emaux E-Lumen X User manual

Keep this Manual for futrue reference
E-Lumen X
Retrofit Underwater Light
INSTRUCTION MANUAL

2
WARNING ------------------------------------------------------ 2
PRODUCE DESCRIPTION ------------------------------------------ 3
CONTROL ------------------------------------------------------ 4
INSTALLATION NOTES -------------------------------------------- 5
INSATALLATION ------------------------------------------------- 7
MAINTENANCE AND TROUBLE SHOOTING -------------------------- 11
REPLACEMENT PARTS ------------------------------------------- 12
CONTENTS

Please read the manual carefully before commencing installation. This manual
contains important information about the correct installtion and operation of E-
Lumen X lights.
—Before
·Only qualified electrician is allowed to carry out the installation of this product.
·Avoid direct contact with electrical power.
·Respect all regulations in effect for preventing accidents.
·All units are required to be disconnected from the main electricity before any
operation of maintenance.
·For safe and proper installation,ensure that those parts supplied with the produce
are used.
·Never handle with wet hands and feet.
·This unit is design for use only when fully submerged in fresh water, connecting with a
safety transformer
·This product should be installed according to your local electrical installation
ordinances and regulations.
·Due to the corrosive natrue of unbalanced pool chemicals, please keep you pool
water is acid-base balanced prior to instaiiation, and ensure the longevity of these
lights.
·If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in
order to avoid a hazard.
—Use
·Check that there is enough cable behind light to allow for servicing above water,
preferably at ground-level pool-side.
·Never operate this Underwater Light for more than 1 minute unless it is totally
submerged in water.
·You lights require cleaning at any time,be sure to a mild detergent or other ways
that don't damage to the lights.
·Be sure power is off before installing or removing LED plate. Allow LED plate to cool
before replacing.
·Maximum Depth for Light installation at 1.2 meter.
·Maximum Water Temperature Range for light operation 0 - 25°C
WARNING
3

—SPECIFICATION
PRODUCT DESCRIPTION
Electrical Specification :
1) Standard Voltage : AC12-32V
2) Frequency : 50/60Hz
3) Power : 25W
4) Mode of operation : ON/OFF Mode or E-Direct control box
—COLOR CHANGE
NO. Mode Description
1
2
White Cool White
Green Single Green
3
4
Blue Single Blue
Green+Blue cyan
5
6
7
Red+Green Pink
Red+Green+Blue purple
Mode A: Blue+ Gradual Red Blue>Red
8
9
10
11
12
13
14
Mode B: Green+Gradual Red Green>Red
Mode C: Blue+Gradual Green Blue>Green
Mode D: RGB Colour Sequence G>B>B+G>G+R>R+B>R+G+B(P)>W>R
Mode E: RGB Colour Sequence R>G>B>B+G>G+R>R+G+B(P)>W
Mode F: Auto Colour Change Slowly Change
Mode G: RGB Colour Sequence R>R+G>G>G+B>B>R+G+B(P)
Mode H:Rapid Auto Colour Change Rapid Change
15 Warn Warn White
4

1) When the light is connected to the transformer directly, the on/off switch controls
the colour changes (Associating a light with a transformer and an on/off switch is
recommended; If you want all the lights to change colour at the same time, install
a master switch, Figure 1).
2) If applicable, when the light is connected to the transformer and the transformer
to the optional control box, the control panel on the control box and its remote
control controls the colour changes (See the Control Box Manual for details).
Attention: It is the light with ON/OFF mode and control mode of E-Direct. The light
auto detect E-Direct control box. When light is connected to E-Direct
Control Box, you can choose a particular color and adjust light brightness
by E-Direct remote.
CONTROL
Figure 1
Light Light Light
5

1) The light have retrofit. You should follow the procedures closely when installing the light.
2) It is recommended to install a light every 20㎡, the approximate exposure area of each
unit.
3) The lights should be installed in the direction that they will not shine directly into the house.
4) For training or competition pools, the lights must be installed on the sides in order to
prevent swimmers from seeing any glare.
5) Nothing should be placed on the poolside directly above the lights for ease of future
maintenance.
6) If the wires are connected inside the lights, you must seal the connections with leak-
proof tapes or products with the same function.
7) The cables connecting the lights and the transformers must be at least 6mm2 and
the distance between them must not exceed 30m (Figure 2); otherwise the lights will
not function properly.
8) Terminal blocks must meet the IEC60988-2-1 standard having the rated connecting
capacity of 4,0mm² use of screw-type terminal at least 25A rated current , mounted
on junction boxes inside. See Figure2-1.
INSTALLATION NOTES
Figure 2-1
Light
Transformer
≤30m
Figure 2
AC 12V
Screw Type
Terminal
Lamp
6

A) Preparing to Install
1)Before installation,a circuit system diagram must be designed by a certified
engineer.
2)The circuit system must comply with local laws and regulations and must be
carried out by qualified electricians.
3)Make sure the voltage is 12-32V and the terminal box is at least 120cm from
the poolside (Figure 3) .
4)Upon installation,top of the light must be at least 45cm from water surface
(Figure 3).
5)Switch off the Pool lighting system power.
INSATALLATION
B) Installation Guide of Retro-fit connector
1)Unscrew the existing light and pull out from the pool.
2)The existing cable as close to the light as possible to reserve enough length
for replacement light.
3)Remove the power cable coating recommended length.Figure 4
Figure 4
Figure 3
Junction box 120cm min.
Water level
45cm min. from water
line to top of lens
29.6cm
6.6cm
Concrete must be cut backaround
niche to allow fora compact plaster
seal
Rigid conduit
12mm
5mm
7

4)Assemble Retrofit connector.First,the cable thru Nut,Washer,Pressing Base
in order(Attention: there are five sized stoppers),Connector Housing.Put Two
sized O-Ring to Connector Housing.And insert two Copper Pins to Connector
Internal,the power cable is thrued Copper Pins and hold it tight by the screws.
Pull the cable back and Tighten Nut,the front face is keeped the frush for
Connector Housing and Connector Internal.Figure 5
Figure 5
5) Insert Four screws to screw holes of Pressing Base.Figure 6
6) Plug the connector into the light connection interface tight and tight the four
screws. Figure 7
Figure 6 Figure 7
2*Screws
Connector
Housing
4*Screws
Washer
Nut
Stopper
O-Ring
Compacting Base
Connector
Internal
2XCopper Pins
8

C) Vinyl Pool Installation and Retro-Installation
1) Retro plate into the concrete wall or install on other part , making sure that it is parallel
to the side of the pool. Or Retro Plate install on other types plate,and relpace other
lights. (Figure 8).
2) Place the Mounting Plate on the concrete wall and tighten it with 4 screws. The
conduit must be next to the Mounting Plate (Figure 9).
3) Note that the light must only be installed on a flat or concave surface.
4) Wrap extra cables behind the light to make sure it could be taken to the pool
surface for future maintenance (Figure 10).
5) Hang the light onto the Mounting Plate and tighten the screws (Figure 11).
6) The wire connections inside the terminal box must be sealed by leak-proof tapes
to prevent water from leaking into the terminal box through the cables.
Figure 8 Figure 9
Figure 10 Figure 11
9

D) Fiberglass Pools / Vinyl Pools Installation
1) Refer to section "Preparing to Install”.
2) Make 2 holes on the pool wall (Figure 12).
3) Place the o-rings between the Mounting Plate and the pool wall and tighten it
with the Nut on the other side of the pool wall (Figure 13).
4) Put the cable sequentially through the sealing Nut, the sealing O-ring and the
cable hole on the mounting plate; then tighten the Nut (Figure14).
5) Wrap extra cables behind the light to make sure it could be taken to the pool
surface for future maintenance. Then, hang the light onto the Mounting Plate
and tighten the screws (Figure 15).
Figure 12 Figure 13
Figure 14 Figure 15
147,5
2X?24
Mounting
plate
O-ring
Nut
10

1) Do not leave the lights “on” above water for longer than 1 minute.
2) Do not leave the lights directly under sunlight. Fill the pool with fresh water as soon as
possible after the lights are installed.
3) Before switching on the lights, check whether the lights are fully submerged
underwater and the circuit boxes are running properly.
4) This unit does not need any kind of maintenance. If it is not working properly, please
contact EMAUX authorized dealer where you purchase the unit from.
5) Warranty will be voided if the Emaux Underwater Light was dismantled by unauthorized
personnel.
MAINTENANCE AND TROUBLE SHOOTING
Trouble Possible Solution
The light is dim
Check voltage of transformer.
Check brightness control of remote if it connects,
D-E-Direct control box.
The light isnot work
After power on , Light up
and not lit a few seconds
Check connected locations of the cable.
Check fuses at switchboard.
Replace light panel.
Contact qualified electrcian to test.
Check transformer.
Contact qualified electrcian to test.
11

REPLACEMENT PARTS
The light is dim
Item No. Part No. Description Qty
1
2
3
03011058
440256797
White Plastic Lid
Gray Plastic Lid
Blue Plastic Lid
Stainless Steel Lid
E042601 20 LEDs Panel 25W Color
440526797
4Fastener
53011364 M4*12 Flat head self-tapping screw
6
7
E042602
E042603
Retro-fit connector
Retro Pool Fitting
1
1
1
4
4
1
1
1
1
1
Pool Fitting
1
2
3
4
5
6
3
12
