Brief Operating Instructions
Liquiport 2010 CSP44
Automatic sampler for liquid media
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information on the device can be found in the
Operating Instructions and in the other documentation
available at:
• www.endress.com/device-viewer
• Smart phone/tablet: Endress+Hauser Operations App
KA01166C/07/EN/06.17
71390876

Liquiport 2010 CSP44
2 Endress+Hauser
TAG No.: XXX000
Ser. No.: X000X000000
Order code 00X00-XXXX0XX0XXX
www.endress.com/deviceviewer Endress+Hauser Operations App
Serial number
A0023555

Liquiport 2010 CSP44 Table of contents
Endress+Hauser 3
Table of contents
1 Document information ............................................................ 4
1.1 Warnings ............................................................................ 4
1.2 Symbols ............................................................................. 4
1.3 Symbols at the device ................................................................... 4
1.4 Documentation ........................................................................ 5
2 Basic safety instructions .......................................................... 6
2.1 Requirements for the personnel ............................................................ 6
2.2 Designated use ........................................................................ 6
2.3 Occupational safety ..................................................................... 6
2.4 Operational safety ......................................................................7
2.5 Product safety ......................................................................... 7
3 Incoming acceptance and product identification ................................... 8
3.1 Incoming acceptance .................................................................... 8
3.2 Product identification ................................................................... 8
3.3 Scope of delivery ....................................................................... 9
3.4 Certificates and approvals ................................................................ 9
4 Installation ...................................................................... 10
4.1 Installation conditions .................................................................. 10
4.2 Installation .......................................................................... 14
4.3 Connecting the suction line .............................................................. 14
4.4 Post-installation check ................................................................. 14
5 Electrical connection ............................................................ 15
5.1 Connecting the sampler ................................................................ 15
5.2 Connecting modules and sensors .......................................................... 17
5.3 Terminal assignment for input/output signals ................................................ 17
5.4 Signal cable connection (optional) ......................................................... 18
5.5 Ensuring the degree of protection ......................................................... 20
5.6 Post-connection check ..................................................................21
6 Operation options ............................................................... 22
6.1 Overview ........................................................................... 22
6.2 Access to the operating menu via the local display ............................................. 23
6.3 Configuration options .................................................................. 24
7 Commissioning .................................................................. 28
7.1 Function check ....................................................................... 28
7.2 Switching on ......................................................................... 28
7.3 Basic setup .......................................................................... 29
7.4 Sampling programs .................................................................... 30

Document information Liquiport 2010 CSP44
4 Endress+Hauser
1 Document information
1.1 Warnings
Structure of information Meaning
LDANGER
Causes (/consequences)
If necessary, Consequences of non-
compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid the dangerous situation will result in a fatal or serious injury.
LWARNING
Causes (/consequences)
If necessary, Consequences of non-
compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid the dangerous situation can result in a fatal or serious injury.
LCAUTION
Causes (/consequences)
If necessary, Consequences of non-
compliance (if applicable)
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid this situation can result in minor or more serious injuries.
NOTICE
Cause/situation
If necessary, Consequences of non-
compliance (if applicable)
‣Action/note
This symbol alerts you to situations which may result in damage to property.
1.2 Symbols
Symbol Meaning
Additional information, tips
Permitted or recommended
Not permitted or not recommended
Reference to device documentation
Reference to page
Reference to graphic
 Result of a step
1.3 Symbols at the device
Symbol Meaning
Reference to device documentation

Liquiport 2010 CSP44 Document information
Endress+Hauser 5
1.4 Documentation
The following manuals which are available on the product pages on the internet complement
these Operating Instructions:
• Operating Instructions for Liquiport CSP44, BA00465C
– Device description
– Commissioning
– Operation
– Software description (excluding sensor menus; these are described in a separate manual -
see below)
– Device-specific diagnostics and troubleshooting
– Maintenance
– Repair and spare parts
– Accessories
– Technical data
• Operating Instructions for Memosens, BA01245C
– Software description for Memosens inputs
– Calibration of Memosens sensors
– Sensor-specific diagnostics and troubleshooting
• Guidelines for communication via fieldbus and web server
• Special Documentation: Sampler application manual SD01068C
• Documentation on other devices in the Liquiline platform:
– Liquiline CM44xR (DIN rail device)
– Liquiline System CA80 (analyzer)
– Liquiline System CAT8x0 (sample preparation)
– Liquistation CSFxx (sampler)
– Liquiport CSP44 (sampler)

Basic safety instructions Liquiport 2010 CSP44
6 Endress+Hauser
2 Basic safety instructions
2.1 Requirements for the personnel
• Installation, commissioning, operation and maintenance of the measuring system may be
carried out only by specially trained technical personnel.
• The technical personnel must be authorized by the plant operator to carry out the specified
activities.
• The electrical connection may be performed only by an electrical technician.
• The technical personnel must have read and understood these Operating Instructions and
must follow the instructions contained therein.
• Faults at the measuring point may only be rectified by authorized and specially trained
personnel.
Repairs not described in the Operating Instructions provided must be carried out only
directly at the manufacturer's site or by the service organization.
2.2 Designated use
Liquiport 2010 CSP44 is a portable sampler for liquid media in non-hazardous areas. The
samples are taken discontinuously using a peristaltic pump and are then distributed into
sampling containers.
The sampler is designed for use in the following applications:
• Communal and industrial wastewater treatment plants
• Laboratories and water management offices
• Monitoring of liquid media in industrial processes
Use of the device for any purpose other than that described, poses a threat to the safety of
people and of the entire measuring system and is therefore not permitted. The manufacturer
is not liable for damage caused by improper or non-designated use.
2.3 Occupational safety
As the user, you are responsible for complying with the following safety conditions:
• Installation guidelines
• Local standards and regulations
Electromagnetic compatibility
• The product has been tested for electromagnetic compatibility in accordance with the
applicable European standards for industrial applications.
• The electromagnetic compatibility indicated applies only to a product that has been
connected in accordance with these Operating Instructions.

Liquiport 2010 CSP44 Basic safety instructions
Endress+Hauser 7
2.4 Operational safety
1. Before commissioning the entire measuring point, verify that all connections are
correct. Ensure that electrical cables and hose connections are undamaged.
2. Do not operate damaged products, and safeguard them to ensure that they are not
operated inadvertently. Label the damaged product as defective.
3. If faults cannot be rectified:
Take the products out of operation and safeguard them to ensure that they are not
operated inadvertently.
2.5 Product safety
2.5.1 State of the art
The product is designed to meet state-of-the-art safety requirements, has been tested, and
left the factory in a condition in which it is safe to operate. The relevant regulations and
European standards have been observed.
Devices connected to the sampler must comply with the applicable safety standards.
2.5.2 IT security
We only provide a warranty if the device is installed and used as described in the Operating
Instructions. The device is equipped with security mechanisms to protect it against any
inadvertent changes to the device settings.
IT security measures in line with operators' security standards and designed to provide
additional protection for the device and device data transfer must be implemented by the
operators themselves.

Incoming acceptance and product identification Liquiport 2010 CSP44
8 Endress+Hauser
3 Incoming acceptance and product identification
3.1 Incoming acceptance
1. Verify that the packaging is undamaged.
 Notify your supplier of any damage to the packaging.
Keep the damaged packaging until the matter has been settled.
2. Verify that the contents are undamaged.
 Notify your supplier of any damage to the delivery contents.
Keep the damaged products until the matter has been settled.
3. Check the delivery for completeness.
 Check it against the delivery papers and your order.
4. Pack the product for storage and transportation in such a way that it is protected
against impact and moisture.
 The original packaging offers the best protection.
The permitted ambient conditions must be observed (see "Technical data").
If you have any questions, please contact your supplier or your local sales center.
3.2 Product identification
Nameplates can be found:
• On the inside of the door
• On the packaging (adhesive label, portrait format)
• On the inside of the device cover
3.2.1 Nameplate
The nameplate provides you with the following information on your device:
• Manufacturer identification
• Order code
• Extended order code
• Serial number
• Firmware version
• Ambient and process conditions
• Input and output values
• Activation codes
• Safety information and warnings
‣Compare the data on the nameplate with your order.

Liquiport 2010 CSP44 Incoming acceptance and product identification
Endress+Hauser 9
3.3 Scope of delivery
The scope of delivery comprises:
• 1 Liquiport 2010 CSP44 with:
– The ordered bottle configuration
– Optional hardware
• 1 print version of Brief Operating Instructions in the language ordered
• Optional accessories
If you have any questions, please contact your supplier or your local sales center.
3.4 Certificates and approvals
3.4.1  mark
Declaration of Conformity
The product meets the requirements of the harmonized European standards. As such, it
complies with the legal specifications of the EC directives. The manufacturer confirms
successful testing of the product by affixing to it the  mark.
MCERTS
The device has been assessed by Sira Certification Service and complies with "MCERTS
Performance Standards for Water Monitoring Equipment Part 1, Version 2.1 dated November
2009"; certificate no.: Sira MC100176/02.
cCSAus General purpose
The product meets the requirements in accordance with "Class 8721 05, laboratory
equipment, electrical; Class 8721 85, laboratory equipment, electrical, certified to US
standards" for indoor use. Certificate no.: 2318018

Installation Liquiport 2010 CSP44
10 Endress+Hauser
4 Installation
4.1 Installation conditions
4.1.1 Dimensions
480 (18.9)
675 (26.6)
320 (12.6)
355 (14.0)
A0013473
 1 CSP44 standard version, dimensions in mm (in)

Liquiport 2010 CSP44 Installation
Endress+Hauser 11
4.1.2 Installation site
A0013474
 2 Installation site, example
The suction line must be routed with a downward slope to the sampling point. Avoid
siphon formation!
Note the following when erecting the device:
• Erect the device on a level surface.
• Protect the device against additional heating (e.g. from a heating system).
• Protect the device against mechanical vibrations.
• Protect the device against strong magnetic fields.

Installation Liquiport 2010 CSP44
12 Endress+Hauser
4.1.3 Connection for suctioning samples
• Maximum suction height: 8 m (26 ft)
• Maximum hose length: 30 m (98 ft)
• Diameter of hose connection: 10 mm (3/8")) internal diameter
• Intake speed:
> 0.5 m/s (> 1.6 ft/s) as per EN 25667, ISO 5667
> 0.6 m/s (> 1.9 ft/s) as per Ö 5893, US EPA
Note the following when erecting the device:
• Always route the suction line so that it slopes upwards from the sampling point to the
sampler.
• The sampler must be located above the sampling point.
• Avoid siphoning effects in the suction line.
Requirements for the sampling point:
• Do not connect the suction line to pressurized systems.
• Use the suction filter to impede coarse and abrasive solids and solids which can cause
clogging.
• Immerse the suction line in the direction of flow.
• Take the sample at a representative point (turbulent flow, not directly at the bottom of the
channel).
Useful sampling accessories
• Suction filter:
Impedes coarser solids and solids which can cause clogging.
• Immersion assembly:
The adjustable immersion assembly fixes the suction line at the sampling point.
4.1.4 Connection to sample intake on version with pump
• Maximum suction height: 8 m (26 ft)
• Maximum hose length: 30 m (98 ft)
• Diameter of hose connection: 10 mm (3/8")) internal diameter
• Intake speed:
> 0.5 m/s (> 1.6 ft/s) as per EN 25667, ISO 5667
> 0.6 m/s (> 1.9 ft/s) as per Ö 5893, US EPA
Note the following when erecting the device:
• Always route the suction line so that it slopes upwards from the sampling point to the
sampler.
• The sampler must be located above the sampling point.
• Avoid siphoning effects in the suction line.
Requirements for the sampling point:
• Do not connect the suction line to pressurized systems.
• Use the suction filter to impede coarse and abrasive solids and solids which can cause
clogging.
• Immerse the suction line in the direction of flow.
• Take the sample at a representative point (turbulent flow, not directly at the bottom of the
channel).

Liquiport 2010 CSP44 Installation
Endress+Hauser 13
Useful sampling accessories
• Suction filter:
Impedes coarser solids and solids which can cause clogging.
• Immersion assembly:
The adjustable immersion assembly fixes the suction line at the sampling point.

Installation Liquiport 2010 CSP44
14 Endress+Hauser
4.2 Installation
4.3 Connecting the suction line
1. When installing the device, take the installation conditions into account.
2. Open the device cover at the front fastening clasp.
3. Route the suction line from the sampling point to the device.
4. Screw the suction line onto the device's hose connection.
4.4 Post-installation check
1. Verify that the suction line is securely connected to the device.
2. Visually check that the suction line is installed correctly from the sampling point to the
device.
3. Verify that the rotating arm is correctly engaged.
4. Allow the sampler to rest for a minimum of 12 hours following installation and before
switch-on. Otherwise you may cause damage to the climate control module.

Liquiport 2010 CSP44 Electrical connection
Endress+Hauser 15
5 Electrical connection
5.1 Connecting the sampler
LWARNING
Device is live
Incorrect connection may result in injury or death
‣The electrical connection may be performed only by an electrical technician.
‣The electrical technician must have read and understood these Operating Instructions and
must follow the instructions contained therein.
‣Prior to commencing connection work, ensure that no voltage is present on any cable.
1
2
3
4
5
A0029150
 3 Electrical connections of the controller
1 Connection socket for charger
2 Socket for M12 sensor connector (optional)
3 Socket for M12 sensor connector (optional)
4 Connection socket for signal cable (optional)
5 Service interface
5.1.1 Battery connection
The device is delivered with a built-in rechargeable battery. The battery is not yet connected.
Charge the battery before initial commissioning. It takes approx. 5 hours to fully charge the
battery. Please refer to the charger's operating manual for detailed information on the
charger.
1. Unscrew the cover plate of the battery compartment, →  3,  15, item 2.
2. Remove the battery from the battery compartment.
3. Plug the connectors on the device into the color-coded terminals of the battery (red -->
red; black --> black).

Electrical connection Liquiport 2010 CSP44
16 Endress+Hauser
4. Plug the connectors on the device into the color-coded terminals of the battery (red -->
red; black --> black).
5. Make sure the connections are secure.
6. Place the battery back into the battery compartment. The battery terminals must be
toward the front.
7. After establishing the connection, screw the cover plate back onto the battery
compartment.
8. Reverse the procedure to disconnect the battery from the device.
Only replace batteries with the following battery type: Panasonic LC-R127R2PG1.
Connecting the charger when the batteries are installed
The mains plug of the charger must be easily accessible so that the charger can be easily
disconnected from the power supply.
‣Connect the battery charger to the connection socket (item 1). If the battery is not fully
charged, it is recharged by the charger.
Only use the chargers specified by the manufacturer.
Connecting the charger when the batteries are removed
If you are charging batteries that have been removed, you require the adapter cable (accessory
no.: 71111882) to connect to the charger.
5.1.2 Removing the cover on the power unit
LWARNING
Device is live
Incorrect connection may result in injury or death
‣If a power unit or charger is connected, disconnect it from the power supply.

Liquiport 2010 CSP44 Electrical connection
Endress+Hauser 17
12 1
A0014207
1 Fixing screws
2 Battery compartment cover
1. Release the two securing screws (1).
2. Remove the cover of the battery compartment (2).
3. Remove the old batteries and release the plug-in connections.
4. Connect the new batteries (pay attention to the battery polarity).
5. Insert the new batteries and secure the battery compartment cover.
5.2 Connecting modules and sensors
5.3 Terminal assignment for input/output signals
Input signals
• 2 analog signals 0/4 to 20 mA (optional)
• 2 binary signals > 100 ms pulse width or edge (optional)
Signals of digital sensors with Memosens protocol (optional)
Output signals
2 binary signals > 1 s pulse width or edge (optional)
2 current outputs 0/4 to 20 mA (optional)

Electrical connection Liquiport 2010 CSP44
18 Endress+Hauser
5.4 Signal cable connection (optional)
+
-
+
-
-
-
+
+
R R
l l
Ui
Ui
1
(A)
(K)
(J)
(H)
(M)
(G) (F) (E)
(D)
(C)
(L)
(B)
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(J)
(K)
(L)
(M)
1
2
3
4
U1-
U1+
B 1+I
B 1-I
B 2+I
B 2-I
B 1+O
B 1-O
B 2+O
B 2-O
AI1In
AI1GND
WH
BN
BU
RD
GN
YE
GY
PK
BK
VT
GY/PK
RD/BU
A0014162
 4 Pin assignment and wiring diagram of signal cable (version K3)
1 Auxiliary voltage U: 24 V max. 30 mA load capacity
2 Binary inputs BI: > 20 ms, only extra-low voltage Ui £ 30 V DC
3 Binary outputs BO: only extra-low voltage Ui £ 30 V DC, max. current when using ext. auxiliary
voltage (max. 200 mA)
4 Analog input AI: 0 to 20 mA, 4 to 20 mA

Liquiport 2010 CSP44 Electrical connection
Endress+Hauser 19
+
-
Ui
-
+
Ui
1
(A)
(K)
(J)
(H)
(M)
(G) (F) (E)
(D)
(C)
(L)
(B)
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(J)
(K)
(L)
(M)
1
2
3
4
-
+
-
+
U1-
U1+
B 1+I
B 1-I
B 1+O
B 1-O
AI1OUT
AI1IN
AI1GND
AI2OUT
AI2IN
AI2GND
WH
BN
BU
RD
GN
YE
GY
PK
BK
VT
GY/PK
RD/BU
A0014197
 5 Pin assignment and wiring diagram of signal cable (version K4)
1 Auxiliary voltage U: 24 V max. 30 mA load capacity
2 Binary input BI: > 20 ms, only extra-low voltage Ui £ 30 V DC
3 Binary output BO: only extra-low voltage Ui £ 30 V DC, max. current when using ext. auxiliary voltage
(max. 200 mA)
4 Analog inputs AI: 0 to 20 mA, 4 to 20 mA

Electrical connection Liquiport 2010 CSP44
20 Endress+Hauser
+
-
Ui
-
+
Ui
-
+
Ui
1
(A)
(K)
(J)
(H)
(M)
(G) (F) (E)
(D)
(C)
(L)
(B)
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(J)
(K)
(L)
(M)
1
2
3
4
-
+
A
-
+
A
U1-
U1+
B 1+I
B 1-I
B 1+O
B 1-O
B 2+O
B 2-O
I 1+O
I 1-O
I 2+O
I 2-O
WH
BN
BU
RD
GN
YE
GY
PK
BK
VT
GY/PK
RD/BU
A0014198
 6 Pin assignment and wiring diagram of signal cable (version K5)
1 Auxiliary voltage U: 24 V max. 30 mA load capacity
2 Binary input BI: > 20 ms, only extra-low voltage Ui £ 30 V DC
3 Binary output BO: only extra-low voltage Ui £ 30 V DC, max. current when using ext. auxiliary voltage
(max. 200 mA)
4 Analog inputs AI: 0 to 20 mA, 4 to 20 mA
5.5 Ensuring the degree of protection
Only the mechanical and electrical connections which are described in these instructions and
which are necessary for the required, designated use, may be carried out on the device
delivered.
‣Exercise care when carrying out the work.
Individual types of protection permitted for this product (impermeability (IP), electrical safety,
EMC interference immunity) can no longer be guaranteed if, for example:
• Covers are left off.
• Different power units to the ones supplied are used.
• Cable glands are not sufficiently tightened (must be tightened with 2 Nm for the confirmed
level of IP protection).
• Modules are not fully secured.
• The display is not fully secured (risk of moisture entering due to inadequate sealing).
• Loose or insufficiently tightened cables/cable ends.
• Conductive cable strands are left in the device.
