Ercol Ella 4241 User manual

ercol Ella Medium Extending Dining
Table
Stock Number: 4241
H75 W170 D90cm
Ref: 2507 / 4241

Thank you for purchasing the ercol Ella Medium Extending Dining Table. Please read the instructions and warnings
carefully before use, to ensure safe and satisfactory operation of this product.
We are committed to making great products possible.
From our in-house Design Team, to our Buyers, we work together to bring great design to life.
Our expert Product Technologists work collaboratively with our buyers and suppliers to assure the legality, safety
and quality of the product we sell.
We are all committed to designing and developing products to the highest industry standards.
We hope you are happy with your ercol product and welcome any feedback or comments you may have.
1
Time to assemble
1 hour
People to assemble

2
Important safety information
Warnings
The product should only be used on firm, level ground.
Keep small parts ot of reach of children.
Ensure the product is fully assembled as illustrated before use.
Do's
Check the pack and make sure you have all the parts listed.
Check all screws or bolts are tightened and inspect regularly.
Make sure the legs remain in contact with the ground at all times.
Dont's
Do not over tighten screws or bolts.
Do not stand on the product.
Don not use power tools to construct as overtightening and panel failure may occur.

3
Your Table
Ref
1
1
2
2
Description Dimensions
Qty
90mm x 900mm x 1640mm
90mm x 900mm x 525mm
1
1
Top Panel
Extension Leaf
750mm x 900mm x 61mm
1
L/H Leg Frame
3
3
4
4
750mm x 900mm x 61mm
1
R/H Leg Frame
Internal dimensions
Stock number: 4241
Table open size:
Table closed size:
H75 W220 D90cm
H75 W170 D90cm

4
Fixtures and fittings
Fixtures and fittings
supplied (actual size)
Ref
A
Description Dimensions Qty
8mm x 40mm 12 Imbus Bolt (Chrome)
Fixtures and fittings
supplied (not actual size)
Ref
C
Description Dimensions Qty
1
Allen Key M6
8
B12
Washer (Chrome)

5
Product Assembly
Ella Medium Extending Dining Table
4241
A
Step 1
Parts, fittings and tools
1 2
2
1
Take out the extension leaf (2).
Step 2
Parts, fittings and tools
Bring together the leg frames (3 and 4) and the top panel (1).
1
3
4
1 3 4

1A
6
Step 4
Parts, fittings and tools
1
3
4
While in extended position, place the extension leaf (2) inside. Move the
leg frame (3) towards the top panel (1) and use catch lock to fix it in
place.
Ella Medium Extending Dining Table
4241
Step 3
Parts, fittings and tools
Attach the leg frames (3 and 4) to the top panel (1) by using 12x imbus
bolts (A) and 12x washers (B).
2
B C
C
43 4
BA
AB
AB
BA

Ella Medium Extending Dining Table
4241
Step 5
Parts, fittings and tools
7
Step 6
Parts, fittings and tools
2
2
In order to extend the table, first free the catch lock and move the leg
frame (3) as shown below.
Take the extension leaf (2) out.
Hold the table
with one hand and
open the drawer
with the other.

Ella Medium Extending Dining Table
4241
Step 7
Parts, fittings and tools
2
2
8
Place the extension leaf (2).
Step 8
Parts, fittings and tools
Move the leg frame (3) and the extension leaf towards the top panel (1)
and use 4 catch locks to fix them in place.

9
ercol
Care and maintenance
Wood Furniture
Wood displays dierent grain patterns depending on which way it is cut - for example, the ‘medullary ray’ which
can appear on oak furniture is a mark of good quality timber - these are just characteristics of the natural beauty
of the wood. Some furniture is also deliberately aged and rustic.
All timber surfaces will change colour and mellow over time. New furniture will initially vary in shade from items
that have been previously purchased.
How to care for your wood furniture
Furniture with hard lacquer, wax polish or painted surface should be dusted with a dry cloth. When using the
surface for serving food and drinks it is best to use protective mats and coasters. Spillages should be wiped up as
soon as possible.
Spray polishes are best avoided as they contain silicones which may spoil the furniture’s surface by building up
over time. Use of cleaning materials containing abrasive compounds, acidic or caustic reagents and any bleaches
containing oxidising reagents should be avoided as prolonged use may damage the lacquer surface. Wipe up spills
immediately. If sticky marks occur on the surface they can be removed with a dilute solution of warm soapy
water. The oending area should be rubbed lightly and then completely dried immediately afterwards, before
replacing any mats etc.
Our furniture will endure most temperatures in the home but it is best to avoid placing furniture next to heat
sources such as radiators or fires. Be particularly careful with solid wood as the lack of humidity caused by
central heating can cause damage such as warping.
Safety Instructions
Never drag furniture when moving it, always lift it. Please take care when handling or moving the furniture as
careless handling may cause damage or injury. No liability will be accepted for damage or injury caused by
incorrectly installed furniture.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX www.ercol.com
YNG TAL 14 / EOMT6 D: 02.05.2018 / RN 003
