ENFORCER Enforcer SD-927PKC-NEQ User manual

NO TOUCH
EXIT
1
4 /2"
(115mm)
Application:
Technical Specifications:
SD-927PKC-NEQ
No Touch -- just wave a hand in front of sensor.
Sensing range up to 4" (10cm).
Attractive "ring" illuminator turns from green to red
when the sensor is activated.
Reduce the risk of cross contamination.
Easy and clean operation.
Reliable IR technology senses motion.
Durable stainless-steel plate.
Quick-connect screwless terminal block.
SPDT 3A relay output.
1.949.261.2999 (CA& Int’l) 1.800.662.0800 Fax: [phone]
Email: [e-mail] Website: www.seco-larm.com
16842 Millikan Avenue, Irvine, CA 92606
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
SECO-LARM's "No Touch" Request-To-Exit Sensor uses IR
technology to open a door or activate a device with the
simple wave of a hand. The trigger distance is up to 4".
Since it is no touch, this sensor is ideal for use in
hospitals, clinics, labs, cleanrooms (to reduce the risk of
contamination) or for use in schools, factories, or offices
(anywhere an easy way to exit is required).
12VDC
40mA @ 12VDC
Form-C dry contact, 3A@12VDC
10mS
0.5S or as long as unit is triggered
Up to 4" (10cm)
o o o o
-4 ~131 F (-20 ~55 C)
3oz (85g)
135
4 /2" x 2 /4" x 1 /16" (115 x 70 x 33.5mm)
Voltage
Current Drain
Relay Type
Response Time
Output Time
Range
Temperature Range
Weight
Dimensions
SD-927PKC-NEQ
Dimensions:
Features:
NoTouchSensorc.cdr
®
3
2 /4"
(70mm)
2"
(51mm)
1
1 /16"
(27mm)
