Dynojet Power commander III User manual

2001-2004 Aprilia Falco - PCIII - 1i905-211
2001-2004 Aprilia Falco
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 [phone] www.powercommander.com
Installation Instructions
Parts List
1 Power Commander
1 CD-ROM
1 Installation Guide
1 Wire Tap
1 Power Adapter
2 Power Commander Decals
2 Dynojet Decals
1 Velcro®Strip
1 Alcohol Swab
You can also download the Power Commander software
and latest maps from our web site at:
www.powercommander.com
The ignition MUST be turned OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

1 Remove the seat.
2 Lift up the front of the fuel tank.
3 Disconnect the wiring harness
from the injector on the left
hand side of the bike by pushing
up (squeeze) on the spring clips
from the injector connector (Fig.
A). Plug one of the leads from
the PCIII in line of the connec-
tors you just unplugged.
4 Repeat step 3 for the right hand
side (Fig. B).
5 Locate the throttle position sen-
sor on the trottle bodies. Locate
the yellow wire with the brown
tracer coming from the sensor.
Connect the wire tap to this
wire. Plug the grey wire from
the PCIII into this connector
(Fig. C). It is recommended to
seal this connector with dialec-
tric grease or silicone.
Fig. AFig. B
Fig. C
2001-2004 Aprilia Falco - PCIII - 2i905-211 www.powercommander.com
Stock connectors
PCIII connectors
Stock connectors
PCIII connectors
Wire tap
Gray cable from PCIII

6 Attach the ground wire from the
PCIII to the negative side of the
battery (Fig. D).
7 Install the PCIII in the rear trunk
area of the bike (Fig. E) using
the supplied velcro. Make sure
to clean both surfaces with alco-
hol first.
Fig. DFig. E
2001-2004 Aprilia Falco - PCIII - 3i905-211 www.powercommander.com
Ground wire
