emaux UL-P100 Series Manual

UL-P100 Series Underwater Light
Operating Procedures
DANGER !
1-44-4
REPLACEMENT PARTS
EMLI16022765
Please read the following carefully and
keep this user manual save for future reference
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION
This underwater light fixture must be installed by a licensed or certified electrician or a
qualified serviceman in accordance to the requirements of your government standard or
local authorities. Improper installation will create electric hazards which could result in
serious injury, death as well as damage to the property. Before servicing the light,
disconnect the power supply from the circuit breaker. Failure to do so could result in serious
injury, death and or damage to the property.
Never operate this pool lamp for more than 10 seconds unless it is totally submerged in water. Without total
submersion, the lamp assembly will get extremely hot, which may result in serious injury to pool users, installers,
or bystanders, or in damage to property.
Be sure power is off before installing or removing lamp. Allow lamp to cool before relamping. This light fixture
uses a Halogen Quartz lamp. Do Not touch lamp with bare hand, this may severely reduce its life. Use the
plastic furnished with the replacement lamp to eliminate finger prints pin from the bulb.
lFor use only when immersed in water, IP68
lFor operation only with approved safety isolating transformer: Input:230V Output: 12V~ 75VA
lThe safety isolating transformer must meet the EN61558-2-6 standard lSELV, the safety source shall be installed
outside of Zone 0, 1 and 2. If you want to replacement the lamp, loosen the screw of back cover, open the
back cover and replace the lamp, and carefully fixed gasket seal, re-tightening the screw. The replacement
takes place from the side of the luminaires in contact with the water but after the water of the pool has been
partially or completely drained.
CAUTION: Never try to repair or replace the lamp by yourself. If this underwater light fixture is out of working, it
shall be repaired or replaced by the manufacturer or his service agent or similarly qualified persons in order to
avoid a hazard.
CAUTION: The transparent plastic Protective Shield can not be replaced, if the Protective Shield is cracked,
this underwater light fixture shall be scrapped.
WARNING
Key
No.
Part No.
Description
Qty
1*
01221002
Colour lens (Red+Green+Blue) for P100
1
2
03011321
M5*20 Screw (316#)
1
3
01051059
Face Ring
1
4
01041021
P100 Lights Lens
1
5
03021018
M6 Brass Nut
8
6
01051058
P100 Lights Face plate
1
7
02021004
O-ring
1
8
04011002
Halogen light bulb (Yellow Light)
1
9
89040201
P100 Lights Body set
1
10
03011320
M6*20 Screw (316#)
8
11
04013004
2.5M Cable
1
12
89040203
Concrete Pool Fittingfor P100
1
13
89044501
Vinyl Pool Fitting for P100
1
Notes:1* 01221001 is UL-P100 Light Colour Lens 1 set with (Red+Green+Blue)

1) Ensure that the electrical system and its wiring for the pool conform to the requirements of your govenment or
your local authorities. The installation of the Underwater Light should only be performed by a licensed
electrician.
a) The junction box, or the low voltage transformer for 12 volt Underwater Light model is to be located at least
350cm from the edge of the pool, see Figure 1.
b) The junction boxes shall not be installed in zones 0,1 and 2,where permitted for SELV circuits.
c) Terminal blocks must meet the IEC60988-2-1 standard having the rated connecting capacity of 1.5mm2 use
of screw-type terminal at least 25A rated current , mounted on junction boxes inside. See Figure 0
d) The light fixture and all metal parts that are within 350cm of the pool must be properly protected with non-
ductile materials and that the connections must be waterproof.
e) The mounting bracket must be properly installed so that the top edge of the Underwater Light lens is at least
45cm below the surface of the water in the pool, see Figure 1.
2) Consult the local government Building Department to be certain that the pool's electrical system meets all
applicable requirements.
3-4
C) Winterizing: The luminaire should be left in place for winterization.
2-4
350CM MIN.
WATER LEVEL
6.6CM
29.6CM
RIGID CONDUIT
TO POWER SOURCE;
FEED PARAFFIN
CONCRETE MUST BE CUT BACK
AROUND NICHE TO ALLOW FOR
A COMPACT PLASTER SEAL
45CM MIN. FROM WATER LINE
TO TOP OF LENS
A) Preparatory steps which must be completed by the electrician before light
is installed, see Figure 1.
INSTALLATION
Figure 1.
Figure 3.
Figure 2.
DO NOT MOUNT ON:
REVERSE RADIUS
SURFACE
IRREGULAR OR
UNEVEN SURFACES
DO MOUNT ON:
FLAT
SURFACE
WALLS WITH NO TIGHTER
THAN 6 FT. RADIUS AS
VIEWED FROM TOP
MOUNTING BRACKET
CONDUIT
LIGHT
Figure 4.
O P E N
P O S I T I O N
L O C K
P O S I T I O N
F O R C O N C R E T E P O O L
O P E N
P O S I T I O N
L O C K
P O S I T I O N
Figure 5.
F O R F I B R E G L A S S P O O L ,
P R E - F A B M O D U L A R P O O L
A N D V I N Y L L I N E R P O O L
1 Locate position on a vertical wall where light is to be installed. The top of the light lens must be 45cm below
normal water level, and maximum depth for luminaire is 2.5m, see Figure 1.
2) Connect conduit to midst of Mounting Spacer (left of Bracket), see Figure 2.
3) If pool surface is to be plastered, you must allow proper concrete cutback for plaster thickness. Finish
concrete surface must be flush with Mounting Spacer. CAUTION: Finish area surrounding Mounting Spacer
MUST be flat and flush with the face of Mounting Spacer, this ensures a snug fit between light and wall, see
Figure 3.
4) After pool surface is finished, trim the Conduit.
5) Wrap a length of the cord up to a maximum of 3.5mt long on the back of the light assembly.
6) Connect cord electrical wires at Junction box, through Conduit, be careful not to pull the 75mm-80mm of
slack cord at the luminair through the conduit when connecting the wires.
7) Connect all wires to the corresponding circuit wires in the junction box and feed paraffin.
8) Secure the junction box cover in place.
9) To check for proper operation, turn on main switch or circuit breaker.
10) Rotating Locking System ensures light is secured to bracket, see Figure 4.
11) Before operating the lamp for more than 10 seconds fill pool until the pool luminair is completely submerged
in the water.
12) The flexible cable of this luminaire cannot be replaced, if the cord is damaged, the luminaire shall be
destroyed.
)
B) Perform the following steps after the electrical system requirements are met.
Figure 0.
