Dynojet power commander III User manual

1998-1999 Suzuki GSXR750 - PCIII USB - 1i302-411 www.powercommander.com
1998-1999 Suzuki GSXR750
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
Parts List
1 Power Commander
1 USB Cable
1 Installation Guide
1 Power Adapter
2 Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1 Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
Expansion Port USB Port

1 Remove the main seat and the
passenger seat.
2 Hold the front of the fuel tank
up using the prop rod located in
the trunk area.
3 Lay the PCIII in the tail section.
4 Route the PCIII harness under
the subframe and go towards the
front of the bike. Route the
PCIII harness under the battery
bracket (Fig. A).
5 Locate the connector from the
main wiring harness to the injec-
tor rail and uplug this connector
(Fig. B).
NOTE: This connector is located on
the right hand side of the bike.
6 Plug the connectors from the
PCIII in-line of the stock wiring
harness (Fig. C).
Fig. AFig. BFig. C
1998-1999 Suzuki GSXR750 - PCIII USB - 2i302-411 www.powercommander.com
Unplug this connector
PCIII connector
Stock connector
View from RH side
PCIII harness

7 Locate and unplug the stock wir-
ing harness from the Throttle
Position Sensor on the right
hand side of the throttle bodies.
8 Plug the Power Commadner
in-line of the Throttle Position
Sensor and the stock wiring
harness (Fig. D).
9 Attach the ground wire from the
PCIII to the negative side of the
battery (Fig. E).
10 Install the PCIII in the rear
section of the trunk using the
supplied velcro (Fig. F). Make
sure to clean both surfaces with
alcohol first.
Fig. DFig. EFig. F
1998-1999 Suzuki GSXR750 - PCIII USB - 3i302-411 www.powercommander.com
TPS
PCIII harness
Ground wire
