ETC®Quick Guide
Source Four®Revolution™ Scroller Cartridge
Scroller Cartridge Quick Guide Page 1 of 2 Electronic Theatre Controls, Inc.
Americas  3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel: [phone]  800 688 4116  Fax: [phone]  800 555 8912
Europe  Unit 5, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel: [phone]  Fax: [phone]
Asia  Room 605-606, Tower III Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel: [phone]  Fax: [phone]
Web : www.etcconnect.com  Email : (US) [e-mail]  (UK) [e-mail]  (Asia) [e-mail]
Service : [e-mail]  Toll free: 800 775 4382  Comments about this document: [e-mail]
7160M1350  Rev A  Released 02/2004  Copyright © 2004 Electronic Theatre Controls, Inc. All RightsReserved. Product information and specifications subject to change.
Overview
The Source Four Revolution fixture is provided with a removable Scroller Cartridge. You
can swap whole cartridges, or you can replace only the gel string within the cartridge.
Remove and replace the Scroller Cartridge:
Step 1: Pull the latch on top of the Scroller Cartridge forward and pull the scroller up out
of the head. The gel string is held in tension and may roll back after being
released from the head.
Step 2: To insert a Scroller Cartridge, align the metal tabs on the fixture with the slots on
the back of the Scroller Cartridge and slide the cartridge back onto the tabs.
Step 3: Pull the latch on the top of the cartridge forward and press the cartridge down
into place.
Step 4: Release the latch. It is spring-loaded and will slide back into the locked position
upon release.
Step 5: Recalibrate the fixture after replacing the scroller cartridge.
Tab
Latch
Pull forward to remove Scroller.
Scroller Cartridge

Quick Guide:
Source Four®Revolution™ Scroller Cartridge
Scroller Cartridge Quick Guide Page 2 of 2 Electronic Theatre Controls, Inc.
Gel Strings
You can change the gel string in your fixture. Replacement strings must have a minimum
of 2 frames or a maximum of 24 frames of gel media. If you are going to make or purchase
your own gel strings, follow the specifications in the Source Four Revolution User Manual
to ensure proper performance.
Replace the gel string:
Step 1: Remove the scroller cartridge from the fixture by pulling the latch forward and
pulling the cartridge up out of the head. The gel string is held in tension and may
roll back after being released from the head.
Step 2: Place the cartridge on a flat surface and, if necessary, wind the gel string back
onto the right spool.
Step 3: When the attachment tab on the left spool is revealed at the end of the leader,
release the tab from the attachment point.
Step 4: Carefully roll up the gel string. When the gel string is rolled up, you will see the
trailer attachment point on the right spool.
Step 5: Detach trailer from the right spool and remove the gel string.
Step 6: Attach the replacement gel string’s trailer to the right spool by feeding the
attachment tab down through the bar/slot and around onto the attachment point.
Step 7: Roll the gel string tightly onto the right spool. Leave enough of the scroll unrolled
to allow you to attach the leader to the left spool. Keep tension on the scroll.
Step 8: With your other hand, placing yourthumb on the bar/slot portion of the left spool,
spin the spool away from the center of the cartridge until the attachment point is
facing up, then spin the spool another eight revolutions to generate the proper
tension in the spring. Continue spinning the spool about 1/4 turn until the bar/slot
is visible and facing the center of the scroller cartridge, as shown above.
Step 9: Feed the end of the leader up through the bar/slot and over onto the attachment
point.
Step 10: When the leader is attached to the left spool, let go of the spools. The gel scroll
should spool a number of frames onto the left spool and then settle.
Step 11: Reset the fixture to calibrate and ensure proper performance of the scroller.
x 8
Trailer
Attachment
Leader
Attachment
To tension the scroller
Leader shown
Left spool
Right spool
Rear View
