fantastic furniture Vision Display Cabinet MK2 User manual

Version: 1.1
Vision
Display Cabinet MK2
www.fantasticfurniture.com.au

Page 2
Love it? Share it!
Fantastic buy! Share how it looks at home on Instagram
for your chance to win a $250 Fantastic Furniture Gift Card!
@fantasticfurniture
fantasticfurniture.com.au
Looks like you’ve found
your Fantastic!
We’re thrilled you’ve chosen Fantastic Furniture
to help create a home you’ll love

Page 3
fantasticfurniture.com.au
Scratches, chips, sudden changes in temperature and hairline fractures may
cause glass to break. This glass is designed to break into small, relatively
harmless pieces and not sharp fragments.
Avoid placing hot or cold items directly onto the table unless using a thick
insulation material such as placemats or coasters.
Avoid dropping objects onto the glass. Do not allow hard or pointed objects to
come into contact with the glass. Never use the top area as a chopping
surface. Do not sit or stand on the glass surface.
Warning: Ensure the wall strap is
attached to avoid serious injury.
To avoid any serious of fatal injury, a wall strap has been provided with
this product to prevent toppling. We strongly recommend that this
product is permanently fixed to the wall or other suitable surface. Fixing
of what fixing device to use.
Tempered Glass
Glass should always be handled with care.
Weight capacity: 10kgs/shelf.
THIS PRODUCT MUST BE ASSEMBLED ON A SOFT
SURFACE SUCH AS CARPET OR A RUG TO PREVENT
ACCIDENTAL SHATTERING DURING ASSEMBLY. IF
YOU DO NOT HAVE THESE IN YOUR HOME THEN LAY
THE CARDBOARD PACKAGING FLAT AND ASSEMBLE
ON TOP OF THE EMPTY PACKAGING.
DO NOT ASSEMBLE ON A HARD SURFACE.

Page 4
Assembly Checklist
Read through the instructions carefully
before you begin
Identify and lay out all of the
components before you begin assembly
! Never use power tools unless specifically instructed. They can damage your
components or hardware if used incorrectly.
! The most common mistakes made during assembly are using the wrong hardware or
getting components back to front.
! Always use a soft surface (such as carpet or cardboard) when assembling your
product to avoid scratching or damaging the surface of the product.
! Bulky items such as wardrobes and bunk beds should be assembled in the room they
will be used in as they may not fit through a door once assembled.
! Never use any glue until you are certain that the parts belong together.
! Periodically check and re-tighten all fasteners. Check the product care label or
website for product care instructions.
components please visit our website Help Centre for further assistance.
Make sure you have all the required tools.
Never use power tools unless instructed.
Unless instructed, do not fully tighten
screws until the item is fully assembled.
Useful information
www.fantasticfurniture.com.au
! Please see page 3 for any safety requirements or weight restrictions.

fantasticfurniture.com.au
Other tools you need
Phillips Head Screwdriver
Parts List:
Base (P1);
Back panel (P2);
Joining brackets (P3) x2;
Side panels (P4) x2;
Top Panel (P5);
Door Panel (P6);
Shelves (P7) x3;
Hardware Pack
What you need
to assemble the product
Door
panel
(P6)
Base (P1)
8 x Bolts
(H1)
4 x Metal Brackets
(H2)
4 x Transparent
Washers (H3)
28 x Washers
(H4)
4 x Feet
(H5)
4 x Feet Screws
(H6)
12 x Shelf Supports
& Screws (H7)
2 x Door Hinges
& Hinge Plates (H8)
2 x Hinge Sleeves
(H9)
1 x Door Plate
& Foam Insert (H11)
1 x Door Handle
& Foam Insert (H12)
1 x Wall Strap
(H13)
1 x Wall Strap
Screw (H14)
2 x Wall Strap
Washers (H15)
Page 5
Side
panel
(P4)
Side
panel
(P4)
Joining brackets
P3)
Joining brackets
P3)
Top
panel (P5)
Back
panel
(P2)
Shelves (P7)
Shelves (P7)
Shelves (P7)
2 x Magnetic Door
Catches (H10)

Page 6
fantasticfurniture.com.au
Step 1
Attach 4 x Feet (H5) to the underside of the Base (P1) with 4 x Feet Screws (H6) by
tightening with the Phillips Head Screwdriver.
You will need
4 x Feet Screws
(H6)
4 x Feet
(H5)
Phillips head
Screwdriver
Step 2
Turn Base (P1) over to rest on Feet (H5). Insert Back Panel (P5) into the groove of
the Base (P1) as shown.
Base
(P1)
Back
(P2)
(H5)
(H6)
(H5)
(H6)
(H5)
(H6)
(H5)
(H6) Base
(P1)
THIS PRODUCT MUST BE ASSEMBLED ON A SOFT
SURFACE SUCH AS CARPET OR A RUG TO PREVENT
ACCIDENTAL SHATTERING DURING ASSEMBLY. IF YOU
DO NOT HAVE A SOFT SURFACE. LAY THE CARDBOARD
PACKAGING FLAT AND USE AS A BASE FOR ASSEMBLY.

fantasticfurniture.com.au
Step 4
Step 3
Slide the Joining Brackets (P3x2) onto each side
of the Back Panel (P2) and into the Base (P1).
Ensure that the shorter side of the Joining Brackets
(P3x2) are attached to the Back Panel (P2) as shown.
Push down on the Joining Brackets (P3x2) to ensure
that they are firmly secured into the Base (P1).
Insert Side Panel (P4) into Joining Bracket (P3) and groove of the Base (P1) as shown.
Ensure that it is secured firmly. Repeat for the second Side Panel (P4). Push down on
the Joining Brackets (P3x2) to ensure that they are firmly secured into the Base (P1).
Page 7
(P4)
(P4)
(P1)
(P2)
(P1)
(P3) (P3)
(P3)
6mm
6mm
9mm
6mm
11mm
(P2)
(P4)
(P4)
(P3) (P3)

fantasticfurniture.com.au
Step 5
(H1)
(H4)
(H3)
(H1)
You will need
4 x Metal
Brackets (H2) 8 x Bolts (H1)
Phillips head
screwdriver
4 x Washers (H4)
4 x Transparent
washers (H3)
Step 6
Align the grooves on the Top Panel (P5) with the top of Back & Side Panels (P2&P4x2)
and then place securely.
Page 8
Secure Top and Base Panels (P5&P1) to Side Panels (P4x2) by attaching 4 x Metal
Brackets (H2) with 8 x Bolts (H1), 4 x Transparent Washers (H3) and 4 x Washers
(H4) at each end of the Side Panels (P4x2) by tightening with the Phillips Head
Screwdriver as shown.
(P4)
(P4)
(P2)
(P5)
(P4) (P4)
(P1)
(P5)
(H2)
(P4)

fantasticfurniture.com.au
Step 7
(P4)
(P4) (H7)
(H4)
(H4)
(H7)
(H10)
(H10)
(P5)
(P1)
24 x Washers (H4)
You will need
12 x Shelf Supports
& Screws (H7)
2 x Magnetic
Door Catches (H10)
You will need
Phillips head
Screwdriver
2x Door hinges/hinge
plates (H8)
Note: the door can be fitted to
open from the left or right side
of the cabinet. These instructions
show how to assemble the door to open from the
left side. If you prefer the door to open from the right side, place the Magnetic Door Catches
on the opposite side of the Top & Bottom Panels.
Insert 2 x Magnetic Door Catches (H10) into the Top and Bottom Panels (P5&P1). Attach 12 x
Shelf Supports & Screws (H7) to Side Panels (P4x2) with 24 x Washers (H4) as shown.
Step 8
ends of the Door Panel (P6) as shown. Slide 2 x Door Hinges (H8) over the top of the Hinge
Plates (H8), ensuring the hinge nodule is positioned in the corners of the Door Panel (P6),
then secure with the Hinge Bolts by tightening with a Phillips Head Screwdriver.
Do not overtighten.
Page 9
(H8)
(P6)
(H8)
(H8)
Peel the backing o 2x Hinge Plates (H8) to expose the adhesive side and place at adjacent

(H12)
Step 9
fantasticfurniture.com.au
You will need
Phillips head
Screwdriver
2x Hinge Sleeves
(H9)
You will need
1x Door handle/
foam insert (H12)
1x Door plate/
foam insert (H11)
Step 10
Page 10
Remove foam insert from the Door Plate (H11).
Peel the backing o the foam insert to expose
the adhesive side and place at the bottom corner of the Door Panel (P6) as shown.
Slide the Door Plate (H11) over the foam insert at the bottom of Door Panel (P6).
Repeat steps to attach the Door Handle (H12) at the top of Door Panel (P6).
(H11)
Note: This step shows the door being fitted to open
from the left side of the cabinet. If you wish to open
from the right side, please ensure the Magnetic Door
Catches are placed on the right side of the Top &
Bottom Panels and attach the Door Panel on the
opposite side.
Insert 2 x Hinge Sleeves (H9) into Top & Bottom
Panels (P5&P1) as shown. Insert the Door Hinge (H8)
at the bottom of the Door Panel (P6) into the Hinge
Sleeve (H9) in the Base (P1). Loosen the Door Hinge (H8) at the top
of the Door Panel (P6) with the Phillips Head Screwdriver so that the
Door Hinge can slide along the top of the Door Panel. Insert the Door
Hinge (H8) at the top of the Door Panel (P6) into the Hinge Sleeve (H9)
in the Top Panel (P5) then slide the top corner of the Door Panel into the
Door Hinge. Ensure the Door Hinge is aligned with the Hinge Plate then
secure by tightening the Hinge Bolts with Phillips Head Screwdriver.
(H9)
(H9)
(P6)
(P1)
(P5)
(H11)
(H11)
(H12) (H12)

F
fantasticfurniture.com.au
Step 11
(P7)
(P7)
(P7)
Page 11
Carefully place each Shelf (P7x3) into the cabinet by resting
gently on the Shelf Supports (H7) as shown. Ensure each
Shelf is sitting securely on all four Shelf Supports.
Step 12
You will need
Phillips head
Screwdriver
1 x Wall strap
screw (H14)
1x Wall strap
washer (H15)
(H13) (H14)
Fix Wall Strap (H13) to Top Panel (P5) with Wall Strap
Washer (H15) and Wall Strap Screw (H14) as shown by
tightening with the Phillips Head Screwdriver.
1x Wall strap
(H13)
We strongly advise that you use
the wall safety strap provided to
prevent the unit from toppling. (H15)
(P5)

Step 13
fantasticfurniture.com.au
Step 14
Page 12
Job complete!
In the interest of our environment please dispose
of all packaging thoughtfully.
You will need
Phillips head
Screwdriver
1x Wall strap
washer (H15)
Move the cabinet to the final position and attach
the Wall Strap (H13) to the wall securely.
Seek advice from a qualified
tradesperson on how to attach
safety strap to the wall.
Screw & wall plug are not
provided. Please use appropriate
fixtures for your wall.
(H13)
(H15)
Wall
