FLEX Safety vacuum cleaners. For your good health.
Vacuum Power.

Safety vacuum cleaner
FLEX safety vacuum cleaner.
For your good health!
The filter system of the FLEX safety vacuum cleaners intercept all dust and even
health-harmful substances. This provides even more safety during dry and wet
operation. And before the filter becomes clogged, it is automatically cleaned wi-
thout interrupting the work process.
The suction power remains constant, and there is no down time for filter cleaning!
The 13 best advantages of the FLEX Safety vacuum cleaners.
1. Integrated flat-fold filter
Is extremely flat and, different from cart-
ridge filters, does not protrude into the
container. Thus the container can be used
100% and the filter remains absolutely dry
even during wet vacuuming.
2. Filter cleaning
Can be activated manually when running at
any time by pressing the filter-clean switch
or on some models automatically.
3. reinforced paper bags
Extra rip-proof and safe even with shar-
pedged objects.
4. Deposit tray and holders
Keep hoses and accessories tidy.
5. Bayonet connector
The suction hose connection rotates and is
fastened by bayonet: no twisting, no acci-
dental loosening of the suction hose during
operation.
6. Drive motor with bypass ventilator
Vacuum air and motor cooling air blow
separately in two channels. Dirty vacuum
air is not fed through the motor. This pro-
tects the motor and increases the vacuum
performance.
7. Power take off
To connect other tools. Starts and stops the
safety vacuum as the machine is switched
on and off. With 15-second automatic after-
running.
8. Housing
The impact-resistant, recyclable plastic
housing is tough, light, easy to clean, and
corrosion-free.
9. Smooth-running carriage
Two large wheels and two double-castoring
rollers with locking brakes.
10. Sound insulation hood
The suction turbine is encapsulated;
operating noise is greatly reduced.
11. Dust class L
- Dust with MAK values > 1 mg/m³
12. Dust category M
- Dust with MAK values > 0.1 mg/m³
- Mineral dusts 1)
- Wood dust (also beech and oak)
13. Dust class H
- Dust with TLV values < 0.1 mg/m³
- carcinogenic dust
- dust containing pathogens
1) Mineral dusts arise when construction
material is worked on (grinding, cutting,
drilling...). That is why M Dust Class equip-
ment is prescribed for working on concrete,
stone, masonry, screed and plaster, for in-
stance. The sand component contained
specially as quartz sand in these materials
is responsible for this classification.
*except VC 25 L MC

3
Safety vacuum cleaner
Compact
class Building site/workshop class
VC 25 L MC VC 35 L MC VCE 35 L AC VCE 45 L AC VCE 45 M AC VCE 45 H AC
Order number 385.468 369.799 369.780 369.802 369.810 379.093
Dust class L L L L M H
Power input in watts 1400 1380 1380 1380 1380 1150
Max. volumetric flow l/min 3600 3660 3660 3660 3660 2300
Max. vacuum Pascal 19000 23000 23000 23000 23000 22000
Container capacity in litres 25 34 34 43 43 43
Liquid capacity in litres 15 19 19 30 30 30
Weight kg 5,7 9,50 12,50 13,50 13,50 13,50
Complete antistatic equipment – – • • • •
Filter cleaning manual manual autom. autom. autom. autom.
Suction control – – • • • •
Automatic switch-on/o with 15 sec. run-on • • • • • •
Connection for power tools • • • • • •
4-m suction hose 32 mm Ø 3,5 m • antistatic antistatic antistatic antistatic
• included
– not included

4

VC 25 L MC. The “Small one” has powerful suction.
The FLEX safety vacuum cleaner VC 25 L MC is a handy and compact vacuum cleaner, simple to use and easy to transport. It is ideal
for cleaning offices, storage rooms, workshops and vehicles (passenger compartment and boot). For this work the VC 25 L MC fea-
tures an extensive range of suction tubes and nozzles. The VC 25 L MC is authorized for dust class L and is therefore ideal for all
dust with MAK values > 1 mg/m³.
For extraction work on smaller electric power tools, such as palm, delta and random orbit sanders, jigsaws, etc., the device is
equipped with important features, such as device socket, automatic switch-on, manual filter cleaning, PET filter material, fleece
filter bag and waste bag. The VC 25 L MC is also suitable for extracting liquids. The level monitor with installed float valve, stops
the suction process when maximum level is reached.
Safety vacuum cleaner and power
tools work automatically with
electronic remote on/o switching.
Two swivel casters see to ease of
movement in the workshops and on
the sites.
Suction nozzles can be stored
conveniently in the tool depot.
Highly tear-proof fleece for trou-
blefree disposal of the extracted
dust.
Cable and hose holder for compact
storage to optimise transportation.
The high-performance turbine provi-
des high suction power and high
underpressure. For an excellent
suction result.
To facilitate transportation, the
handle of the VC 25 L MC is recessed.
Suitable for suction tubes with a
diameter of 36 mm.
Easy to clean filter element made of
PET with a dirt-repellent surface for
dust classes L and M.
The “small one” has everything
at hand. Light and compact – this
facilitates transportation.
The safety vacuum cleaner VC 25 L MC, as a universal device, features
extensive accessories for all-round cleaning work.
By actuating manual filter clea-
ning, dust deposited in the filter
element is removed by a targeted
blast of air.
Safety vacuum cleaner
Compact class
5

Illustration
Funktion
Flachfaltenlter
Foto
Detail Ablagesystem
fine dust
flat folded
filter
coarse dust
The innovative flat-fold filter system with the flat-fold filter at the top allows full use of the container volume. The flat-fold filter is automatically cleaned
by a percussive pressure reversal every 15 seconds. There is no loss of suction at the end of the hose throughout the cleaning process. Downtimes for filter
cleaning/changing are therefore a thing of the past. The fold-out filter cover provides easy access to the main filter element to the clean-air side.
Flat-fold filter system with cleaning function.
6

7
Safety vacuum cleaner
Building site/workshop class
Whether 35 or 45 litres. Whether manual or automatic.
The FLEX safety vacuum cleaners are always convincing.
The FLEX safety vacuum cleaners are fitted with high-performance turbines. High suction power and vacuum ensure an excellent-
extraction. The VCE 35 L AC, VCE 45 L AC, VCE 45 M AC and VCE 45 H AC vacuum cleaners are equipped with an automatic
filtercleaning system. Targeted jets of air clear the flat-fold filter of any dust deposits. This ensures optimum suction without
interruption to operations. The filter cleaning system can be either switched on or off. A long service life of the flat-fold filter is
ensured from the filter pores being dependably cleared of dust. Moreover, the flat-fold filter design is such that the container
capacity can be optimally used for dust and dirt. The antistatic set (with VCE 35 L AC, VCE 45 L AC, VCE 45 M AC and VCE 45 H AC)
stops any static charging of the machine or suction hose.
Thanks to the large wheels, all FLEX
safety vacuum cleaners have
excellent running properties on une-
ven surfaces.
Continuous control for suction
power to suite the attached tool.
All class M, H safety vacuum clea-
ners are provided with a special cap
lock. This stops any dust escaping
whenthe cleaner is being moved
around.
The suction hose can be easily
wound up on the holders envisa-
ged for this very purpose. This
eases handling/transport.
Class M safety vacuum cleaner: sui-
table for all dusts with > 0.1 mg/m³
TLV values. Airflow sensonr techno-
logy. If the suction power (airflow)
falls below the madatory minimum
an acoustic tone is sounded.
Safety vacuum cleaner and power
tools work automatically with
electronic remote on/o switching.
The ergonomic handle makes it
easy to move the vacuum cleaner
around.
Two swivel casters see to ease of
movement in the workshops and on
the sites.
Practical storage of suction nozzles
and vacuum tubes at the back.
Convenient disposal of the extracted
material either with a filter sack or
disposal sack. Recommendation:
working with Filter sack turn o
filter cleaning system. Working with
disposal sack turn system on.
To dispose of the extracted mate-
rial, a slight turn of the hand opens
the container.
Easy and secure stacking of tools on
the vacuum cleaner top.
For stacking Vario-Girae® and wall
chaser, the special storage system is
available as an accessory.

Safe disposal of dust in the
doublewalled safety filter bag.
The accessories contaminated
with toxic dust are packed and
protected for transportation as
specified.
Whatever the infestation, it can
be eliminated professionally
with tools from FLEX – for exam-
ple the RETECFLEX.
How the surfaces are to be trea-
ted subsequently is the respon-
sibility of the trained and expert
craftsman.
When the device is transported,
the intake opening is sealed
with the non-detachable locking
sleeve.
The FLEX safety vacuum cleaner
VCE 45 H AC is particularly suc-
cessful at solving problems when
used with the FLEX renovation
devices.
Suction power adjusted to the
connected tool and hose connec-
tion Ø by stepless control.
The plaster is milled off. The
resulting dirt and dust are op-
timally extracted with the FLEX
safety vacuum cleaner
VCE 45 H AC.
Safety vacuum cleaner VCE 45 H AC.
The professional against toxic dust.
Fusty odour, unsatisfactory ambient temperature, black stains on walls: Everyone knows these typical stains in corners of rooms
and on interior furnishings. This is an unmistakable sign of mildew infestation.
Mildew is actually a collective name for around 180,000 types of fungi which constantly surrounds us. It has since been scientifically
proven that mildew causes a wide range of diseases, from allergies and asthma through chronic fatigue to rheumatism.
Usually the human body can tolerate a natural exposure to mildew.
However, this exposure increases dramatically in buildings which are infested with mildew. There is a considerable risk of illness.
Frequently the danger is “hiding” behind furniture. If the furni-
ture is moved to one side, you’ll get a big surprise. Only the qua-
lified technician can help here. And for this case he needs a FLEX
safety vacuum cleaner of class H.
Safety vacuum cleaner
Building site/workshop class
9

10
Safety vacuum cleaner
Suction systems
1
1 Antistatic vacuum hose SH 32x4m AS ................. 354.953
2 Vacuum hose SH 32x4m ................................... 338.508
3 Vacuum hose SH-M 32x4m ............................... 297.011
4 Antistatic vacuum hose SH 27x4m AS ................. 379.395
5 Vacuum hose SH 32x3,5m ................................ 385.484
6 Extraction adapter SAD-C 32 ............................. 369.861
7 Extraction adapter SAD 27-32 ........................... 385.506
8 Elbow K-C 32 KU ............................................. 297.038
9 Elbow K 32 ME ............................................... 369.853
10 Extension tube V 36x500 AL VE2 ........................ 385.522
11 Extension tube V 36x500 ME VE2 ....................... 385.514
12 Crevice nozzle CN 36x300 ................................. 385.530
13 Upholstery nozzlev PN 36x115 .......................... 385.549
14 Combination floor nozzle KN 36x250 .................. 385.565
15 Round brush RN 36x120 .................................. 385.646
6
8
9 9
4
10 11
12 13 14 15 16 17 20
FLEX Suction systems
Cleaning technology
2
3
19
18
21
22

9
5
7
16 Brush nozzle BN 36x220 .................................. 385.557
17 Floor nozzle CNW 36x300 ................................. 300.659
18 Brush strip BL-CNW 36x300 VE2 ........................ 300.675
19 Rubber strip GL-CNW 36x400 VE2 ....................... 300.683
20 Clip floor nozzle with rollers CNW 36x400 ............ 385.537
21 Brush strip BL-CNW 36x400 VE2 ........................ 385.581
22 Rubber strip GL-CNW 36x400 VE2 ....................... 385.603
23 Height-adjustable floor nozzle FN-K 36x450 ....... 385.611
24 Rubber strip GL-FN-K 36x450 ............................ 385.638
25 Floor nozzle with rollers FN-AL 36x370 ............... 369.896
26 Brush strip BL-FN-AL 36x370 ............................ 374.075
27 Rubber strip GL-FN-K 36x450 ............................ 374.083
28 Vacuum hose extension SH-V 32x0,5m................ 296.953
29 Adapter SAD-C 25-32 AS .................................. 320.188
23 25
Safety vacuum cleaner
Suction systems
11
28
29
7
1
1
1
2
2
2
3
3
3
4
5
24 26
27
Tools with FLEX clip system
WSE 7 Vario
WSE 7 Vario Plus
WSE 500
WST 700 VV
WST 700 VV Plus
WST 1000 FV
MS 1706 FR
RE 14-5 115
Tools without FLEX clip system
LD 1709 FR
+ 340.790
LD 3206 C
+ 340.790
LDC 1709 FR
+ 340.790
HPI 603
+ 257.169
LST 1503 VR
LST 803 VR
XS 713
MS 713
X 1107 VE
OS 80-2
OSE 80-2
OD 100-2
ODE 100-2
ORE 125-2

12
Safety vacuum cleaner
VC 25 L MC VC 35 L MC
Safety vacuum cleaner with manual
filter cleaning system, 25 L, class L
• Handy and compact vacuum cleaner, easy to use and easy to
transport
• The high-performance turbine ensures both a high suction capa-
city and a high vacuum. The outcome is an excellent extraction
result
• By actuating manual filter cleaning, dust deposited in the filter
element is removed by a targeted blast of air.
• Level monitor, no malfunctions when drawing in liquids thanks
to installed float valve
• With appliance socket and electronic automatic switch on/off
• With accessories magazine for suction nozzles and suction tubes
on the back
• Equipped with large wheels and two swivel guide rollers
• Suitable for increased stress when used commercially. Ideal
for cleaning work in offices, storage rooms, workshops and
vehicles. Smaller electric power tools, e.g. palm sander, delta
sander, random-orbit sander, jigsaws, are primarily used for
extraction work. Tools which produce fairly low amounts of dust
• Features a filter bag made of highly tear-proof fleece for opti-
mum
filling. The extracted dust can be disposed of without difficulty
• Safety vacuum cleaner, approved for dust class L, suitable for all
dust with TLV value >1 mg/m³
SPECIFICATIONS
Power input P.max. 1400 watt
Max. volume flow 3600 l/min
Max. vacuum 19000 Pa
Filter surface 3000 qcm
Container volume 25 l
Capacity liquid 15 l
Power take off 100-1800 watt
Size ( W x L x H)
380 x 375 x 485 mm
Weight 5,7 kg
Type Order No.
VC 25 L MC 385.468
Standard equipment:
Suction hose 32 mm Ø x
3.5 m with elbow
1 adapter Ø 27-32 mm
1 filter element class L/M
1 fleece filter bag class L
1 PP waste disposal bag
2 x 0.5 m aluminium suction tube
1 crevice nozzle
1 combination floor nozzle, switchable
1 upholstery nozzle
1 round brush
1 suction pipe holder
1 accessories holder
1 cable/hose holder
Safety vacuum cleaner with manual
filter cleaning system, 35 L, class L
• The high-performance turbine ensures both a high suction capa-
city and a high vacuum. The outcome is an excellent extraction
result
• Patented filter vibration: vibration at the press of a button on the
vacuum hose
• The flat-fold filter design is such that the container capacity can
be optimally used for dust and dirt
• Level monitor, no malfunctions when drawing in liquids thanks to
installed float valve
• With power take off and electronic automatic on/off. Soft start
stops any voltage peaks at the start and the run-on feature emp-
ties any remaining dust in the vacuum hose
• Scope for tool storage on top of vacuum cleaner and accessories
depot for suction nozzles and tubes at the back
• Equipped with large wheels and two swivel guide rollers
• Suitable for increased stress when used commercially. Ideal
for cleaning work in offices, storage rooms, workshops and
vehicles. Smaller electric power tools, e.g. palm sander, delta
sander, random-orbit sander, jigsaws, are primarily used for
extraction work. Tools which produce fairly low amounts of dust
• Safety vacuum cleaner, approved for dust class L, suitable for all
dust with TLV value >1 mg/m³
SPECIFICATIONS
Power input P.max. 1380 watt
Max. volume flow 3660 l/min
Max. vacuum 23000 Pa
Filter surface 6150 qcm
Container volume 34 l
Capacity liquid 19 l
Power take off 100-2200 watt
Size ( W x L x H)
505 x 380 x 580 mm
Weight 9,5 kg
Type Order No.
VC 35 L MC 369.799
Standard equipment:
4 m vacuum hose 32 mm Ø with
32/28 mm Ø adapter, 25-32 mm Ø
universal adapter and vacuum hose
extension
1 filter bag
1 flat-fold filter class L/M
1 elbow
2 x 0,5 m metal vacuummtube
1 clip floor nozzle complete
with replacement insert (brush,
rubber-lip)
1 crevice nozzle
NEW

Safety vacuum cleaner
13
VCE 35 L AC VCE 45 L AC
Safety vacuum cleaner with automatic
filter cleaning system, 35 L, class L
• The high-performance turbine ensures both a high suction
capacity and a high vacuum. The outcome is an excellent extrac-
tion result
• Continuous automatic flat filter cleaning ensures no loss of suction
• The flat-fold filter design is such that the container capacity can
be optimally used for dust and dirt
• Suitable for wet vacuuming: with electronic liquid level control
• With power take off and electronic automatic on/off. Soft start
stops any voltage peaks at the start and the run-on feature emp-
ties any remaining dust in the vacuum hose
• he all-in antistatic equipment prevents any static charging at
the implement or suction hose
• Scope for tool storage on top of vacuum cleaner and accessories
depot for suction nozzles and tubes at the back
• Equipped with large wheels and two swivel guide rollers
• Recommendation: When working with a filter bag turn off the
automatic cleaning system. When using a disposable sack leave
the system on
• Safety vacuum cleaner, approved for dust class L, suitable for all
dust with TLV value >1 mg/m³
SPECIFICATIONS
Power input P.max. 1380 watt
Max. volume flow 3660 l/min
Max. vacuum 23000 Pa
Filter surface 6150 qcm
Container volume 34 l
Capacity liquid 19 l
Power take off 100-2200 watt
Size ( W x L x H)
520 x 380 x 580 mm
Weight 12,5 kg
Type Order No.
VCE 35 L AC 369.780
VCE 35 L AC,
1 filter cleaning set
375.349
Standard equipment VCE 35 L AC:
4 m antistatic vacuum
hose, 32 mm Ø with
positive-lock connector
and vac connection, incl.
universal adapter antistatic
1 flat-fold filter class L/M
1 filter bag
1 PP waste disposal bag
additional for VCE35 L AC,
kit filter cleaning set:
1 filter cleaning set
Safety vacuum cleaner with automatic
filter cleaning system, 45 L, class L
• The high-performance turbine ensures both a high suction capa-
city and a high vacuum. The outcome is an excellent extraction
result
• Automatic switch-on and 15 seconds run-on
• Continuous automatic flat filter cleaning ensures no loss of suction
• The flat-fold filter design is such that the container capacity can
be optimally used for dust and dirt
• Suitable for wet vacuuming: with electronic liquid level control
• With power take off and electronic automatic on/off. Soft start
stops any voltage peaks at the start and the run-on feature
empties any remaining dust in the vacuum hose
• The all-in antistatic equipment prevents any static charging at
the implement or suction hose
• Equipped with large wheels and two swivel guide rollers
• Scope for tool storage on top of vacuum cleaner and accessories
depot for suction nozzles and tubes at the back
• Recommendation: When working with a filter bag turn off the au-
tomatic cleaning system. When using a disposable sack leave the
system on
• Safety vacuum cleaner, approved for dust class L, suitable for all
dust with TLV value >1 mg/m³
SPECIFICATIONS
Power input P.max. 1380 watt
Max. volume flow 3660 l/min
Max. vacuum 23000 Pa
Filter surface 6150 qcm
Container volume 43 l
Capacity liquid 30 l
Power take off 100-2200 watt
Size ( W x L x H)
520 x 380 x 695 mm
Weight 13,5 kg
Type Order No.
VCE 45 L AC 369.802
VCE 45 L AC,
1 filter cleaning set
375.357
Standard equipment VCE 45 L AC:
4 m antistatic vacuum hose, 32 mm Ø
with positive-lock connector and
vac connection, incl. universal
adapter antistatic
1 flat-fold filter class L/M
1 filter bag
1 PP waste disposal bag1
additional for VCE45 L AC,
kit filter cleaning set:
1 filter cleaning set

14
Safety vacuum cleaner
VCE 45 M AC VCE 45 H AC
Safety vacuum cleaner with automatic
filter cleaning system, 45 L, class M
• The high-performance turbine ensures both a high suction capacity and a high
vacuum. The outcome is an excellent extraction result
• Automatic switch-on and 15 seconds run-on
• Continuous automatic flat filter cleaning ensures no loss of suction
• The flat-fold filter design is such that the container capacity can be optimally
used for dust and dirt
• Suitable for wet vacuuming: with electronic liquid level control
• With power take off and electronic automatic on/off. Soft start stops any voltage
peaks at the start and the run-on feature empties any remaining dust in the
vacuum hose
• The all-in antistatic equipment prevents any static charging at the implement or
suction hose
• Flow sensor technology monitors the volumetric flow and any dropping of the
suction capacity under the prescribed minimum figure is reported by an acoustic
signal
• Equipped with large wheels and two swivel guide rollers
• Scope for tool storage on top of vacuum cleaner and accessories depot for suc-
tion nozzles and tubes at the back
• Recommendation: When working with a filter bag turn off the automatic cleaning
system. When using a disposable sack leave the system on
• Class M safety vacuum cleaner, suitable for all dusts with TLV values > 0.1 mg/
m3. Specifically for mineral and timber dusts (also beech and oak)
SPECIFICATIONS
Power input P.max. 1380 watt
Max. volume flow 3660 l/min
Max. vacuum 23000 Pa
Filter surface 6150 qcm
Container volume 43 l
Capacity liquid 30 l
Power take off 100-2200 watt
Size ( W x L x H)
520 x 380 x 695 mm
Weight 13,5 kg
Type Order No.
VCE 45 M AC 369.810
VCE 45 M AC,
kit
filter cleaning set
375.365
Standard equipment VCE 45 M AC:
4 m antistatic vacuum hose, 32 mm
Ø with positive-lock connector
and vac connection, incl. universal
adapter antistatic
1 flat-fold filter class L/M
1 filter bag
1 PP waste disposal bag
additional for VCE 45 M AC,
kit filter cleaning set:
1 filter cleaning set
Safety vacuum cleaner with automatic
filter cleaning system, 45 L, class L
• The high-performance turbine ensures both a high suction capacity and a high
vacuum. The outcome is an excellent extraction result
• Automatic switch-on and 15 seconds run-on
• Continuous automatic flat filter cleaning ensures no loss of suction
• The flat-fold filter design is such that the container capacity can be optimally used
for dust and dirt
• Suitable for wet vacuuming: with electronic liquid level control
• Suction control, suction adapted to the tool by stepless control
• With power take off and electronic automatic on/off. Soft start stops any voltage
peaks at the start and the run-on feature empties any remaining dust in the vacuum
hose
• The all-in antistatic equipment prevents any static charging at the implement or
suction hose
• Flow sensor technology monitors the volumetric flow and any dropping of the suc-
tion capacity under the prescribed minimum figure is reported by an acoustic signal
• Equipped with large wheels and two swivel guide rollers
• Scope for tool storage on top of vacuum cleaner and accessories depot for suction
nozzles and tubes at the back
• Safety filter bag for the safe disposal of the dust collected. Double-walled filter bag
with additional PE cover, sealable
• Safety vacuum cleaner class H: suitable for all dusts with TLV values < 0.1 mg/m³.
Suitable for dry, non-flammable dusts that are harmful to the health and carcinoge-
nic substances incl. asbestos
• Ideal to remove mould, restore roofs and walls insulated with mineral wool and
remove asbestos. Sanding dust from wooden surfaces that have been impregnated
with hazardous wood preservatives and from painted surfaces with paint that
contains substances such as lead, nickel, cadmium, chromium, zinc chromate, etc.
SPECIFICATIONS
Power input P.max. 1000 watt
Rated power P 1150 watt
Max. volume flow 2300 l/min
Max. vacuum 22000 Pa
Filter surface 6000 qcm
Container volume 43 l
Capacity liquid 30 l
Power take off 100-2200 watt
Size ( W x L x H)
520 x 380 x 695 mm
Weight 13,5 kg
Type Order No.
VCE 45 H AC 379.093
VCE 45 H AC,
kit
filter cleaning set
383.880
Standard equipment VCE 45 H AC:
4 m antistatic vacuum hose, 32 mm
Ø with positive-lock connector
and vac connection, incl. universal
adapter antistatic
1 safety filter bag
1 flat folded filter class H/HEPA 14
1 transport bag TS VCE 45 H
additional fore VCE 45 H AC,
kit filter cleaning set:
1 filter cleaning set

Safety vacuum cleaner
15
Filter bags, waste bags
Fleece filter bag
Highly tear-proof fleece for optimum filling of the filter
bags and trouble-free disposal of the extracted dust.
Dust class L, for VC 25 L MC.
Fleece filter bags
Filter bag with FLEX VacuFleece technology for the S 36, S 36 M,
VCE 35 L AC, VC 35 L MC. Double volume capacity and signifi-
cantly better suction capacity compared to paper filter bags.
Highly tear resistant due to 4-layered VacuFleece material: of-
fers protection against damage from sharp objects. Resistant to
unintentional wet vacuuming or damp material.
Paper-Filter bags
Filter bag for S 47, S 47 M, VCE 45 L AC, VCE 45 M AC.
Paper-Filter bags
Filter bag for S 36, S 36 M, VC 35 L MC, VCE 35 L AC.
Safety filter bag
Double-walled filter bag with additional protective
PE cover and seal for low-dust disposal for VCE 45 H AC.
Disposal sack
Sealable waste bag made of PP, ideal for coarse dirt.
Disposal sack
For S 47, S 47 M, VCE 35 L AC, VCE 45 L AC, VCE 45 M AC.
Transport bag
For the transport of accessories such as hoses, nozzles...
Accessories contaminated with dust harmful to the health are
correctly packed and protected for transport in accordance with
the regulations.
Designation QP Order
number
SFS VCE 45 H 5 379.115
Designation QP Order
number
ES-PP VC 25 VE5 5 385.107
QP Order
number
10 340.766
Designation QP Order
number
TS VCE 45 H 1 379.123
Designation QP Order
number
FS-F VC 25 L VE5 5 385.093
QP Order
number
5 329.630
QP Order
number
5 340.758
QP Order
number
5 296.961

16
Safety vacuum cleaner
Antistatic suction hose
Antistatic suction hose Ø 32 mm x 4 m with snap coupling
and coupling bush for vacuum cleaner incl. universal adapter
(320.188) antistatic.
Antistatic suction hose Ø 27 mm x 4 m with connections for
vacuum cleaner and power tool with rotary coupling.
Suction hose
Suction hose Ø 32 mm x 3,5 m with elbow.
32 mm internal Ø, with snap connection 4,0 m long, tempera-
ture resistant to 70°C, incl. coupling bush for vacuum cleaner,
filter-free switching module with snap coupling, vacuum hose
extension, 32/28 mm adapter and universal asapter for S
47and S 36 M.
32 mm internal Ø, with snap connection 4,0 m long, tempera-
ture resistant to 70°C, incl. coupling bush for vacuum cleaner,
32/28 mm adapter and universal asapter forS 47, S 47 M, VCE
35 L AC, VCE 45 L AC, VCE 45 M AC.
32 mm internal Ø, 4,0 m long, incl. coupling bush for vacuum
cleaner and special adapter with metal ring. For Giraffe® and
Okapi.
Suction hose extension
with click connection.
Vacuum hoses
Filter elements
Filter element
Folded filter made of hard-wearing and washable PET. Dirt-
resistant surface and long service life. Approval dust class L
and M.
PES flat-fold filter
Filter for the L / M class. High-grade PES filter fleece for a long
service life. The dirt-repellent surface improves filter material
removal and the filter pores are dependably cleared of dust.
Easy-to-clean, lengthy life.
Flat folded filter
Sturdy and ultra-strong flat-fold filter with special nano-coa-
ting. Extremely,long-life filter, superb suction results, ensuring
a high level of economy.
Flat folded filter
Filter for the class H/HEPA 14 made of special material with a
permeability of <0.005%.
Designation QP Order
number
FE VC 25/PET LM 1 385.085
QP Order
number
1 369.829
QP Order
number
1 337.692
Designation QP Order
number
FE VCE 45 H / HEPA 14 1 379.107
QP Order
number
1 354.953
Designation Dimensions
in mm
QP Order
number
SH 27mm x 4m AS 27 Ø x 4m 1 379.395
Designation QP Order
number
SH 32x3,5m 1 385.484
QP Order
number
1 297.011
QP Order
number
1 338.508
QP Order
number
1 341.355
QP Order
number
1 296.953

Safety vacuum cleaner
17
Vacuum hose snap coupling repair kit
Coupling bush for suction hose with snap coupling, 3-part. Also
suited for antistatic suction hose (electrically conductive).
Rotating vacuum adapter
The connector rotates and connects the 32 mm diameter suc-
tion hose with its intake fitting. Also suitable for the antistatic
suction hose (electrically conductive).
Coupling bush
For connecting two FLEX vacuum hoses.
Adapter
Adapter
Adapter for connecting suction hose (297.011, 354.953,
338.508) with snap coupling and metal elbow.
Adapter 32/28 mm for connecting machines with 28 mm Ø
vacuum attachment to 32 mm vacuum hose.
Adapter rotating
Adapter 32/32 mm, for connecting a machine with 32 mm Ø
vacuum cleaner outlet (e.g. renovation sander or angle grinder
with cutting guard) with 32 mm vacuum hose.
QP Order
number
1 296.988
QP Order
number
1 340.804
QP Order
number
1 296.996
QP Order
number
1 369.861
QP Order
number
1 251.847
QP Order
number
1 328.308
Adapter
Adapter 32/36 mm, for connecting machines with 36 mm Ø
extraction connection (e.g. HPI 603) with 32 mm suction hose.
Clip-Adapter
For connecting a FLEX power tool to extraction units from other
manufacturers. Suitable for hoses inside Ø 27 mm, outside Ø
36 mm.
Adapter
Universal adapter antistatic, for universal connection of
machines with 25-32 mm Ø extraction connection with 32 mm
suction hose (297.011, 354.953, 338.508), for adapter with
snap connection, can be trimmed to three different diameters.
Connecting sleeve for electric power tools. Ø 27 to 32 mm. For
vacuum hose 385.484.
Antistatic Ø 27 mm, passend für Saugschlauch 379.395.
Special adapter
With metal ring, for connecting the 32 mm vacuum hose to the
original WS/WSK 702 VEA. Suitable for 341.355.
Cable clip
For fixing power tool cable to vacuum hose, suitable for 27-36
mm external Ø.
VE Order
number
1 257.169
Diameter
in mm
VE Order
number
42/37 1 380.377
VE Order
number
1 320.188
Designation VE Order
number
SAD D27-32 1 385.506
VE Order
number
382.736
VE Order
number
1 340.790
VE Order
number
1 252.188

18
Safety vacuum cleaner
Cleaning set, elbow
Cleaning set
Consisting of elbow with clip attachment for connecting
suction hose and vacuum tube (297.038), 2 x metal vacuum
tube 0.5 m, chrome-plated (300.691), crevice nozzle (259.627)
and clip floor nozzle with replacement insert for floor cleaning
with brush insert for dry cleaning and rubber-lip insert for wet
cleaning (300.659).
Elbow
For connecting the vacuum hose (297.011, 354.953,
338.508) with snap coupling and vacuum tube.
Chrome-plates metal elbow for connecting the vacuum tubes.
Only to be used with adapter plus clip attachment.
Extension tubes
Extension tubes made of aluminium, diameter 32 mm, length
500 mm.
Extension tubes made of steel, chrome-plated, diameter 32
mm, length 500 mm.
Nozzles
Brush nozzle
Oval brush nozzle with brush edge for cleaning sensitive
surfaces, with pivoted connection. Diameter 36 mm, length
220 mm.
Round brush
Round brush nozzle with brush edge for cleaning sensitive
surfaces. Diameter 36 mm, length 120 mm.
Upholstery nozzle
Upholstery nozzle withthread catcher, diameter 36 mm, width
115 mm.
Crevice nozzle
Crevice nozzle diameter 36 mm, length 300 mm.
Combination floor nozzle
Switchable combination floor nozzle for cleaning carpeted
floors and hard floors. Diameter 36 mm, width 260 mm.
Designation QP Order
number
BN 36x220 1 385.557
Designation QP Order
number
RN 36x120 1 385.646
Designation QP Order
number
PN 36x115 1 385.549
Designation QP Order
number
CN 36x300 1 385.530
Designation QP Order
number
KN 36x260 1 385.565
QP Order
number
1 Set 369.845
QP Order
number
1 297.038
QP Order
number
1 369.853
Designation QP Order
number
V 36x500 AL VE2 2 385.522
Designation QP Order
number
V 36x500 ME VE2 2 385.514

Safety vacuum cleaner
19
Clip floor nozzle with rollers
Clip floor nozzle with rollers and interchangeable insert.
Brush insert for dry cleaning and rubber lip insert for wet
cleaning. Diameter 36 mm, width 400 mm.
Combination insert for use with the floor nozzle 300.659.
Carpet insert for use with the floor nozzle 300.659.
Aluminium floor nozzle with height-adjustable castors and
replacement insert. Inserts: brush insert for dry cleaning and
rubber lips for wet cleaning. 370 mm width.
Brush strip
Brush insert for aluminium floor nozzle.
Rubber strip
Rubber lip insert for aluminium floor nozzle.
Clip floor nozzle with rollers
Clip floor nozzle with rollers and interchangeable insert. Brush
insert for dry cleaning and rubber lip insert for wet cleaning.
Diameter 36 mm, width 400 mm.
Brush strip
Brush strips (replacement requirement) for the clip floor
nozzle CNW36x400.
Rubber strip
Rubber lips (replacement requirement) for clip floor nozzle
CNW 36x400.
Height-adjustable floor nozzle
Height-adjustable floor nozzle with rollers and rubber lips.
Can be used for wet and dry cleaning. Diameter 36mm, width
400 mm.
Rubber strip
Rubber lips (replacement requirement) for floor nozzle FN-K
36x450.
Accessories
Storage system
Fits on to the industrial vacuum for resting the S 47, S 47 M,
VCE 35LAC, VCE 45 L AC, VCE 45 M AC, VCE 45 H AC, suitable
for Vario-Giraffe® WST 700 VV, WST 1000 FV or MS1706FR and
vacuum hose.
Designation VE Order
number
BL-CNW 36x400 VE2 2 385.581
Designation QP Order
number
GL-CNW 36x400 VE2 2 385.603
Designation QP Order
number
FN-K 36x450 1 385.611
Designation QP Order
number
GL-FN-K 36x450 VE2 2 385.638
QP Order
number
1 350.370
Designation QP Order
number
CNW 36x300 1 300.659
Designation QP Order
number
GL-CNW 36x300 VE2 2 300.683
Designation QP Order
number
BL-CNW 36x300 VE2 2 300.675
Designation QP Order
number
FN-AL 36x370 1 369.896
Designation QP Order
number
BL-FN-AL 36x370 VE2 2 374.075
Designation QP Order
number
GL-AN-AL 36x370 VE2 2 374.083
Designation QP Order
number
CNW 36x400 1 385.573
Rubber strip
Brush strip
Floor Nozzle with rollers

www.flex-tools.com
FLEX. The original.
02-2012 / The fittings of the machines correspond to the usual standard equipment. Technical specifications are subject to change without prior notice. FLEX accepts no responsibility for mistakes and printing errors.
FLEX-Elektrowerkzeuge GmbH, Bahnhofstraße 15, 71711 Steinheim, Germany, Phone + 49 (0) 7144 828-0, Fax + 49 (0) 7144 25899, www.flex-tools.com
For more information on our new
safety vacuum cleaners and
accessories refer to your competent
specialist!
For exact directions, contact us per
phone [phone] or
by email: info@flex-tools.com
Your specialist retailer
Since 90 years, Stuttgart-based FLEX has been known as a manufacturer of high-
quality power tools. This is one of the secrets of our success: We are closely aligned
with the requirements of craftsmen. This results in products that are famous for their
long service life, performance and high functionality in many industries.
For more, see www.flex-tools.com
This means performance: the high-speed
angle grinder - a FLEX invention
