EDS EDA-T Series User manual

EDA-T Series
VOICE WARNING SYSTEMS
DISABLED ASSISTANCE FOR TOILET
Installation Manual
www.eds.com.tr

2
Disabled assistance for toilet systems is designed for disabled people to use
in toilets. The system consists of an alarm reveiver and alarm transmitter with
a cord. Alarm transmitter has a red cord, the user could pull the cord to call
people on the receiver side. It is simple to use and user-friendly as the ngers
could t in the pulling cord equipment.
Product Family
DESCRIPTION
1
P/N Description
EDA-TR Disabled Assistance Toilet for Receiver
EDA-TT Disabled Assistance Toilet for Transmitter

3
LED indicator
Cover opening /
Reset slot
EDA-TR Disabled Assistance Toilet for Receiver
EDA-TT Disabled Assistance Toilet for Transmitter
1
1
2
2
PHYSICAL
2
110
110
39
86 39
86

4
SPECIFICATIONS
3
Model EDA-TR
Environmental class II indoor
Description Receiver
Electrical
Nominal voltage 220V AC 50hz (with adapter)
Stand-by current 10 mA DC (Buzzer silence)
Max. Alarm current 400 mA DC (Buzzer active)
DC input voltage 12V DC – 6V AAA Battery (300mAh)
Speaker type 8R 0.5W speaker
Speaker current 390 mA
Speaker frequency 1 kHz Tone
Charge voltage 12.3V DC
Discharge protection ≤ 3V DC
Operating frequency 433.92 Mhz
Modulation type ASK
Indicator
Alarm LED’i Alarm Flash
Normal Sönük
Audio Police siren / Fire engine siren / Ambulance siren /
Machine gun

5
General
Housing ABS Plastic
Color White
Dimension (HxWxD) 110x110x39mm
Weight 147g
Year of manufacture The year and week of manufacture is included in
the rst four digit of your product serial number
(located on the product identication label)
Manufacturer EDS Elektronik Destek Sanayi ve Ticaret Ltd.
Meclis Mah. Teraziler Cad. Hayran Sk. No: 4 34785
Sancaktepe / Istanbul / TURKEY
Recycle

6
Model EDA-TT
Environmental class II indoor
Description Transmitter
Electrical
Input voltage 12V DC (MN21/23 Battery)
Stand-by current 0 mA
Alarm current 19 mA DC (Max.)
Operating frequency 433.92 Mhz
Modulation type ASK
Indicator
LED indicator
Alarm Light on
Normal Light off
Operating Cord pull 1 Alarm active
Cord pull 2 Alarm deactivate
General
Cord length 1,5 m
Cord color Red
Cord thickness ≥ 1 mm
Housing ABS Plastic
Color White
Dimension (HxWxD) 86x86x39mm
Weight 118g

-12V+
Speaker
Cell
1
1
2
3
7
The device is mounted to the wall from (1) points.
The only cable of the device removing is 12V DC supply cables. These
cables are taken out from 12V DC connector and removed from (3) point to
the outside of the box.
1
2
3
Mounting points
AAAx4 300mAh Cell
12V DC Supply
Main Panel Connection
CONNECTIONS
4

8
Button Connection
AAA
AAA
D
D
D
D
BB
C
A
D
E
E
B
C
Mounting hole
Cable conduit terminal
Cable connection terminal block
Mounting tabs
Red rope hole

9
Sound Type Selection
For selecting the Main Panel sound type of the Rope Call Device, JP2 and
JP7 are used as seen in the table. The jumpers are installed according to the
following table.
2 pieces of M4x40 YSB pan heads
and M4 dowels should be used for
mounting to wall.
After closing the upper cover, the
lower and upper covers are xed with
two screws from the place shown in
the picture.
JP2 JP7 Sound Type
Not installed Not installed Police car siren
In 1 and 2 positions Not installed Fire truck siren
In 2 and 3 positions Not installed Ambulance siren
- Installed Machine gun
MOUNTING
5

10
Resetting
The resetting / opening tool (Figure 2) is installed to the section marked in
the photograph. By pressing the tool downwards, the opening of the cover is
supplied (Figure 3).
Figure 1 Reset /
Opening Tool
Figure 2 Figure 3

11
Disabled Assistance Toilet for Receiver
Disabled Assistance Toilet for Transmitter
1
2
The Rope Call Button should be mounted as shown in the picture. While the
Rope Call Button is mounted, its ground clearance should be 2m. In emergency
case, when the red rope with length 1.5m is rstly pulled, the device passes to
alarm state. In alarm state, the device on the exterior door gives continuous
audible and light warnings. When the red rope is secondly pulled, the device
leaves from alarm state and becomes normal. It will get ready for the next
emergency case.
OPERATING
6

V1 06.02.2019
