferred language and press the 0. Please note that you need Internet
access to download other languages besides English.
Depending on what language is chosen it can take up to 20 minutes before your
language is downloaded and installed. Please follow the on-screen instructions.
If a language you do not understand is selected and you cannot nd the language menu
again, do the following: In Idle mode, press 0 to enter the main menu, and key in 888.
The language list is displayed.
Using the Menus and Typing Text and Numbers
How to enter the Main menu
In Idle mode, press 0. The Main menu opens.
Typing text and numbers
When you are in a number editor or text editor there are a number of ways in which you
can edit text. The Erase key enables you to delete text that is already in the editor, or to
delete text that you have just typed. The Options key provides you with the following two
options: Insert symbol and Input mode.
How to insert a symbol
In a text editor, press the Options key, choose Insert symbol and press 0.
Use the navigation keys to choose the preferred symbol and press 0.
Change the text mode option
When you are in a text editor, the upper right corner of the display shows which text input
mode option is currently selected. You can change the input mode of the text editor.
In a text editor, press the Options key, choose Input mode and press 0.
Choose the preferred input mode and press 0. You can choose among the following
options: ABC (all upper case), Abc (rst letter in upper case, remaining in lower case),
abc (all lower case) and 123 (numbers only).
You can also change the case of letters on the y, or type a number in the middle of a text.
● Press the *-key once to change the case, or press the *-key twice to type numbers.
1�
2�
3�
4�
1�
2�
1�
2�

7www.doro.com
Country selection
Setting the country selection properly ensures, among other things, that you can make and
receive landline calls and receive Caller ID information on your phone if supported by
your telephony provider. It is therefore important that you specify in which country you are
using the phone.
In the Main menu, choose Settings and press 0.
Choose System settings, press 0, and then choose Country and press 0.
Select the country that you are in, and then press 0.
Note:
The handset language and country settings are independent of each other. You can change the handset
language whenever you want, but we recommend that you only change the country settings if you bring your
phone to another country and want to make landline calls.
Change the time zone
Setting the time zone properly ensures that the time displayed in the Idle mode screen
corresponds to the time zone that you are in.
In the Main menu, choose Settings and press 0.
Choose System settings, press 0, and then choose Time and date. Press 0.
Choose Time zone, press 0, and then select the appropriate time zone. Press 0.
You should also verify that the time format and the daylight saving settings are correct.
Date and time are automatically synchronized with a time server on the Internet to ensure
that the time and date displayed on the phone is always correct. For information on how to
disable automatic time setting, see page 38 of this manual.
Change emergency line settings
The default setting of emergency calls is VoIP (Internet call). However, we recommend that
you check which way emergency calls are routed on your phone.
Press 0, choose Settings and press 0.
Choose Telephony settings, and press 0.
Choose Emergency line, and then choose VoIP or Landline and press 0.
When requested to reboot the gateway, press Yes or press Reset button on the rear of the
gateway.
Important!
You must check with you Internet Telephony Service Provider whether they have a service that makes it
possible for your call to reach the appropriate emergency call center and for the emergency call center to
locate from where you are calling. If not, you must use landline settings for emergency calls. This requires a
functioning landline connection.
1�
2�
3�
1�
2�
3�
1�
2�
3�

8www.doro.com
Configure VoIP servers and accounts�
VoIP Server
In Idle mode, press 0, choose Settings, and press 0.
Choose VoIP settings, and press 0.
Chose Server 1 (and Server 2 if required) and then press 0.
You then specify the Domain and the SIP proxy.
• Choose Domain and press 0.
• Enter the domain name. Press 0.
• Choose SIP proxy, press 0, and then key in domain name or IP address of the SIP
proxy, if it is different from the Domain.
SIP Account(s)�
Choose the appropriate SIP Account and ll in the user data. If you have more than
one SIP account, then you need to enter the account settings for each account.
Choose the listed parameters one by one, press 0.
• Display name (optional) – Caller ID that the called party sees
• Nickname – name of the account used in Call Groups and VoIP line settings
• SIP user name – usually the phone number you received from your service provider
• Authentication Name – usually the same as User name
• SIP password – the password you received from your SIP provider
• Server ID – assign VoIP Server 1 or 2 as specied in previous section (default=1).
After each change, press 0 and then the Yes key when prompted to save changes. When
requested to reboot the gateway, press Yes or press Reset button on the rear of the gateway.
Change the PIN code
Make sure to change the PIN code after rst login to prevent unauthorized access to your
VoIP settings.
In Idle mode, press 0, choose Settings, and then press 0.
Choose VoIP settings, and then press 0.
Choose Change PIN code and then press 0.
Enter a new PIN code, and then press 0.
Press the Yes key when prompted to save the PIN code.
For future reference, write your new PIN code here:
Note!
The handset PIN code and the online conguration password are independent of each other. Changing the
handset PIN code will not affect the online conguration password.
1�
2�
3�
1�
2�
1�
2�
3�
4�
5�
6�

9www.doro.com
First setup via web-interface
The following sections describe how to congure and set up your phone for rst use.
You have to congure your phone before it is ready for rst use. You will need the
account information that you received from your SIP Service Provider to complete the
conguration of your phone.
Configure using a web browser
Open a browser on your PC; go to the IP address of the gateway (Press the volume up
key to get the IP address).
Log in to the menu. Default settings:
username: admin
password: admin
In the menu, select and configure VoIP Server 1 (and VoIP Server 2 if required) by filling in:
• Server is local: Yes or No
• Proxy address: IP or DNS address of the SIP-Server
• Domain: Usually the same as Proxy address
• Server port: 5060 is default
• Re-registration time: 3600 is default
• Domain cong: Add domain or Force domain
• DTMF Signalling: Inband, SIP-Info or RFC2833
• Codec priority: Set the order for codec usage
• Enable silence suppression: Yes or No
Click SAVE CHANGES�
In the menu, choose VoIP Accounts and configure Account 1 (and 2 -8 if needed):
• Account alias name: Name of the account used in call groups (Nickname)
• Used VoIP server: VoIP Server 1 (or 2. if the second VoIP Server has been congured)
• SIP user name: Usually the phone number you received from your service provider
• SIP auth name: Usually the same as SIP user name
• SIP auth password: the password you received from your SIP Provider
• Display name (optional): Caller ID that the called party sees
• Voice Mailbox Name:
• Voice Mailbox Number:
Click SAVE CHANGES.
If more than one VoIP Server or VoIP Accounts has been congured you may select
which account should ring on your handset and also set what account (or line) to use for
outgoing calls in the menu Telephony Settings.
Click SAVE CHANGES.
Click Reboot to activate your settings.
1�
2�
3�
4�
5�
6�
7�
8�
9�

10www.doro.com
Making and answering calls
With this phone you can make both Internet and landline calls. All outgoing calls are by
default Internet calls unless you specify otherwise. The following sections describe how to
make and answer Internet and landline calls.
Internet call
If your primary line is Internet, you do the following to make an Internet call.
In Idle mode, type the number you want to dial, and then press O.
If your primary line is Landline, you do the following to make an Internet call.
In Idle mode, type the number you want to dial, press the Options key, and then
choose Call on VoIP. Press 0.
Press L to end a call.
Make an Internet call using contacts
In the Main menu, choose Contacts, and then press 0.
Choose the contact you want to call, and then press O. The default number is dialled.
If you want to call a contact, and use another number than the default number, do the following:
In the Main menu, choose Contacts, and then press 0.
Choose the contact you want to call, and then press 0.
Choose a number from the list, and then press O.
Make an Internet call using the call log
In Idle mode, press the Call log key, or choose Call log from the Main menu, and
then press 0.
Choose the number you want to call, and then press O.
Make an Internet call using redial
Press the Options key, choose Redial, and then press 0. The most recently dialled
number is displayed.
Press O to call the number.
Make an Internet call using speeddials
In Idle mode, type the speed dial number assigned to the contact you want to call, and
then press O.
Make an emergency call
Enter the emergency number for your country, and then press O.
When you make emergency calls, always press O regardless of whether your emergency
calls are routed through the Internet or via landline.
You cannot make emergency calls in the following situations:
•
•
1�
2�
1�
2�
3�
1�
2�
1�
2�
•
•

11 www.doro.com
Firmware update is in progress
Battery is empty
Power failure
Handset is out of range of the gateway
Landline Calls
When you make and receive landline calls, the following icons are displayed:
Calling
Ongoing call
Make a landline call
If your primary line is Internet, you do the following to make a landline call.
In Idle mode, type the number you want to dial, press the Options key, and then
choose Call on landline. Press 0.
If your primary line is Landline, you do the following to make a landline call.
In Idle mode, type the number you want to dial, and then press O.
Make a landline call using contacts
In the Main menu, choose Contacts, and then press 0.
Choose the contact you want to call, press the Options key, and then choose Call on
landline. Press 0. The default number is dialled.
If you want to call a contact, and use another number than the default number, do the following.
In the Main menu, choose Contacts, and then press 0.
Choose the contact you want to call, press 0, and then choose a number from the list.
Press the Options key, and then choose Call on landline.
Make a landline call using the call log
In Idle mode, press the Call log key, or choose Call log from the Main menu, and
then press 0.
Choose the number you want to call, press the Options key, and then choose Edit for
call. Press 0.
Press the Options key, choose Call on landline, and then press 0.
Make a landline call using redial
Press the Options key, choose Redial, and then press 0. The most recently dialled
number is displayed.
Press the Options key, choose Call on landline, and then press 0.
Make a landline call using speeddials
•
•
•
•
•
•
•
•
•
1�
2�
1�
2�
3�
1�
2�
3�
1�
2�

12www.doro.com
In Idle mode, type the speed dial number assigned to the contact you want to call.
Press the Options key, choose Call on landline, and then press 0.
Answer a call
Pick up the handset, and then press O.
You can also set the phone to auto answer when you pick up the handset from the charger.
Lock and unlock the keypad
In Idle mode, press *, and then press the Lock key.
To unlock, press *, and then press the Unlock key.
Note! The keypad unlocks automatically when you answer an incoming call or if you make an emergency call.
Caller ID
When you receive an incoming Internet call, the Caller ID is always displayed. Usually Caller ID
is also displayed on incoming landline calls, but some telephony providers may require that you
subscribe to a Caller ID service. If the caller is stored as a contact, the contact name is displayed
instead of the Caller ID. If the caller has blocked display of the number, no Caller ID is displayed.
Call log
The call log keeps track of all your incoming and outgoing calls. It consists of 4 tabs that you can
scroll through using the navigation keys on the handset. The tabs display the following information:
All calls
Missed calls
Incoming calls
Outgoing calls
The call log stores up to 30 numbers. For each call, the call log keeps track of the number,
the date and time of the call, and the type of call: incoming, outgoing, or missed. If the
caller’s name and number is stored in Contacts, the caller’s name is displayed. A number or
name is only listed once, but all missed calls are counted so you can always see how many
times the same caller has tried to reach you.
View numbers in the call log
In Idle mode, press the Call log key, or choose Call log from the Main menu, and
then press 0. Use the navigation keys to page through the tabs and scroll through the
names and numbers.
1�
2�
•
1�
2�
•
•
•
•
•

13 www.doro.com
When you select a number in the call log and press the Options key, you have the
following options:
Option What it does
Add as contact Opens a text editor so that you can add the selected number as a
contact.
Append as
contact
Opens Contacts so that you can add the selected number to an
already existing contact.
Edit for call Opens the number editor so that you can edit the number before
calling.
Delete Deletes the selected number from the call log.
Delete list Deletes all numbers in the call log list.
During calls
Place a call on hold
During a call, press the Options key, and then choose Hold call.
Retrieve a call from hold
Press the Options key, and then choose Retrieve call.
Adjust the handset volume
During a call press the volume up or volume down buttons on the side of the phone to
adjust the volume up or down. The volume setting is automatically saved when you end
the call.
Speakerphone
The speakerphone allows you to make and answer calls without picking up the handset.
During a call, press the speakerphone button on the side of the phone. To deactivate the
speakerphone, press the speakerphone button again.
Note: To enjoy the best sound quality, place the handset in a horizontal position rather than a vertical
position.
Mute a call
During a call, you can switch off the microphone so that the person on the line cannot hear
what you are saying.
Press the Mute key. To turn the microphone on again, press the Mute off key.
Call Waiting
Call waiting noties you about an incoming call during an ongoing call. You can put the current
call on hold, and then answer the incoming call. If you do not answer a waiting call, the call is
added to the call log as a missed call. Call waiting works for both Internet and landline calls,
but it works in different ways as described in the following. When you receive an incoming call
during an ongoing call, you can also choose to start a conference between all three parties.
•
•
•
•
•

14www.doro.com
Answer an Internet call during an ongoing landline call
Press O. The current call is automatically put on hold.
Press the Options key, and then choose Swap calls to switch between the two calls.
Press L to end the ongoing call.
Answer a landline call during an ongoing Internet call
Press O. The current call is automatically put on hold.
Press the Options key, and then choose Swap calls to switch between the two calls.
Press the L to end the ongoing call.
Answer a landline call during an ongoing landline call
Long-press O until an R is displayed. The current call is automatically put on hold.
Long-press O until an R is displayed to switch between the two calls.
Press L to end both calls.
Note: The procedure for answering an incoming landline call during an ongoing landline call may vary
depending on your telephone company. Contact your telephony provider for more information.
Answer an internal call during an ongoing Internet or landline call
If you have more than one handset registered with the gateway, you can receive an incoming
internal call during an ongoing call.
Press O. The current call is automatically put on hold.
Press the Options key, and then choose Swap calls to switch between the two calls.
Press L to end the ongoing call.
Transfer a call
Call transfer is for Internet calls only. To be able to use call transfer you need to contact
your Internet Telephony Service Provider to nd out if they support this service.
During a call, press Hold and then the Options key, and then choose Transfer call.
Press the Options key, choose Contacts, and then press 0.
Choose the contact to which you want to transfer the call, and then press 0.
Alternatively, you can type the number to which you want to transfer the call.
During a call, press Hold and then the Options key, and then choose Transfer call.
Enter the number to which you want to transfer the call, and then press 0.
1�
2�
3�
1�
2�
3�
1�
2�
3�
1�
2�
3�
1�
2�
3�
1�
2�

15 www.doro.com
Intercom
You can register up to 8 handsets to the same gateway and you can have up to 8 different VoIP
accounts provided they belong to the same Internet Telephony Service Provider. However, you
can only have 4 active calls at a time: 3 Internet calls and 1 landline call. If you use Call Groups,
you should only include up to 6 handsets in a Call Group, because only 6 handsets at a time can
receive incoming calls. If you have more than one handset, you can make intercom calls, and
you can transfer calls to other handsets. You can answer incoming calls on any of the registered
handsets, and if you reject a call on one handset, you can still answer the call on the other
registered handsets. Contact entries are automatically shared between all handsets.
Register an additional handset with the gateway
Press the Reset button on the rear of the gateway to enable registration mode.
If the handset is not already turned off, press the Red phone key to turn it off.
Place the handset in the charger. The left status indicator in the upper left corner of the
display will turn yellow, indicating that you have successfully registered the handset.
You can also register a handset by means of the handset.
Press the Reset button on the rear of the gateway to enable registration mode.
In the Main menu, choose Settings, and then press 0.
Choose System settings, press 0, and then choose Handset settings. Press 0.
Choose Register handset, press 0, and then press the Yes soft key when prompted
to register handset.
If the handset you want to register is already registered with another gateway, you need to
deregister the handset from that gateway before you can register it with a new gateway.
Deregister a handset with the gateway
In the Main menu, choose Settings, and then press 0.
Choose System settings, press 0, and then choose Handset settings. Press 0.
Choose Deregister handset, press 0, and then press the Yes soft key when
prompted to deregister the handset.
View all handsets registered with the gateway
In the Main menu, choose Settings, and then press 0.
Choose System settings, press 0, and then choose Handset settings. Press 0.
Choose Handsets, and a list of all handsets is displayed.
Here you choose to deregister another handset. Choose required handset and press
Deregister.
1�
2�
3�
1�
2�
3�
4�
1�
2�
3�
1�
2�
3�
4�

16www.doro.com
Give your handset a name
Naming your handsets can be useful when you register extra handsets with the gateway.
This way you can easily identify the various handsets when you make internal calls. When
the phone is in Idle mode, the name of the handset is displayed. If you do not name your
handsets, they are numbered consecutively starting with Handset 1, which is the handset
rst registered with the gateway.
In the Main menu, choose Settings, and then press 0.
Choose System settings, press 0, and then choose Handset settings. Press 0.
Choose Handset name, write a name for the handset, and then press 0.
Press the Yes soft key when prompted to save.
Call another handset
You can make calls between all handsets registered to the same gateway.
In the Main menu, choose Intercom, press 0, and then choose the handset you want
to call. Press 0.
Call all handsets
In the Main menu, choose Intercom, press 0, and then choose All handsets. Press
0. The rst handset to answer the call, receives the call.
Transfer a call to another handset
During a call, press the Hold soft key.
Press the Options key, choose Intercom, and then press 0.
Choose the handset to which you want to transfer the call, and then press 0.
Press L either after the other handset answers the call or before the other handset
answers the call.
1�
2�
3�
4�
1�
1�
1�
2�
3�
4�

17 www.doro.com
Making conference calls
Conference call with one external party and two internal parties.
You can make a 3-way conference call that includes two handsets registered with the same
gateway and either an Internet call or a landline call.
During a call, press the Hold soft key.
Press the Options key, choose Intercom, and then press 0
Choose the preferred handset, and then press 0.
When the other handset has answered the call, press the Options soft key, choose
Conference, and then press 0. All three parties are now in conference.
Press L to end the conference.
Conference call with two external parties
You can make a 3-way conference call where one external call is an Internet call and the
other external call a landline call.
During a call, press the Hold soft key.
Press the Options soft key, type the phone number you want to call, and then press 0
When the other handset has answered the call, press the Options soft key, choose
Conference, and then press 0. All three parties are now in conference.
Press L to end the conference and to end both calls. If you press the End conf. soft
key, you will still have one ongoing call and one call on hold.
Note!
If you want to make a 3-way conference where the two external calls are landline calls, you need to contact
your telephony provider to nd out if they support this feature.
How to join a call
You can join an ongoing call from another handset.
In Idle mode, press the Options soft key, and then choose Active calls. Press 0.
The phone number of the party in call is displayed. If the party in call is in Contacts, the
name is also displayed.
Choose the call you want to join and press the Join soft key. An advisory tone is
emitted informing the caller on the other handset that you are joining the call.
Press L to leave the call. An advisory tone is emitted informing the caller on the
other handset that you are leaving the call.
1�
2�
3�
4�
5�
1�
2�
3�
4�
1�
2�
3�
Table of contents
Other Doro Cordless Telephone manuals

Doro
Doro MoveEasy 316 User manual

Doro
Doro HandlePlus 334gsm User manual

Doro
Doro HEARPLUS 318W User manual

Doro
Doro PhoneEasy 740 User manual

Doro
Doro DECT 160 User manual

Doro
Doro PHONEEASY 336W User manual

Doro
Doro 720 User manual

Doro
Doro NeoBio 30 User manual

Doro
Doro 615r User manual

Doro
Doro 7001H User manual
Popular Cordless Telephone manuals by other brands

Topcom
Topcom BUTLER 5020 user guide

Sailor
Sailor RT 2048 Instruction book

Bell Sonecor Equipment
Bell Sonecor Equipment BE-3872 Installation and operating guide

Panasonic
Panasonic KX-TCD210G operating instructions

SBC
SBC SBC-383 Owner's manual installation and operating instructions

AUDIOLINE
AUDIOLINE CDL500 Handbook
