Liquistation CSF33
Automatic sampler for liquid media
Operation & settings

Operation concept
a0013353-en
Fig. 1: Pressing the soft key: selecting the menu directly
a0013354-en
Fig. 2: Turning the navigator: moving the cursor in the menu
a0013355-en
Fig. 3: Pressing the navigator: launching a function
a0013356-en
Fig. 4: Turning the navigator: selecting a value (e.g. from a list)
a0013357-en
Fig. 5: Pressing the navigator: accepting the new value
a0013358-en
Fig. 6: Result: new setting is accepted

Endress+Hauser
Liquistation CSF33
Table of contents
1 About this manual . . . . . . . . . . 4
2 General settings . . . . . . . . . . . . 5
2.1 Basic settings . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Date and time . . . . . . . . . . . . . . . . . . . . . . 5
2.3 Automatic hold (optional) . . . . . . . . . . . . . . 6
2.4 Logbooks . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.5 Configuring the sampling depending on the
device version . . . . . . . . . . . . . . . . . . . . . 10
2.6 Extended setup . . . . . . . . . . . . . . . . . . . . 13
3 Inputs . . . . . . . . . . . . . . . . . . . 16
3.1 Binary inputs . . . . . . . . . . . . . . . . . . . . . . 16
3.2 Current inputs . . . . . . . . . . . . . . . . . . . . . 20
4 Programming . . . . . . . . . . . . . 23
4.1 Overview of the possible program types . . 23
4.2 Program type: Basic . . . . . . . . . . . . . . . . . 27
4.3 Program types: Standard and Advanced . . 39
5 Outputs . . . . . . . . . . . . . . . . . 53
5.1 Binary outputs . . . . . . . . . . . . . . . . . . . . . 53
6 Data administration . . . . . . . . 56
6.1 Firmware update . . . . . . . . . . . . . . . . . . . 56
6.2 Saving the setup . . . . . . . . . . . . . . . . . . . . 56
6.3 Loading the setup . . . . . . . . . . . . . . . . . . . 57
Index . . . . . . . . . . . . . . . . . . . 58

About this manual Liquistation CSF33
4Endress+Hauser
1 About this manual
This manual gives a detailed account of all the configuration options in the "Setup" menu.
A description of the following menus is provided here:
• Inputs
– Input configuration
•Outputs
– Output configuration
– Split into separate sections based on the different output types
• Sampling programs
– Creating sampling programs
– Configuring different types of programs
• Additional functions
– Settings for the alarm sensor
– Cleaning program configuration
• Data management
– Firmware updates
– Saving and loading configurations
This manual does not include the following:
• Setup/General settings
--> Operating Instructions BA479C "Commissioning"
• Display/Operation
--> Operating Instructions BA479C "Commissioning"
• Calibration
--> Operating Instructions BA489C "Calibration"
•Diagnostics
--> Operating Instructions BA488C "Maintenance & diagnostics"
• Expert
--> Internal Service Manual

Liquistation CSF33 General settings
Endress+Hauser 5
2 General settings
2.1 Basic settings
2.2 Date and time
Path: Menu/Setup/General settings
Function Options Info
Device tag Customized text, 20 characters Select any name for your controller. Use the TAG name
for example.
Temperature unit Options
•°C
•°F
•K
Factory setting
°C
Alarm delay 0 to 9999 s
Factory setting
0 s
The system only displays the errors that are present
longer than the set delay time. This makes it possible to
suppress error messages that only occur briefly and are
caused by normal process-specific fluctuations.
Path: Menu/Setup/General settings/Date/Time
Function Options Info
Set date Depends on the format Editing mode:
DD (day): 01 to 31
MM (month): 01 to 12
YYYY (year): 2005 to 2100
Set time Depends on the format Editing mode:
hh (hour): 00 to 23 / 0 am to 12 pm
mm (minutes): 00 to 59
ss (seconds): 00 to 59
Extended setup
Date format Options
• DD.MM.YYYY
• YYYY-MM-DD
• MM-DD-YYYY
Factory setting
DD.MM.YYYY
Decide which date format you want to use.
Time format Options
• HH:MM am (12h)
• HH:MM (24h)
• HH:MM:SS (24h)
Factory setting
HH:MM:SS (24h)
Decide whether you want to use the 12-hour or
24-hour clock. Seconds can also be displayed with the
latter version.

General settings Liquistation CSF33
6Endress+Hauser
2.3 Automatic hold (optional)
2.4 Logbooks
Logbooks record the following events:
• Calibration/adjustment events
• Operator events
• Diagnostic events
• Programming events
Here you define how the logbooks should store the data.
In addition, you are also able to define individual data logbooks. Assign the logbook name and select the
measured value to be recorded. The data recording rate (Sample Time) is then the same for all data
logbooks.
Time zone Options
•None
• Choice of 35 time zones
Factory setting
None
If no time is selected, then Greenwich Mean Time
is used (London).
DST Options
•Off
• Europe
•USA
•Manual
Factory setting
Off
The controller adapts the summertime/normal time
changeover automatically if you choose European or
American daylight saving time.
Manual means that you can specify the start and end of
daylight saving time yourself. Here, two additional
submenus are displayed in which you specify the
changeover date and time.
Path: Menu/Setup/General settings/Automatic hold
Function Options Info
Device specific hold
Setup menu Options
• Disabled
•Enabled
Factory setting
Disabled
Decide whether a hold should be output at the current
output when the particular menu is opened.
Diagnostics menu
Calibration menu
Hold delay 0 to 600 s
Factory setting
0 s
The hold is maintained for the duration of the delay
time when you switch to the measuring mode.
Path: Menu/Setup/General settings/Date/Time
Function Options Info

Liquistation CSF33 General settings
Endress+Hauser 7
Path: Menu/Setup/General settings/Logbooks
Function Options Info
Logbook ident Customized text Part of the file name when exporting a logbook.
Event logbook Options
•Off
• Ring buffer
• Fill up buffer
Factory setting
Ring buffer
All diagnostic messages are recorded
Ring buffer
If the memory is full, the latest entry automatically
overwrites the oldest entry.
Fill up buffer
If the memory is full, there is an overflow, i.e. no new
values can be saved. The controller displays a
corresponding diagnostic message. The memory then
has to be cleared manually.
Program logbook Options
•Off
• Ring buffer
• Fill up buffer
Factory setting
Ring buffer
All diagnostic messages are recorded
Ring buffer
If the memory is full, the latest entry automatically
overwrites the oldest entry.
Fill up buffer
If the memory is full, there is an overflow, i.e. no new
values can be saved. The controller displays a
corresponding diagnostic message. The memory then
has to be cleared manually.
Overflow warnings
Data logbook="Fill up buffer"
Calibration logbook Options
•Off
•On
Factory setting
Off
Decide whether you want to receive a diagnostic
message from the controller in the event of memory
overrun of the logbook in question.
Diagnostic logbook
Configuration logbook
Data logbooks
Scan time 00:00:01 to 01:00:00
Factory setting
00:01:00
Minimum interval between two entries
Format: HH:MM:SS
New You can create a maximum of 8 data logbooks.
Logbook name Customized text, 20 characters
Source of data Options
•None
• Binary input 1
• Binary input 2
• Current input 1
• Current input 2
• Temperature 1
Factory setting
None
Select the input that should be the data source of the
logbook entries.
Measured value Options
Depends on data source
The measured value to be recorded depends on the
selected data source and thus also on the sensor
connected.

General settings Liquistation CSF33
8Endress+Hauser
Add new logbook Action Only if you want to create another data logbook
immediately.
You add a new data logbook at a later data using
New.
Ready Action This allows you to exit the menu New.
"Logbook name" The menu only appears if you have created a new data
logbook.
Source of data Read only This is for information purposes only. If you want to
record another value, delete this logbook and create a
new data logbook.
Measured value
Log time left
Data logbook="Fill up buffer"
Read only Displays the days, hours and minutes remaining until
the logbook is full.
Log size
Data logbook="Ring buffer"
Read only Displays the number of entries remaining until the
logbook is full.
Logbook name Customized text, 20 characters You can change the name here.
Data logbook Options
•Off
• Ring buffer
• Fill up buffer
Factory setting
Off
Ring buffer
If the memory is full, the latest entry automatically
overwrites the oldest entry.
Fill up buffer
If the memory is full, there is an overflow, i.e. no new
values can be saved. The controller displays a
corresponding diagnostic message. The memory then
has to be cleared manually.
Overflow warnings
Data logbook="Fill up buffer"
Options
•Off
•On
Factory setting
Off
Decide whether you want to receive a diagnostic
message from the controller in the event of memory
overrun of the logbook in question.
Line plotter Menu to define the graphic display
Axes Options
•Off
•On
Factory setting
On
Should the axes (x, y) be displayed (On) or not (Off)?
Orientation Options
• Horizontal
• Vertical
Factory setting
Horizontal
Path: Menu/Setup/General settings/Logbooks
Function Options Info

Liquistation CSF33 General settings
Endress+Hauser 9
Example for setting up a new data logbook
1. Menu/Setup/General settings/Logbooks/Data logbooks/Scan time: Specify the interval between
two logbook entries.
2. .../New:
a. Logbook name: Assign a name, e.g. "01".
b. Source of data: Select a data source, e.g. the sensor connected to binary input 1.
c. Measured value: From the sensor signals, select the signal that you want to record.
3. .../Ready: Execute this action.
--> Your new logbook now appears in the list of data logbooks.
4. Select the data logbook with the name "01".
5. Activate the logbook by going to "Data logbook" and specifying Ring buffer or Fill up buffer as the
type of memory.
6. If you selected "Fill up buffer", you can also decide whether you want to receive a diagnostic
message in the event of memory overrun.
7. Depending on the type of memory selected, you receive information about the memory space (for
"Ring buffer") or the time remaining until memory overrun (for "Fill up buffer").
8. Define the graphic display mode in the "Line plotter" submenu.
X-Description Options
•Off
•On
Factory setting
On
Decide whether a description should be displayed for
the axes and whether grids should be shown. In
addition, you can also decide whether a pitch should be
displayed.
Y-Description
Grids
Pitches
X Pitch/Grid distance 10 ... 50%
Factory setting
10 %
Specify the pitch.
Y Pitch/Grid distance
Path: Menu/Setup/General settings/Logbooks
Function Options Info

General settings Liquistation CSF33
10 Endress+Hauser
2.5 Configuring the sampling depending on the device version
The list of functions displayed depends on the device version selected. Functions marked 1) are
available in device versions with a vacuum pump. Functions marked 2) are available
in device versions with a peristaltic pump. Functions marked 3) are available in device versions
with a distributor plate.
Path: Menu/Setup/General settings
Function Options Info
Sampling
Number of bottles Choice of all possible bottle com-
binations
The bottle configuration you ordered is preset in the
device.
Bottle volume 0 to 100000 ml
Factory setting
1000 ml
Set the bottle volume.
Distribution reference 3) Options
• Pre sampling
• Pre bottle change
•Preprogramstart
Factory setting
Pre sampling
The distributor arm goes through a reference point
depending on the option selected.
Power failure Options
• Resume program
• Stop program
Factory setting
Stop program
Decide how the sampler should react when it is
energized after a power failure.
Sample retries 0 to 3
Factory setting
0
If sampling is started and no sample is drawn in, samp-
ling can be repeated up to 3 times.
Sampling delay 0 to 99 s
Factory setting
0 s
The start of the sampling cycle can be delayed by up to
99 s. The binary output is switched without any delay.
Liquid detection 1) Options
•Automatic
•Semiautomatic
Factory setting
Automatic
If "Semiautomatic" is selected, the purge times and
intake times can be defined separately.
Dosing volume 1) 20 to 350 ml
Factory setting
200 ml
Adjust the dosing tube in the dosing chamber to change
the dosing volume. The level in the bottle is calculated
using the set dosing volume.
Dosing chamber 1) Options
• Dose without pressure (A)
• Dose with pressure (B)
Factory setting
Dose without pressure (A)
Dosing with pressure e.g. in conditions with low
suction heights and slight counterpressure or low
volumes.

Liquistation CSF33 General settings
Endress+Hauser 11
Liquid detection 2) Options
•Automatic
• Semiautomatic
•Off
Factory setting
Automatic
If "Semiautomatic" is selected, the purge times and
intake times can be defined separately.
Rinse cycles 2) 0 ... 3
Factory setting
0
The suction line is rinsed with the sample up to 3 times.
Safety interlock 2) (optional) Options
•Off
•On
Factory setting
Off
If the peristaltic pump is opened, the safety interlock
stops all the functions.
Diagnostics settings
Sensor fouling 1)
Warning 0 ... 10
Factory setting
7
Indicates maintenance work must be performed on the
conductivity sensors.
Alarm 0 ... 10
Factory setting
10
Pump tube life 2)
Control Options
•Off
•On
Factory setting
Off
Indicates the pump hose has to be exchanged.
Warning 10 to 50 h
Factory setting
30 h
Alarm 30 to 200 h
Factory setting
50 h
Totalizer 00-00:00 ... 49710-06:28
Factory setting
00-00:00
Operating time of the pump in days, hours and minutes
Reset Action
Path: Menu/Setup/General settings
Function Options Info

General settings Liquistation CSF33
12 Endress+Hauser
Sample temperature (optional)
Temp. control Options
•Off
•On
Factory setting
On
On:
Temperature control of the sample compartment
Economy operation Options
•Off
•On
Factory setting
Off
On:
Temperature control only activated when the program
is running
Sample temperature 2 to 20 °C
Factory setting
4 °C
Set the sample compartment temperature.
Cooling control Options
• Standard operation
• Quick cool down
Factory setting
Standard operation
The temperature regulator is switched off for a certain
time if quick cool-down is selected.
Defrosting
The automatic defrosting function is preset at the factory. The following changes may only be made by experts.
Mode Options
•Off
•On
Factory setting
On
Configuration of the automatic defrosting function
Interval Options
•Hourly
• Daily
•Weekly
•Monthly
Factory setting
Hourly
Select the defrosting interval
Time 00-01:00 ... 00-23:59
Factory setting
00-04:00
Duration 00:01 ... 02:00
Factory setting
00:05
Path: Menu/Setup/General settings
Function Options Info

Liquistation CSF33 General settings
Endress+Hauser 13
2.6 Extended setup
2.6.1 Diagnostics settings
This branch, along with the same functions, can be found in different "Extended setup" menus.
The list of diagnostic messages displayed depends on the path selected. There are device-specific
messages, and messages that depend on what sensor is connected.
Path: ... /Extended setup/Diagnostics settings/Diag. behavior
Function Options Info
List of diagnostic messages Select the message to be changed. Only then you can
make the settings for this message.
Diag. code Read only
Diagnostic message Options
•On
•Off
Factory setting
Depends on the message
You can deactivate or reactivate a diagnostic message
here.
Deactivating means:
• No error message in the measuring mode
• No error current at the current output
Error current Options
•On
•Off
Factory setting
Depends on the message
Decide whether an error current should be output at
the current output if the diagnostic message display is
activated.
Status signal Options
• Maintenance (M)
• Out of specification (S)
• Function check (C)
• Failure (F)
Factory setting
Depends on the message
The messages are divided into different error categories
in accordance with NAMUR NE 107.
--> BA488C "Maintenance & diagnostics"
Diag. output Options
•None
• Alarm relay
• Relay 1 to n (depends on the
device version)
Factory setting
None
You can use this function to select a relay output
and/or binary output to which the diagnostic message
should be assigned.
Cleaning program (optional) Options
•None
•Cleaning1
•Cleaning2
•Cleaning3
•Cleaning4
Factory setting
None
Decide whether the diagnostic message should trigger a
cleaning program.
You can define the cleaning programs under:
Menu/Setup/Additional functions/Cleaning.
Detail Information Read only Here you can find more information on the diagnostic
message and instructions on how to resolve the
problem.

General settings Liquistation CSF33
14 Endress+Hauser
2.6.2 Data management
Firmware update
Please contact your local sales office for information on firmware updates available for your controller
and its compatibility with earlier versions.
Your current firmware version can be found at: Menu/Diagnostics/System information/Software
version.
First save your current setup on an SD card since a firmware update overwrites your settings with
the factory settings. After updating the firmware, you can restore your setup by uploading it from
the SD card.
To install a firmware update, you must have the update available on an SD card.
1. Insert the SD card into the controller card reader.
2. Go to: Menu/Setup/General settings/Extended setup/Data management/Firmware update.
--> The update files on the SD card are displayed.
3. Select the desired update and select yes when the following question is displayed: The current
firmware will be overwritten. After this the device will reboot. Do you want to proceed?
--> The firmware is loaded and the device is then started with the new firmware.
Saving the setup
Saving the setup gives you the following advantages:
• Quick and easy to restore a setup following a firmware update
• Copying settings for other devices
• Quick and easy switching between various setups, e.g. for different user groups or for recurring sensor
type change
• Restoring a tried-and-tested setup, e.g. if you have changed a lot of settings and no longer know what
the original settings were
1. Insert the SD card into the controller card reader.
2. Go to: Menu/Setup/General settings/Extended setup/Data management/Save setup.
3. Assign a file name (Name).
4. Then select "Save".
5. If you have already assigned the file name, you will be asked whether you want to overwrite the
existing setup.
Select "OK" to confirm, or cancel the action and give the file a new name.
--> Your setup is stored on the SD card and you can upload it quickly to the device at a later date.

Liquistation CSF33 General settings
Endress+Hauser 15
Loading the setup
You can load a setup you have saved quickly and easily:
1. Insert the SD card into the controller card reader.
2. Go to: Menu/Setup/Data management/Load setup.
--> A list of all the setups on the SD card is displayed.
3. Select the desired setup.
The device then displays the following message: The current parameters will be overwritten and
the device will reboot. Do you want to proceed?
4. Select "OK" to confirm or cancel the action.
--> The desired setup is restored after restarting the device.
Exporting the setup
Exporting the setup gives you the following advantages:
• Export in xml format
• Import the data e.g. into MS Excel (drag&drop the xml file in an open Excel window)
1. Insert the SD card into the controller card reader.
2. Go to: Menu/Setup/General settings/Extended setup/Data management/Export setup.
3. Assign a file name (Name).
4. Then select "Export".
5. If you have already assigned the file name, you will be asked whether you want to overwrite the
existing setup.
Select "OK" to confirm, or cancel the action and give the file a new name.
--> Your setup is saved on the SD card.
Activation code
You require activation codes for:
• Additional functions, e.g. other inputs
• Software upgrades
1. Install the hardware or load the new software.
2. Go to: Menu/Setup/General settings/Extended setup/Data management/Activation code.
3. Enter the activation code which you received with the hardware or software.
4. Then select "Confirm".
--> Your new hardware or software is now activated and can now be configured.

Inputs Liquistation CSF33
16 Endress+Hauser
3Inputs
The CSF33 sampler has 2 binary inputs and 2 current inputs as standard. All inputs are galvanically
isolated from one another.
3.1 Binary inputs
The binary inputs are used to control the sampler using external signals.
With the CSF33, the auxiliary voltage of 24 V DC from the terminal block in the connection
compartment of the sampler can be used for floating contacts (see BA479C "Commissioning").
Path: Menu/Setup/Inputs
Function Options Info
Binary input S:x
Mode Options
•Off
•On
Factory setting
Off
Switches the function on or off
Input mode Options
•Flowrate
•Rainfall
• External event
Factory setting
Flow rate
• Pulse input for connected flowmeters or rain gages
• Control of sampling functions via external signals
If the Input mode Flow rate is selected:
Signal slope Options
•Low-High
• High-Low
Factory setting
Low-High
Preselect the level change of the signal.
Unit Options
•m³
•l
•cf
•gal
Factory setting
m³
Select the unit.
Meas. value format Factory setting
#.#
Specify the number of decimal places for the flow.
1 Impulse = 0 to 1000 m3
Factory setting
10 m3
Definition of the pulse value, limits are calculated
depending on the unit

Liquistation CSF33 Inputs
Endress+Hauser 17
Totalized flow
Current totalized flow - - - The totalized flow values are displayed.
Reset totalizer Options
•Manual
•Automatic
• At program start
Factory setting
Manual
Manual:
Reset the counter manually.
Automatic:
The counter is reset automatically at intervals.
At program start:
The counter is reset at program start.
If Manual is selected for the counter reset:
Reset totalized flow Action The totalized flow currently calculated is set to zero
when the counter is reset.
If Automatic is selected for the counter reset:
Interval Options
• Daily
• Weekly
•Monthly
Factory setting
Daily
Daily:
If a daily interval is selected, set the Time in the menu
item that follows.
Weekly:
If a weekly interval is selected, set the Day of week and
the Time in the menu items that follow.
Monthly:
If a monthly interval is selected, set the Day of month
and the Time in the menu items that follow.
If the Input mode Rainfall is selected:
Signal slope Options
•Low-High
•High-Low
Factory setting
Low-High
Preselect the level change of the signal.
Unit Options
•mm
•inch
Factory setting
mm
Select the unit.
Meas. value format Factory setting
#.#
Specify the number of decimal places.
1 Impulse = 0.00 to 5.00 mm
Factory setting
1.0 mm
Definition of the pulse value, limits are calculated
depending on the unit. The correct switch value is
provided in the Operating Instructions of your rain
gage.
Path: Menu/Setup/Inputs
Function Options Info

Inputs Liquistation CSF33
18 Endress+Hauser
Intensity Options
• mm/min
•mm/h
•mm/d
Factory setting
mm/min
Select the intensity per minute, hour or day according
to your requirements.
Totalized rainfall
Totalized rainfall - - - The totalized rainfall is displayed.
Reset totalizer Options
•Manual
•Automatic
•Atprogramstart
Factory setting
Manual
Manual:
Reset the counter manually.
Automatic:
The counter is reset automatically at intervals.
At program start:
The counter is reset at program start.
If Manual is selected for the counter reset:
Reset totalized rainfall Action The totalized rainfall currently calculated is set to zero
when the meter is reset manually.
If Automatic is selected for the counter reset:
Interval Options
• Daily
• Weekly
•Monthly
Factory setting
Daily
Daily:
If a daily interval is selected, set the Time in the menu
item that follows.
Weekly:
If a weekly interval is selected, set the Day of week and
the Time in the menu items that follow.
Monthly:
If a monthly interval is selected, set the Day of month
and the Time in the menu items that follow.
If Input mode External event is selected:
Path: Menu/Setup/Inputs
Function Options Info

Liquistation CSF33 Inputs
Endress+Hauser 19
Operation Options
• No operation
• Start sampling
• Program start
•Programstop
• Program duration
•Programpause
• Partprogram activation
• Change bottle
• Bottle synchronization
• External hold
Factory setting
No operation
No operation:
No action is executed.
Start sampling:
A pulse triggers sampling.
Program start:
A pulse starts a program.
Program stop:
A pulse stops all programs running.
Program duration:
A program is active as long as the input signal is present.
The signal is a level signal, i.e. the action takes effect as
long as the level is present. The level that triggers the
action is configured in the Signal slope menu item that
follows.
Program pause:
The input signal stops all programs running. The
programs continue running when the signal disappears.
The signal is a level signal, i.e. the action takes effect as
long as the level is present. The level that triggers the
action is configured in the Signal slope menu item that
follows.
Partprogram activation:
A pulse triggers a subprogram.
Change bottle:
A pulse triggers a changeover to the next bottle.
Bottle synchronization:
A pulse triggers a changeover to the set bottle position.
--> Select the bottle position in the menu item that
follows.
External hold:
The input signal triggers an external hold.
The signal is a level signal, i.e. the action takes effect as
long as the level is present. The level that triggers the
action is configured in the Signal slope menu item that
follows.
Signal slope Options
•Low-High
•High-Low
Factory setting
Low-High
Preselect the level change of the signal.
--> If Low-High is selected, the high level brings about
the corresponding setting.
Path: Menu/Setup/Inputs
Function Options Info

Inputs Liquistation CSF33
20 Endress+Hauser
3.2 Current inputs
The current input must be assigned an analog signal for the functions described. Active and passive
current inputs are available to connect 2-wire or 4-wire devices.
For the correct wiring of the current inputs, see:
BA479C "Commissioning"
Path: Menu/Setup/Inputs
Function Options Info
Current input S:x
Mode Options
•Off
•0..20mA
•4..20mA
Factory setting
Off
Enter the output signal of the connected device: 0 to 20
mA or 4 to 20 mA.
Input mode Options
•Flowrate
• Parameter
• Current
Factory setting
Current
Select the input variable.
Flow rate:
The input can be used as the source for
time/flow-paced or flow-paced sampling programs.
Parameter:
The input can be used as the source for limit switches,
logbooks and enabling and disabling events for sampling
programs.
Current:
The input can be used as the source for limit switches,
logbooks and enabling and disabling events for sampling
programs.
A unit name cannot be specified.
If Input mode Flow rate is selected:
Unit of flow Options
•l/s
•m³/s
•m³/h
•m
3/d
•cfs
•cfm
•gpm
•gph
•mgd
Factory setting
l/s
Select the unit.
Unit of totalized flow Options
•l
•m³
•cf
•gal
Factory setting
m³
Select the unit for the totalized flow.
