Dynojet Power commander V User manual

22-044 www.powercommander.com 2009-2013 Yamaha YFZ450 R/X PCV - 1
PARTS LIST
1 Power Commander
1 USB Cable
1 CD-ROM
1 Installation Guide
2 Power Commander Decals
2 Dynojet Decals
2 Velcro
1 Alcohol Swab
YOU CAN ALSO DOWNLOAD THE
POWER COMMANDER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
www.powercommander.com
2009-2013 Yamaha YFZ450 R/X
Installation Instructions
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
FUEL AND IGNITION

22-044 www.powercommander.com 2009-2013 Yamaha YFZ450 R/X PCV - 2
EXPANSION PORTS 1 & 2
Optional Accessories such as
Color LCD unit or Auto tune kit.
POWER COMMANDER V
INPUT ACCESSORY GUIDE
Map - (Input 1 or 2) The PCV has the ability to hold
2 different base maps. You can switch on the
fly between these two base maps when you
hook up a switch to the MAP inputs. You can
use any open/close type switch. The polarity
of the wires is not important. When using the
Autotune kit one position will hold a base map
and the other position will let you activate the
learning mode. When the switch is “CLOSED”
Autotune will be activated. This feature is set
to Input 1 by default.
Shifter- (Input 1 or 2) These inputs are for use with the
Dynojet quickshifter. Insert the wires from the
Dynojet quickshifter into the SHIFTER inputs.
The polarity of the wires is not important. This
feature is set to Input 2 by default.
Speed- If your application has a speed sensor then
you can tap into the signal side of the sensor
and run a wire into this input. This will allow
you to calculate gear position in the Control
Center Software. Once gear position is
setup you can alter your map based on gear
position and setup gear dependent kill times
when using a quickshifter. Thru input 1 or 2
you can also setup a speed limiter that can be
activated thru a momentary switch.
Analog- This input is for a 0-5v signal such as
engine temp, boost, etc. Once this input
is established you can alter your fuel curve
based on this input in the control center
software.
Launch- The PCV allows you to setup a launch limiter
based on a grounding switch. With this
activated you can set a RPM limit when the
clutch is engaged.
ACCESSORY INPUTS
Wire connections:
To input wires into the PCV first remove the rubber
plug on the backside of the unit and loosen the
screw for the corresponding input. Using a 22-24
gauge wire strip about 10mm from its end. Push the
wire into the hole of the PCV until is stops and then
tighten the screw. Make sure to reinstall the rubber
plug.
NOTE: If you tin the wires with solder it will make
inserting them easier.
CRANK
ANALOG
SPEED
INPUT 1 (Grnd)
INPUT 1
INPUT 2 (Grnd)
INPUT 2
USB CONNECTION

22-044 www.powercommander.com 2009-2013 Yamaha YFZ450 R/X PCV - 3
1 Remove seat.
2 Remove the side covers (Fig. A).
3 Remove the fuel tank.
4 Lay the PCV in the tail section of the quad temporarily.
5 Route the PCV wiring harness from the rear of the quad to the throttle body
going along the left hand side of the frame.
Route the harness underneath the frame crossover (Fig. B).
6 Unplug the stock wiring harness from the injector (Fig. C).
FIG.A
FIG.B
PCV harness
Remove
Unplug
FIG.C

22-044 www.powercommander.com 2009-2013 Yamaha YFZ450 R/X PCV - 4
7 Plug the PCV wiring harness in-line with the fuel injector and stock wiring
harness (Fig. D).
FIG.D
8 Route the branch of the wiring harness with RED and GREEN colored wires
to the right side of the quad, across the top of the rear shock, and under the
rubber flap, where the ignition coil is located (Fig. E).
FIG.E
9 Unplug the RED/BLACK wire on the ignition coil.
10 Connect the pair of RED colored wires of the PCV harness in-line with the coil
and the RED/BLACK wire.
11 Unplug the ORANGE wire on the ignition coil.
12 Connect the pair of GREEN colored wires of the PCV harness in-line with the
coil and the ORANGE wire (Fig. F).
FIG.F
Stock Connector
PCV Connectors

22-044 www.powercommander.com 2009-2013 Yamaha YFZ450 R/X PCV - 5
13 Route the set of 3 pin connectors, and the set of 2 pin connectors, of the PCV
harness down the left side of the throttle body (Fig. G).
14 Unplug the Throttle Position Sensor connector from the left hand side of the
throttle body (Fig. H).
This connector is covered with a BLACK rubber boot.
15 Connect the set of 3 pin connectors of the PCV in-line of the TPS and the
stock wiring harness (Fig. I).
FIG.G
FIG.I
FIG.H
PCV harness
Unplug TPS

22-044 www.powercommander.com 2009-2013 Yamaha YFZ450 R/X PCV - 6
18 Attach the ground wire of the PCV with the ring lug to the negative side of the
battery (Fig. L).
19 Mount the PCV in the pocket of the rear fender on the left side using the
supplied velcro. Use the supplied alcohol swab to clean the surface before
attaching the unit.
20 Mount the fuel tank back into place.
21 Make sure the wiring harness is routed in a manner that it is free from getting
damaged by any hot or moving parts.
FIG.
FIG.L
16 Unplug the Crank Position Sensor connectors on the left side of the quad
behind the frame rail (Fig J).
These are the WHITE 2pin connectors.
FIG.J
17 Connect the set of 2 pin connectors of the PCV in-line of the stock Crank
Position Sensor connectors (Fig. K).
FIG.K
Unplug
Ground
