Bouncer
Cover’n Play™
Model Number: 79619
Please keep this instruction sheet for future reference,
as it contains important information.
Adult assembly is required.Tool required for assembly:
Phillips Screwdriver (not included).
Requires one “D” (LR20) alkaline battery (not included).

2
Warning
To prevent serious injury and/or falls:
• Never use on any elevated surface,
since child’s movement may cause
bouncer to slide or tip over.
• Never use as a carrier or lift while child
is seated.
• Always use the restraint system.
• Never leave child unattended.
• Never use as a car seat.
• Never use with a child able to sit
up unassisted.
WARNING

Parts
3
#8 x 3/4" Screw - 2
3 Toys
Toy Bar
Pad
Footrest
Seat Back
Tube
Retainer
Retainer
Right Base Wire
Left Base Wire
Base Tube
Shown Actual Size

• Locate the soothing unit on the footrest.
• Insert a coin into the battery compartment door and pry the battery
compartment door off.
• Insert one “D” (LR20) alkaline battery, as indicated inside the battery
compartment. Be sure to place the battery on top of the ribbon.
• Replace the battery compartment door and be sure it snaps securely closed.
Battery Installation
4
1.5V
“D” (LR20)
SHOWN ACTUAL SIZE
+–
Battery Compartment Door
+–
Battery Tips
• Remove the battery during long periods of non-use. Always remove an
exhausted battery from the product. Battery leakage and corrosion can
damage the product. Dispose of the battery safely.
• Do not dispose of the battery in a fire.The battery may explode or leak.
• Never short circuit the battery terminals.
• A non-rechargeable battery is not to be recharged.
• Only a battery of the same or equivalent type as recommended in the
“Battery Installation” instructions is to be used.
• If a removable rechargeable battery is used, it is only to be charged under
adult supervision.
• A rechargeable battery is to be removed from the product before it
is charged.
• If you use a battery charger, it should be examined regularly for damage
to the cord, plug, enclosure and other parts. Do not use a damaged
battery charger until it has been properly repaired.
Hints:
• We recommend the use of an alkaline battery for longest battery life.
• For easy battery removal, simply lift the ribbon.

• Place the base tube on a flat surface as shown.
• Position the left and right base wires as shown. Note the location
of the colored tabs on the left and right base wires.
• Fit the left base wire into the base tube.
• Fit the right base wire into the base tube.
Assembly
Base Tube
Left Base
Wire
Colored Tabs
Right Base
Wire
1
5
This package contains small parts
in its unassembled state.
Adult assembly is required.
CAUTION

• Position the footrest so that the
soothing unit is upright.
• While flexing the base wires toward
each other, hook the footrest onto the
ends of the base wires.
• Push the footrest down completely to
the tabs on the base wires.
• Make sure the colored tabs on the left and right base wires are visible
through the base tube holes (see inset). If the colored tabs are not
visible through the base tube holes, you have assembled the base
incorrectly. Disassemble all parts and refer back to Assembly Step 1.
Assembly
Tab Tab
Footrest with
Soothing Unit
Flex Base
Wires Inward
2
6
Base Tube
Colored Tab
Back View
Base Wire

• Position the seat back tube above the base assembly.
• Fit the seat back tube completely onto the base wires.
Assembly
3
7
Seat Back Tube
Base Wire
Base Wire

• Fit a retainer to the outside of the
seat back tube, as shown. Make sure
the socket in the retainer is upright.
• Insert a screw through the hole in
the seat back tube, base wire and
into the inside of the retainer.
• Tighten the screw with a Phillips
screwdriver. Do not over-tighten.
• Repeat this procedure to assemble the other retainer to the other
side of the seat back tube.
• Pull up on the seat back tube to be sure it is secure. If you can
remove either end of the seat back tube, you have not assembled
the retainers correctly. Remove the screws, re-read and repeat
Assembly steps 3 and 4.
Assembly
4
8
PULL UP
Seat Back Tube
Retainer
Socket
Up
Retainer
Socket
Up

• Position the pad above the frame with the blanket toward the
soothing unit.
• Fit the upper pocket on the back of the pad onto the seat back
tube .
• Lift the footrest. Fit the lower pocket on the back of the pad onto
the footrest . Lower the footrest.
• Attach the pad fastener to the fastener on the soothing unit .
Assembly
Fastener Seat Back
Tube
Pad
Footrest
Soothing
Unit
5
9




• Fit the toy bar plugs into each retainer socket.
• Unfasten a strap on the toy bar.
• Wrap the strap around a toy ring and re-fasten the strap.
• Repeat this procedure to attach the other two toys to the toy bar.
• The toy bar is removable. Simply pull to remove.
Assembly
6
10
Toys
Plugs
Toy Bar
Strap
Retainer
Socket Retainer
Socket

11
Set-Up & Use
To prevent serious injury and/or falls:
• Never use on any elevated surface,
since child’s movement may cause
bouncer to slide or tip over.
• Never use as a carrier or lift while child
is seated.
• Always use the restraint system.
• Never leave child unattended.
• Never use with a child able to sit
up unassisted.
WARNING
Securing Your Child
• If the toy bar is attached, remove it before placing your child in the seat.
• Place your child in the seat. Position the restraint between your
child’s legs.
• Fasten both belts to the buckles on each side of the restraint.
Make sure you hear a “click” on both sides.
• Check to be sure the restraint is securely attached by pulling it away
from your child. The restraint should remain attached.
• Attach the toy bar, if desired (see Assembly Step 6).
1
Belt
Buckle
Restraint

Loosen
To tighten the restraint:
• Feed the anchored end of the belt up through the buckle to
form a loop .
• Pull the free end of the belt .
• Repeat this procedure to tighten the other belt.
To loosen the restraint:
• Feed the free end of the belt up through the buckle to form a
loop . Enlarge the loop by pulling on the end of the loop
toward the buckle.
• Pull the anchored end of the belt to shorten the free end of
the belt .
• Repeat this procedure to loosen the other belt.
Please Note: After adjusting the belts to fit your child, make sure
you pull on the restraint to be sure it is securely fastened.
Set-up & Use
Anchored End
Free End
Buckle Anchored End Buckle
Free End
2
Tighten
12




3
Calming Vibrations
• Make sure your child is properly secured in the seat.
• To turn vibrations on, slide the power switch on the soothing unit
to the on position •.
• To turn vibrations off, slide the power switch on the soothing unit
to the off position °.
IMPORTANT! If vibrations from the soothing unit become faint, or if
there are no vibrations, remove the battery from the soothing unit
and dispose of it properly. Replace the battery with a new “D” (LR20)
alkaline battery.

4
13
Set-up & Use
• Pull the blanket down completely.
• Fold the blanket under the footrest wire.
• Tuck the blanket into the pocket on the underside of the pad.
Storing the Blanket
• Fold blanket up on baby’s lap.
Blanket

The pad is machine washable.Wash it separately in cold water on
the gentle cycle. Do not use bleach. Tumble dry separately on low
heat and remove promptly. The frame, toy bar and toys may be
wiped clean using a mild cleaning solution and a damp cloth.
Do not immerse the soothing unit.
Care
14

FCC Note (United States Only)
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user‘s
authority to operate the equipment.
15

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2001 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
Printed in China 79619pr-0920
Questions? We’d like to hear from you!
Call Fisher-Price®Consumer Relations, toll-free at 1-800-432-KIDS,
8 AM – 6 PM EST Monday through Friday. Hearing-impaired
consumers using TTY/TDD equipment, please call 1-800-382-7470.
Or, write to:
Fisher-Price®Consumer Relations
636 Girard Avenue
East Aurora, New York 14052
Consumer Information
For other countries, outside the United States:
Canada: call 1-800-567-7724, or write to: Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2.
Great Britain: telephone [phone].
Australia: Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond,
Victoria 3121 Australia. Consumer Advisory Service 1300 135 312.
New Zealand: 16-18 William Pickering Drive, Albany 1331, Auckland.
