DREAMS 225-00135 User manual

Before you
Minimum No.of people
is some
225-00136 (Sprung slats)
helpful advice
recommended to assemble
start,here
this product
225-00135 (Solid slats)
CORDOVA KING BED
Approx assembly time
We suggest you spend a short time reading through this leaflet and1. then follow the simple step by step instructions.
If you follow the instructions carefully the end result should be worth2. the effort.
Do not discard any of the packaging until you have checked that you3. have all the parts and the pack of fittings.
To ensure an easier assembly, we strongly advise that all fittings are4. only finger tightened during initial assembly. Only upon completion of
the. Assembly should all fixing points be fully tightened.
We recommend a periodic check on all fixing points to make sure they5. remain fully tightened.
Keep glue and fittings out of children’s reach.6. In the unlikely event that this product has missing or damaged parts,7. please call 08442 920000 to obtain spares
Page 1 of 6
Assembly Instruction

Page 2 of 6
Note:The following fittings will be found in the box which contains the Sprung
Frame,NOT with the bed frames Assembly Kit.
1(1 piece)
2(1 piece)
3(2 pieces)
A
Ø10 x 40mm x 8pcs.
B
C
D
E
M8 x 65mm x 8pcs.
Ø35 x 8pcs.
M8 x 8pcs.
Spanner x 1pc.
Center leg x 1pc.
M
Support leg x 2pcs.
P
M6 x 12mm x 8pcs.
Allen key 4mm x 1pc.
F
G
M6 x 38mm x 4pcs.
H
N
M6 x 6pcs.
K
LØ4 x 40mm x 6pcs.
M6 x 22mm x 4pcs.
F
Allen key 4mm x 2pcs.
PARTS Fittin
g
s

B
46mm
1
BB
BB
Insert cam bolts "B" into
the headboard "1" by hand.
Insert cam bolts "B" into
the footboard "2" by hand.
BB
B
46mm
2
BB
Page 3 of 6
Assembly

3x2
AA
3
3
1
2
Ex1 Cx8
Dx8
Page 4 of 6
AA
Insert dowels "A" into the
side rails "3".
Fix the side rails "3" to the
headboard "1" and
footboard "2".
Insert cam locks "C" and
nuts "D" to side rails "3",and
tighten with a spanner "E".

3
3
1
2
Kx6
Lx6
Open the metal slat frame
outwards.
Attach center leg "M" and
support legs "N" to the
frame and secure using
bolts "P",tighten using allen
key "F".
Option 1:
Dreams solid slats
Note:You have bought your
bed, choosing one of two
slat options; either solid or
sprung.
Although the assembly of
both options are explained
here, only one option will
apply to you.
Place the fixed wood slats
onto the slat holders on
side rails "3".
Fix the slats at both ends
and the middle using screws
"K" and washer "L",tighten
with a screwdriver. total of
six screws and washers.
Option 2:
Dreams sprung slat frame
N
N
MPx8
Fx1
Page 5 of 6

3
3
1
2
Page 6 of 6
Fx1
Gx4
Hx4
Fx1
Turn the metal slat frame
falling upward and
carefully lower the slat
frame into the bed.
Ensure that the frame sits
on the guides located on
the side rails "3".
Position the slat frame so
that the holes in the
frame align with those in
the side rails "3".Secure
the frame to the side rails
"3" by threading bolt "G"
and through the holes in the
frame and the side rails "3".
Finally,tighten the bolt "G"
into the sleeve nut "H" from
the top of slat frame with
allen key "F".
SAFETY WARNINGS
THIS PRODUCT COMPLIES WITH BS EN1725
1.THE TOP SURFACE OF THE MATTRESS MUST NOT BE ABOVE THE LINE MARKED ON
THE FRAME
2.DO NOT ALLOW CHILDREN UNDER 6 YEARS OLD TO USE THE UPPER BUNK
3.ALWAYS USE THE LADDER FOR ENTERING THE UPPER BUNK
4.DO NOT ALLOW HORSEPLAY ON OR UNDER THE BED AND PROHIBIT JUMPING ON
THE BED
5.USE A NIGHTLIGHT AS AN ADDED SAFETY PRECAUTION FOR PERSONS USING THE
UPPER BUNK
6.USE GUARDRAILS ON BOTH LONG SIDES OF THE UPPER BUNK
