Endress+Hauser analytikjena multi N/C 2100 User manual

Operating Manual
multi N/C 2100
TOC/TNbAnalyzer

Analytik Jena AG
Konrad-Zuse-Str.1
07745 Jena Germany
Phone + 49 3641 / 77 70
Fax + 49 3641 / 77 92 79
Email [email protected]
Analytik Jena AG
Konrad-Zuse-Str. 1
07745 Jena Germany
Phone + 49 3641 / 77-7407 (Hotline)
Email [e-mail]
http://www.analytik-jena.com
multi N/C and multiWin are registered trademarks of Analytik Jena AG in Germany.
Microsoft and Windows are registered trademarks of Microsoft Corp.
The identification with ® or TM is omitted in this manual.
11-0109-003-23
02.17
Analytik Jena AG
© Copyright 2017, Analytik Jena AG
Manufacturer
Service
General information
Copyrights and
Trademarks
Documentation number
Edition
Implementation of the
Technical Documentation

Index of Figures
multi N/C 2100 Edition 02.17 i
Table of Contents
1Basic information.......................................1
1.1 User manual notes ........................................1
1.2 Intended use..................................................1
1.2.1 General..........................................................1
1.2.2 Analyzer area of application .......................... 2
1.3 Warranty and liability .....................................3
2Technical data............................................4
3Safety instructions ....................................6
3.1 Standards and directives ............................... 6
3.2 Symbols and signal words used ....................7
3.3 Safety markings on the analyzer ...................7
3.4 Technical condition........................................8
3.5 Requirements for the operating personnel ....8
3.6 Safety instructions, transport and installation 9
3.7 Safety instructions - operation ..................... 10
3.7.1 General........................................................10
3.7.2 Safety instructions - protection against
explosion and fire ........................................ 10
3.7.3 Safety instructions - electrical equipment .... 10
3.7.4 Safety instructions for compressed gas
containers and systems............................... 11
3.7.5 Handling of auxiliary and operating
materials......................................................11
3.7.6 Safety instructions - service and repair........12
3.8 Behavior in an emergency...........................13
4Technical description..............................14
4.1 System design............................................. 14
4.1.1 Components for sample preparation ...........15
4.1.1.1 TIC lock .......................................................15
4.1.1.2 TC lock ........................................................ 15
4.1.1.3 Microliter syringes........................................15
4.1.2 Hose system................................................ 16
4.1.2.1 Components for flow adjustment .................18
4.1.2.2 Condensate pump .......................................18
4.1.2.3 Connection method .....................................19
4.1.3 Combustion system ..................................... 20
4.1.4 Components for gas drying and cleaning ....20
4.1.4.1 Condensation coil ........................................20
4.1.4.2 TIC condensate container ........................... 21
4.1.4.3 Water traps..................................................22
4.1.4.4 Halogen trap................................................ 22
4.1.5 Detectors..................................................... 23
4.1.5.1 NDIR detector ............................................. 23
4.1.5.2 Electrochemical NO detector
(ChD, optional)............................................ 23
4.1.6 Indicator and control elements,
connections................................................. 24
4.1.7 Accessories................................................. 25
4.1.8 Extension options for the analyzer .............. 26
4.1.8.1 Sampler (optional)....................................... 26
4.1.8.2 External solids module (optional) ................ 26
4.1.8.3 Double furnace solids module (optional) ..... 26
4.1.8.4 TIC solids module (optional) ....................... 26
4.2 Principle of operation .................................. 27
4.3 Measuring method ...................................... 28
4.3.1 TC analysis ................................................. 28
4.3.2 TOC analysis .............................................. 28
4.3.3 TIC analysis ................................................ 29
4.3.4 NPOC analysis............................................ 29
4.3.5 NPOC analysis according to the
NPOC plus method ..................................... 29
4.3.6 TNbanalysis ................................................ 30
4.4 Catalysts ..................................................... 30
4.5 Calibration................................................... 31
4.5.1 Calibration strategies .................................. 31
4.5.1.1 Multiple point calibration with constant
sample volume............................................ 31
4.5.1.2 Single point calibration ................................ 31
4.5.2 Daily factor .................................................. 31
4.5.3 Calibration method in multiWin ................... 31
4.5.3.1 TC/NPOC.................................................... 32
4.5.3.2 TIC .............................................................. 32
4.5.3.3 TOC (Diff).................................................... 33
4.5.3.4 NPOC plus .................................................. 33
4.5.3.5 Calibration TNb............................................ 33
4.5.4 Method characteristics ................................ 34
4.5.5 Other calculations ....................................... 35
4.6 Blank values................................................ 35
4.6.1 Blank water values ...................................... 35
4.6.1.1 Water for preparing standard solutions
preparation water blind value ...................... 35
4.6.1.2 Water for diluting solutions diluting
blind value................................................... 36

Index of Figures
ii Edition 02.17 multi N/C 2100
4.6.1.3 Eluate blank value....................................... 37
4.6.2 Boat blank value.......................................... 37
5First commissioning................................38
5.1 Site requirements ........................................ 38
5.1.1 Installation conditions.................................. 38
5.1.2 Space requirement...................................... 38
5.1.3 Power supply............................................... 39
5.1.4 Gas supply .................................................. 39
5.2 Unpacking and installing the analyzer......... 39
6Connecting add-on devices ....................40
6.1 Sampler APG 60 ......................................... 40
6.2 External solids module ................................ 42
7Operation ..................................................43
7.1 General information on analysis work ......... 43
7.2 Switching on the analyzer (standard
commissioning) ........................................... 44
7.3 Carrying out the calibration ......................... 45
7.3.1 Preparing and starting the calibration.......... 45
7.3.2 Displaying calibration results....................... 48
7.3.3 Editing an existing calibration...................... 49
7.3.4 Transferring calibration parameters to a
method ........................................................ 51
7.3.5 Managing calibration data ........................... 53
7.4 Performing measurements.......................... 54
7.4.1 Measurement with manual sample supply .. 54
7.4.2 Measurement with sampler ......................... 55
8Maintenance and care .............................57
8.1 Maintenance intervals ................................. 57
8.2 Adjustment and setup tasks ........................ 59
8.2.1 Adjust the sampler ...................................... 59
8.2.1.1 Adjust position 1 / furnace position.............. 59
8.2.1.2 Adjusting the piston position ....................... 60
8.2.2 Adjust the NPOC purge flow ....................... 61
8.3 Replacing the water traps ........................... 63
8.4 Replacing the halogen trap ......................... 65
8.5 Exchanging the catalyst .............................. 66
8.5.1 Lifetime of the catalyst ................................ 66
8.5.2 Removing the combustion tube................... 66
8.5.3 Filling the combustion tube ..........................67
8.5.4 Inserting the combustion tube......................69
8.6 Regenerating the TIC reactor ......................71
8.7 Cleaning the TC condensate vessel ............71
8.8 Maintaining the condensation coil................72
8.8.1 Removing and cleaning the
condensation coil .........................................72
8.8.2 Installing the condensation coil ....................74
8.9 Removing and installing the combustion
furnace.........................................................75
8.9.1 Removing the combustion furnace ..............75
8.9.2 Installing the combustion furnace ................76
8.10 Removing and replacing the pump hose .....77
8.11 Replacing the hose connections ..................78
8.12 Replacing the septums ................................80
9Troubleshooting...................................... 81
9.1 General information .....................................81
9.2 Error messages in multiWin.........................82
9.3 Status errors – indications in the System
state window................................................86
9.4 Equipment faults and analytical problems ...86
10 Transport and storage ............................ 91
10.1 Transport .....................................................91
10.1.1 Preparing the analyzer for transport ............91
10.1.2 Transport notes............................................92
10.1.3 Moving the analyzer in the laboratory ..........92
10.2 Storage ........................................................93
10.3 Recommissioning after transport or
storage.........................................................93
10.3.1 Assembling the analyzer after transport or
storage.........................................................93
10.3.2 Connecting the analyzer ..............................94
11 Disposal ................................................... 96
11.1 Waste water.................................................96
11.2 Halogen trap ................................................96
11.3 Catalyst........................................................96
11.4 Analyzer.......................................................96

Index of Figures
multi N/C 2100 Edition 02.17 iii
Index of Figures
Fig. 1 Front view (doors open)............................14
Fig. 2 Lateral view left (side wall removed)......... 15
Fig. 3 TC lock at the top of the device ................15
Fig.4 Hose diagram ...........................................17
Fig.5 Needle valve for adjusting the carrier gas
flow ...........................................................18
Fig.6 Needle valve for adjusting the NPOC
purging flow (see arrow) ........................... 18
Fig.7 Condensate pump ....................................19
Fig.8 Different Fast connector designs ..............19
Fig.9 Finger-tight screw connection................... 19
Fig.10 Combustion furnace (see arrow) ..............20
Fig.11 Condensation coil ..................................... 21
Fig.12 TIC condensation module......................... 21
Fig.13 Water traps ...............................................22
Fig.14 Halogen trap .............................................22
Fig.15 LED to indicate readiness for operation....24
Fig.16 LED strip (right door open) ....................... 24
Fig.17 Connections on the rear of the device ......25
Fig.18 Principle of operation ................................ 27
Fig.19 APG 60 mounted on the analyzer
multi N/C 2100.......................................... 40
Fig.20 Media connections on the backplate of the
solids module ........................................... 42
Fig.21 Window Calibration - Data of new
calibration................................................. 46
Fig.22 Window Current sample data
(with sampler operation)........................... 47
Fig.23 Window Calibration - Data of new
calibration................................................. 48
Fig.24 Disabling individual measured values
of a calibration.......................................... 50
Fig.25 Window Link to Method ............................ 51
Fig.26 Window Link with method with three
areas ........................................................ 53
Fig.27 Window Selection calibration report ......... 54
Fig.28 Adjusting the syringe piston ..................... 61
Fig. 15 Water traps on the left-hand side of the
analyzer.................................................... 64
Fig.30 Angled FAST connector with connected
hose ......................................................... 79
Fig.31 Replacing the finger-tight connection ....... 79
Fig. 32 Mains connection and gas connections
at the multi N/C 2100................................ 94

Index of Figures
iv Edition 02.17 multi N/C 2100

Basic information
multi N/C 2100 Edition 02.17 1
1 Basic information
1.1 User manual notes
The analyzer multi N/C 2100 is intended for operation by qualified specialist personnel ob-
serving this user manual.
The user manual contains information about the design and operation of the analyzer and
provides personnel familiar with TC/TN analysis the necessary know-how for the safe han-
dling of the equipment and its components. The user manual also includes notes on the
maintenance and service of the equipment and potential causes and remedies of any faults.
This user manual describes the basic device multi N/C 2100.
Conventions
Instructions for action which occur in chronological order are numbered and combined into
action units and furnished with the corresponding results.
Lists which are not in chronological order are shown as itemized lists, sub-listings as bullet
points.
Safety notes are indicated by pictographs and signal words. The type and source of the
danger as well as the consequences are stated together with notes on preventing the dan-
ger. The meaning of the pictographs and signal words used is explained in the chapter
"Safety notes".
The elements of the control and analysis software are indicated as follows:
Menu commands, buttons, options etc. are formatted in bold.
Menu commands of a command sequence are separated by slashes (/), e.g., Meth-
od / Edit.
Window names are shown in bold italics, e.g., Measurement window.
Buttons are marked with square brackets, e.g., [Save].
1.2 Intended use
1.2.1 General
The analyzer multi N/C 2100 is a device for determining the total carbon content and/or total
nitrogen content in aqueous samples by way of digestion using thermocatalytic high temper-
ature oxidation in the presence of special catalysts in accordance with national and interna-
tional standards.
When using the integrated solids module or connecting an external solids module, the ana-
lyzer can be used to determine the total carbon content in small solids samples.
The analyzer multi N/C 2100 must only be used for the methods for the determination of the
total carbon and/or the total nitrogen content in aqueous samples as described in this user
manual and in conjunction with an external solids module for the determination of the total
carbon content of solid samples. Any other use is not as intended! Only the operator is liable
for any damage that results from such use.
In particular it is prohibited to use the analyzer to analyze flammable liquids or substances
that could form explosive mixtures. No concentrated acids may be analyzed with the analyz-
er.
The device must only be operated with synthetic air or oxygen as the carrier gas.

Basic information
2 Edition 02.17 multi N/C 2100
The operational safety of the analyzer multi N/C 2100 is only ensured during proper use
according to the information in this user manual. The intended use also includes the adher-
ence to the installation conditions prescribed by Analytik Jena AG which are available from
the customer service address stated above.
1.2.2 Analyzer area of application
The analyzer multi N/C 2100 is versatile in its application due to its large measuring range,
high degree of automation and expandability.
Water treatment
The multi N/C 2100 is especially suitable for use in wastewater analysis in communal and
industrial treatment systems. Complex and saline water bodies can also be safely analyzed.
Environmental monitoring
The analysis of contaminated surface water, which often has a low TOC content and high
TIC concentrations as well as high salt content, is possible using special analysis modes
(see section "NPOC analysis according to the NPOC plus method" p. 29).
Waste and soil
Carbon determination (TC/TOC determination) in solid samples is possible with the exten-
sion of the multi N/C 2100 by the solids module HT 1300. Eluates can also be analyzed effi-
ciently due to the possibility of simultaneous TC/TNbdetermination in liquid samples.
Research and teaching
Due to the many specific configuration options, the multi N/C 2100 is suitable for use in
teaching and research. In conjunction with a solids module the TC in solids can be deter-
mined.

Basic information
multi N/C 2100 Edition 02.17 3
1.3 Warranty and liability
The warranty duration and liability comply with the legal requirements and the provisions in
the general terms and conditions of Analytik Jena AG.
Deviations from the intended use described in this user manual will result in limitations of
warranty and liability in the event of damage. Damage to wear parts is not included in the
warranty.
Warranty and liability claims for personal injury and property damage are excluded if they
were caused by one or several of the following reasons:
use of the analyzer multi N/C 2100 other than intended
improper commissioning, operation and service of the analyzer
modifications of the equipment without prior consultation with Analytik Jena AG
unauthorized intervention in the equipment
operation of the device with faulty safety equipment or improperly fitted safety and
protection equipment
inadequate monitoring of the equipment components subject to wear
use of other than original spare parts, wear parts or consumables
improper repairs
faults due to the non-observance of this user manual

Technical data
4 Edition 02.17 multi N/C 2100
2 Technical data
General characteristics
Designation/type Analyzer multi N/C 2100
Dimensions Basic device (W x H x D) (513 x 464 x 540) mm
Mass approx. 28 kg
Procedural data
Digestion principle Thermocatalytic oxidation
Digestion temperature up to 950°C, depending on the catalyst
Catalyst
−for liquid samples
−for internal solids module
Pt(Al2O3) for multi N/C
CeO2 (special catalyst for multi N/C)
Measuring method TC, TIC, TOC (differential method), NPOC,
TNb(optional)
Carbon detection NDIR (coupled with VITA method)
Nitrogen detection (optional) ChD
Sample volumes 50 – 500 µl
Particle handling capacity According to DIN EN 1484
only for syringes suitable for particles
Sample feed Direct injection
Gas supply
(carrier gas /NPOC auxiliary
gas/auxiliary gas for injector
lock)
Synthetic air (free of HC, free of CO2)
Synthetic/Purified air can be supplied from gas
cylinders or after clean-up of pressurized air by a
TOC gas generator.
Purity specifications to be met: CO2< 1 ppm
Hydrocarbons < 0,5 ppm (as CH4)
Supply pressure: min. 5 bar (72 psi)
Provided flow rate: min. 300 ml/min
or
oxygen (at least 4.5)
preliminary pressure 4 – 6 bar
Gas consumption:
in total
measuring gas flow
purge flow
measuring gas flow for internal
solids module (optional)
approx. 15 l/h, dependent on the measuring mode
160 ± 10 ml/min
approx. 50 – 160 ml/min
400 ± 10 ml/min
Control/analysis (control and
analysis software multiWin)
Real-time graphics, status indication during analysis,
graphical display of the measured results, result print-
out
Electrical variables
Connection 230 V AC, optionally 115 V AC, 50/60 Hz
Protection 230 V: T 6.3 A H, 115 V: T 6.3 A H
(Use only original fuses of Analytik Jena AG)
Average power consumption 400 VA
PC interface USB 2.0

Technical data
multi N/C 2100 Edition 02.17 5
Environmental conditions
Temperature during storage 5 – 55°C
Temperature during operation 10 – 35°C
Humidity during operation max. 90% at +30°C
Humidity during storage 10 – 30% (use drying agent)
Air pressure 0.7 – 1.06 bar
Minimum equipment for the control and analysis unit
Operating system: Windows 7 Professional or higher
Processor: Intel Core I3 or higher
Working memory: 4 GB
Free hard disk space: 40 GB
Drive: CD-ROM drive (for software installation)
Monitor resolution: min. 1024 x 768
Interfaces USB 2.0

Safety instructions
6 Edition 02.17 multi N/C 2100
3 Safety instructions
For your own safety and to ensure error-free and safe operation of the analyzer
multi N/C 2100, please read this chapter carefully before using the appliance.
Observe all safety notes listed in this user manual and all messages displayed by the control
and analysis software on the monitor.
3.1 Standards and directives
Safety class and safety type
The analyzer belongs to protection class I. The casing has protection class IP 20.
Device safety
The analyzer conforms to the safety standards
EN 61010-1
EN 61010-2-081
EN 61010-2-010
EN 61010-2-051 (for operation with sampler)
EMC compatibility
The analyzer has been checked for interference emission and resistance.
It meets the requirements for interference emission of
EN 61326-1 (EN 55011 Group 1, Class B)
It meets the requirements of interference resistance of
EN 61326-1 (requirements for use in basic electromagnetic environments)
Environmental compatibility
The analyzer has been tested for environmental compatibility and meets the requirements of
ISO 9022-3
ISO 9022-2
EU directives
The analyzer is built and tested according to standards that meet the requirements of EU
directives 2014/35/EU and 2014/30/EU. The analyzer leaves the factory in a sound condition
as far as technical safety is concerned. To maintain this condition and to ensure safe opera-
tion, the operator must strictly observe the safety and operating instructions contained in this
manual. For accessories which have also been supplied, and system components from other
manufacturers, their operating instructions should be referred to.

Safety instructions
multi N/C 2100 Edition 02.17 7
Chinese directives
The analyzer contains regulated substances (according to directive SJ / T 11363-2011).
Analytik Jena AG guarantees that these substances will not leak out during the next 25 years
if the analyzer is used in accordance with its intended use and thus do not pose a threat to
the environment or health within this period.
3.2 Symbols and signal words used
The user manual uses the following symbols and signal words to indicate hazards or instruc-
tions. The safety instructions are always placed before an action.
WARNING
Indicates a potentially hazardous situation.
If it is not prevented, death or serious injuries (incapacitation) may result.
CAUTION
Indicates a potentially hazardous situation.
If it is not prevented, minor or moderate injuries and material damage may result.
CAUTION! HOT SURFACE!
Touching the hot surface can cause burns.
WARNING! DANGER OF ELECTRIC SHOCK IF TOUCHED!
IMPORTANT
Indicates application hints and other especially useful information without any resulting
hazardous or damaging situations.
ENVIRONMENTAL PROTECTION
Indicates application hints and information to aid the proper disposal and handling of the
substances and materials used.
3.3 Safety markings on the analyzer
Safety symbols have been attached to the analyzer and accessories whose content must
always be observed.
Damaged or missing safety symbols can cause incorrect actions leading to personal injury or
material damage! The safety symbols must not be removed! Damaged safety symbols must
be replaced without delay!
The following safety symbols have been attached to the analyzer and accessories:

Safety instructions
8 Edition 02.17 multi N/C 2100
Fire, naked flame and smok-
ing prohibited!
Warning against dangerous
electrical voltage
Warning against hazardous
substances
Warning against hot surface Warning against corrosive
substances
The device contains restricted substances (according to di-
rective SJ/T 11363-2011). Analytik Jena AG guarantees, that
those hazardous substances may not leak out during the next
25 years when the device is used in accordance with its in-
tended purpose.
3.4 Technical condition
The analyzer corresponds in its design and construction to the current state-of-the-art tech-
nology. Unauthorized modifications or changes, especially such that affect the safety of the
staff and the environment, are not allowed.
The following has to be observed:
Any manipulation of the safety equipment is prohibited!
In the event of an accident, manipulations of the safety equipment will be interpreted
as deliberate!
The operator must only operate the analyzer in a sound and operationally safe con-
dition. The technical condition must always comply with the legal requirements and
regulations.
Prior to every use, the analyzer must be checked for damage and sound condition.
Any changes in the analyzer affecting its safety must be reported by the operating
personnel to the operator without delay.
The equipment components must only be connected to supply cables intended and
designed for this purpose.
All safety equipment and locking devices must be well accessible and regularly
checked for proper operation.
3.5 Requirements for the operating personnel
The analyzer multi N/C 2100 must only be operated by qualified specialist personnel in-
structed in the use of the analyzer. The instruction must also include conveying the content
of this user manual and the user manuals of other system components or add-on equipment.
The analyzer may pose a danger if it is not used by trained personnel, improperly or other
than intended.

Safety instructions
multi N/C 2100 Edition 02.17 9
Therefore, every person entrusted with the operation of the analyzer must have read and
understood this user manual and the user manuals of any additional equipment before carry-
ing out the respective tasks. This also applies if the respective person has already worked
with or been trained on this kind of analyzer.
It is recommended that the operator have the operating personnel confirm their knowledge of
the content of the user manual in writing. Ultimate responsibility for the accident-free opera-
tion of the analyzer rests with the operator or the specialist personnel authorized by him.
In addition to the safety at work instructions in this user manual, the generally applicable
safety and accident prevention regulations of the respective country of operation must be
observed and adhered to. The operator must ascertain the latest version of these regula-
tions.
The user manual must be accessible to the operating and service personnel at all times!
The following has to be observed:
The analyzer must only be commissioned, operated and serviced by trained person-
nel instructed in technical safety.
The operation or servicing of the analyzer by minors or individuals under the influ-
ence of alcohol, drugs or medication is not permitted.
It must be ensured that only authorized personnel works at the analyzer.
The operating personnel must be familiar with the dangers arising from the measur-
ing liquids. The appropriate protective equipment must be used.
Prior to pauses or at the end of work, appropriate skin cleaning and protection
measures must be carried out.
Eating, drinking, smoking or handling open flames in the operating room of the ana-
lyzer is prohibited!
3.6 Safety instructions, transport and installation
The analyzer is always installed by the Analytik Jena AG customer service department or its
authorized and trained specialist personnel. Independent assembly and installation are not
permitted. Incorrect installation can create serious hazards.
The following has to be observed:
Insufficiently secured components pose a risk of injury! During transport, the compo-
nents of the equipment must be secured in accordance with the instructions in the
user manual.
Only transport the analyzer in its original packaging! Ensure that the transport secur-
ing devices have been fitted and the analyzer is completely empty.
To prevent damage to health, the following must be observed when moving the ana-
lyzer in the laboratory (lifting and carrying):
−For reasons of safety, 2 persons are required to transport the analyzer who must
position themselves on both sides of the equipment.
−Because the analyzer does not have any handles, firmly grip the device from the
bottom and make sure prior to simultaneous lifting the device that the sensitive
components at the front are protected by the closed doors.
−The guide values and statutory limits for lifting and carrying loads without auxiliary
equipment must be observed and adhered to.

Safety instructions
10 Edition 02.17 multi N/C 2100
3.7 Safety instructions - operation
3.7.1 General
The operator of the analyzer must make sure before each commissioning that the condition
of the analyzer including the safety equipment is sound. This applies in particular after each
modification or extension of the analyzer or its repair.
The following has to be observed:
The analyzer must only be operated if all protective equipment (e.g., covers, drip
pans for chemicals and doors) are present, properly installed and fully operational.
The sound condition of the protection and safety equipment must be checked regu-
larly. Any defects must be corrected as soon as they occur.
Protective and safety equipment must never be removed, modified or decommis-
sioned during operation.
Free access to the power switch on the back of the enclosure has to be ensured dur-
ing operation.
The ventilation equipment on the multi N/C 2100 and the extension modules must be
in good working condition. Covered vents or ventilation slits etc. may cause the de-
vice to break down or may cause damage to it.
The furnace operates with temperatures of up to 950°C. The hot components (fur-
nace, condensation coil) must not be touched during or directly after the analyzer
operation.
Keep all combustible materials away from the analyzer.
3.7.2 Safety instructions - protection against explosion and fire
The analyzer must not be operated in an explosive environment. Smoking or handling open
flames in the operating room of the analyzer is prohibited!
The operating personnel have to be familiar with the location of the fire-fighting equipment in
the operating room of the analyzer.
3.7.3 Safety instructions - electrical equipment
Work on electrical components of the analyzer may only be carried out by a qualified electri-
cian in accordance with the applicable electrical engineering rules. Life-threatening electrical
voltages may occur in the right-hand side component of the analyzer.
The following has to be observed:
Extension modules or system components must always be connected to or discon-
nected from the analyzer in a deactivated condition.
Before opening the analyzer, it must be switched off at the power switch and the
power plug must be disconnected from the mains outlet!
Any work on the right-hand side component of the analyzer may only be carried out
by the Analytik Jena AG customer service and specially authorized technicians.

Safety instructions
multi N/C 2100 Edition 02.17 11
The electrical components must be checked regularly by a qualified electrician. Any
defects, such as loose connections, faulty or damaged cables, must be repaired
without delay.
The analyzer must be switched off immediately at the power switch (on the equip-
ment backplate) and the power plug disconnected from the mains if there is any in-
terference with the electric components.
3.7.4 Safety instructions for compressed gas containers and
systems
The carrier gas (synthetic air and/or oxygen) is taken from compressed gas containers or
local compressed gas systems. The required purity of the carrier gas must be ensured (→
see chapter "Technical data" p.4)!
Work on compressed gas containers and systems must only be carried out by individuals
with specialist knowledge and experience with compressed gas systems.
The following has to be observed:
For gas cylinder or gas plant operation, the safety instructions and guidelines which
are valid at the operating location must be strictly complied with.
High pressure hoses and pressure reducers may only be used for the assigned gas-
es.
Pipes, hoses, screw connections and pressure reducers for oxygen must be kept
free from grease.
All pipes, hoses and screw connections must be checked regularly for leaks and ex-
ternally visible damage. Leaks and damaged must be repaired without delay.
Prior to inspections, service and repairs, the valves must be closed and the analyzer
vented!
After successful repair and service of the components of the compressed air con-
tainers or system, the analyzer must be checked for sound operation prior to re-
commissioning!
Independent assembly and installation are not permitted!
3.7.5 Handling of auxiliary and operating materials
The operator is responsible for the selection of substances used in the process as well as for
their safe handling. This is particularly important for radioactive, infectious, poisonous, corro-
sive, combustible, explosive and otherwise dangerous substances.
When handling dangerous substances, local safety codes and guidelines must be observed.
The following general notes do not replace the specific local regulations or the regulations in
the EC safety data sheets of the manufacturers for the auxiliary and operating materials.
The following has to be observed:
The relevant regulations and the notes in the EC safety data sheets of the manufac-
turers have to be observed and complied with regards to storage, handing, use and
disposal for all auxiliary and operation materials used during operation or mainte-
nance of the analyzer.

Safety instructions
12 Edition 02.17 multi N/C 2100
Auxiliary and operation materials may never be placed in containers or vessels for
food. The approved containers for the relevant material are to be used and these
have to be labeled accordingly. The notes on the labels have to be observed!
Protective goggles and rubber gloves have to be worn when handing reagents. The
notes on the labels have to be observed.
The regulations and notes on the safety data sheets for the handling of orthophos-
phoric acid (H3PO4) or hydrochloric acid (HCl) have to be observed!
The catalysts supplied by the manufacturer (platinum catalyst multi N/C or special
catalyst multi N/C) must be treated with the usual caution when handling chemicals.
Biological samples have to be handled according to local guidelines regarding the
handling of infectious material.
Caution when handing quartz glass and glass parts. Risk of broken glass and there-
fore risk of injury!
Avoid dust formation and inhalation of dust when handing the quartz glass wool dur-
ing filling of the combustion tube.
Auxiliary and operating materials as well as their containers may not be disposed of
in domestic waste or enter the sewage system or the soil. The applicable regulations
for disposal of these materials must be meticulously observed.
Ensure good room ventilation in working rooms.
3.7.6 Safety instructions - service and repair
The analyzer is to be serviced by the Analytik Jena AG customer service department or its
authorized and trained specialist personnel.
Independent servicing can misadjust or damaged the analyzer. Therefore, the operator may
only carry out the tasks listed in the chapter "Service and care".
The following has to be observed:
The exterior of the analyzer may only be cleaned with a damp, not dripping, cloth af-
ter the analyzer has been switched off.
Any service and repair work to the analyzer may only be carried out in the switched-
off condition (unless stated otherwise).
Service tasks and the replacement of system components (removal of the combus-
tion tube, catalyst replacement) must only be carried out after a sufficiently long cool-
ing down phase.
Prior to commencing servicing or repair tasks, the energy and gas supplies must be
disconnected and the analyzer must be vented!
Only use original accessories and original replacement parts from Analytik Jena AG.
The notes in the chapter "Service and care" must be observed.
All protective equipment must be correctly reinstalled and checked for operation im-
mediately after completion of the service and repair work!

Safety instructions
multi N/C 2100 Edition 02.17 13
3.8 Behavior in an emergency
The analyzer must be switched off at the power switch (on the equipment backplate) and the
power plug must be disconnected from the mains in the case of dangerous situations or ac-
cidents.
Because a rapid response can save lives during an emergency, the following has to be en-
sured:
The operating staff must be familiar with the location of safety equipment, accident
and danger alarms and first aid and rescue equipment, and also have an under-
standing of how they are used.
The operator is responsible for ensuring that all operating staff is appropriately
trained.
All first aid equipment (first-aid kit, eyewash bottles, stretcher, etc.) as well as fire-
fighting equipment (fire extinguishers) must be within reach and easy to access. All
equipment has to be in a sound condition and should be checked regularly.

Technical description
14 Edition 02.17 multi N/C 2100
4 Technical description
4.1 System design
The analyzer multi N/C 2100 is a compact bench-top device with permanently installed main
components. The complete measuring design also includes accessory parts and reagents
which must be connected to the analyzer or made ready prior to a measurement.
The control of the analyzer and the analysis of the measurements takes place via the control
and analysis software multiWin.
All components of the analyzer to be operated or serviced by the user can be reached via 2
doors at the front, the left-hand removable side wall or the top cover.
The analyzer multi N/C 2100 consists of the following main components:
Components for sample preparation
Hose system
Combustion system
Components for measuring gas drying and cleaning
Detectors
Indicator and control elements, connections
Electronic component
Accessories
1 LED display
2 Needle valve for adjusting the
carrier gas
3 Condensate pump
4 TIC container
5 Halogen trap
6 Water traps
Fig. 1 Front view (doors open)
