Fisher-Price T2684 User manual

www.fi sher-price.com
T2684
Swing
High Chair

2
To prevent injury or death from falls and being strangled in the restraint system:
• Always use the restraint system. Never use the tray to restrain child.
• Never use with an active child who may be able to climb out of the swing.
• Never leave child unattended.
• Never convert to high chair with child in product.
Prevent serious injury or death from falls or sliding out.
• The child should be secured in the high chair at all times by the restraint system,
either in the reclining or upright position. The restraint belts must be adjusted to t
your child snugly. The tray is not designed to hold the child in the chair.
• Only use as a high chair when child is capable of sitting up unassisted.
• Never leave child unattended.
• Never convert to swing with child in product.
WARNING
WARNING
Consumer Information
Swing
• Weight limit: 25 lbs (11,3 kg).
• If your child weighs less than 25 lbs (11,3 kg), but is really active and appears to be able to climb out
of the swing, immediately discontinue its use.
High Chair
• Weight limit: 50 lbs (22,6 kg).

3
• IMPORTANT! Please keep these instructions for future reference.
• Please read these instructions before assembly and use of
this product.
• Adult assembly is required.
• Tools required for assembly: Phillips screwdriver (not included)
and Allen wrench (included).
• Requires four “D” (LR20) alkaline batteries for swing operation,
sounds and music. Batteries not included.
• Product features and decoration may vary from photographs.
Consumer Information
ICES-003
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
NMB-003
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.L’utilisation de ce dispositif est autorisée seule-
ment aux conditions suivantes : (1) il ne doit pas produire de brouillage
et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage
radioélectrique reçu, même si ce brouillage est susceptible de
compromettre le fonctionnement du dispositif.
FCC Statement (United States Only)
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
Note: Changes or modifications not expressly approved by the manu-
facturer responsible for compliance could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAUTION
This package contains small parts
in its unassembled state. For adult
assembly only.

4
IMPORTANT! Please remove all parts from the package and identify them before assembly. Some parts may be packed in the pad.
Note: Tighten or loosen all screws with the Allen wrench or a Phillips screwdriver. Do not over-tighten.
Seat Bottom
Frame
2 Seat Tubes
(Left and Right)
Tray Allen Wrench
Tray Insert
2 Upper Frame Tubes
(Left and Right)
Seat Back
Hinge Rod
Pad
Parts
All Shown Actual Size
2 Feet
(Left and Right)
M4.5 x 12 mm Screw - 3 M3.5 x 25 mm Washer Head Screw - 2
M5 x 38.5 mm Screw - 2 M5 x 32 mm Screw - 2

5
• Fit a foot onto the end of each base tube, as shown.
Hint: Make sure the feet curve outward.
• Insert an M4.5 x 12 mm screw into the hole in the underside of
each foot and tighten with a Phillips screwdriver.
2
Assembly
• Lift the rear and front tubes to open the frame.
1
Foot Foot
Rear Tubes
Frame
Front Tube
Front
Tube
Base Tube
Base Tube
2 - M4.5 x 12 mm
Screws
• Position the upper frame tubes so that the hubs face each other.
• Fit the upper frame tubes into the rear frame tubes.
Hint: The upper frame tubes are designed to fit one way. If they do
not seem to fit, turn them around and try again.
4
Upper Frame Tube Hubs
Rear Frame Tubes
3
IMPORTANT! Before assembly and each use, inspect this product for
damaged hardware, loose joints, missing parts or sharp edges. DO
NOT use if any parts are missing or broken. Contact Fisher-Price® for
replacement parts and instructions if needed. Never substitute parts.
BOTTOM
VIEW
TOP VIEW

6
Assembly
• Insert an M5 x 38.5 mm screw into each side of the frame. Fully
tighten the screws with the Allen wrench.
M5 x 38.5 mm
Screw M5 x 38.5 mm
Screw
5
6
• Position the seat bottom face down on a flat surface.
• With the seat back also face down, fit the recline posts into the
upper slots in the seat bottom.
Seat Bottom
Upper Slots Seat Back
Recline Posts
• Push the seat back down to fit the tabs on the edge of the seat
back to the tabs on the seat bottom.
7
• Insert the hinge rod through the hinge on the seat bottom.
• Insert an M4.5 x 12 mm screw into the hinge rod. Tighten the
screw with a Phillips screwdriver.
8
Hinge
M4.5 x 12 mm
Screw
Hinge Rod
Hinge Rod
Seat Back Tabs

7
Assembly
• Press the seat height adjustment levers on each side of the seat.
10
Lever Lever
• Insert an M3.5 x 25 mm washer head screw into the hole under
each armrest. Tighten the screws with a Phillips screwdriver.
9
M3.5 x 25 mm
Screw
M3.5 x 25 mm
Screw
Armrest
Armrest
• While continuing to press the seat height adjustment levers, slide a
seat tube up through the socket in each seat hub.
Hint: One of the seat tubes includes a tab. Match this seat tube with
the socket that has a notch.
11
Seat Tubes
Seat Hub Seat Hub
Lever
Notch
Tab
Hole

8
Note: Do not attach the seat tubes to the frame crossbar in this
assembly step.
• While holding the seat assembly in place, insert an M5 x 32 mm
screw into the hole in each frame tube hub. Tighten the screws
with the Allen wrench.
13
2 M5 x 32 mm
Screws
• Insert both elastic loops on the pad through the holes in the
seat back.
15 FRONT VIEW
Elastic
Loops
Holes
Pad
• First lift, and then lower the latches onto the crossbar.
14 Tabs
• Fit the ends of the seat tubes up into the holes in each frame
tube hub.
Hint: You may need the help of another adult to hold the seat
assembly in place.
12
Frame Tube Hubs
Assembly
Crossbar
Latches
BACK VIEW

9
Assembly
• Insert the waist belts through the lowest slots in the seat pad.
• Insert the shoulder belts through the slots in the pad.
Hint: The shoulder belts are assembled to the seat back in the lower
shoulder belt slots. If you would like to change to the upper slots, go
to page 12, Changing Shoulder Belt Slots.
• From the front of the seat, insert the crotch belt up through the
large slot in the pad. Make sure the crotch belt is not twisted.
18
19
17
Crotch Belt
Large Slot
Waist Belts
Lowest Slots
Shoulder Belts
FRONT VIEW
• From the back of the seat, hook the elastic loops to the tabs on
the seat back.
16 BACK VIEW
Elastic Loops
Tabs

10
• Fit both clips on the bottom edge of the pad around the edge of
the seat bottom.
21
Assembly
Clips
Seat Bottom
• Fit the pocket at the top of the pad over the seat back.
20
Pad Pocket
Seat Back
SIDE VIEW
• Locate the battery compartment door on the frame.
• Loosen the screws in the battery compartment door with a
Phillips screwdriver.
• Insert four “D” (LR20) alkaline batteries.
Hint: We recommend using alkaline batteries for longer battery life.
• Replace the battery compartment door and tighten the screws. Do
not over-tighten.
• If this product begins to operate erratically, you may need to reset
the electronics. Slide the power switch off and then back on.
• When motion from the swing becomes slow or stops, replace
the batteries.
Battery Installation
• Protect the environment by not disposing of this product with
household waste (2002/96/EC). Check your local authority for
recycling advice and facilities (Europe only).
Battery Safety Information
In exceptional circumstances, batteries may leak fluids that
can cause a chemical burn injury or ruin your product. To avoid
battery leakage:
• Do not mix old and new batteries or batteries of different types:
alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use. Always remove
exhausted batteries from the product. Dispose of batteries safely.
Do not dispose of this product in a fire. The batteries inside may
explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type, as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the product before charging.
• If removable, rechargeable batteries are used, they are only to be
charged under adult supervision.
1,5V x 4
“D” (LR20)
