FRAME IT ALL 200001090 User manual

200001090/200002090/200003090/200004090
200001091/200002091/200003091/200004091
200001092/200002092/200003092/200004092
200001093/200002093/200003093/200004093
RAISED GARDEN BED
2’ x 6’
Layout your boards along the borderline and connect each board
together by inserting the top of the stake through the bracket loops
with the stake pointing to the sky. This enables you to freely position
your border to get your desired location.
Customer Service: 1800-914-9835 |
[email protected]m
© Frame It All. All Rights Reserved.
1 LEVEL KIT CONTAINS:
•Composite boards 2’ x 8
•Stacking Brackets x 16
•Stacking Stakes x 8
•Plugs x 32
•Caps x 8
ASSEMBLY INSTRUCTIONS –For the First level
STEP 1:
Assemble the boards by sliding one end of board into channel end
of one of the brackets. Use plugs to cover the holes on both sides to
lock the bracket in place.
STEP 2a: For one level, add caps to each of the top corner joints to finish off the raised garden.
HAPPY GARDENING!
How the Joints Work
Use plugs (included)
to cover the holes on
both side of boards
STEP 1a:
Repeat this process on the opposite end of the board flipping the bracket in
the opposite direction (see image below). Repeat for 8 boards.
STEP 2:
Layout the base level of your raised garden in a straight rectangular shape, using 8 x 2’
boards. Insert stake through the hole of the bracket and into each of the corners to lock all
sides in place.
FOR INDOOR & HARD SURFACE:
If you plan to assemble raised bed on a hard surface, use
hacksaw to remove the spike of each stake. Use these cut
down stakes for the base level only of your raised garden.
Trim stake spike with
hacksawfor use indoor
or on hard surfaces
Use plugs to
cover the holes
–two plugs are
required per
bracket (1 on
each side)
Use a Capto
complete the
top level.
Use stacking
stakes for
ground level
framesand
stacking
additional levels.
Use stacking
stake when
creating a
multi-level
Stacking stake fit
into the tops other
Stacking stakes
3-Way Connection:
Combining one half of a
4-way bracket and a
stacking bracket (A),will
result in a 3-way
junction (B).
2 LEVEL KIT CONTAINS:
•Composite boards 2’ x 18
•Stacking Brackets x 28
•4-way Brackets x 8
•Stacking Stakes x 16
•Plugs x 72
•Caps x 8
3 LEVEL KIT CONTAINS:
•Composite boards 2’ x 26
•Stacking Brackets x 44
•4-way Brackets x 8
•Stacking Stakes x 24
•Plugs x 104
•Caps x 8
4 LEVEL KIT CONTAINS:
•Composite boards 2’ x 36
•Stacking Brackets x 56
•4-way Brackets x 16
•Stacking Stakes x 32
•Plugs x 144
•Caps x 8
ASSEMBLY INSTRUCTIONS –For Product with Two to Four Levels
STEP 3:
For the second level, connect 4 boards with a
stacking bracket on one end and a mid-section 4-
way bracket on the other end in alternating
orientation.
Then, connect 2 boards with top 4-way brackets on
both ends in alternating orientation as shown to the
right. These 3 boards will be used to install the cross
board.
Now connect 4 boards with stacking brackets on
both ends as you did for the first level.
4 x
2 x
4 x
A
B
C

STEP 4:
Layout the boards for the second level flat on the ground while referencing
the diagram below. Place the cross boards for level 2 on top of the upside
stakes to ensure it will fit. Once adjustments have been made, the stakes can
be hammered into the ground and the second level can be stacked.
A
BC
STEP 5:
Connect 8 boards for level 3 with stacking brackets on both ends
and stack them as you did for level 1.
4 x cross
boards on a
4-level design
2 x cross board
for a 3-level
design.
3 LEVELS
4 LEVELS
Note: Stacking stakes insert into the top of the previous level stakes.
STEP 6:
Connect 10 boards for level 4 in the same quantity and pattern as
you did for level 2. Stack and connect them in the same way as
well.
C
C
C
B
A
A
A
