Enwork ALKALIGN TABLE TI0042 User manual

Alkalign Table Base Installation Guide 09.03.20 – Rev. A
ALKALIGN TABLE INSTALLATION
INSTRUCTIONS
CONFERENCE TABLE
TI0042

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
Alkalign End Leg Weldment
ALM-2334-xx-01
ALM-2334-xx-02
ALM-2334-xx-03
Beam Weldment
ALM-2333-xxx
Beam Stretcher
ALM-1840-02
Alkalign Mid Leg Weldment
ALM-2335-xx-01
ALM-2335-xx-02
ALM-2335-xx-03
Formed Trough Panel
ALM-1803-xxx
Mid Leg Trough Cover
ALM-1829-02
Alkalign Mid Leg Weldment
ALM-2335-xx-01
ALM-2335-xx-02
ALM-2335-xx-03
Trough Door
ALM-1832-xxx
Inll Panel

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
#10-24 x 1/2” Phillis Head
#8-32 x 3/8 Phillips Pan Head
Thread Cutting Screw
5/16-18 X 1-1/4”
Serrated Flange Bolt
#8 x 5/16 Nylon Bushing
Alignment Biscuit
5/8-16 x 1/2” Flange Bolt
#8 Split Lock Washer
Tight Joint Connector
#10 X 1” Truss Head
Wood Screw

INSTALLATION GUIDE
2) TOOLS AND SUPPLIES REQUIRED
Drill
5mm Hex Driver Bit
Level
Square Driver Bit
Ratchet
Phillips Driver Bit
3/8” Socket

INSTALLATION GUIDE
Attach Beam Weldment to End Leg
Weldment using 5/16-18 X 1-1/4” Serrated
Flange Bolt.
Note: Snug t. DO NOT tighten
Attach Beam Stretcher to Beam Weldment using
5/16-18 x 1/2” Flange Bolt. Insure Beam Stretcher
tabs are facing the middle of the Beam Weldment.
Note: 2x Beam Stretcher per Beam Weldment
Snug t. DO NOT tighten
When Mid Legs are required, attach Mid Leg
Weldment to Beam Weldment using 5/16-18 X
1-1/4” Serrated Flange Bolt.
Mid Legs may not apply to all applications.
Note: Snug t. DO NOT tighten
FIGU RE 3.1
FIGURE 3.2
FIGURE 3.3
3) ASSEMBLY:
4x
4x
2x

INSTALLATION GUIDE
Tighten all connections.
Install inll.
Note: Inll attachment hardware is dependent on
inll material option.
Locate and center the work surface on the leg
assembly.
FIGURE 3.4
FIGURE 3.5
FIGURE 3.6
3) ASSEMBLY:

INSTALLATION GUIDE
Secure the surface using the supplied #10
X 1” Truss Head Wood Screws.
Attach Formed Trough Panel to Beam Weldment
using #10-24 x 1/2” Phillips Head.
Note: DO NOT tighten. Component needs to slide
along slots of part.
Mid Leg option:
When Mid Legs are required, install the outer
most Trough Panels 1st. Next, install 1 of the inner
Trough Panels. Next install the magnetic Mid
Leg Trough Cover before installing the nal inner
Trough Panels.
Note: DO NOT tighten. Component needs to slide
along slots of part.
FIGURE 3.7
FIGURE 3.8
FIGURE 3.9
3) ASSEMBLY:
2x
2x

INSTALLATION GUIDE
Assemble #8-32 x 3/8 Phillips Pan Head
Thread Cutting Screw and #8 Split Lock
Washer Trough Door.
Insert #8 x 5/16 Nylon Bushing into each Formed
Trough Panel pivot hole.
Note: 2x per Trough Panel.
Push the Formed Trough Panel as far apart as
possible.
FIGU RE 3.10
FIGURE 3.11
FIGURE 3.12
3) ASSEMBLY:

INSTALLATION GUIDE
Insert the Trough Door assembly into the
Nylon Bushings.
Push the Formed Trough Panel together as far
as possible and tighten the #10-24 x 1/2” Phillis
Head that hold the Formed Trough Panels to the
Beams.
Rotate the Trough Door into it’s closed position.
FIGU RE 3.13
FIGURE 3.14
FIGURE 3.15
3) ASSEMBLY:

INSTALLATION GUIDE
Level the table.
Assembly complete.
FIGU RE 3.16
3) ASSEMBLY:

INSTALLATION GUIDE
OPTIONAL) PARTS AND FASTENERS INCLUDED
4 Trac Circuit 1 Duplex
(BE41917-3-A-1-8B)
4 Trac Circuit 2 Duplex
(BE41917-3-A-2-8B)
4 Trac Duplex Mount
BE41955
4 Trac Receptacle Connector
BE4191919-3
4 Trac Power Jumpers
BE42081-3-72 (72”L)
BE42081-3-60 (60”L)

INSTALLATION GUIDE
Connect the 4 Trac Circuit modular power
receptacles together using the Receptacle
Connector.
Locate and attach the 4 Trac Duplex Mount to the
underside of the work surface.
Route 4 Trac Power Jumpers through the leg
weldment knock-out and attach to the 4 Trac
Circuit
FIGU RE 4.1
FIGURE 4.2
FIGURE 4.3
4) ASSEMBLY: OPTIONAL

Specications subject to change without notice.
Rev 11.2020
1.800.815.7251
www.enwork.com
12900 Christopher Dr. Lowell, MI 49331
