Drive PreserveTech RTL12C002-WH User manual

PreserveTech™
Universal Raised Toilet Seat
Asiento Elevado Universal
para Inodoro PreserveTech™
Siège de Toilette Rehaussé
Universel PreserveTech™
Item # RTL12C002-WH
www.drivemedical.com
VER.A.12.20
OSMUNDA Medical Technology Service GmbH
Georg-Sigismund-von Oppen-Weg 15, 14476
Postdam, Germany
M
A
D
E
U
S
I
N
G
R
E
C
Y
C
L
E
D
M
A
T
E
R
I
A
L
S

getting started
Step 1: Determine the height needed
Measure the length of
your lower back leg
Add 2"
19" + 2" = 21"
Measure the height of
your toilet bowl
Be sure not to include
the seat and lid
Calculate the difference
21" – 17" = 4"
You need a 4" raised
toilet seat!
4"
19"
17"
Step 2: Determine the shape of your toilet
Toilets come in 2 different shapes
- Standard Round
- Elongated
To ensure you are correctly measuring your toilet bowl, measure from the center
front to the center of the mounting holes.
17"
18.5"
Standard Round Elongated

parts
A
B
D
E
F
C
G
HI
J
K1
K2
L
A. Armrest (2)
B. Armrest holder
C. Locking mechanism for adjustable holder
D. Body
E. Recessed grip (in the lid)
F. Lid
G. Fixing screw (2)
H. Knurled nuts (2)
I. Rear support
J. Adjustable holders (2)
K. Supports (4)
L. Hygiene openings
WEIGHT CAPACITY: 350 LB / 158 KG

assembly
1. Remove existing toilet seat and lid assembly
I
GG
HH
3. Insert adjustable holders (J) onto
the rear support (I) at the desired
seat height.
J
J
I
6"/ 15.2cm
4"/ 10.1cm
2"/ 5cm
2. Place rear support (I) on toilet bowl
and attach at required length based
on your toilet shape using fixing
screws (G) and knurled nuts (H).
NOTE: There are letter indicators on the
rear support (I) marked “E” for Elongated
and “S” for Standard to assist with which
hole to thread the fixing screws (G)
through for your toilet shape.
4. To set the height in the front, insert the
supports (K1) in the corresponding
opening until they click into place.
NOTE: Be sure that the supports (K1) are
inserted at the same height on the right
and left side. The supports (K1) can be
set lower than the rear support (I).
5. Insert supports (K2) in the corresponding
openings until they click into place.
K1
K2
J
I
6"/ 15.2cm
4"/ 10.1cm
2"/ 5cm

6. Push armrests (A) into the
armrest holders (B). If not
using armrests, skip this step.
A
7. Slide body (D) of raised toilet
seat onto adjustable holders (J)
until you hear a click into place.
J
J
D
B
height adjustment
The raised toilet seat can be adjusted using the adjustable holders (J) for an elevation
of 2"(5cm) 4"(10.1cm) and 6"(15.2cm). If you wish to change the seat height, follow
these steps:
1. Push the locking tabs on the right and left under the armrests (A) and pull the
body (D) of the raised toilet seat up.
2. Pull out the adjustable holders (J) and set the desired height. To do this insert
the rear support (I) into the corresponding hole in the adjustment holder (J).
Be sure that the adjustable holders (J) are set at the same height on both the left
and right sides.
3. To adjust the height in the front, insert the supports (K) into the corresponding
openings until you hear them click into place. Be sure that the supports (K) are
set at the same height on both the left and right sides.
NOTE: The supports (K) can be set lower than the rear support (I).
4. Set the body (D) of the raised toilet seat back onto the rear support (I).

lid assembly
The lid is preassembled at the time of delivery but can be replaced if necessary. To
do this, turn the body of the raised toilet seat around and press the lid clips at the
same time. The lid can then be taken out of the holders.
additional precautions
• Inspect all parts for shipping damage before assembly. If there is shipping damage
- DO NOT USE. Contact dealer/carrier for further instructions.
• Check for secure fit routinely before using product. User’s weight should be
centered over toilet seat, not too far forward or too far to one side, as unit
may tip.
• Use the arm supports only for assistance. DO NOT attempt to use the arms to
support full body weight.
• The lid must not be used as a backrest in the opened position.
• The lid must not bear a load when closed.
maintenance
Drive recommends periodic visual inspection of this product by the user, to ensure that
all parts and hardware are secure, that components are in good working order and not
worn, torn, frayed, loose, or rusted and that there are no obstructions or impediments
to normal, safe operation. If any part or mechanism appears to be unsafe or
compromised, do not use the product. If you experience problems, please contact the
provider that sold you the product or visit www.drivemedical.com/help for more info.
NOTE: To maintain the beauty of the original finish, clean with mild soap and rinse with
warm water. Wipe bath seat dry after each use.
Drive PreserveTech™ products are manufactured with an antimicrobial* agent that helps
to minimize the growth of stain and odor-causing bacteria and mold on treated surfaces.
*Antimicrobial properties are built in to protect the products. These products do not
protect users or others against bacteria, viruses, germs or other disease organisms.
PreserveTech
Stays Cleaner •Lasts Longer
TM

lifetime limited warranty
Your Drive brand product is warranted to be free of defects in materials and
workmanship for the lifetime of the original consumer purchaser.
This device was built to exacting standards and carefully inspected prior to shipment.
This Lifetime Limited Warranty is an expression of our confidence in the materials
and workmanship of our products and our assurance to the consumer of years of
dependable service.
This warranty does not cover device failure due to owner misuse or negligence, or
normal wear and tear. The warranty does not extend to non-durable components,
such as rubber accessories, casters, and grips, which are subject to normal wear and
need periodic replacement.
If you have a question about your Drive device or this warranty, please contact an
authorized Drive dealer.
© 2020 Medical Depot, Inc. All rights reserved.
Drive is a trademark of Medical Depot, Inc.
Port Washington N.Y. 11050 USA Made in China

para comenzar
Paso 1: Determina la altura necesaria
Mida la longitud de la
parte inferior trasera de
su pierna.
Agregue 2” = 19” + 2” = 21”
Mida la altura de la taza
del inodoro.
No incluya el asiento
ni la tapa.
Calcule la diferencia
21” – 17” = 4”.
Usted necesita un asiento
elevado de 4”.
4"
19"
17"
Paso 2: Determina la forma de tu inodoro
Los inodoros vienen en 2 formas diferentes
- Redondo estándar
- Alargado
Para asegurarse de medir correctamente la taza del inodoro, mida desde el centro
de la parte delantera hasta el centro entre los orificios de montaje.
17"
18.5"
Redondo estándar Alargado

partes
A
B
D
E
F
C
G
HI
J
K1
K2
L
A. Apoyabrazos (2)
B. Sostén de apoyabrazos
C. Mecanismo de traba para el sostén ajustable
D. Cuerpo
E. Tirador encastrado (en la tapa)
F. Tapa
G. Tornillo de sujeción (2)
H. Tuerca estriada (2)
I. Soporte trasero
J. Sostén ajustable (2)
K. Soportes (4)
L. Aberturas para la higiene
CAPACIDAD DE PESO: 350 LB / 158 KG

armado
1. Retire el asiento y la tapa del inodoro existentes
I
GG
HH
3. Inserte los sostenes ajustables (J) en
el soporte trasero (I) a la altura
deseada para el asiento.
J
J
I
6"/ 15.2cm
4"/ 10.1cm
2"/ 5cm
2. Coloque el soporte trasero (I) sobre
la taza del inodoro y fíjelo a la longitud
deseada, según la forma del inodoro,
usando los tornillos de sujeción (G) y
las tuercas estriadas (H).
NOTA: Hay letras indicadoras en el
soporte trasero (I) que dicen “E” para
la forma Alargada y “S” para la forma
estándar para que sepa en qué orificio
enroscar los tornillos de sujeción (G)
según la forma del inodoro.
4. Para establecer la altura en la parte
delantera, inserte los soportes (K1) en el
orificio correspondiente hasta escuchar el
clic que indica que calzaron en su lugar.
NOTA: Asegúrese de que los soportes (K1)
estén insertados a la misma altura del lado
derecho e izquierdo. Los soportes (K1)
pueden fijarse más abajo que el soporte
trasero (I).
5. Inserte los soportes (K2) en los orificios
correspondientes hasta escuchar el clic
que indica que calzaron en su lugar.
K1
K2
J
I
6"/ 15.2cm
4"/ 10.1cm
2"/ 5cm
