iCamera Switch #6002
USER’S GUIDE
50 Broadway
Hawthorne, NY 10532
Tel. [phone] / Fax [phone]
Toll Free 800.832.8697
www.enablingdevices.com

Say cheese!
Say cheese!Say cheese!
Say cheese!
We’ve created a switch activated shutter control interface for taking
photos on your iPhone, iPad and iPod (with camera . Simply plug
your capability switch into the compact iCamera Interface and attach
the Interface to your iPhone, iPad or iPod. Great compact design.
Now picture taking is accessible to all. Size: 1½"W x 1½"L x ¾"H.
Weight: 1 oz.
Operation:
Operation:Operation:
Operation:
1. Plug the iCamera Switch Adapter into the earphone port on your
iPhone, iPad or iPod. Next connect any external capability switch
via the 1/8" jacks. If you need to use a ¼ " to 1/8" adapter for
your switch, it must be a mono adapter, not stereo. Make sure
that the connections between the external capability switch and
the adapter (if applicable and the jack are plugged in all the
way, there should be no gaps.
2. Next launch the camera app on your iDevice. Each time you
activate your switch it will take a photo.
3. Please Note:
Please Note:Please Note:
Please Note: If you switch to video mode on your iDevice, any
video you record using the iCamera Switch Adapter will have no
audio. This adapter is meant for taking photos only.
Troubleshooting:
Troubleshooting:Troubleshooting:
Troubleshooting:
Problem:
Problem:Problem:
Problem: The iCamera Switch Adapter fails to operate, or operates
incorrectly.
Action
ActionAction
Action:
::
: Make sure that you have your iCamera Switch Adapter
plugged into to your iDevice properly, and your capability switch is
plugged into the iCamera Switch Adapter all the way, there should be
no gaps in the connection.
Care of the Unit:
Care of the Unit:Care of the Unit:
Care of the Unit:
The iCamera Switch Adapter can be wiped clean with any household
multi-purpose, non-abrasive cleaner and disinfectant. We
recommend Simple Green, which is a non toxic biodegradable all-
purpose cleaner.
Do not use
Do not useDo not use
Do not use abrasive cleaners, as they will scratch the surface of the
unit.
Do not submerge
Do not submergeDo not submerge
Do not submerge the unit, as it will damage the electrical
components.
Rev
Rev Rev
Rev 6
