Enwork Solano VT2 User manual

E�WORK
01.2019 Rev. #1
Solano VT2
Installation Instructions
LVTERBA, LVTERJJ
Electric Height-Adjustable Table Base

INSTALLION GUIDE
1) Parts and Fasteners Included
Leg (2 Pcs) Top Frame (2 Pcs) End Pipe (1 Set)
Feet (2 Pcs) Plate (2 Pcs) Smart Control Unit (1 Pc)
Motor Cables (2 Pcs) Power Cable (1 Pc) M6x10 (20 Pcs) / ST 5.5x16 (18 Pcs)
E�WORK

2) Assembly:
Torque Guide:
•M6 Screw's max torque= 6nm
•M10 Screw's max torque= 6nm
x10
INSTALLION GUIDE
Step1
Adjust the Top Frame to the suitable length.
Step 2
Assemble the Top Frame and Leg as illustrated left.
Please refer to the Torque Guide.
Step 3
Assemble the End Pipe and Leg as illustrated left.
Please refer to the Torque Guide.
• M8 Screw's max torque= 6nm
• Tapping screws hand tightening only
E�WORK

M6x10
I
ST5.5x16
Torque Guide:
•M6 Screw's max torque= 6nm
• M10 Screw's max torque= 6nm
INSTALLION GUIDE
Step4
Assemble the Feet as illustrated left. The smooth side
of the plate faces the foot. Please refer to the Torque
Guide.
Step 5
Mount the Frame to the Table top and fix the Top
Frame as illustrated left. Please refer to the Torque
Guide.
Step 6
Mount the Control Unit as illustrated left. Please refer
to the Torque Guide.
•M8 Screw's max torque= 6nm
• Tapping screws hand tightening only
E�WORK

Torque Guide:
•M6 Screw's max torque= 6nm
•M10 Screw's max torque= 6nm
INSTALLION GUIDE
Step 7
Connect the Motor and Power Cables to the Control
Unit as illustrated left.
Step 8
Connect the Motor Cable to the Leg as illustrated left.
Step 9
Please refer to zero setting instructions on next page.
•M8 Screw's max torque= 6nm
• Tapping screws hand tightening only
E�WORK

• ▼
• ▼
• ▼
E�WORK
  
 
Specifications subject to change without notice.
