EOS Vision User manual

EN
EOS Vision
Heater for Sauna Cabins
Installation and Operating Instructions

EN-2 Installation and Operating Instructions - EOS Vision
Documentation
EN
Documentation
Manufacturer
Original installation instructions EN
Copyright for these installation instructions remains with
EOS Saunatechnik GmbH.
The copying and distribution of this document, as well as the use and com-
munication of its contents without express authorisation, are not permit-
ted. Compensation will be claimed in the event of infringements.
All rights reserved with regard to patent claims or submission of design or
utility patent.
Characters, symbols and illustrations
Revision history
EOS Saunatechnik GmbH
Schneiderstriesch 1
35759 Driedorf, Germany
Tel. [phone]
Fax [phone]
Email servicecent[email protected]
Web www.eos-sauna.com
Additional information about an operating step
Cross-reference to a page
Read instructions
Result of a step
Table title
Title of figure
≤ ≥ Less than or equal to, greater than or equal to
Date Version Description
23 Jan. 2023 01.00 First version

EOS Vision - Installation and Operating Instructions EN-3
Contents
Documentation..................................................................................................EN-2
1 General safety instructions..........................................................................EN-5
1.1 Mounting and electrical installation .................................................EN-5
1.2 Operator instruction ...............................................................................EN-7
1.3 Safety levels................................................................................................EN-9
1.4 Standards and regulations....................................................................EN-9
2 Identification.................................................................................................... EN-10
2.1 Requirements for operation.............................................................. EN-10
2.2 Nameplate ............................................................................................... EN-10
2.3 Scope of delivery................................................................................... EN-11
2.4 Accessories (optional).......................................................................... EN-11
2.5 Technical data ........................................................................................ EN-12
2.6 Intended use........................................................................................... EN-13
3 Installation ........................................................................................................ EN-15
3.1 Specifications for the cabin............................................................... EN-15
3.1.1 Installation site ...................................................................... EN-16
3.1.2 Air inlets and outlets............................................................ EN-17
3.1.3 Temperature sensor............................................................. EN-19
3.2 Heater guard rail.................................................................................... EN-20
3.3 Preparing for installation.................................................................... EN-20
3.4 Connecting cable.................................................................................. EN-22
3.5 Installing the heater ............................................................................. EN-26
4 Electrical installation.................................................................................... EN-28
4.1 General instructions for electrical installation............................ EN-28
4.2 Inner wiring diagrams ......................................................................... EN-28
4.2.1 Connecting to 400 V 3N ~.................................................. EN-29
4.2.2 Connecting to 230 V 1N ~.................................................. EN-32
4.2.3 Internal wiring........................................................................ EN-33
4.3 Establishing an electrical connection............................................ EN-35
4.4 Heating period limitation................................................................... EN-35
5 Commissioning ............................................................................................... EN-36
5.1 Filling with stones ................................................................................ EN-36
5.2 Starting the heater................................................................................ EN-37
5.3 Switching the heater on remotely .................................................. EN-37
5.4 Water splash............................................................................................ EN-38

EN-4 Installation and Operating Instructions - EOS Vision
EN
6 Service and maintenance...........................................................................EN-39
6.1 Cleaning....................................................................................................EN-39
6.2 Sauna stones...........................................................................................EN-40
6.3 Replacing the tubular heating elements......................................EN-41
6.4 Troubleshooting....................................................................................EN-46
7 General terms and conditions of service ...........................................EN-47
8 Disposal ..............................................................................................................EN-50

1
EOS Vision - Installation and Operating Instructions EN-5
General safety instructions
General safety instructions
1.1 Mounting and electrical installation
The installation instructions are intended for qualified personnel
familiar with the laws and regulations applicable to electrical in-
stallations at the installation site. Observe the following general
safety instructions during mounting, configuration and commis-
sioning of the product.
Risk to life and limb
and risk of fire
Risk to life and limb from electric shock and fire in the event of im-
proper or faulty electrical connection. This risk remains also after
completion of the installation work.
The electrical installation of the heater, power extension units
and other electrical systems or equipment with a fixed mains
connection must only be performed by a trained electrician
from an authorised electrical company.
Ensure compliance with the applicable standards and regula-
tions for electrical installation.
The system must be completely disconnected from the mains
supply before commencing installation and repair work.
The housing cover must only be removed by a qualified electri-
cian.
Fire hazard from
overheating
Insufficient ventilation can lead to device overheating and fire.
Install air inlets and outlets in the cabin.
Observe the cabin manufacturer’s safety and installation in-
structions.
Risk of fire due to
sauna stones
It is possible for hot stones or stone pieces to fall out of the rock
store.
The sauna heater may not be placed on a floor made of easily
flammable material (e.g. laminate or synthetic flooring). Ceram-
ic tiles are recommended as a flooring option.

EN-6 Installation and Operating Instructions - EOS Vision
General safety instructions
EN
Risk of burns from
hot glass
Glass surfaces in the cabin become hot while the sauna is in oper-
ation.
When installing the cabin, ensure that the touchable glass sur-
faces on the outside of the cabin may reach a maximum tem-
perature of 76°C. Appropriate protection may need to be
installed if required.
Risk of burns from
hot unit
During operation, the sauna heater may become hot and, if
touched, could cause burns.
Maintain a safe distance.
Sauna cabin and
sauna heater
The sauna cabin must be constructed with proper material and
built in a professional manner, and the sauna heater must be suit-
ed for the cabin.
The sauna heater may only be used in sauna cabins made of
suitable, low-resin and untreated material (e.g. Nordic spruce).
The control unit must not be used in the cabin.
Multiple heaters may be installed in one sauna if the heater out-
put can properly supply the cabin volume. In this case, depend-
ing on the position, an additional safety temperature limiter
must be installed for each additional heater.
The sauna heater is not designed to be installed or set up in an
alcove or under a bench or sloping roof unless the sauna heater
is specifically designed and approved for this type of installa-
tion.
Receptacles may not be installed inside the sauna cabin.
Each sauna cabin must have air inlets and outlets. The air inlets
and outlets may be installed from below or from behind the
heater. The minimum dimensions of the air inlets and outlets
can be found here: 2.5 Technical data, EN-12, 3.1.2 Air inlets
and outlets, EN-17.
The air outlet is always installed in the lower part of the wall, di-
agonal to the sauna heater. The air inlets and outlets must not
be closed. Please observe the instructions provided by your
sauna cabin manufacturer.
Use one of the control units listed below to check and control
the sauna heater. This control unit is fixed to a suitable location
on the cabin's external wall, and the corresponding tempera-
ture sensor according to the installation instructions that ac-
company the control units inside the sauna cabin.

EOS Vision - Installation and Operating Instructions EN-7
General safety instructions
Electrical installations and equipment in the sauna cabin must
comply with IEC 60364-7-703 (DIN VDE 0100-703).
The cabin lighting must be safe for sauna cabin use and in-
stalled in such a way that it can be used safely in a sauna cabin.
Ensure that the heater is installed in compliance with the stand-
ards and legal norms valid in your country.
The cabin door must open outward and must not have a lock
that cannot be opened in the case of failure. We recommend
magnetic or spring locks.
The door opening should be > 80 cm.
1.2 Operator instruction
The operator of the sauna cabin must be instructed in the general
safety instructions during commissioning. The operator must be
given a copy of the operating instructions.
Risk of electric shock A risk to life and limb from electric shock and fire arises in the event
of improper repair work. This risk remains also after work is com-
pleted.
The housing cover must only be removed by a trained special-
ist.
Repairs and installations must only be performed by a trained
specialist.
The system must be disconnected and removed entirely from
the mains supply before commencing repair work.
Use only original spare parts from the manufacturer.
Fire hazard Objects placed on the heater can easily be ignited and cause fires.
Do not place objects on the heater.
Fill the rock store as directed.
Attach the heater guard rail.
Inspect the sauna cabin prior to each commissioning.
If you operate the sauna heater using pre-set timers or a remote
control, install a suitable safety system.
Health risks Spending time in a sauna cabin can lead to serious health risks or
even death for persons with health impairments.
Persons with health impairments who spend time in a sauna
must consult a doctor before entering a sauna cabin.

EN-8 Installation and Operating Instructions - EOS Vision
General safety instructions
EN
Equipment damage
due to overuse
If the cabin is used commercially, the heating time must be set so
that the sauna heater switches off automatically after a specific pe-
riod of time.
If the heating does not switch off automatically after a defined
heating period, cabin use must be supervised at all times.
Inspect the cabin before each use.
Damage to health Excessive time spent in a heated sauna cabin can lead to overheat-
ing of the body (hyperthermia), which may cause serious health
problems and even death. Hyperthermia occurs when the core
temperature of the body exceeds the norm by a few degrees.
Symptoms of hyperthermia include fever, dizziness, lethargy,
sleepiness, and fainting. Side effects of hyperthermia include per-
ception disorders, inability to recognize the need to leave the
room, inability to identify imminent danger, harm to the foetus in
the case of pregnant women, inability to physically leave the
room, unconsciousness.
Alcohol, drugs, and medications increase the risk of hyperthermia.
Do not exceed the maximum recommended time in the sauna.
Leave the sauna cabin if your body responds abnormally to the
heat or if you do not feel well.
Avoid alcohol, drugs, and medications when you are using the
sauna.
Operation by
children or persons
with reduced mental
capacity
This unit should not be used by children or persons with reduced
mental capacity or limited physical or sensory abilities.
Children must be supervised to ensure they do not play with
the unit.
Children and persons who have not received proper instruction
must not clean or service the system.

EOS Vision - Installation and Operating Instructions EN-9
General safety instructions
1.3 Safety levels
Safety instructions and important operating instructions are classified
according to ANSI Z535.6. Please familiarise yourself with the following
terms and symbols:
WARNING
Warning
Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Caution
Indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
NOTICE
Notice
Indicates a hazardous situation which, if not avoided, will result in
damage to the unit.
1.4 Standards and regulations
For an overview of the standards that were observed during design and
construction of the sauna heaters, please refer to the individual product’s
technical data sheet that can be downloaded from www.eos-sauna.com.
Local regulations also apply to the installation and operation of heating,
sauna, and steam room systems.

2
EN-10 Installation and Operating Instructions - EOS Vision
Identification
EN
Identification
EOS Vision/Vision Stone is an electrically heated sauna heater for Finnish
mode available in a variety of output capacities.
2.1 Requirements for operation
The heater must be operated with one of the following control units:
EmoStyle series
EmoTec series
EmoTouch series
Econ series (Econ D2 and higher)
Compact series
The control unit is not included in the scope of delivery.
A power extension unit is also required for the output capacities 12 and
15 kW.
2.2 Nameplate
A Name
B Model
C Item number
D Electrical connection
E Country of origin
F Manufacturer
G Heater output
H Manufacturing date
I Serial number
Elektro-Saunaofen
Type EOS 9LVLRQ
Art. Nr. 94 XXXX 00
400V 3N ~ 50 Hz XX kW
IPX4
Made in Germany 00001S-No. 41.22
EOS SAUNATECHNIK GmbH, Schneiderstriesch 1, 35759 Driedorf
H I
A
F
E
D
C
B
G

EOS Vision - Installation and Operating Instructions EN-11
Identification
2.3 Scope of delivery
Check the unit upon delivery to ensure that all components were delivered
and
that it is in proper working order. Contact your distributor if components
are missing or damaged. The heater must not be operated if components
are missing or damaged.
The base plate is made of different stone variations depending on the
model.
The following parts are included in the scope of delivery:
2.4 Accessories (optional)
It is essential that the unit is protected from being touched. We recom-
mend using the EOS heater guard rail.
A Vision sauna heater with base plate C Connecting cable, 8 m, pre-installed
B Sauna stones, 40 kg
Caliber 50–100 mm
D Installation and Operating Instruc-
tions
D
A
C
B
Accessories (optional) Item number
Heater guard rail bracket for Vision 94.8104
Heater guard rail, stainless steel + heater guard rail
bracket for Vision
(completely pre-assembled)
94.8105

EN-12 Installation and Operating Instructions - EOS Vision
Identification
EN
2.5 Technical data
All line cross-section specifications are the minimum cross-sections for the
copper line. The sauna heater must be operated by a sauna control unit.
*) Not required for Compact D18/H18 control units.
Heater output 9 kW 10 kW 12 kW 15 kW
Unit dimensions HxWxD in cm 95 x 60 x 60
For cabin volume 9–14 m³ 11–15 m³ 14–18 m³ 18–25 m³
Minimum size
Air inlets and outlets 35 x 6 cm 35 x 7 cm 35 x 9 cm
Weight without rocks Vision: 89.5 kg
Vision Stone: 91 kg
Stone filling weight ~ 40 kg
Caliber 50–100 mm
Power extension unit No LSG 10*
Power connection 400 V 3N ~ 50 Hz
Connection mains – control unit 5 x 2.5 mm²
Connection control unit – heater 5 x 1.5 mm²
Connection mains – LSG -5 x 2.5 mm²
Connection LSG – heater - 5 x 1.5 mm²
Connection control unit – LSG -4 x 1.5 mm²
Leakage current Max. 0.75 mA per kW heater output
Fuse protection for control unit 3 x 16 A
Fuse protection for LSG unit 3 x 16 A

EOS Vision - Installation and Operating Instructions EN-13
Identification
2.6 Intended use
This heater is intended solely for the purpose of heating sauna cabins,
together with a suitable control unit.
EOS Vision/Vision Stone is suitable for commercial and private use.
The heater is not suitable for outdoor use.
It must be operated only inside buildings and may not be exposed to envi-
ronmental conditions such as extreme humidity and moisture or the possi-
ble formation of condensation or corrosive substances in the ambient air,
as well as other weather conditions.
Any use beyond this is considered improper use. Proper use also includes
compliance with operating, maintenance and servicing requirements.
Foreseeable misuse
The following are considered instances of foreseeable misuse:
The heater power does not match the sauna volume.
The control and sensor cable plugs are plugged in incorrectly.
The unit is operated without knowledge of or compliance with the
safety instructions.
Operating, service and maintenance requirements are not observed.
The unit is operated after technical or other modifications are made to
the relay box.
The unit is operated with insufficient air supply or exhaust air.
The unit is operated without sauna stones or with a rock store that is not
filled as directed.
The unit is operated by children under 8 years of age.
The unit is operated by children 8 years of age or older, or persons with
reduced mental capacity who have not been thoroughly instructed in
its use.
The manufacturer is not responsible for unauthorised modifications and
damages resulting from these modifications; the person modifying the
equipment alone shall bear the associated risk.

EN-14 Installation and Operating Instructions - EOS Vision
Identification
EN
General instructions
Please note that an optimal sauna climate can be achieved only if the
cabin with its air inlets and outlets, the sauna heater, and the control
unit are synchronized.
Observe the specifications and information provided by your sauna
retailer.
The sauna heaters heat the sauna cabin with heated convection air.
Fresh air is drawn in through the air inlet. It is warmed and rises (convec-
tion) and is then circulated in the cabin. Some of the used air is pushed
out of the cabin through the cabin's air outlet. This creates a typical
sauna climate in which temperatures of approx. 110°C are achieved
directly below the ceiling. These temperatures drop to approx. 30–40°C
in the cabin along the floor. Therefore, it is not unusual that if the tem-
perature sensor above the sauna heater reads 110°C, the thermometer
that is mounted approx. 20–25 cm below the cabin ceiling on the cabin
wall reads only 85°C.
When the max. temperature is set for the area around the upper sauna
bench, the bathing temperature is typically between 80°C and 90°C.
Please note that the highest temperatures in the cabin are always above
the sauna heater and that is where the temperature sensor and safety
temperature limiter should be mounted according to the installation
instructions.
The first time the cabin is heated, you may notice a slight odour result-
ing from the evaporation of consumables used in the manufacturing
processes. Air out your cabin once it has been heated and before using
the sauna.

3
EOS Vision - Installation and Operating Instructions EN-15
Installation
Installation
This chapter describes how to install Vision. Prior to installing the unit, air
inlets and outlets must be installed in the cabin. It may be necessary to
mount additional fans in the inlets/outlets. All protective films must be
removed.
NOTICE
Damage due to incorrect mounting location
The heater is not suitable for outdoor use.
The heater must be operated only inside buildings and may not
be exposed to environmental conditions such as extreme hu-
midity and moisture or the possible formation of condensation
or corrosive substances in the ambient air, as well as other
weather conditions.
The heater is not designed to be installed or set up in an alcove
or under a bench or sloping roof.
3.1 Specifications for the cabin
The cabin must be planned and installed according to specifications before
the heater is installed. It must be ensured that the heater can be removed
from the cabin even after the cabin has been installed
All electrical installations laid inside the cabin must be suitable for silicone
cables and a temperature of at least 170°C.
All lines must be routed in such a way that they are well-protected, e.g. in a
cable duct. EOS recommends laying all connecting cables through a bend-
able metal tube connected to the protective conductor.
The floor on which the heater stands must be level.
In general, it should be noted that the sauna heater must not be set on a
floor made of highly flammable material (laminate, flooring made of plastic
material, etc.). Ceramic tiles are recommended as a flooring option.

EN-16 Installation and Operating Instructions - EOS Vision
Installation
EN
3.1.1 Installation site
The sauna heaters output selected must be appropriate for the cabin vol-
ume; see 2.5 Technical data, EN-12.
Ceiling height of at least 190 cm
Distance heater – cabin wall min. 8 cm (base plate serves as orientation)
Distance heater – bench (lower than heater) min. 5 cm
Distance heater – bench (higher than heater) min. 8 cm
Distance heater – flammable material (wood wall, sauna bench, etc.);
see the following figures.
A heater guard rail must be mounted around the upper edge of the
heater. It prevents accidental contact with hot parts of the heater.
Dimensions in the cabin
A Cabin ceiling
B Temperature sensor
C Cabin wall
D Heater guard rail
E Heater
F Air inlet
min. 190 cm
95 cm
60 cm
6 cm
5 cm
35 cm
60 cm
6 cm
5 cm
35 cm
60 cm 6 cm
6 cm
60 cm
B
A
C
C
D
E
F
E
D

EOS Vision - Installation and Operating Instructions EN-17
Installation
3.1.2 Air inlets and outlets
Air inlets and outlets must be installed in the cabin to ensure a sufficient air
flow in the cabin and to prevent the heater from overheating.
The required size of the air inlets and outlets depends on the heater out-
put; see 2.5 Technical data, EN-12.
WARNING
Fire hazard from overheating
The heater can overheat if the air supply is insufficient. There is a
risk of death due to fire.
Ensure that the air inlets and outlets provide sufficient ventila-
tion. Install a fan if necessary.
Start the sauna only after all air inlets and outlets have been
opened.
NOTICE
Heating process takes too long
If the heating process takes a long time, the underlying reason is
that the sauna heater receives insufficient air.
A minimum of 5 times the cabin volume of air per hour must be
exchanged.

EN-18 Installation and Operating Instructions - EOS Vision
Installation
EN
Air inlet
Depending on the location of the heater, the air inlet must be installed
below or behind the heater.
Heater is located in the middle of the cabin: air inlet from below
Heater is located in front of the cabin wall: air inlet from the side
If the natural air flow is insufficient, a fan may need to be installed at the
air inlet side.
Supply air from below (figure on the left) and from the side (figure on the right)
Air outlet
The air outlet must meet the following criteria:
Position: across from the heater
Height: 30–50 cm above the cabin floor
A Air inlet B Heater
A
BB
A
A

EOS Vision - Installation and Operating Instructions EN-19
Installation
3.1.3 Temperature sensor
It is essential that the temperature sensor with the safety temperature lim-
iter (STB) is installed.
The temperature sensor with the safety temperature limiter is not included
in the scope of delivery.
WARNING
Risk of fire due to incorrect temperature sensor position
Overheating can occur if the temperature sensor is installed in the
incorrect position; in this case, the sensor may read a lower tem-
perature than actually exists in the cabin.
This would trigger the sauna heater to continue to heat, even
though the desired temperature has already been reached.
Install the sensor as shown in the figure Dimensions in the
cabin, EN-16.
The temperature sensor must be installed where expected temperatures
are the highest, meaning above the heater.
For placement, see Dimensions in the cabin, EN-16.
NOTICE
Malfunction due to damaged temperature sensor
The temperature sensor is protected by its housing.
Ensure that the housing and the temperature sensor are not
damaged during operation.

EN-20 Installation and Operating Instructions - EOS Vision
Installation
EN
3.2 Heater guard rail
CAUTION
Risk of burns if heater is touched.
The outer casing of the heater may become hot and, if touched,
could cause burns.
It is essential that a heater guard rail is installed so that the unit
is protected from being touched.
A heater guard rail must be mounted around the upper edge of the heater.
It prevents accidental contact with hot parts of the heater.
You can purchase a suitable heater guard rail from the sauna heater manu-
facturer. See 2.4 Accessories (optional), EN-11
3.3 Preparing for installation
The heater is supplied packaged on a pallet. The heater and the base plate
sit separately on the pallet. Once the cabin is prepared, the heater and the
base plate are placed in a pre-defined position. Two people should always
transport the heater and the base plate.
Unpacking the heater and base plate
1Remove the heater and base plate packaging.
Leave the heater and base plate on the pallet.
2Remove all transport locks and protective films in the heater.
