Stealth Two Base Installation Guide – Rev B.
STEALTH TWO BASE
INSTALLATOIN GUIDE
CONFERENCE TABLE
TI0009

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
Leg
LYTS Bracket
LY.ENGLEG Bracket
Beam
5⁄16-18 Flange Nuts
LPPLT Plate
#10 x 1” Pan Head Phillips
LY.MTP Plate
#8-32 x .75 Flathead Screw

INSTALLATION GUIDE
2) TOOLS AND SUPPLIES REQUIRED
Powerdrill #2 Square Bit 1⁄2” Wrench

INSTALLATION GUIDE
3) ASSEMBLY:
Slide the LYTS’s equidistant onto the beams.
Depending on the size of the table each
Beam may get 1-3 LYTS’s.
See Figure 1 for proper slot on the Beam.
The LY.ENDLEG’s can be attached to
the Leg using the 5/16-18 Nuts and the
preinstalled LY.MTP’s on the Leg.
When nished it should look like Figure 2.
Install the LPPLT plates using the
#8-32 x .75 screws.
FIGURE 1
FIGURE 2
FIGURE 3

INSTALLATION GUIDE
3) ASSEMBLY:
Once the LY.ENDLEG’s are installed the Beams can
be slotted onto the LY.MTP’s on the LY.ENDLEG’s.
The LY.MTP should t neatly into the slot on the
beams as shown in Figure 4.
Repeat Step 3 until the base is completely
assembled. See Figure 5.
Loosen and adjust the 5⁄16-18 nuts and LY.MTP’s to
ensure proper alignment.
Once the complete table base is assembled place
the table top onto it and use the provided #10
screws to securely attach the top to the base.
See Figure 6.
Place the table top onto the completed table base
and attach the two together using the provided
#10 x 1” screws.
Level the table by threading the glides in and out.
See Figure 7.
FIGURE 4
FIGURE 5
FIGURE 6
FIGURE 7

Specications subject to change without notice.
Rev 02.2020
