Enwork PROXI User manual

Proxi Height-Adjustable Table Installation Guide – Rev A.
PROXI INSTALLATION GUIDE
HEIGHT-ADJUSTABLE TABLES

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
Leg (2 pieces)
Connection Cable
M6x10 (8)
ST 4.2x16 (2)
Frame (2 pieces)
Power Cable
M6x16 (26)
ST 5.5x16 (18)
End Pipe (1 set)
Remote Control
M6x40 (4)
Feet (2 pieces)
Control Unit
ST 2.9x16 (2)
Torque Guide
• M6 Screw’s max torque = 6nm
• M8 Screw’s max torque = 6nm
• M10 Screw’s max torque = 6nm
• Tapping screws hand tightening only

INSTALLATION GUIDE
Adjust Top Frame to suitable length.
Mount the End Pipe.
Mount the Frame and End Pipe to the Table top.
Assemble the Leg and Frame.
Mount the Feet as illustrated above. The smooth side of
the plate faces the foot.
Mount the Frame and End Pipe to the Table top.
FIGURE 1
FIGURE 3
FIGURE 5
FIGURE 2
FIGURE 4
FIGURE 6
2) ASSEMBLY:

INSTALLATION GUIDE
Mount the Control Unit Bracket.
Connect the Cables to the Control Unit.
Mount the Remote Control to the Table top.
Mount the Control Unit.
Connect the Connection Cable to the Leg.
Do not put power to the system before it is fully assembled.
Connect the Remote Control Cable to the Control Unit.
FIGURE 7
FIGURE 9
FIGURE 11
FIGURE 8
FIGURE 10
FIGURE 12
2) ASSEMBLY: CONT.

INSTALLATION GUIDE
Perform Zero Setting.
Zero Setting:
When you use the height adjustable frame for the rst time, you have to reset the lowest desktop position to the minimum height.
• Press button and keep pressing it until the desktop has reached the lowest position (programmed desktop position).
• Press button again and keep pressing it. After about 5 seconds, the desktop will slowly move further down until it
reaches the absolutely lowest desktop position possible.
• Release button. The electric height adjustable frame can now be used.
FIGURE 12
2) ASSEMBLY: CONT. 2

Specications subject to change without notice.
Rev 03.2020
