Designated use
The SPC-10 is designed for fitting into a machine or an
automated system.
In conjunction with a cylinder of type DGP(L)-..., the
potentiometer type MLO-POT-...-TFL and a proportional
directional control valve type MPYE-5-... , the SPC-10
can move at speed to one of two end positions set with
fixed stops. The end position cushioning is regulated
electronically. The cushioning path of the internal end
position cushioning of the cylinder (PPV) should not
project into the range of the working stroke.
The SPC-10 may only be used as follows:
– in accordance with designated use
– in its original state
– without any modifcations by the user
– in faultless technical condition.
When used together with commercially available com-
ponents, such as sensors and actuators, the specified
limits for pressures, temperatures, electrical data, tor-
ques etc. must be observed. National and local safety
regulations must also be observed.
Service
Please consult your local Festo repair service if you
have any technical problems.
SPC-10 9902a V

Target group
This manual is directed exclusively at technicians
trained in control and automation technology.
Important user instructions
This manual contains instructions on the possible
dangers which may occur if the SPC-10 is not used
correctly. These instructions are printed in italics, are
enclosed in a frame and also marked with a pictogram.
Danger
categories
A distinction is made between the following:
WARNING
This means that serious personal injury or material
damage can occur if this warning is not observed.
CAUTION
This means that personal injury or material damage
can occur if this warning is not observed.
PLEASE NOTE
This means that material damage can occur if this
warning is not observed.
VI SPC-10 9902a

The following pictograms are used.Pictograms
Uncontrolled movements of loose tubing.
Undesired movements of the connected actuators.
Recommendations and tips are marked with this picto-
gram.
•The bullet indicates activites which may be carried
out in any order.
Text
markings
1. Figures indicate activities which must be carried out
in the sequence shown from top to bottom.
– Hyphens indicate general activities.
SPC-10 9902a VII

VIII SPC-10 9902a

Chapter 1
Summary of system
1. Summary of system
SPC-10 9902a 1-1

Contents
1. Summary of system
1.1 Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2 Method of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.3 Displays and connections on the SPC-10 . . . . . . . . . . . . . . . . . 1-8
1. Summary of system
1-2 SPC-10 9902a

1.1 Structure
In conjunction with a cylinder of type DGP(L)-..., the
potentiometer type MLO-POT-...-TFL and a proportional
directional control valve type MPYE-5-... , the SPC-10
can move at speed to one of two end positions set with
fixed stops. The end position cushioning is regulated
electronically. The diagram below shows the principal
structure of a cylinder with the SPC-10.
1
2
3
4
Potentiometer type MLO-POT-...-TLF
SPC-10
Proportional directional control valve
type MPYE-5-...
Service unit with 5 µm filter, without lubricator
5
6
7
Compressed air supply
(5 to 7 bar)
Cylinder type DGP(L)-...
Fixed stop (e.g. KYP-...)
Fig. 1/1: Structure of a cylinder with SPC-10
2
1
4
5
3
7
67
1. Summary of system
SPC-10 9902a 1-3

With the SPC-10, movement from one fixed stop to the
other is closed-loop regulated. During commissioning,
the end positions (position of the fixed stops) are
”taught” by the SPC-10. During operation it then en-
sures that the slide moves at the highest possible
speed into the programmed end positions under closed-
loop control. Shortly before the slide reaches the end
position, it is braked so that it comes to a stop in the
end position.
In order that the slide remains in the end position, it is
pressed against the fixed stop, at maximum with a
pressure equal to the operating pressure.
Compared with pneumatic-impact drives with double-
solenoid control, this closed-loop procedure permits
higher positioning speeds. Also, the following measures,
which would be required for controlling a cylinder with a
single-solenoid valve, can be dispensed with:
Advantages
•the use of restrictors
•the use of limit switches
•the use of mechanical end position cushioning
(shock absorbers)
•the maintenance of fixed stops.
Compared with pneumatic-impact drives with double-
solenoid control, the SPC-10 permits:
•higher machine cycle times
•less vibration of the system
•lower maintenance costs.
1. Summary of system
1-4 SPC-10 9902a

You will require the following components for imple-
menting fast movement with electronically closed-loop
controlled end position cushioning:
Components
•the SPC-10
•a proportional directional control valve type
MPYE-5-...
•a service unit with 5 µm filter, without lubricator
•a potentiometer type MLO-POT-...-TLF
•a cylinder, if necessary with mechanical guide
•two fixed stops
•24 V DC power supply
•if necessary, components for a pneumatic emer-
gency stop circuit.
1. Summary of system
SPC-10 9902a 1-5

1.2 Method of operation
The SPC-10 is enclosed in an aluminium housing and
performs the following tasks:
Tasks of the
SPC-10 •it determines characteristic system values of the con-
nected components
•it saves the desired end positions
•it specifies the two end positions
•it compares the nominal and actual positions and
controls positioning by means of the proportional di-
rectional control valve (status control).
The SPC-10, the valve, the cylinder and the poten-
tiometer are connected to form a closed-loop control
circuit. The position of the slide or of the piston repre-
sents the control variable in this control circuit. This cir-
cuit is therefore also called a positioning control circuit.
Method of
operation
In the following section the terms piston and slide have
the same meaning.
The following diagram shows the principal structure of a
positioning control circuit with the SPC-10.
1. Summary of system
1-6 SPC-10 9902a

1
2
3
Potentiometer
Actual position value
SPC-10
4
5
6
Valve control (nominal value)
Proportional directional control
valve
Linear drive
Fig. 1/2: Positioning control circuit with pneumatic
components
The potentiometer continuously registers the position of
the slide and passes this information on in the form of
an electrical signal to the SPC-10. The SPC-10 com-
pares the actual position with the programmed cylinder
end position and calculates therefrom the positioning
signal for the proportional directional control valve.
The proportional directional control valve controls the
slide by pressurizing one cylinder chamber and ex-
hausting the other. The flow is blocked in the valve
slide mid-position.
4
5
2
3
6
1
1. Summary of system
SPC-10 9902a 1-7

1.3 Displays and connections on the SPC-10
The diagram below shows the displays and connections
on the SPC-10.
1
2
3
4
5
6
7
8
9
0
!
Operating voltage supply as well as inputs and outputs
Groove for identification plates (type IBS 6x10)
Green LED (operating voltage display)
Valve connection
Red LED (error display)
Identification plates on side
Teach key for teaching the desired end positions
Yellow LEDs for position display A/B
DIL switch for configuration
Earth/ground connection
Potentiometer connection
Fig. 1/3: Displays and connections on the SPC-10
1
4
5
9
0
!8
23
6
7
1. Summary of system
1-8 SPC-10 9902a

Chapter 2
Fitting
2. Fitting
SPC-10 9902a 2-1

Contents
2. Fitting
2.1 Fitting the SPC-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2. Fitting
2-2 SPC-10 9902a

PLEASE NOTE
When fitting the pneumatic components, observe
also the notes on fitting in the operating instructions
supplied and the notes on installation in chapter 3.
2.1 Fitting the SPC-10
With the aid of the support brackets supplied the SPC-
10 can be fitted either vertically or horizontally on a flat
surface.
The following diagram shows the mounting surface, the
dimensions for the M4 screws and how to fit the sup-
port brackets. You should fasten the SPC-10 with at
least 3 screws.
2. Fitting
SPC-10 9902a 2-3
