Erbe LAP BiSect User manual

DISMANTLING AND ASSEMBLING
LAP BiSect scissors
Dismantling the product The product must be cleaned and disinfected in disassembled condition with jaws opened.
1 Pull out the connecting cable
(no illustration).
2 Hold the handle (a) in such a way that the
moving handle is not obstructed. Press the
push-button and withdraw the shaft (c)
from the handle.
3 Hold the electrode jaws (b) between your
thumb and index nger. Screw the electrode
out of the shaft by turning the rotary wheel
(e) (approx. 6 turns).
4 Withdraw the electrode (d) from the shaft.
5 Pull the insulating tube (b) off the shaft.
Assembling the product
1 Push the insulating tube (b) onto the shaft
(c).
2 Insert the electrode (d) into the shaft up to
the stop position.
3 Hold the electrode jaws (b) between your
thumb and index nger. Screw the electrode
in, tightening it well, by turning the rotary
wheel (e) (approx. 6 turns); do not jam the
thread.
4 Hold the handle (a) just like you would hold
a pen in such a way that the handles face
upwards and the moving handle is not ob-
structed, and press the push-button. Insert
the shaft into the handle (a) until it snaps
into place, without jamming it.
The complete instrument
The four disassembled components:
a Handle b Insulating tube c Shaft d Electrode
c
a
d b
cd
b
a
For the complete notes on use, refer to erbe-med.com
a
c
b
d
b
e
b
e

Insert for LAP BiSect scissors Micro (complete instrument Micro, no. 20195-204) Pieces No.
Insert for LAP BiSect Micro, ø 5 mm, length 350 mm 120195-206
Insert for LAP BiSect scissors Macro (complete instrument Macro, no. 20195-205) Pieces No.
Insert for LAP BiSect Macro, ø 5 mm, length 350 mm 120195-207
Individual components for LAP BiSect Micro and Macro scissors Pieces No.
Shaft tube for LAP BiSect Micro and Macro,
ø 5 mm, length 350 mm 120195-208
Insulated tube for LAP BiSect Micro and Macro,
ø 5 mm, length 350 mm 120195-209
Handle for LAP BiSect Micro and Macro 120195-210
Reconditioning accessories for LAP BiSect Micro and Macro scissors Pieces No.
Cleaning brush, length 650 mm,
for manual cleaning and disinfection 120191-279
Rinsing tube with Luer Lock connector, length 500 mm,
for cleaning and disinfection by machine 120195-201
