DWT ABS-12 E User manual

2
Content / Contenido / Содержание / Зміст / Мазмұны /
English
Explanatory drawings ������������������������������������������������������������������������������������������������������������ pages
General safety rules, instructions manual ����������������������������������������������������������������������������� pages
3 - 6
7 - 13
Español
Dibujos explicativos ������������������������������������������������������������������������������������������������������������ páginas
Recomendaciones generales de seguridad, manual de instrucciones ������������������������������ páginas
3 - 6
14 - 20
Русский
Пояснительные рисунки ��������������������������������������������������������������������������������������������� страницы
Общие указания по ТБ, инструкция по эксплуатации �������������������������������������������� страницы
3 - 6
21 - 28
Украïнська
Пояснювальні малюнки �������������������������������������������������������������������������������������������������� сторінки
Загальні вказівки по ТБ, iнструкція з експлуатації ����������������������������������������������������� сторінки
3 - 6
29 - 36
Қазақ тілі
Түсіндіргіш әлеміштер ��������������������������������������������������������������������������������������������������� беттер
Жалпы қауіпсіздік жөніндегі ұсыныстар, пайдалану нұсқаулығы ����������������������������������� беттер
3 - 6
37 - 43
����������������������������������������������������������������������������������������������������������������������������
����������������������������������������������������������������������������������������������������
3 - 6
44 - 49
�������������������������������������������������������������������������������������������������������������������������
��������������������������������������������������������������������������������������������
3 - 6
50 - 56

3

4

5

6

7
English
Noise
information
Always wear ear protection if the sound
pressure exceed 85 dB(A).
Declaration of
conformity
We declare under our sole responsibility that the
product described under "Power tool specications" is
in conformity with all relevant provisions of the
directives 2006/42/EC including their amendments
and complies with the following standards:
EN 62841-1:2015,
EN 62841-2-1:2018,
EN 62841-2-2:2014�
Certication Wu Cunzhen
manager
Merit Link International AG
Stabio, Switzerland, 27�07�2021
General
safety rules
WARNING - To reduce the risk of injury,
user must read instruction manual!
WARNING! Read all safety warnings, in-
structions, illustrations and specica-
tions provided with this power tool. Failure
to follow the warnings and instructions may
Power tool specication
Cordless drill / screwdriver ABS-12 E
Power tool code 744634
Rated voltage [V] 12
No-load speed:
- first gear [min-1]0-350
- second gear [min-1]0-1350
Battery type Li-Ion
Battery charging time [min] 195
Battery capacity [Ah] 1,3
Turndown of rotation torque [Nm] 0,7-20 / 0,7-5
Chuck tightening range [mm]
[inches]
0,8-10
1/32"-3/8"
Drilling output:
- steel [mm]
[inches]
6
1/4"
- wood [mm]
[inches]
16
5/8"
Max. screw diameter [mm]
[inches]
5
13/64"
Weight [kg]
[lb]
1,6
3�53
Sound pressure [dB(A)] —
Acoustic power [dB(A)] —
Weighted vibration [m/s2]—

8
English
result in electric shock, re and / or serious
injury�
Save all warnings and instructions for future refer-
ence.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operat-
ed (cordless) power tool�
Work area safety
•Keep work area clean and well lit. Cluttered or
dark areas invite accidents�
•Do not operate power tools in explosive atmos-
pheres, such as in the presence of ammable liq-
uids, gases or dust. Power tools create sparks which
may ignite the dust or fumes�
•Keep children and bystanders away while oper-
ating a power tool. Distractions can cause you to lose
control�
Electrical safety
•Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Un-
modied plugs and matching outlets will reduce risk
of electric shock�
•Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded�
•Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock�
•Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock�
•When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock�
•If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock� NOTE! The term "residual current
device (RCD)" may be replaced by the term "ground
fault circuit interrupter (GFCI)" or "earth leakage circuit
breaker (ELCB)"�
•Warning! Never touch the exposed metal surfaces
on gearbox, shield, and so on because touching metal
surfaces will be interfered with the electromagnetic
wave, thus causing potential injury or accidents�
Personal safety
•Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury�
•Use personal protective equipment. Always
wear eye protection. Protective equipment such as
dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries�
•Prevent unintentional starting. Ensure the
switch is in the off-position before connecting to
power source and / or battery pack, picking up or
carrying the tool. Carrying power tools with your n-
ger on the switch or energising power tools that have
the switch on invites accidents�
•Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left at-
tached to a rotating part of the power tool may result
in personal injury�
•Do not overreach. Keep proper footing and bal-
ance at all times. This enables better control of the
power tool in unexpected situations�
•Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts�
•If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust
collection can reduce dust-related hazards�
•Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles� A careless action can cause
severe injury within a fraction of a second�
•Warning! Power tools can produces an electromag-
netic eld during operation. This eld may under some
circumstances interfere with active or passive medical
implants� To reduce the risk of serious or fatal injury,
we recommend persons with medical implants to con-
sult their physician and the medical implant manufac-
turer before operating this power tool�
Power tool use and care
•The persons with lowered psychophysical or men-
tal aptitudes as well as children can not operate the
power tool, if they are not supervised or instructed
about use of the power tool by a person responsible
for their safety�
•Do not force the power tool. Use the correct
power tool for your application� The correct power
tool will do the job better and safer at the rate for which
it was designed�
•Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be con-
trolled with the switch is dangerous and must be re-
paired�
•Disconnect the plug from the power source
and / or the battery pack from the power tool be-
fore making any adjustments, changing accesso-
ries, or storing power tools� Such preventive safety
measures reduce the risk of starting the power tool
accidentally�
•Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users�
•Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool's op-
eration. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools�
•Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control�

9
English
•Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for operations
different from those intended could result in a hazard-
ous situation�
•Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations�
•Note that when you operate a power tool, please
hold the auxiliary handle correctly, which is helpful
when controlling the power tool� Therefore, proper
holding can reduce the risk of accidents or injuries�
Battery tool use and care
•Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack�
•Use power tools only with specically designat-
ed battery packs. Use of any other battery packs may
create a risk of injury and re.
•When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a re.
•Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acci-
dentally occurs, ush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns�
•Avoid unintentional switching on. Ensure the
on / off switch is in the off position before inserting
battery pack. Carrying the power tool with your nger
on the on / off switch or inserting the battery pack into
power tools that have the switch in accidents�
•Do not open the battery. Danger of circuit
•In case of damage and improper use of the bat-
tery, vapors may be emitted. Provide for fresh air
and seek medical help in case of complaints. The
vapors can irritate the respiratory system�
•When the battery is defective, liquid can escape
and come into contact with adjacent components�
Check any parts concerned� Clean such parts or re-
place them, if required�
•Protect the battery against heat, e.g., also
against continuous sun irradiation and re. There
is danger of explosion�
WARNING! Read all safety warnings and
all instructions.
•Protect the battery charger from rain and mois-
ture. The penetration of water in a battery charger in-
creases the risk of electric shock�
•Do not charge other batteries. The battery charger
is suitable only for charging lithium ion batteries within
the listed voltage range� Otherwise there is danger of
re and explosion.
•Keep the battery charger clean. Contamination
may cause the danger of electric shock�
•Check the battery charger, cable and plug each
time before using. Do not use the battery charger
when defects are detected. Do not open the battery
charger yourself and have it repaired only by quali-
ed personnel using original spare parts. Damaged
battery chargers, cables and plugs increase the risk of
electric shock�
•Do not operate the battery charger on easily in-
ammable surfaces (e.g. , paper , textiles , etc.) or
in combustible environments. There is danger of
re due to the heating of the battery charger during
charging�
Service
•Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the power tool
is maintained�
•Follow instruction for lubricating and changing ac-
cessories�
•
Special
safety warnings
Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a "live" wire may
make exposed metal parts of the power tool "live" and
could give the operator an electric shock�
•Wear ear protectors Exposure to noise can cause
hearing loss�
•
Safety guidelines during
power tool operation
The workpiece shall be fastened� Fixed devices or
vice shall be used to fasten the workpiece, which will
be more secure than holding the workpiece with your
hands�
•Considering that asbestos may cause cancer, as-
bestos - containing materials shall not be processed�
•The power tool could be put down only after the
parts of power tool is completely static� Accessory on
the power tool might be clamped during work, which
may make it difcult for you to control the power
tool�
• Appropriate detector shall be used to nd the loca-
tion of hidden power wires� Or you should obtain rel-
evant information from local power supply unit� Drilling
electric wires will cause re and electric shock. Dam-
aged gas pipe will cause exploration� If water pipes are
punctured, damage will be caused to property�
•In case a accessory installed on the power tool is
clamped, you shall shut down the power tool and stay
calm� At that time, the power tool will produce extreme-
ly high reactive torque thus resulting in return stroke�
The accessory installed on the power tool are likely to
be clamped, for example: hypercharge of power tool or
skewing of accessory installed on the power tool dur-
ing work�
•If hidden electric wires or power lines of the power
tool itself might be cut off during work, you must hold
the insulated handle to operate the power tool� When
the power tool is in touch with a charged line, the metal
parts on the power tool will conduct electricity and may
cause the operator to get an electric shock�

10
English
•During work, you must tightly hold the power tool
and ensure you stand rmly. You should hold the pow-
er tool with your hands�
•When operating and using the power tool, you can
only hold switch position of the main handle rather than
other parts�
•Avoid stopping an power tool motor when loaded�
•Never remove any chips or fragments with your
power tool's motor running�
•Use accessories without defects - it will make work-
ing with the power tool easier�
• The modication of the drill bits design and the use
of removable orices and accessories not envisaged
for this power tool is strictly forbidden�
•Do not apply excessive pressure when operating the
power tool - it can jam the drill bit and overload the
engine�
•Do not allow drill bits to jam in the material pro-
cessed� If this occurs, do not try to release them by
means of the power tool engine� This can put the pow-
er tool out of order�
•Striking out drill bits jammed in the material pro-
cessed with a hammer or other objects is strictly for-
bidden - metal fragments can hurt both the operator
and the people nearby�
•Avoid overheating your power tool, when using it for
a long time�
Symbols used in
the manual
Following symbols are used in the operation manual,
please remember their meanings� Correct interpreta-
tion of the symbols will allow correct and safe use of
the power tool�
Symbol Meaning
Cordless drill /
screwdriver
Sections marked gray - soft
grip (with insulated surface)�
Serial number sticker:
ABS ��� - model;
XX - date of manufacture;
XXXXXXX - serial number�
Read all safety regulations
and instructions�
Wear safety goggles�
Wear a dust mask�
Symbol Meaning
Do not heat the battery
above 45°C� Protect from
prolonged exposure to direct
sunlight�
Do not dispose of the battery
in a domestic waste con-
tainer�
Do not dispose of the battery
in the re.
Protect the battery from the
rain�
min
Battery charging time�
Movement direction�
Rotation direction�
Locked�
Unlocked�
Attention� Important�
A sign certifying that the
product complies with es-
sential requirements of the
EU directives and harmo-
nized EU standards�
Wear protective gloves�
Torque control position:
"Drilling"�
Stepless speed control�
