emaux LED-TP100 Series Manual

1-44-4
REPLACEMENT PARTS
WARNING
!
!
Operating Procedures
LED-TP100 Series Underwater Light
EML I16 022 768
PLEASE READ THE FOLLOWING CAREFULLY AND
KEEP THIS USER MANUAL SAVE FOR FUTURE REFERENCE
DANGER !
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION
This underwater light fixture must be installed by a licensed or certified electrician or a
qualified serviceman in accordance to the requirements of your government standard or
local authorities. Improper installation will create electric hazards which could result in
serious injury, death as well as damage to the property. Before servicing the light,
disconnect the power supply from the circuit breaker. Failure to do so could result in serious
injury, death and or damage to the property.
Never operate this Underwater Light for more than 10 seconds unless it is totally
submerged in water. Without total submersion, the light assembly will get extremely hot,
which may result in serious injury to pool users, installers, or bystanders, or in damage to
property.
Be sure power is off before installing or removing lamp. Allow lamp to cool before
relamping. This light fixture uses a Halogen Quartz lamp. Do Not touch lamp with bare
hand, this may severely reduce its life. Use the plastic furnished with the replacement
lamp to eliminate finger prints from getting on lamp.
Key No.
Part No.
Description
Qty
1
01050119
Lights Face plate
1
2
03011364
M4*12 Screw
1
3
04011109
Bulb plate 12V/8W 198LEDs For white Colour Only
1
3
04011110
Bulb plate 12V/8W 198LEDs For Colour-changing Only
1
3
04011113
Bulb plate 12V/8W 198LEDs For Blue Colour Only
1
4
03011364
M4*12 Screw
2
5
01012005
UL/LED-TP100 Lights Bracket
1
6
03011363
M4*16 Screw
2
7
89040401
UL/LED-TP100 Lights Vinyl pool Fitting
1
8
89040501
LED-TP100 Lights Concrete Pool Fitting
1

2-4
120CM MIN.
WATER LEVEL
6.6CM
23.0CM
RIGID CONDUIT
TO POWER SOURCE;
FEED PARAFFIN
CONCRETE MUST BE CUT BACK
AROUND NICHE TO ALLOW FOR
A COMPACT PLASTER SEAL
45CM MIN. FROM WATER LINE
TO THE EDGE OF THE FACE PLATE
A) Preparatory steps which must be completed by the electrician before light
is installed, see Figure 1.
INSTALLATION
Figure 1.
3-4
Figure 4.
C. Winterizing: Light should be left in place for winterization.
Figure 3.
Figure 2.
DO NOT MOUNT ON:
REVERSE RADIUS
SURFACE
IRREGULAR OR
UNEVEN SURFACES
DO MOUNT ON:
FLAT
SURFACE
WALLS WITH NO TIGHTER
THAN 6 FT. RADIUS AS
VIEWED FROM TOP
X
B) Perform the following steps after the electrical system requirements are met.
1 Locate position on a vertical wall where light is to be installed. The edge of the face plate must be )
45CM below normal water level, see Figure 1.
OPEN
POSITION
LOCK
POSITION
OPEN
POSITION
LOCK
POSITION
Figure 5.
FOR FIBREGLASS POOL, PRE-FAB
MODULAR POOL AND VINYL LINER POOL
FOR FIBREGLASS POOL,
PRE-FAB MODULAR POOL
AND VINYL LINER POOL
FOR CONCRETE POOL
1) Ensure that the electrical system and its wiring for the pool conform to the requirements of your
govenment or your local authorities. The installation of the Underwater Light should only be
performed by a licensed electrician.
a) The junction box, or the low voltage transformer for 12 volt Underwater Light model is to be
located at least 120CM from the edge of the pool, see Figure 1.
b) The light fixture and all metal parts that are within 240CM of the pool must be properly
protected with non-ductile materials and that the connections must be waterproof.
c) The mounting bracket must be properly installed so that the top edge of the Underwater
Light lens is at least 45CM below the surface of the water in the pool, see Figure 1.
2) Consult the local Government Building Department to be certain that the pool's electrical
system meets all applicable requirements.
2) Connect conduit to midst of Mounting Spacer (left of Bracket),see Figure 2.
3) If pool surface is to be plastered, you must allow proper concrete cutback for plaster thickness.
Finish concrete surface must be flush with Mounting Spacer. CAUTION: Finish area surrounding
Mounting Spacer MUST be flat and flush with the face of Mounting Spacer, this ensures a snug
fit between light and wall, see Figure 3.
4) After pool surface is finished, trim the Conduit.
5) Wrap a length of the cord up to a maximum of 2.4mt long on the back of the light assembly.
This extra cord allows you to bring the light out of the pool for relamping and servicing.
6) Connect cord electrical wires at Junction box, through Conduit, be careful not to pull the
75mm-80mm of slack cord at the light through the conduit when connecting the wires.
7) Connect all wires to the corresponding circuit wires in the junction box and feed paraffin.
8) Secure the junction box cover in place.
9) Before operating the light for more than 10 seconds fill pool until the Underwater Light is
completely submerged in water. To check for proper operation turn on main switch or circuit
breaker as well as the switch that operates the Underwater Light itself.
10) Rotating Locking System ensures light is secured to bracket, see Figure 4.(Figure 5.)
