Aquarium Bouncer™
Model Number: 79030
Please keep this instruction sheet for future reference,
as it contains important information.
Adult assembly is required.
Tool required for assembly: Phillips screwdriver (not included).
Requires one “D” (LR20) alkaline battery (not included)
for soother operation; three “D” (LR20) alkaline
batteries (not included) for toy bar operation.

2
Warning
To prevent serious injury and/or falls:
•Never use on any elevated surface,
since child’s movement may cause
bouncer to slide or tip over.
•Never use as a carrier or lift while child
is seated.
•Always use the restraint system.
•Never leave child unattended.
•Never use as a car seat.
•Never use with a child able to sit
up unassisted.
WARNING
Occasionally a consumer may experience a problem with one of our
products. If this should happen, please call us toll-free, rather than
return this product to the store. Usually, we can solve the problem
over the telephone or send you replacement parts.
Please call Fisher-Price® Consumer Relations, toll-free at 1-800-432-KIDS,
8 AM - 6 PM EST Monday through Friday. Hearing-impaired consumers
using TTY/TDD equipment, please call 1-800-382-7470.
Or, write to:
Fisher-Price® Consumer Relations
636 Girard Avenue
East Aurora, New York 14052
Consumer Information

Parts
3
Shown Actual Size
#8 x 3/4" Screw - 2
Pad
Toy Bar
Footrest with
Electronic Unit
Seat
Back
Tube
Right Base
Wire
Left Base Wire
Base
Tube
Removable
Teether Rings
2 Retainers

•Locate the electronic unit on the footrest wire.You will see that there are
two battery compartments. The smaller battery compartment powers
the soother; the larger battery compartment powers the toy bar.
•First, loosen the screw in the soother battery compartment door with a
Phillips screwdriver. Remove the battery compartment door.
•Insert one “D” (LR20) alkaline battery, as indicated inside the battery
compartment.
•Replace the battery compartment door.Tighten the screw with a Phillips
screwdriver. Do not over-tighten.
•Next, loosen the screws in the toy bar battery compartment door with a
Phillips screwdriver.
•Insert three “D” (LR20) alkaline batteries, as indicated inside the battery
compartment.
•Replace the battery compartment door.Tighten the screws with a Phillips
screwdriver. Do not over-tighten.
Battery Installation
4
Soother
Battery Compartment
Toy Bar
Battery Compartment

Battery Tips
5
1.5V – Soother
1.5V x 3 – Toy Bar
“D” (LR20)
SHOWN ACTUAL SIZE
+–
•Do not mix old and new batteries.
•Do not mix different types of batteries: alkaline, standard (carbon-zinc) or
rechargeable (nickel-cadmium).
•Remove the batteries during long periods of non-use. Always remove
exhausted batteries from the toy. Battery leakage and corrosion can
damage this product. Dispose of batteries safely.
•Do not dispose of batteries in a fire. The batteries may explode or leak.
•Never short circuit the battery terminals.
•Non-rechargeable batteries are not to be recharged.
•Only batteries of the same or equivalent type as recommended in the
"Battery Installation" instructions are to be used.
•If removable rechargeable batteries are used, they are only to be charged
under adult supervision.
•Rechargeable batteries are to be removed from the product before they
are charged.
•If you use a battery charger, it should be examined regularly for damage
to the cord, plug, enclosure and other parts. Do not use a damaged battery
charger until it has been properly repaired.
•Low battery power in the toy bar may cause it to operate erratically (no
sounds/no lights/no bubbling action) and the toy bar may not turn off. If this
should happen, remove and discard all three batteries in the large battery
compartment and replace with three, new “D” (LR20) alkaline batteries.

•Place the base tube on a flat surface as shown.
•Position the left and right base wires as shown.
Note the location of the colored tab on the left
and right base wires.
•Fit the left base wire into the base tube.
•Fit the right base wire into the base tube.
•Make sure both colored tabs on the base wires are visible through the
holes in the base tube.
Assembly
Base Tube
Left Base
Wire
Colored Tabs
Right Base
Wire
1
6
This package contains small parts
in its unassembled state.
Adult assembly is required.
CAUTION
Back View
Base Tube
Base Wire
Colored Tab

Assembly
7
•Position the footrest so that the electronic unit battery compartment
doors are upright.
•While flexing the base wires toward each other, hook the footrest onto
the ends of the base wires.
•Push the footrest down completely to the tabs on the base wires.
2
Electronic Unit
Battery Compartment Doors Up
Flex
Base Wires
Inward
Tab
Tab

8
Assembly
•Position the seat back tube so that it
bends backward.
•Match the colored symbol on the seat back tube to the colored symbol on
the base wire (●circles on one side and ▲triangles on the other side). If the
colored symbols do not match, turn the seat back tube over and try again!
•Fit the seat back tube completely onto the base wires.
3
IMPORTANT! You MUST position the seat back tube correctly for proper
assembly of this product!
Seat Back Tube
Bends Backward
▲Triangles Match
●Circles Match

Assembly
9
•Fit a retainer (rounded side inward) to one end of the seat back tube.
•Insert a screw through the outside hole in the seat back tube and into
the retainer.
•While holding the retainer in place, tighten the screw with a Phillips
screwdriver. Do not over-tighten.
•Repeat this procedure to secure the other side of the seat back tube
to the base assembly using the remaining retainer and screw.
4
Retainers

•Check to be sure the seat back tube bends backward.
•Pull the seat back tube up to be sure it is secure.
•If the seat back tube does not bend backward or you can remove either
end of the seat back tube, you have not assembled it correctly. Remove the
screws and retainers. Re-read and repeat Assembly steps 3 - 5.
Assembly
10
5
Pull Up
Seat Back
Tube Bends
Backward

•Unbuckle the restraint belts from the
restraint pad. Push the restraint belts back
through the slots in the pad .
•Fit the pad upper pocket onto the seat back tube .
•Lift the footrest. Fit the pad lower pocket onto the footrest .
Lower the footrest.
B
Assembly
11
6
Seat Back
Tube
Pad
Footrest
B

•Fit both restraint belts back through the pad slots, as shown.
Assembly
12
7
Restraint
Belts

Assembly
13
8
•Insert and “snap” the ends of the toy bar
into the sockets in the footrest.
•Make sure the toy bar latches are secure.
The small tabs on the sockets should be
visible in the opening in the latches.
Assembly is now complete.
Hint: The square end of the toy bar fits into
the square socket and the circular end of the
toy bar fits into the circular socket.
Tab
Latch

14
Set-Up & Use
To prevent serious injury and/or falls:
•Never use on any elevated surface,
since child’s movement may cause
bouncer to slide or tip over.
•Never use as a carrier or lift while child
is seated.
•Always use the restraint system.
•Never leave child unattended.
•Never use with a child able to sit
up unassisted.
WARNING
1
Securing Your Child
•If the toy bar is attached, remove it before placing your child in the seat.
•Place your child in the seat. Position the restraint between your child’s legs.
•Fasten both restraint belts to the buckles on each side of the restraint pad.
Make sure you hear a “click” on both sides.
•Check to be sure the restraint is securely attached by pulling it away from
your child. The restraint should remain attached.
•Attach the toy bar, if desired (see Assembly step 8).
Restraint
Belt
Buckle
Restraint Pad

Loosen
To tighten the belts:
•Feed the anchored end of the belt up through the buckle to form a loop .
•Pull the free end of the belt .
•Repeat this procedure to tighten the other belt.
To loosen the belts:
•Feed the free end of the belt up through the buckle to form a loop .
Enlarge the loop by pulling on the end of the loop toward the buckle.
•Pull the anchored end of the belt to shorten the free end of the belt .
•Repeat this procedure to loosen the other belt.
Please Note: After adjusting the belts to fit your child, make sure you pull on
them to be sure they are securely fastened.
B
B
Set-Up & Use
Tighten
15
3
Calming Vibrations
•Make sure your child is properly secured in the seat.
•To turn vibrations on, slide the power switch on the electronic unit to the
on position .
•To turn vibrations off, slide the power switch on the electronic unit to the
off position O.
IMPORTANT! If vibrations from the electronic unit become faint, or if there
are no vibrations, remove the battery from the small battery compartment
in the electronic unit and dispose of it properly. Replace the battery with a
new “D” (LR20) alkaline battery.
B
Anchored End
Free End
Anchored End
Free End
B
2

Set-Up & Use
•Slide the mode switch to for baby activated mode.
•When baby bats either toy,baby is rewarded with wave sounds, bubbling
action and lights.
•Slide the volume switch to for low volume; for high volume.
•The toy bar automatically turns off after approximately 10 minutes
(from the last time baby bats a toy). To turn the toy bar back on, simply
bat either toy.
•Slide the mode switch to Oto turn off sounds, bubbling action and lights.
IMPORTANT! If lights become dim, sound becomes faint, bubbling action
slows, or the toy bar operates erratically or does not turn off, remove the
three batteries from the large battery compartment in the electronic unit.
Dispose of the batteries properly. Replace the batteries with three, new “D”
(LR20) alkaline batteries.
Baby Activated
16
4
Mode Switch
Volume Switch
Bat Toys for Sounds or Music,
Bubbling Action
and Lights
Hint: Each time baby bats either toy, baby is rewarded with a different sound
and light pattern! Note that the sound selection button
does not work in baby activated mode.

Set-Up & Use
•Slide the mode switch to for parent activated mode. Baby enjoys
10 minutes of music, lights and bubbling action.
•Select music, or sounds, or no sound at all. Push the sound selection
button again and again for:
Lullabies
Ocean Waves
Summer Rain
Babbling Brook
No Sound
•Slide the volume switch to for low volume; for high volume.
•The toy bar automatically turns off after approximately 10 minutes.To turn
the toy bar back on, simply slide the mode switch off and then back on
again; or press the sound selection button.
•Slide the mode switch to Oto turn off sounds, bubbling action and lights.
IMPORTANT! If lights become dim, sound becomes faint, bubbling action
slows, or the toy bar operates erratically or does not turn off, remove the three
batteries from the large battery compartment in the electronic unit.
Dispose of the batteries properly. Replace the batteries with three, new “D”
(LR20) alkaline batteries.
Parent Activated
17
5
Mode Switch
Sound Selection Button
Volume Switch

Set-Up & Use
•The teethers are removable from the toys on the toy bar. Simply twist the
ends of each teether slightly to remove from either toy.
•To replace a teether, simply push to attach it to the bottom of either toy.
Teethers
18
6

Set-Up & Use
19
The pad is machine washable.Wash the pad separately in cold water on
the gentle cycle. Do not use bleach. Tumble dry separately on low heat and
remove promptly.The frame, toy bar and teethers can be wiped clean using
a mild cleaning solution and a damp cloth. Do not immerse the electronic
unit or toy bar.
To remove the pad:
•Lift the footrest and remove the pad lower pocket
•Push the restraint belts back through the pad.
•Slide the pad upper pocket off the seat back tube.
To re-assemble the pad:
•Refer to Assembly steps 6 and 7.
Care
Remove the Toy Bar
•Pull the ends of the latches out and lift the toy bar.
Latch
Latch

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2002 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
Printed in China 79030a-0920
For other countries, outside the United States:
Canada: call 1-800-567-7724, or write to: Mattel Canada Inc., 6155 Freemont Blvd., Mississauga,
Ontario L5R 3W2.
Great Britain: telephone [phone].
Australia: Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond,Victoria
3121 Australia. Consumer Advisory Service 1300 135 312.
New Zealand: 16-18 William Pickering Drive, Albany 1331, Auckland.
FCC Note (United States Only)
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Consult the dealer or an experienced radio/TV technician for help.
Note: Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user‘s authority to operate
the equipment.
