Repair instructions

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 2/53
1. Models described
2. Technical data
3. Notes / requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Disassembly
7. Assembly
8. Troubleshooting
9. Connection diagram
Contents

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 3/53
These instructions describe how to repair the following models:
Model Order no.
ASW 14-30-PC 7 112 53 00 95 0
1. Models described

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 4/53
2. Technical data
Technical data
The complete technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet
(Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 5/53
3. Notes / requirements
Note
These instructions are only intended for persons with suitable technical training. It is assumed
that the reader has mechanical and electrical training.
Only use original FEIN spare parts!
Requirements
Please note that power tools may only be repaired, maintained and checked by a trained
electrician, as improper repair can result in serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employers’ liability insurance associations are
to be observed when commissioning.
The German Equipment and Product SafetyAct applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 6/53
3. Notes / requirements
WARNING!
Damage from electrostatic charging.
Failure to comply with the safety regulations for ESD protection may cause tool damage.
Only undertake assembly/disassembly work on the tool at a workplace with
ESD protection.

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 7/53
Standard tool Special tools
- Torx 10 screwdriver
- Small slotted screwdriver
- Circlip pliers
- Circlip pliers (ground)
- Open-ended spanner, WAF 27, 32
- Flat nose pliers
- Feeler gauge
- Spring balance
- Torque wrench 3 21 23 002 00 6
- Drawing-off socket cap 6 41 04 150 00 8
- Puller 6 41 07 019 00 7
- Adjustable pin wrench 6 29 10 029 00 7
NOTE
You can only order special tools with an order number from FEIN.
4. Tools required

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 8/53
Lubricants
ASW
Grease 3 21 600 14 23 0 0.6g Tool holder; switch ring; cam ring
5. Lubricants and auxiliary substances required
Auxiliary substances
Loctite 638

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 9/53
6. Disassembly
Removing angled head
1. Grip thread ring (1) and unscrew angled head (2) (left-handed thread). Tools:
- Open-ended spanner,
WAF 27
- Open-ended spanner,
WAF 32
2
1

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 10/53
6. Disassembly
Removing angled head
1. Take off angled head (1).
2. Remove connector (2). Tools:
- Open-ended spanner,
WAF 27
- Open-ended spanner,
WAF 32
2
1

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 11/53
6. Disassembly
Removing planetary gear
1. Remove round seal ring (1). Tools:
-Small screwdriver
1

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 12/53
6. Disassembly
Disassembling housing
1. Loosen the eight screws (1). Tools:
- Torx T10 screwdriver
1

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 13/53
6. Disassembly
Disassembling housing
1. Slide sliding cover (1) into gearbox housing.
2. Carefully pry off top part of housing (2).
Place screwdriver between coupling and housing.
Tools:
- Screwdriver
1
1
2

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 14/53
6. Disassembly
Disassembling housing
1. Remove upper part of housing (1).
1

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 15/53
6. Disassembly
Removing clutch
1. Carefully remove the electronic strip (1).
2. Lift the clutch (2) slightly with a screwdriver.
NOTE
When the slide switch is removed, the spring (4) may jump out slightly.
3. Remove slide switch (3).
4. Remove spring (4).
Tools:
- Slotted screwdriver
- Flat-nose pliers
2
1
3
4

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 16/53
6. Disassembly
Removing clutch
1. Remove clutch (1).
2. Pull out straight pins (2) from the flange.
2
1

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 17/53
6. Disassembly
Removing clutch
1. Tension the spring (1) fully to allow better access to the circlip.
The adjusting ring has a left-handed thread.
2. Remove circlip (2).
NOTE
You need modified circlip pliers to dismantle the circlip. The upper side of the pliers must be ground flat.
Tools:
- Torque wrench (supplied)
- Circlip pliers (ground)
1
2

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 18/53
6. Disassembly
Removing clutch
NOTE
The compensating discs in front of and behind the ball bearing must be replaced in the same position
upon assembly. The discs are used to adjust play between slide switch and switch ring on clutch.
1. Remove flange (1) and take disc(s) out of flange.
2. Remove connector (2).
The flange and gearbox are inseparably glued with Loctite, spare parts are
supplied individually and have to be glued together upon assembly.
Tools:
-Circlip pliers
- Drawing-off socket cap
(6 41 04 150 00 8)
- Ball bearing puller 19mm
(6 41 07 019 00 7)
1 2

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 19/53
6. Disassembly
Removing clutch
1. Remove circlip (3).
Use a new circlip for assembly each time.
2. Pull off ball bearing (4).
Tools:
-Circlip pliers
- Drawing-off socket cap
(6 41 04 150 00 8)
- Ball bearing puller 19mm
(6 41 07 019 00 7)
3
4

ASW 14-30-PC
C-SC_CSSM VERSION 1.0 14-07-22 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 20/53
6. Disassembly
Removing clutch
1. Remove discs (1).
2. Remove circlip (2).
2
1
