Dynojet POWER COMMANDER III User manual

i726-411 www.powercommander.com 2005 Benelli TNT 1130 - PCIII USB - 1
2005 Benelli TNT 1130
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
Installation Instructions
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
Expansion Port USB Port

5Route the Power Commander harness
along the right side of the ECU and
the subframe and go towards the
thorttle bodies (Fig. B).
6Unplug the stock wiring harness from
each injector (Fig. C).
1Remove the seats
2Remove the fuel tank.
3Mount the Power Commander on top
of the battery using the supplied vel-
cro. Use the alcohol swab to clean
both surfaces before attaching (Fig. A)
4Attach the ground wire of the PCIII to
the negative side of the battery.
Fig. AFig. B
Fig. C
i726-411 www.powercommander.com 2005 Benelli TNT 1130 - PCIII USB - 2
Ground wire from PCIII
Ground wire from PCIII
Unplug the stock harness

8Locate the Throttle Position Sensor
connector. This is located on the right
hand side of the throttle bodies
(Fig. E).
9Unplug this connector and plug the
connectors from the PCIII in-line of
the stock wiring harness and TPS.
10 Install the fuel tank. Make sure that
the PCIII harness does not get
pinched by the fuel tank.
11 Install the seats.
Fig. DFig. E
7Plug the PCIII connectors in-line of
the stock wiring harness and injectors
(Fig. D).
ORANGE - right cylinder
YELLOW - middle cylinder
GREEN - left cylinder
i726-411 www.powercommander.com 2005 Benelli TNT 1130 - PCIII USB - 3
Unplug the TPS
