Festo Smart cubic CPA-SC Series User manual

Pneumatics manual
CPA−SC valve
terminal
CPA−SC individual
location base block
Type CPA−SC−...
Manual
530 933
en 0412b
[690 375]
Compact performance − Smart cubic

Contents and general instructions
I
Festo P.BE−CPASC−EN en 0412b
Original de. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Edition en 0412b. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Designation P.BE−CPASC−EN. . . . . . . . . . . . . . . . . . . . . . . . . .
Order no. 530 933. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
E(Festo AG&Co. KG, D73726 Esslingen, Germany, 2004)
Internet: http://www.festo.com
E−Mail: [e-mail]
The reproduction, distribution and utilization of this docu
ment as well as the communicaton of its contents to others
without express authorization is prohibited. Offenders will
be held liable for the payment of damages. All rights reser
ved in the event of the grant of a patent, utility module or
design.

Contents and general instructions
II Festo P.BE−CPASC−EN en 0412b

Contents and general instructions
III
Festo P.BE−CPASC−EN en 0412b
Contents
Designated use V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Target group V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Notes on the use of this manual VI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important user instructions X. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Index of abbreviations XII. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Summary of components 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 The CPA−SC valve terminal 1−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.1 Overview of variants 1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description of components 1−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.1 CPA−SC valve terminal 1−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.2 CPA−SC individual location base block 1−16. . . . . . . . . . . . . . . . . . . . . . .
1.2.3 Ident. code of the pneumatic components 1−17. . . . . . . . . . . . . . . . . . .
1.2.4 Connecting and operating elements of the
CPA−SC valve terminal 1−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.5 Connecting and operating elements of the
CPA−SC individual valve 1−23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Fitting 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 General instructions on fitting and dismantling 2−4. . . . . . . . . . . . . . . . . . . . . . .
2.2 Fitting variants 2−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2.1 Fitting onto/removing from a hat rail 2−6. . . . . . . . . . . . . . . . . . . . . . . .
2.2.2 Fitting onto a wall 2−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 CPA−SC individual location base block 2−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Fitting the manual override caps (optional) 2−12. . . . . . . . . . . . . . . . . . . . . . . . . .
3. Installation 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Preparing the compressed air 3−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 Operation with non−lubricated compressed air 3−4. . . . . . . . . . . . . . . .
3.1.2 Operation with lubricated compressed air 3−4. . . . . . . . . . . . . . . . . . . .

Contents and general instructions
IV Festo P.BE−CPASC−EN en 0412b
3.2 Pilot control of the valve solenoid coils (pilot air) 3−6. . . . . . . . . . . . . . . . . . . . .
3.3 Pressure zone separation 3−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Vacuum/low pressure operation 3−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Connecting the CPA−SC valve terminal/individual location base block 3−13. . . . .
3.5.1 Connecting the pneumatic tubing 3−14. . . . . . . . . . . . . . . . . . . . . . . . . .
3.5.2 Loosening the pneumatic connections 3−21. . . . . . . . . . . . . . . . . . . . . . .
3.5.3 Connecting the electric cables 3−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6 Address assignment of the valves 3−26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Commissioning 4−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 General instructions 4−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.1 Before commissioning 4−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.2 Pressure build−up of the complete supply 4−4. . . . . . . . . . . . . . . . . . . .
4.2 Manual override 4−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Testing the valves and the valve−actuator combination 4−9. . . . . . . . . . . . . . . . .
4.4 LED display of the valves 4−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.5 Trouble shooting 4−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.5.1 Impairment of function 4−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Maintenance and conversion 5−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 General precautionary measures 5−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Dismantling the CPA−SC valve terminal 5−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Replacing CPA−SC components 5−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3.1 Replacing valve plates or blanking plates 5−7. . . . . . . . . . . . . . . . . . . .
5.3.2 Fitting/dismantling the pressure zone separator element 5−9. . . . . . .
A. Technical appendix A−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1 Technical data A−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2 Festo accessories A−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.3 Overview of the valve plates A−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B. Index B−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents and general instructions
V
Festo P.BE−CPASC−EN en 0412b
Designated use
The CPA−SC valve terminals or CPA−SC individual location
base blocks described in this manual are intended for fitting
into a machine or automated system. It is absolutely necess
ary to observe the safety instructions in this manual as well
as the designated use of the relevant CPA−SC valve terminal
or CPA−SC individual location base block. The CPA−SC valve
terminals or CPA−SC individual location base blocks may only
be used as follows:
asintended in industrial installations.
inorignal condition without any modifications by the user
Only the conversions or modifications described in the
documentation supplied with the product are permitted.
infaultless technical condition.
When used together with commercially available compo
nents, such as actuators, the specified limits for pressures,
temperatures, electrical data, torques etc. must be observed.
National and local safety regulations must also be observed.
Target group
This manual is intended exclusively for technicians trained in
control and automation technology who have experience in
fitting, installing, commissioning, servicing and converting
pneumatic components.
Service
Please consult your local Festo repair service if you have any
technical problems.

Contents and general instructions
VI Festo P.BE−CPASC−EN en 0412b
Notes on the use of this manual
This manual contains specific information on fitting, installing,
commissioning, servicing and converting the CPA−SC valve
terminal and the CPA−SC individual location base block. This
manual deals exclusively with the pneumatic components
and refers to the valve terminal or individual location base
block variants listed in the following tables.
Valve terminals
Electrical variants Pneumatic variants
Sub−base valves
typeCPASC...
Semi−inline valves
typeCPPSC...
Field bus direct connection
(DIconnection)
Information on electric/
electronic components:
See Electronics manual
CPA−SC−DN
Tab.0/1: Electrical connecting variants of the CPA−SC valve terminal with field bus
direct module DeviceNet"

Contents and general instructions
VII
Festo P.BE−CPASC−EN en 0412b
Valve terminals
Electrical variants Pneumatic variants
Sub−base valves
type CPASC...
Semi−inline valves
type CPPSC...
Multipin connection with
Sub−D socket (MP connection)
Information on electric
components: See information
supplied with the product
Multipin connection with plug
strip for ribbon cable
(FLconnection)
Information on electric
components: See information
supplied with the product
Tab.0/2: Electrical connecting variants of the valve terminal with multipin connection

Contents and general instructions
VIII Festo P.BE−CPASC−EN en 0412b
Valve terminals
Electrical variants Pneumatic variants
Sub−base valves
type CPASC...
Semi−inline valves
type CPPSC...
Plug−in connection
(PIconnection)
Information on the electric
components: in this manual
Horizontal connector
(HCconnection)
Information on the electric
components: in this manual
Tab.0/3: Electrical connecting variants of the valve terminal with individual connection

Contents and general instructions
IX
Festo P.BE−CPASC−EN en 0412b
CPA−SC individual location base block
Electrical variants Pneumatic variants
Sub−base valves
type CPASC...
Semi−inline valves
type CPPSC...
Plug−in connection
(PIconnection)
Information on electric/
electronic components:
inthis manual
Horizontal connector
(HCconnection)
Information on electric/
electronic components:
inthis manual
Tab.0/4: Electrical connecting variants of the individul location base blocks
This manual contains the documentation of the valve
plates with the Ident. codes B, E, G, I, J, K, M, N and X
(seeappendix A).

Contents and general instructions
XFesto P.BE−CPASC−EN en 0412b
Important user instructions
Danger categories
This manual contains instructions on the possible dangers
which may occur if the product is not used correctly. These
instructions are marked (Warning, Caution, etc.), printed on a
shaded background and marked additionally with a picto
gram. A distinction is made between the following danger
warnings:
Warning
This means that failure to observe this instruction may
result in serious personal injury or damage to property.
Caution
This means that failure to observe this instruction may
result in personal injury or damage to property.
Please note
This means that failure to observe this instruction may
result in damage to property.
The following pictogram marks passages in the text which
describe activities with electrostatically sensitive compo
nents.
Electrostatically sensitive components may be damaged if
they are not handled correctly.

Contents and general instructions
XI
Festo P.BE−CPASC−EN en 0412b
Marking special information
The following pictograms mark passages in the text contain
ing special information.
Pictograms
Information:
Recommendations, tips and references to other sources of
information.
Accessories:
Information on necessary or sensible accessories for the
Festo product.
Environment:
Information on environment−friendly use of Festo products.
Text markings
·The bullet indicates activities which may be carried out in
any order.
1. Figures denote activities which must be carried out in the
numerical order specified.
 Hyphens indicate general activities.

Contents and general instructions
XII Festo P.BE−CPASC−EN en 0412b
Index of abbreviations
The following product−specific terms and abbreviations are
used in this manual:
Term Meaning
Base block Sub−base:
 Base for sub−base valves and blanking plates
 With connections for air supply (1, 12/14) and exhaust (3, 5, 82/84)
 With work connections (2, 4)
 With pressure compensation hole (L)
PRS block:
 Base for semi−inline valve plates and blanking plates
 With connections for air supply (1, 12/14) and exhaust (3, 5, 82/84)
Without work connections
 With pressure compensation hole (L)
Blanking plate Plate without valve function, for reserving valve locations.
Components Common term for base block, valve plates and blanking plates
CP Compact Performance
CPA−SC valve terminal Compact Performance sub−base  Smart Cubic valve terminal (type 82) with
HC, PI, FL or MP connection.
DI connection CPA−SC valve terminal variant field bus direct DeviceNet"
FL connection CPA−SC valve terminal variant with 26−pin multipin plug strip for ribbon
cables as per DIN EN 60603−13. All valve solenoid coils are connected
centrally via this plug strip.
HC connection CPA−SC variant on which each valve plate has a horizontal connection.
Each valve is connected electrically with a special cable via this connection.
Ident. code (I.C.) Identification Code. This is usually printed on the relevant component.
The component can be identified with this code (see Tab.1/12).
Manual override Manual override
MP connection CPA−SC valve terminal with 25−pin multipin sub−D connection. All valve
solenoid coils are connected centrally via this connection.
PI connection CPA−SC variant on which each valve plate has a plug−in connection (vertical
connection). The relevant base block has a plug base for the electrical
linking of the valve solenoid coils.

Contents and general instructions
XIII
Festo P.BE−CPASC−EN en 0412b
Term Meaning
Semi−inline valve Valve plate variant with work connections (2, 4) on the valve. These are
intended for fitting on PRS base blocks (see base blocks).
Sub−base valve Valve plate variant without work connections (2, 4). These may only be fitted
onto sub−bases (see base blocks).
Tubing Connecting the supply lines (tubing) to the CPA−SC
Valve plate Plate with single−solenoid, double−solenoid or mid−position valve
Tab.0/5: Product−specific terms and abbreviations

Contents and general instructions
XIV Festo P.BE−CPASC−EN en 0412b

Summary of components
1−1Festo P.BE−CPASC−EN en 0412b
Chapter 1

1. Summary of components
1−2 Festo P.BE−CPASC−EN en 0412b
Contents
1. Summary of components 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 The CPA−SC valve terminal 1−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.1 Overview of variants 1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description of components 1−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.1 CPA−SC valve terminal 1−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.2 CPA−SC individual location base block 1−16. . . . . . . . . . . . . . . . . . . . . . .
1.2.3 Ident. code of the pneumatic components 1−17. . . . . . . . . . . . . . . . . . .
1.2.4 Connecting and operating elements of the
CPA−SC valve terminal 1−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.5 Connecting and operating elements of the
CPA−SC individual valve 1−23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1. Summary of components
1−3
Festo P.BE−CPASC−EN en 0412b
Contents of this chapter This chapter provides an overview of the following aspects of
the CPA−SC valve terminal
 connection variants and components on the valve
terminal
 the maximum number of valve locations
 the identification code of the pneumatic components
 the connecting, display and operating elements
Further information Information on the electric multipin can be found in the brief
description CPA−SC multipin connection.

1. Summary of components
1−4 Festo P.BE−CPASC−EN en 0412b
1.1 The CPA−SC valve terminal
Festo assists you in solving your automation task at the ma
chine level with the CPA−SC series of valve terminals. The va
riey of variants in this series enables you to optimally incor
porate the CPA−SC in your machine or system.
Due to their compact design, the CPA−SC valve terminals can
be fitted close to the actuators to be controlled. This enables
short compressed air tubing to be used. System losses will
therefore be minimized and the times required for pressuriz
ing and exhausting the compressed air tubing will be redu
ced. This is made possible by the use of very compact valves
with sufficient flow, thereby helping to reduce costs.
