Fisher-Price W9981 User manual

W9981
fisher-price.com
Pleasekeepthisinstructionsheetforfuturereference,asitcontainsimportantinformation.
Productfeaturesanddecorationsmayvaryfromthephotograph.
Adultassemblyisrequired.Toolsrequiredforassembly:
PhillipsScrewdriver,HammerandScrapBlockofWood(notincluded).
Requiresthree"AA"batteries(included).
Age:2-6years.
Weightlimit:60lbs(27kg).
Chooseareasforridingthatarefreeofobstacles.
Learntostopsafely.
Usewithcautionasthisproductrequiresskilltooperatesafelytoavoidfalls,collisions,
andinjuriestoyourself(therider)andothers.
IMPORTANT!Itisgoodpracticetostarttrainingchildrenveryyoungregardingtheimportanceofhelmetuse.
Whenchildrenareolderandridingbicyclesandfastervehicles,itisimportantthattheyuseahelmeteachandeverytimethey
ride.Forthisreason,evenwhileridingatricycle,itisagoodideatofamiliarizeyourchildwithhelmetuse,sothatitbecomes
ahabitforlife.Chooseahelmetthatcomplieswithrequirementsoftheapplicablecertifyingagencyforbicyclehelmets.

Consumer Information
#8x3"(7,6cm)Screw–1
#8x3/4"(1,9cm)Screw–4
FASTENERS SHOWN ACTUAL SIZE
CapNut–1
WARNING
TO AVOID SERIOUS INJURY:
•Continuousadultsupervisionisrequired.
•Neverusenearcarsandothermotorvehicles,
nearstreets,steps,slopeddriveways,hills,
roadways,alleys,swimmingpoolsorother
bodiesofwater.
•Alwayswearshoes.
•Neverallowmorethanonerider.
2
Seat
Frame
Pedal
2ForkCovers
FrontWheel
AxleAssembly
Fork
Headlight
Cover
Seat Retainer
Cap
StraightAxle
2Rear
Wheels
Handlebar
2Hubcaps
2Covers
4PedalHubs
#6x½"(1,3cm)Screw–3
•Pleasesaveallpackagingmaterialuntilassemblyiscomplete
toensurethatnopartsarediscarded.
•Pleasewipeeachpartwithaclean,dryclothbeforeassembly.
•Somepartsshownareassembledtobothsidesofthetrike.
•TightenassembledscrewswithaPhillipsscrewdriver.
Donotover-tightenthescrews.
•Partsnotshown:labelsandassemblytool.

CAUTION
Thisproductcontainssmallparts
inanunassembledstate.
Adultassemblyisrequired.
• Slideahubcap(peg side up)ontothestraightaxle.
• Slidearearwheel(indented side down)ontothe
straightaxle.
• Turntheframeupsidedown.
• Insertthestraightaxlethroughtheholesintherearof
theframe.
RearWheel
(Indented Side
Down)
• Turntheframeonitssidewiththeexposedendofthe
straightaxleup.
• Placethecapnutassemblytoolundertheassembledrear
wheelandontothecapnut.
• Slidearearwheel(indented side up)ontotheendofthe
straightaxle.
• Slideahubcap(peg side down)ontothestraightaxle.
• Placeacapnutontheendofthestraightaxle.Tapthe
capnutwithahammer.Gently pull the rear wheel up
to be sure the cap nut is securely attached to the
straight axle.
• Insertoneofthetabsonacoverintoaslotinthehubcap.
Pushtosnapthecoverintoplace.Repeatthisprocedureto
attachtheothercovertotheotherhubcap.
CapNut
RearWheel
(Indented Side Up)
CapNut
AssemblyTool
Assembled
RearWheel
StraightAxle
Hole Hole
Frame
StraightAxle
Hubcap
(Peg Side
Up)
Hubcap
(Peg Side Down)
Frame
StraightAxle
ScrapBlock
ofWood
Cover
Hubcap
• Fittwopedalhubsontothepedalaxletabs.Makesurethe
tabstintotheslotineachpedalhub.
PedalHub
PedalHub
PedalAxle
Tabs
Slot
Assembly
3
1
2
3
4
BOTTOM VIEW

• Whileholdingthepedalhubsonthepedalaxleassembly,
insertthepedalaxlethroughtheholeinthecenterofthe
frontwheel.
• Pushthepedalhubsintothecenterofthefrontwheeluntil
theyareushwiththesurfaceofthefrontwheel.
PedalAxle
Assembly
PedalHubs
FrontWheel
• Fitthepedalonthepedalaxle.Tapthepedalwith
ahammeruntilitissecure.
• Pullthepedaluptobesureitissecure.Ifyoucanremove
it,youhavenotsecureditproperly.Tapitwiththe
hammeragain.
PedalAxle
ScrapBlock
ofWood
Pedal
PedalHub
PedalHub
• Turnthefrontwheelassemblyover.
• Inserttheremainingpedalhubsontopofandbelowthe
pedalaxleandintotheholeinthecenterofthefrontwheel.
• Pushthepedalhubsintothecenterofthefrontwheeluntil
theyareushwiththesurfaceofthefrontwheel. • Placethefrontwheelassemblybetweentheforkarms.
Makesurethepedalaxletsintothegrooveatthebottom
ofeachforkarm.
• Placeaforkcoveroverthepedalaxleononeforkarm.
• Inserttwo#8x3/4"(1,9cm)screwsintotheforkcover
andtighten.
• Repeatthisproceduretoattachtheotherforkcovertothe
otherforkarm.
ForkArms
PedalAxle
Groove
ForkCover
Assembly
4
5
6
7
8

• Inserttheforkpostupthroughtheholeintheneckofthe
frame.Make sure the fork is positioned so that the fork
covers face the rear wheels.
• Placethehandlebarontotheforkpostandpushitdown
ontotheframe.Makesurethehandlebarispositionedso
thatthescrewholefacestherearwheelsandalignswith
thescrewholeintheforkpost.
Hint: You may need to rotate the handlebar to align the holes.
• Insertthe#8x3"(7,6cm)screwthroughtheholeinthe
handlebarandintotheforkpostsothatpartofthescrew
(about3/4"-1,9cm)isstillvisible.Tightenthescrew.
Handlebar
Frame
Neck
Fork
Post
ForkCover
RearofTrike
• Positiontheseatupsidedown.
• Fitthesmallpegsontheseatretainerintotheholesin
theseat.
• Insertand“snap”thecapintotheholeintheframe.
Cap
Seat Retainer
Seat
Peg
• Fitthetheheadlightcoverontothefrontofthehandlebar.
• Insertthree#6x1/2"(1,3cm)screwsintotheheadlight
cover.Tightenthescrews.
Headlight
Cover
Assembly
5
9
11
10
12

• Atanangle,insertthetabsontheseatintoanyofthetop
threesetsofslotsforthelower,middleorupperposition.
• Lowertheseatsothattheseatretainerinsertsandsnaps
intotheslotsintheframe.
• Pullupontheseattobesureitissecure.
Hint: The seat can be attached to the frame in any of
three positions, depending on the size of your child. Check
your child’s t on the trike by observing the seat to pedal
distance, as it is being ridden. If the pedals seem too far
away or too close for your child, move the seat up or down.
• Makesuretheareaswherethelabelswillbeappliedare
cleananddry.Wipeyourvehiclewithaclean,soft,dry
clothtoremoveanydustoroils.
• Forbestresults,avoidapplyingalabelmorethanonce.
• Applythelabelsasshownintheillustrationabove.
• Afterapplyingthelabel,rubthelabelrmlywithaclothto
makesurethelabelisadheredtoyourvehicle.
Lower Position Middle Position Upper Position
Tabs
Slots
Seat
Retainer
Label Decoration Attaching the Seat
6
14
12
2
6
11
18
1
(Label 1's
both sides)
SIDE VIEW
DASH VIEW
BACK VIEW
TM & © DC Comics. (s12)
9
5
17
4
(Label 3
opposite
side)
15
(Label 16
opposite side)
8
(Label 7
opposite side)
13
(Label 10
opposite side)

Note:Forbestperformance,werecommendreplacingthe
batteriesthatcamewiththistrikewiththree,new"AA"(LR6)
alkalinebatteries.
HeadlightCover
• Loosenandremovethescrewsfromtheheadlightcover.
Removetheheadlightcover.
• Loosenthescrewinthebatterycompartmentdoor.Open
thebatterycompartmentdoor.
• Insertthree"AA"(LR6)alkalinebatteries.
• Closethebatterycompartmentdoorandtightenthescrew.
• Replacetheheadlightcover.Replacethescrews
andtighten.
• Whensoundorlightsbecomefaintorstop,it'stimeforan
adulttoreplacethebatteries.Werecommendtheuseof
alkalinebatteriesforlongerbatterylife.
• Ifthisproductbeginstooperateerratically,youmayneed
toresettheelectronics.Slidethepowerswitchoffandthen
backon.
(United States Only)
Thisequipmenthasbeentestedandfoundtocomplywith
thelimitsforaClassBdigitaldevice,pursuanttoPart15
oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesand
canradiateradiofrequencyenergyand,ifnotinstalledand
usedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.However,thereis
noguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterference
toradioortelevisionreception,whichcanbedeterminedby
turningtheequipmentoffandon,theuserisencouragedto
trytocorrecttheinterferencebyoneormoreofthe
followingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipment
andreceiver.
• Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
Note:Changesormodicationsnotexpresslyapprovedby
themanufacturerresponsibleforcompliancecouldvoidthe
user’sauthoritytooperatetheequipment.
ThisdevicecomplieswithPart15oftheFCCRules.
Operationissubjecttothefollowingtwoconditions:(1)this
devicemaynotcauseharmfulinterferenceand(2)thisdevice
mustacceptanyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.
FCC Statement
Inexceptionalcircumstances,batteriesmay leakuidsthatcan
causeachemicalburninjuryorruinyourproduct.Toavoid
batteryleakage:
• Donotmixoldandnewbatteriesorbatteriesofdifferent
types:alkaline,standard(carbon-zinc)orrechargeable
(nickel-cadmium).
• Insertbatteriesasindicatedinsidethebatterycompartment.
• Removebatteriesduringlongperiodsofnon-use.Always
removeexhaustedbatteriesfromtheproduct.Disposeof
batteriessafely.Donotdisposeofthisproductinare.
Thebatteriesinsidemayexplodeorleak.
• Nevershort-circuitthebatteryterminals.
• Useonlybatteriesofthesameorequivalenttype,
asrecommended.
• Donotchargenon-rechargeablebatteries.
• Removerechargeablebatteriesfromtheproduct
beforecharging.
• Ifremovable,rechargeablebatteriesareused,theyare
onlytobechargedunderadultsupervision.
Battery Replacement Battery Safety Information
7
•Protecttheenvironmentbynotdisposingofthis
productwithhouseholdwaste(2002/96/EC).Check
yourlocalauthorityforrecyclingadviceandfacilities.
1,5V x 3
“AA” (LR6)
1
2

Seat Retainer Tab
• Turntheframeonitsside.
• Squeezetheseatretainertabstowardoneanotherandlift
theseatfromtheframe.
Seat Retainer Tab
Seat
• SlidethepowerswitchON .
• Turntheignition,“VRROOOM!”
• Presstheleft orright turnsignalsforashingblinkers.
• Pressanyofthesoundbuttonsformusic,ahornorother
funphrases!
• Whenyouarenishedplayingwiththistoy,slidethepower
switchOFF .
PowerSwitch
Horn Sounds
Ignition
TurnSignal
TurnSignal
Sounds
Care
• Periodicallyinspectthisproductforwearordamage.Check
plasticpartsregularlyandifbrokenorcracked,disposeof
themproperly.Replacewornorbrokenpartsimmediately.
• Checkallfastenersregularlytobesuretheyaretight.Ifthe
fastenersarenottight,tightenthemasnecessary.
• Tocleanthisproduct,useamildsoapandwatersolution
andacleancloth.Rinsecleanwithwatertoremove
soapresidue.
Removing the Seat
Let's Go!
Consumer Information
ICES-003
• ThisClassBdigitalapparatuscomplieswithCanadian
ICES-003.
• Operationissubjecttothefollowingtwoconditions:(1)this
devicemaynotcauseharmfulinterferenceand(2)this
devicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
NMB-003
• CetappareilnumériquedelaclasseBestconformeàla
normeNMB-003duCanada.
• L’utilisationdecedispositifestautoriséeseulement
auxconditionssuivantes:(1)ilnedoitpasproduirede
brouillageet(2)l’utilisateurdudispositifdoitêtreprêt
àacceptertoutbrouillageradioélectriquereçu,même
sicebrouillageestsusceptibledecompromettrele
fonctionnementdudispositif.
CONSUMER ASSISTANCE
1-800-432-5437 (US & Canada)
1300 135 312 (Australia)
Fisher-Price, Inc., 636 Girard Avenue, East Aurora, NY 14052.
Hearing-impaired consumers: 1-800-382-7470.
Outside the United States:
Canada: Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2; www.service.mattel.com.
Great Britain: Mattel UK Ltd, Vanwall Business Park,
Maidenhead SL6 4UB. Helpline: 01628 500303.
www.service.mattel.com/uk
Mattel Europa, B.V., Gondel 1, 1186 MJ Amstelveen, Nederland.
Australia: Mattel Australia Pty. Ltd., 658 Church Street,
Locked Bag #870, Richmond, Victoria 3121 Australia.
New Zealand: 16-18 William Pickering Drive,
Albany 1331, Auckland.
©2011Mattel.AllRightsReserved.®and™designateU.S.trademarksofMattel,exceptasnoted.
PRINTED IN MEXICO W9981pr-0920
DCSUPERFRIENDSandallrelatedcharactersandelementsaretrademarksofand©DCComics.
WBSHIELD:TM&©WarnerBros.EntertainmentInc.
(s12)
